MegaDome™ Series
The AV3155/3155-16 MegaDome™ series
network camera is part of Arecont Vision’s
full line of H.264 megapixel cameras. This
fully compliant implementation of H.264
(MPEG 4, Part 10) provides full 2048 x 1536
megapixel resolution at full video frame rates
of 15fps. The MegaDome™ camera line
provides an all-in-one solution with integrated
megapixel camera, lens, and vandal resistant
dome enclosure. Using MegaVideo®
technology, these cameras offer bandwidth
and storage efficiency of up to 10X on
average over traditional megapixel
counterparts.
Learn more about our products at www.arecontvision.com
www.arecontvision.com [email protected] +1.818.937.0700 877.CAMERA.8
AV3155
3 Megapixel H.264 IP MegaDome™ Camera
Arecont Vision Advantages:
All-in-one H.264 MegaDome™ Solution
• Integrated megapixel camera, IR corrected lens
(AVxx55: 4.5-10mm lens;
AVxx55-16: 8-16mm lens), and IP66 dome housing
• Vandal resistant aluminum chassis with 4” polycarbonate
dome bubble
• Easily adjustable 3-axis camera gimbal with 360° pan,
90° tilt and 360° z-axis
• Available in 1.3, 2, 3, and 5 MP sensor configurations with
color only or Day/Night versions
• Supports both H.264 and MJPEG at full resolutions and full frame rates
• Heater kit versions for cold climate environments
• Surface mount with optional pendant mount, wall mount, pole mount,
corner mount or electrical box adapter
• IP66 weatherproofing standard
H.264 (MPEG4 Part 10) Compression Standard
• Simultaneous support of both H.264 and MJPEG
• 10x average bandwidth and storage reduction over MJPEG
Multi-Streaming
• Up to 8 concurrent non-identical streams with different frame rates,
bit rates, resolutions and picture quality
Bit Rate Control
• Maintain desired bandwidth and storage size
Real Time Streaming Protocol (RTSP)
• Allows for compatibility with media players such as Apple QuickTime,
Windows Media Player, VLC Player, etc.
Superior Low Light Performance
• 1/2” CMOS Sensor
Unparalleled High Definition Resolution - 2048 x 1536
•Ten times the resolution of IP VGA or analog cameras
Fastest MegaPixel Image Rates
• Up to 15fps in 3 megapixel mode
Forensic Zooming
• Zoom live or after-event while recording full field of view in HD …
replace PTZ devices
Reduced Overall System Cost
• Less cameras to install, less wiring, no external power (POE), less
NVR licensing fees
Full or 1/4 Resolution
• Can be used for either live viewing or archiving purposes
Other key features:
• Simultaneous full field of view and Region-of-Interest (ROI)
• Image cropping allows streaming of full density partial images
• On-camera motion detection
• Assembled 10W heater versions or separate heater module for retrofit
• Motorized IR Cut Filter (DN Version) and more
AV3155 (Color) AV3155-1HK AV3155DN (Day/Night) AV3155DN-1HK
AV3155-16 (Color) AV3155-16HK AV3155DN-16 (Day/Night) AV3155DN-16HK

©2008 Arecont Vision
AV3155
3 Megapixel H.264 IP MegaDome™ Camera
Imaging
• 3 megapixel CMOS image sensor
• 2048(H) x 1536(V) pixel array
• 1/2” optical format
• 3.2 μm pixel pitch
• Bayer mosaic RGB lter
• Minimum illumination of:
• Color: 0.2 Lux @ F1.4
• Day/Night: 0 Lux, IR sensitive
• Dynamic range 61 dB
• Maximum SNR 49 dB
Full Field of View (FOV) Resolutions
• 2048(H)x1536(V) 3 megapixel
• 1024(H)x768(V) 1/4 resolution
Cropped Field of View Resolutions
• 1920x1200 WUXGA
• 1920x1080 HDTV-1080p
• 1600x1200 2MP
• 1280x1024 1.3MP
• 1280x720 HDTV-720p
• 1024x768 XGA
• 800x600 SVGA
• 704x570 PAL
• 704x480 NTSC
• 640x480 VGA
• 352x288 CIF
• 320x240 SIF
Data Transmission
Programmability
• Auto Exposure (AE) and Gain Control (AGC) >120dB
• On-camera real-time motion detection with 64 detection zones
• Programmable backlight compensation
• Auto multi-matrix white balance
• 50/60Hz selectable icker control
• Electronic pan, tilt, zoom (PTZ)
• Electronic image ip - 180 degree rotation
• Resolution windowing down to 32x32 pixels window
• Programmable shutter speed to help control motion blur
• MoonLight™ mode - extended exposure and proprietary noise
cancellation
• Programmable resolution, brightness, saturation, gamma,
sharpness, tint
• Picture-in-Picture: simultaneous delivery of full eld of view and
zoomed images
• Bandwidth & storage savings by running at 1/4 resolution
•
• Video frame rate up to:
• 15fps @ 2048x1536
• 20fps @ 1920x1200
• 22fps @ 1920x1080
• 24fps @ 1600x1200
• 32fps @ 1280x1024
• Compression type:
• H.264 (MPEG4, Part 10)
• Motion JPEG
• 21 levels of quality
• TFTP, HTTP, RTSP, RTP/TCP, RTP/UDP image transmission protocols
• 100Base-T Ethernet Network Interface
• Data rate:
• bit rate control from 100Kbps to 10Mbps
• bit rate control available for full view, multi view, and archive
• unthrottled data rate up to 55Mbps
• Multi-streaming: 8 non-identical streams
www.arecontvision.com [email protected] +1.818.937.0700 877.CAMERA.8
©2009 Arecont Vision
Made in USA Revised on 12/10/09
Camera Electrical
• General purpose opto-coupled input and output
• Power over Ethernet (PoE): PoE 802.3af
• Auxiliary power: 12-48VDC and 24VAC
• Power consumption 5 Watts maximum
Regulatory Approvals
• FCC, Class A
• CE and RoHs compliant
Environmental
Mechanical
• IP66 weatherproong standard
• Operating temperature:
• No heater: 0˚C (32°F) to +50˚C (122°F)
• With heater: -30˚C (-22°F) to +50˚C (122°F)
• Storage temperature: -20˚C (-4°F) to +60˚C (140°F)
• Humidity: 0% to 90% (non condensing)
• Easily adjustable 3-axis camera gimbal with 360° pan, 90° tilt and 360° z-axis
• Die-cast aluminum chassis with 4” polycarbonate dome bubble
• Total Unit dimensions:
• Ø5.5 x 4.9 in (H), bubble only: Ø4.0 x 2.4 in (H)
• Ø140.3 x 124.6 mm (H), bubble only: Ø102 x 61.8 mm (H)
• 2.0 lbs (0.91 kg)
Ø - Diameter
Pendant Mount Bracket
Ø154.1 mm (6.1”)
53.9 mm (2.1”)
233.4 mm (9.2”)
43.0 mm (1.7”)
Ø101.7 mm (4”)
Wall Mount Bracket
Ø154.1 mm (6.1”)
Ø144.0 mm (5.7”)
195.8 mm (7.7”)
85.5 mm (3.4”)
Ø140.3 mm (5.5”)
102.0 mm (4”)
61.8 mm (2.4”)
62.8 mm (2.5”)
47.8 mm (1.9”)
Heater Electrical
• Voltage Input: 10V to 50V DC (separate power required)
• Power Output: 10W Max
• Switch: On: 17C° (62.6 °F), O: 30 °C (86 °F)
Model Numbers:
MegaDome™ Accessories:
MD-WMT: Wall Mount for MegaDome
MD-PMT: Pendant Mount for MegaDome
MD-CRMA: Corner mount adapter
MD-PMA: Pole mount adapter
MD-EBA: Electrical box adapter
MD-1HK: Optional 10W Heater Kit
(for retrot and on-site installation)
Lens:
Integrated 4.5-10mm IR corrected Megapixel Varifocal Lens (AVxx55 models)
Integrated 8-16mm IR corrected Megapixel Varifocal Lens (AVxx55-16 models)
AV3155 - Color
AV3155-1HK - Color w/Heater
AV3155DN - Day/Night
AV3155DN-1HK - Day/Night w/Heater
AV3155-16 - Color
AV3155-16HK - Color w/Heater
AV3155DN-16 - Day/Night
AV3155DN-16HK - Day/Night w/Heater
