Argo AUG38PCLI Manual

TECHNICAL DATA & SERVICE MANUAL
ULISSE 13PCL
A
AUG38PCLI
0.8180.516.0 11/2006
Model No. Product Code No.
AUG38PCLI 39.7028.942

IMPORTANT!
Please read before installation
This air conditioning system meets strict safety and operating
standards.
For the installer or service person, it is important to install or
service the system so that it operates safely and efficiently.
For safe installation and trouble-free operation, you must:
• Carefully read this instruction booklet before beginning.
• Follow each installation or repair step exactly as shown.
• Observe all local, state and national electrical codes.
• Pay close attention to all warning and caution notices given in
this manual.
•The unit must be supplied with a dedicated electrical line.
This symbol refers to a hazard or unsafe practice which can result
in severe personal injury or death.
This symbol refers to a hazard or unsafe practice which can result
in personal injury or product or property damage.
If necessary, get help
These instructions are all you need for most installation sites and
maintenance conditions.
If you require help for a special problem, contact our sale/service
outlet or your certified dealer for additional instructions.
In case of improper installation
The manufacturer shall in no way be responsible for improper
installation or maintenance service, including failure to follow the
instructions in this document.
SPECIAL PRECAUTIONS
• During installation, connect before the refrigerant system and
then the wiring one; proceed in the reverse orden when removing
the units.
When wiring
ELECTRICAL SHOCK CAN CAUSE SEVERE
PERSONAL INJURY OR DEATH. ONLY QUALIFIED,
EXPERIENCED ELECTRICIANS SHOULD ATTEMPT
TO WIRE THIS SYSTEM.
• Do not supply power to the unit until all wiring and tubing are
completed or reconnected and checked, to ensure the grounding.
• Highly dangerous electrical voltages are used in this system.
Carefully refer to the wiring diagram and these instructions when
wiring.
Improper connections and inadequate grounding can cause
accidental injury and death.
•Ground the unit following local electrical codes.
• The Yellow/Green wire cannot be used for any connection
different from the ground connection.
• Connect all wiring tightly. Loose wiring may cause overheating
at connection points and a possible fire hazard.
• Do not allow wiring to touch the refrigerant tubing, compressor,
or any moving parts of the fan.
• Do not use multi-core cable when wiring the power supply and
control lines. Use separate cables for each type of line.
When transporting
Be careful when picking up and moving the indoor and outdoor
units. Get a partner to help, and bend your knees when lifting to
reduce strain on your back. Sharp edges or thin aluminium fins on
the air conditioner can cut your fingers.
When installing...
• Keep all tubing runs as short as possible.
• Use the flare method for connecting tubing.
• Apply refrigerant lubricant to the matching surfaces of the flare
and union tubes before connecting them; screw by hand and
then tighten the nut with a torque wrench for a leak-free
connection.
• Check carefully for leaks before starting the test run.
NOTE:
Depending on the system type, liquid and gas lines may be either
narrow or wide. Therefore, to avoid confusion, the refrigerant
tubing for your particular model is specified as narrow tube for
liquid, wide tube for gas.
When servicing
• Turn the power OFF at the main power board before opening
the unit to check or repair electrical parts and wiring.
• Keep your fingers and clothing away from any moving parts.
• Clean up the site after the work, remembering to check that no
metal scraps or bits of wiring have been left inside the unit being
serviced.
• Ventilate the room during the installation or testing the refrigeration
system; make sure that, after the installation, no gas leaks are
present, because this could produce toxic gas and dangerous
if in contact with flames or heat-sources.
WARNING
CAUTION
WARNING
… In a ceiling
Make sure the ceiling is strong enough to hold the unit-weight.
It may be necessary to build a strong wooden or metal frame to
provide added support.
… In a room
Properly insulate any tubing run inside a room to prevent
"sweating", which can cause dripping and water damage to
walls and floors.
... In moist or uneven locations
Use a raised concrete base to provide a solid level foundation
for the outdoor unit. This prevents damage and abnormal
vibrations.
... In area with strong winds
Securely anchor the outdoor unit down with bolts and a metal
frame. Provide a suitable air baffle.
... In a snowy area (for heat pump-type systems)
Install the outdoor unit on a raised platform that is higher then
drifting snow. Provide snow vents.
When connecting refrigerant tubing
2

Page
1. SPECIFICATIONS 4
1-1 Unit specifications 4
1-2 Major Component specifications 5-6
1-3 Other Component specifications 6
2. DIMENSIONAL DATA 7
2-1 Unit Dimensions 7
3. REFRIGERANT FLOW DATA 8
3-1 Refrigerant Flow Diagram 8
4. ELECTRICAL DATA 9
4-1 Electric Wiring Diagram 9
5. PERFORMANCE DATA 10
5-1 Performance Chart 10
6. FUNCTIONS 11
6-1 Cool Mode Operation 11
6-2 Dry Mode Operation 12
6-3 Fan Mode Operation 12
6-4 Auto Fan Speed 12
6-5 Forced Mode 13
6-6 Protection Operation in Cool and Dry Mode 13
6-7 I FEEL Function 14
6-8 NIGHT Function 14
6-9 Drain Pump 14
7. DIAGNOSTIC 15
8. JUMPERS CONFIGURATION 16
9. MAINTENANCE 17
10. TROUBLESHOOTING 18-25
11. CHECKING ELECTRICAL COMPONENTS 26-27
Table of Contents
3

1. SPECIFICATIONS
1-1 Unit Specifications
Power Source
V
olta
g
e Ratin
g
V
Available Volta
g
e Ran
g
eV
Runnin
g
Ampere A
Power Input W
Power Factor
C.O.P. W/W
Compressor Locked Rotor Amperes A
Performance
Capacity BTU/h
kW
Air Circulation High/Med./Low m³/h
Moisture Removal High Speed l/h
Power Noise Level Indoor Unit (1) High/Med./Low dB-A
Power Noise Level Outdoor Unit (1) dB-A
Features
Controls / Temperature Controls
Control Unit
Timer
Fan Speed Indoor / Outdoor Unit
Airflow Direction Vertical
Orizzontal
Air Filter
Compressor
Refrigerant Gas
Refrigerant Standard Charge at Shipment g
Refrigerant Control
Condensate Drain System
Dimensions & Wei
g
ht
Indoor Unit Height mm
Width mm
Depth mm
Outdoor Unit Height mm
Width mm
Depth mm
Net Weight Internal Unit kg
External Unit kg
DATA SUBJECT TO CHANGE WITHOUT NOTICE
NOTE
Rating Cooling Conditions:
- Outside Air Temperature: 35°C DB
- Inside Air Temperature: 27°C DB, 19°C WB
(1) Reference data: room size 100 m³, reverberation time 0,5 s, distance 2 m.
62
230 V ~ 50 Hz
230
198 - 264
4,00
400/375/335
Washable/ Easy Access
790
580
490
245
Automatic with Pump
Capillary Tube
1150
R410A
Wireless remote control
55/54/52
44
250
525
Microprocessor / I.C. thermostat
Manual
Manual
3 and Auto / 1
ON/OFF 24 Hours & Daily Program
15
AUG38PCLI
5,60
1245
0,96
Rotary (Hermetic)
3,21
35
13640
1,90
4

1-2 Major Component Specifications
Controller PCB
Model
Controls
Control Circuit Fuse (F1)
Jumper Setting JP1 … JP5
Remote Control Unit
Thermistor Coil Sensor
Resistance at 25°C k
Thermistor Room Sensor
(
TH Room
)
Resistance at 25°C k
Fan Motor Indoor Unit
(
FMI
)
Model
Number / Diameter / Length mm
No. Of Pole - RPM High/Med./Low (230V)
Nominal Input W
Coil Resistance at 25°C Ω
Ω
Ω
Ω
Safety Device
Setting Operating temp. Open °C
Close
Run Capacitor (C) µF
VAC
Fan Motor Outdoor Unit
(
FMO
)
Model
Diameter mm
No. Of Pole / RPM (230V)
Nominal Input W
Coil Resistance at 25°C Ω
Ω
Safety Device
Setting Operating temp. Open °C
Close
Run Capacitor (C) µF
VAC
Compressor
Model
Nominal Cooling Capacity W
Compressor Oil: RB68A or Freol Alpha68M cc
Compressor Oil: DAPHNE FV68S or equivalent cc
Coil Resistance at 20°C Ω
*at 25°C Ω
Run Capacitor (C) µF
VAC
Overload Rela
y
(
OLR
)
Operating Temperature Open °C
Close °C
Short Time Trip 6-16 Sec. At 25°C A
DATA SUBJECT TO CHANGE WITHOUT NOTICE
27
440
VLT-ORG: 62 ÷ 71 ± 5%
GRY-BRN: 78 ÷ 90 ± 5%
Internal Bimetallic Type
150 ± 10
Autoreset
WHT-VLT: 92 ÷ 105 ± 5%
GRY-WHT: 545 ÷ 630 ± 5%
Cross-Flow / Ø 100 / 410
K35406-MO2024
10 ± 5%
SAC ON-OFF IDU
NTC (with Brass Pipe)
Microprocessor
2,54mm - 5 pcs
---
External
450
Rotary (Hermetic)
520
*C-R : 2402
BLU-BLK: 243 ± 5%
2,5
80235455
3680
Internal Bimetallic Type
Autoreset
150 ± 5
AUG38PCLI
4 - 1350/1275/1165
2,00
K35610-MO1525
250VAC - 3,15A - T
10 ± 3%
SAC WREM
Ø 340
6 / 885
75
BLU-BRN: 230 ± 5%
69 ± 11%
23,5
*C-S : 3582
30
450
150 ± 5%
5

Condensate Pump
Model
Rating
Nominal Input W
Coil Resistance at 20°C 
Safet
y
Float Switch
Model
Contact Rating
Float Up
Down
Heat Exchan
g
er Coil
(
Evaporator
)
Coil
Rows
Fin Pitch mm
Face Area m²
Heat Exchan
g
er Coil
(
Condenser
)
Coil
Rows
Fin Pitch mm
Face Area m²
DATA SUBJECT TO CHANGE WITHOUT NOTICE
1-3 Other Component Specifications
OPERATING RANG
E
DATA SUBJECT TO CHANGE WITHOUT NOTICE
AUG38PCLI
Alluminium Plate Fin / Copper Tube
122 ± 10%
Alluminium Plate Fin / Copper Tube
Close
Open
2
0,185
F83161,3
10(4)A - 250VAC
PC 95643
230V - 50Hz
12 ± 10%
1,8
Maximun
Minimun
Temperature Indoor Air Intake
Temperature
Dry 43°C DB
16°C DB
46°C DB
19°C DB
32°C DB / 23°C WB
19°C DB / 14°C WB
32°C BS / 80% R.U.
16°C BS / 80% R.U.
Maximun
3
1,6
0,3
Cooling Minimun
Outdoor Air Intake
Temperature
6

2. DIMENSIONAL DATA
2-1 Unit Dimensions
A
E
C
B D F
A
B
C
D
E
F
245
525
490
250
790
580
AUG38PCLI
7

3. REFRIGERANT FLOW DATA
3-1 Refrigerant Flow Diagram
8

4. ELECTRICAL DATA
4-1 Electric Wiring Diagram
PCB Controller SWITCH Switch Assy
FMI Indoor fan motor IND Indicator assy
CM Compressor motor TH Thermistor
OLR Overload relay TP Terminal plate
FMO Outdoor fan motor FS Float switch
CCapacitor
DP Drain Pump
9

5. PERFORMANCE DATA
5-1 Performance Chart
Operation characteristics with relative humidity around 50%.
AUG38PCLI
5
6
7
8
9
20 25 30 35 40 45 50
EXTERNAL TEMPERATURE (°C)
OPERATING CURRENT (A)
32 °C
27 °C
21 °C
10

6. FUNCTIONS
6-1 Cool Mode Operation
In Cooling Mode, the operation of the compressor (CM), Outdoor Fan (FMO) and Indoor Fan (FMI) are
determined by the difference between the room air temperature (RAT) and the set point temperature (SPT)
as shown in the graph.
NOTES
1. In this graph, the FMI is operating with the “Auto Fan Speed” setting. If the user has selected the Low,
Medium or High fan speed, the FMI will run constantly at that speed only.
2. In addition to the temperature difference of above, the operations of the main components (CM, FMO,
FMI) is also controlled by protection delays. That is: - the minimum off time of compressor is 3 minutes. -
- the minimum off time of compressor is 3 minutes. -
- the indoor fan can change speed only after it has operated at the same speed for 30 sec if in AUTO
and 1 sec for the other settings (High, Med, Low).
11

6-2 Dry Mode Operation
Dry operation remove moisture from indoor air running, in cooling mode, at a low level without reducing the
ambient temperature. This is done cycling ON and OFF indoor and outdoor units according to below.
SPT = Set Point Temperature
6-3 Fan Mode Operation
With this mode, the indoor fan is turned ON while CM and FMO stay OFF all the time. The user can select
between 4 speeds: HIGH, MEDIUM and LOW.
6-4 Auto Fan Speed
With this option selected, the indoor fan speed changes automatically according to the difference between
the detected air temperature (RAT sensor) and the set point (SPT):
COOLING MODE
2 ≤(RAT – SPT): HIGH speed
1 ≤(RAT – SPT) <2: MEDIUM speed
(RAT – SPT) <1: LOW speed
NOTE
SPT = Set Point Temperature
ROOM
TEMPERATURE DRY LEVEL
< SPT-1°C
15°C LEVEL 2
SPT+2°C LEVEL 0
< 15°C DRY OFF ZONE
CM OFF
FMO OFF
FMI OFF
CM switches 9 minutes OFF and 3 minutes ON
FMO switches 9 minutes OFF and 3 minutes ON
FMI switches OFF and L during CM operation
< SPT+2°C
SPT-1°C
Operation according to COOLING mode
LEVEL 1
CM ON
FMO ON
FMI switches between L and OFF (30 seconds)
12

6-5 Forced Mode
In this mode the system operates (COOLING or HEATING mode – fixed settings) or is switched off by
means of the MODE button of the indoor unit control board. The operation modes can be selected
pressing the button in a cyclic way (OFF COOL HEAT OFF…). The settings are:
COOLING mode
SET POINT temperature = 25°C
FAN SPEED = HIGH
6-6 Protection Operations in Cool and Dry Mode
Freeze-up
This protection prevents ice formation on the indoor coil heat exchanger.
The protection is activated by the indoor coil temperature (ICT sensor) and only after 6 minutes
of compressor operation.
This protection acts in 2 levels:
LEVEL 1
INDOOR FAN SPEED: ANY (as selected from remote controller)
COMPRESSOR: ON
OUTDOOR FAN: cycling (30 seconds ON B30 seconds OFF).
DRAIN PUMP: operates according to paragraph 9.2
LEVEL 2
INDOOR FAN SPEED: ANY (as selected from remote controller)
COMPRESSOR: OFF for at least 6 minutes and until ICT 8°C
OUTDOOR FAN: OFF for at least 6 minutes and until ICT 8°C
DRAIN PUMP: always ON ( stops when exiting the protection)
The system exit this protection routine when ICT temperature rises above 8°C.
13

6-7 I FEEL Function
As standard configuration the air conditioner operates detecting the room temperature through the sensor
equipped in the wireless remote controller (icon I FEEL shown on the display). This feature provides a
personalised environment since the temperature can be detected where the remote controller is located.
It is possible to de-activate this option pressing the I FEEL button on the remote controller.
In this case the I FEEL icon is no longer displayed and room temperature is detected through the sensor
included in the indoor unit.
6-8 NIGHT Function
When this function is active, room temperature changes automatically to compensate for body temperature
variations while sleeping. After 10 hours of operation system switches automatically to OFF state.
This mode of operation is available both in COOLING and HEATING mode.
When running in this mode indoor fan is automatically switched to LOW speed.
6-9 DRAIN PUMP
Pump operates when the unit is running in COOLING and DRY modes.
The level detection is done through a float switch connected at the input FS (closed under normal condition,
and opened when water overflow). System operation is according to the following chart:
30sec 30sec
20sec
20sec
FS
Contact
14

7. DIAGNOSTIC
With this feature is possible to have a visual signal that a trouble is occurring.
This mode is always active and the signalling is made through the display board LEDS .
In case of no troubles the LEDS status follows its normal function.
NOTES
 The troubles are showed according a priority list that is in case of more than one
trouble present, is always showed, at first, the one with the highest priority (1 23 etc).
 Sensor damaged means a situation where sensor is short-circuited or opened.
 In case of damaged sensors, the system (CM, FMO, FMI etc), if in OFF state, does not start.
 WRONG MODE SELECTED means a situation where the operating mode chosen with remote controller
does not comply with the one allowed by jumpers settings.
Priority TROUBLE
LD1(stby) LD2(opr) LD3(timer)
1 No parameters zFO
2 RAT damaged F O O
3 ICT damaged F F O
4 WRONG MODE F F F
SELECTED
5 Water level alarm O F O
O = LED off
z= LED on
F = LED blinking
System does not operate
See paragraph
6-9 DRAIN PUMP
LEDS status Effects
15

8. JUMPERS CONFIGURATION
Jumpers are located on the indoor PCB near the MODE button.
Unit is shipped with jumpers set according to the following table:
STATUSJUMPER
JP1
JP2
JP3
JP4
JP5
open
closed
open
closed
closed
16

9. MAINTENANCE
Changing the Address of the Air Conditioner
In case of more than one air conditioner operating in the same room, it may be necessary to assign
an address to each unit in order to avoid operation conflicts.
Address is set acting on the dip-switches located on the indoor PCB and on the
remote controller. The PCB settings must match the corresponding ones on the wireless remote controller.
How to change address of the air conditioner
Dip switch is located on the indoor PCB near the buzzer.
Set the PCB to the address desidered
UNIT
ADDRES
S
SW1 SW2
1 off off
2 off on
3 on off
4onon
As default switches SW1 and SW2
are in off status (PCB factory state).
How to change address on Remote Control Unit
Dip switch is located on the battery compartment.
1) Pull out the door and remove the batteries.
2) Set the switch SW1 and SW2 according to the indoor PCB settings
(do not act on SW3 and SW4)
3) Insert the batteries and pull on the door
As default switches SW1 and SW2 are in off status (remote controller factory state).
SETTINGS
17

10. TROUBLESHOOTING
CHECK BEFORE AND AFTER «TROUBLESHOOTING»
(A) Check power supply wiring.
• Check the power supply wires are correctly connected.
(B) Check power supply.
• Check that voltage is in specified range (±10% of the rating).
• Check that power is being supplied.
• WARNING: If the following troubleshooting must be done with power supplied,
be careful not to touch any uninsulated live part that can cause ELECTRIC SHOCK.
A CIRCUIT BREAKER TRIPS OR FUSE BLOWS.
• When circuit breaker is set to ON, it trips in a few moments. Resetting is not possible.
• Measure insulation resistance. There is a possibility of ground fault.
If resistance value is 1 Mohm or less, insulation is defective.
B CIRCUIT BREAKER TRIPS IN SEVERAL MINUTES AFTER TURNING AIR CONDITIONER ON.
1 • There is the possibility of short circuit.
18

2 • The unit does not run.
C WATER LEVEL ALARM - OPERATION LAMP IS BLINKING.
Malfunctioning of the condensate drainanege system.
NOTE: In case of emergency the air conditioner can work by draining the condensate from
the little pipe into a rather short container. Extract the little pipe and remove the cap.
19

D UNIT AND COMPRESSOR DO NOT RUN.
The unit does not run when air conditioner is in the follwing conditions:
• When the room temperature is below the setting temperature.
• During the protection modes.
