Argo purissimo User manual

9
V 01/15
AIR PURIFIER
OPERATING INSTRUCTIONS
Read the instructions carefully before operating or servicing the air purifier.
Observe all the safety instructions; failure to observe the instructions may lead to accidents
and/or damage. Store these instructions in a safe place for future reference.
EN

10
V 01/15
GENERAL OPERATING AND SAFETY INSTRUCTIONS
•This appliance is a highly efficient air purifier designed for domestic use only!
•Use this air purifier only as outlined in this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock or malfunctions.
•The unit must be placed in a vertical position at all times.
•Ensure that the available power source conforms to the required voltage and frequency (220 -
240V/50Hz).
•Make sure that the plug is fully inserted. Do not use multiple adapters. Do not touch the plug with wet
hands. Make sure that the plug is clean.
•This product is not a toy. Children should be adequately supervised to ensure that they do not play
with the appliance.
•This air purifier can be used by children aged 8 years and older and by persons with reduced physical,
sensory and mental abilities, or who are not familiar with its operation, under the supervision or
instruction of a person responsible for their safety, so that they are fully aware of the attendant risks.
•Do not allow the unit to be cleaned or serviced by unsupervised children.
•Disconnect the main power when the appliance is not in use or during cleaning operations. Keeping
the appliance plugged in may cause electric shocks or accidents.
•To disconnect the appliance, set the switch to OFF and remove the plug from the socket. Pull on the
plug only. Do not pull the cord.
•Do not bend, drag or twist the cord, or apply force to remove it. Do not operate the unit if its cable or
plug are damaged; doing so can cause fires or electric shock. If the power cord is damaged, it must
be replaced by a service centre.
•Do not place heavy objects on the appliance.
•Do not use the appliance on unstable or sloping surfaces.
•The air purifier must be placed at least 50 cm from the wall or from other obstacles, to ensure proper
heat dissipation.
•Close all open windows to maximise air purification efficiency.
•Do not insert objects or sharp instruments into the air outlet grille.
•Do not cover the air intake and outlet grilles in any way.
WARNING!
In the event of an anomaly, switch the appliance off and unplug it immediately. Do not dismantle, repair
or modify this product freely. In the event of a malfunction, contact the after-sales service centre
directly.
•Do not immerse the power cord, plug or any other part of the appliance in water or other liquids.
•Do not expose the air purifier to direct sunlight.
•Keep the appliance well away from sources of heat which could cause plastic parts to become
warped.
•Do not spray insecticides, oils or paints near the appliance; doing so may damage its plastic parts or
start a fire.
•Keep flammable gases and oils away from the appliance!
•Do not move the appliance while it is operating, as this may cause malfunctions.

11
V 01/15
DESCRIPTION OF PARTS
PRE-FILTER. Its main function is to filter the coarsest particles, which consequently allows for extending the
life of the HEPA filter.
COTTON PRE-FILTER. It is capable of decomposing odours in the air.
HEPA FILTER. It can filter particles with a diameter above 0.3 microns and effectively eliminates pollen,
smoke, animal hairs, mould and dust.
HIMOP (High Efficiency Multi Oxidation Porcelain) FILTER. Made of ceramic and biopolymers, it is
endowed with strong oxidising properties for destroying odours and toxic gases in the environment, such
as formaldehyde.
IONISER/PLASMA. Generates a large amount of negative ions. Household air is filled with positive ions
generated by many appliances such as television sets and radios. Using the ANION mode helps to
release plenty of negative ions which naturally abound in areas renowned for their high well-being, such
as mountainous areas. The air becomes fresh and crisp, just like mountain air.
1) CONTROL PANEL AND DISPLAY
2) FRONT PANEL
3) ON/OFF BUTTON
4) PRE-FILTER
5) FILTER FRAME
6) AIR INTAKE
7) COTTON PRE-FILTER
8) HIMOP FILTER
9) HEPA FILTER
10) FILTER FRAME
11) ACTIVATED CARBON FILTER
12) FILTER SUPPORT
13) IONISER
14) REAR SECTION
15) HANDLE
16) AIR DISCHARGE
17) IONISER/PLASMA
18) REMOTE CONTROL SLOT
19) PLUG
(2)
(1)
(10)
(3)
FRONT VIEW
(4)
(5)
REAR VIEW
(12)
(6)
(18)
(15)
(16)
(17)
(11)
(7)
(8)
(9)
(13)
(14)
(19)

12
V 01/15
OPERATING INSTRUCTIONS
APPLIANCE START-UP
Place the product on a flat and stable heat-
resistant surface, at least 1 metre away from
flammable or heat-sensitive materials and 50
cm away from walls or other objects.
Connect the power cord to a suitable
electric socket (220-240V/50Hz).
Remove the plastic seal from the HIMOP +
HEPA filters prior to using the appliance, and
place it inside the air purifier as shown in the
adjacent sequence.
REMOTE CONTROL OPERATION
Insert the batteries into the remote control, while respecting the
indicated polarities.
Only use type CR2025 batteries. Remove the batteries if the remote
control is not used for a month or longer. Do not attempt to recharge the
batteries. Change all batteries at the same time. Do not throw the
batteries into a fire, as they may explode.
If you do not expect to use the remote control for a
long time, store it in its appropriate slot on the side of
the air purifier.
For optimal operation of the remote control, point
the head of the transmitter towards the receiver
located on the air purifier.
INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EUROPEAN DIRECTIVE 2006/66/EC
Please replace the battery when flat: at the end of its working life, the battery must not be disposed of together with
unsorted waste. It must be delivered to appropriate separated waste disposal facilities or to dealers that provide a
similar service. Separate waste disposal of batteries prevents potential negative effects on the environment and human
health due to inadequate disposal, and also allows for recovering and recycling their constituent materials, resulting in
significant savings in terms of energy and resources. The separate disposal obligation is underlined by the crossed-out
dustbin symbol appearing on the batteries. Illegal disposal of the product by the user shall result in the application of
administrative sanctions as defined by current regulations.

13
V 01/15
CONTROL PANEL AND REMOTE CONTROL
ON/OFF BUTTON: press the ON/OFF button to turn the appliance on and off.
The MODE button on the air purifier allows for manually setting the following modes: AUTO-TURBO-SLEEP-ANION-
ODOR.
This button cannot be used to set the ventilation mode. The speed is adjusted automatically.
BUTTONS ON THE REMOTE CONTROL:
ODOR BUTTON: press the ODOR button to neutralise odours at the maximum speed.
SLEEP BUTTON: press this button for the appliance to operate more silently. The fan
speed will be set to the minimum level.
SPEED BUTTON: press this button to adjust the fan speed according to the following
sequence:
Mute →Low →High
LUM BUTTON: press this button to adjust the LED luminosity from lower to higher.
ELECTROSTATIC BUTTON: not operational.
TIMER BUTTON: press this button to set the timer to 1 – 2 - 4 hours.
When the appliance is off, the timer switches it on; when the appliance is on, the timer switches it off.
ANION BUTTON: when pressed, it allows for emitting negative ions. The fan speed will be set to the minimum
(Low) level.
TURBO BUTTON: maximum air purifying function. The fan speed is set to the maximum level and cannot be
adjusted.
LOCK BUTTON (CHILD SAFETY): press this button for 2 sec. to lock the buttons on the appliance.
Press again to unlock the buttons.
AUTO BUTTON: the speed is adjusted automatically.
MEMORY FUNCTION: the air purifier maintains its settings after a power failure.
This button cannot be used to set the ventilation mode. The speed is adjusted automatically.
FAN SPEED LED
ODOUR
SENSOR
ON/OFF
BUTTON
TIMER
MODE
BUTTON
LOCK LED
DUST LED
RUNNING MODE
LED
HIMOP/HEPA
FILTER
CHANGE LED
DUST SENSOR
ODOUR LED
