Argo FCR518CL Operating manual

TECHNICAL & SERVICE MANUAL
Indoor Unit Outdoor Unit
FCR518/522CL AER518SC3
AWR518/522CL AER518SCL3
SPLIT SYSTEM AIR CONDITIONER
AER518SCL3
AER522SC3
AWR518/522CL
FCR518/522CL
0.8180.143.104/2002
AER522SC3
AER522SCL3
AER518SC3
AER522SCL3

i
Important!
Please Read Before Starting
This air conditioning system meets strict safety and
operating standards. As the installer or service person,
it is an important part of your job to install or service the
system so it operates safely and efficiently.
For safe installation and trouble-free operation, you
must:
●Carefully read this instruction booklet before
beginning.
●Follow each installation or repair step exactly as
shown.
●Observe all local, state, and national electrical codes.
●Pay close attention to all warning and caution notices
given in this manual.
This symbol refers to a hazard or
unsafe practice which can result
in severe personal injury or
death.
This symbol refers to a hazard or
unsafe practice which can result
in personal injury or product or
property damage.
If Necessary, Get Help
These instructions are all you need for most installation
sites and maintenance conditions. If you require help
for a special problem, contact our sales/service outlet
or your certified dealer for additional instructions.
In Case of Improper Installation
The manufacturer shall in no way be responsible for
improper installation or maintenance service, including
failure to follow the instructions in this document.
Special Precautions
When Wiring
ELECTRICAL SHOCK CAN CAUSE
SEVERE PERSONAL INJURY OR
DEATH. ONLY A QUALIFIED,
EXPERIENCED ELECTRICIAN SHOULD
ATTEMPT TO WIRE THIS SYSTEM.
• Do not supply power to the unit until all wiring and
tubing are completed or reconnected and checked.
• Highly dangerous electrical voltages are used in this
system. Carefully refer to the wiring diagram and
these instructions when wiring. Improper connections
and inadequate grounding can cause accidental
injury or death.
• Ground the unit following local electrical codes.
• Connect all wiring tightly. Loose wiring may cause
overheating at connection points and a possible fire
hazard.
WARNING
CAUTION
WARNING
When Transporting
Be careful when picking up and moving the indoor and
outdoor units. Get a partner to help, and bend your
knees when lifting to reduce strain on your back. Sharp
edges or thin aluminum fins on the air conditioner can
cut your fingers.
When Installing…
…In a Ceiling or Wall
Make sure the ceiling/wall is strong enough to hold the
units weight. It may be necessary to construct a strong
wood or metal frame to provide added support.
…In a Room
Properly insulate any tubing run inside a room to
prevent “sweating” that can cause dripping and water
damage to walls and floors.
…In Moist or Uneven Locations
Use a raised concrete pad or concrete blocks to
provide a solid, level foundation for the outdoor unit.
This prevents water damage and abnormal vibration.
…In an Area with High Winds
Securely anchor the outdoor unit down with bolts and a
metal frame. Provide a suitable air baffle.
…In a Snowy Area (for Heat Pump-type Systems)
Install the outdoor unit on a raised platform that is
higher than drifting snow. Provide snow vents.
When Connecting Refrigerant Tubing
• Use the flare method for connecting tubing.
• Apply refrigerant lubricant to the matching surfaces
of the flare and union tubes before connecting them,
then tighten the nut with a torque wrench for a leak-
free connection.
• Check carefully for leaks before starting the test run.
When Servicing
• Turn the power off at the main power box (mains)
before opening the unit to check or repair electrical
parts and wiring.
• Keep your fingers and clothing away from any
moving parts.
• Clean up the site after you finish, remembering to
check that no metal scraps or bits of wiring have
been left inside the unit being serviced.
Others
• Ventilate any enclosed areas when installing or
testing the refrigeration system. Escaped refrigerant
gas, on contact with fire or heat, can produce
dangerously toxic gas.
• Confirm upon completing installation that no
refrigerant gas is leaking. If escaped gas comes in
contact with a stove, gas water heater, electric room
heater or other heat source, it can produce
dangerously toxic gas.
CAUTION

Table of Contents
Page
1OPERATING RANGE 1
2SPECIFICATIONS
2-1Unit Specification 2
2-2Major Components Specifications 10
2-3Other Component Specifications 16
3DIMENSIONAL DATA 22
4REFRIGERANT FLOW DIAGRAM 26
5PERFORMANCE DATA
5-1Air Throw Distance Chart 285-2Cooling Capacity 31
6ELECTRICAL DATA
6-1Electrical Characteristic 376-2Electric Wiring Diagrams 41
7 INSTALLATION INSTRUCTION
7-1Installation Site Selection 45
7-2Remote Control Unit Installation Position 47
7-3Recommended Wire Lengthand Diameter 48
8FUNCTION
8-1Room Temperature Control 49
8-2Dry Operation 50
8-3Freeze Prevention 50
8-4Low Ambient Fan Speed Control 51
9REFRIGERANT R407C:SPECIAL PRECAUTION WHEN SERVICING UNIT
9-1Characteristics of new refrigerant R407c 53
9-2Checklist before servicing 53
9-3Tools specifically for R407c 54
9-4For tubing installation procedures 54
9-5In case of compressor malfunction 55
9-6In case refrigerant is leaking 57
9-7Charging additional refrigerant 59
9-8Retro-fitting existing systems 59
10 TROUBLESHOOTING
10-1Check before and after troubleshooting60
10-2Air Conditioner Does not operate 61
10-3Some Parts of Air Conditioner does not operate 66
10-4Air Conditioner operates, but abnormalities are observed 69
10-5If a Sensor is defective 70
11 CHECKING ELECTRICAL COMPONENTS
11-1Measure of insulation Resistance 7111-2Check Continuity of fuse on PCB Ass’y72

11-3Checking Motor Capacitor 72
12 DISASSEMBLY PROCEDURE FOR INDOOR UNIT
12-1Removing air intake grille 73
12-2Removing side panels 74
12-3Access and removal of electrical component box 74
12-4Removing flap motor 75
12-5Removing evaporator 75
12-6Removing fan and fan motor 77

1
1. OPERATING RANGE
Temperature Indoor Air Intake Temp. Outdoor Air Intake Temp.
Cooling Maximum 32°C D.B. / 23°C W.B. 43°C D.B.
Minimum 19°C D.B. / 14°C W.B. 19°C D.B.(*)
(*) SCL Models : -15°C D.B.

2
2. SPECIFICATIONS
2-1. Unit Specifications
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Remarks: Rating conditions are:
Cooling: Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
Power Surce.......Voltage Rating 400V - 3N - 50Hz .. ....400 V
Control Circuit V 230 V 50 Hz
Cooling
Capacity kW 5.1
BTU/h 17400
Air circulation (High) m3/h 760
Moisture removal (High) Liters/h 2.3
Available voltage range V342 to 418
Running amperes A3.7
Power input W2100
Power factor %82
C.O.P. W/W 2.4
Compressor locked rotor amperes A 21.5
Controls / Temperature control Microprocessor / I.C. thermostat
Control unit Wireless remote control unit
Timer ON/OFF 24 hours & Daily program, 1-hour OFF
Fan speeds Indoor / Outdoor 3 and Auto / Auto(Hi,LO)
Airflow direction (Indoor) Horizontal Manual
Vertical Auto
Air filter Washable
Compressor Rotary (Hermetic)
Refrigerant / Amount charged at shipment gR407c/ 1840
Refrigerant control Capillary tube
Noise Power Level Indoor – Hi / Me / Lo dB-A 55 / 51 / 49
Outdoor – Hi dB-A 64
Refrigerant tubing connections Flare type
Max. allowable tubing length at shipment m7.5
Refrigerant tube Narrow tube mm (in.) 6.35 (1/4)
diameter Wide tube mm (in.) 12.7 (1/2)
Indoor Unit Outdoor Unit
Unit dimensions Height mm 285 630
Width mm 995 830
Depth mm 206 305
Package dimensions Height mm 276 713
Width mm 1,070 994
Depth mm 363 413
Weight Net kg 12.0 52
Shipping kg 15.0 57
Shipping volume m30.11 0.29
Dimensions & Weight Features Electrical Rating Performance
Indoor Unit AWR518CL
Outdoor Unit AER518SC3

3
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Remarks: Rating conditions are:
Cooling: Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
Power Source..... Voltage Rating 400V - 3N - 50Hz........ 400 V
Control Circuit 230 V 50 Hz
Cooling
Capacity
kW 6.15
BTU/h 21000
Air circulation (High) m3/h 830
Moisture removal (High) Liters/h 3.3
Available voltage range V342 to 418
Running amperes A4.8
Power input W2800
Power factor %84
C.O.P. W/W 2.20
Compressor locked rotor amperes A28
Controls / Temperature control Microprocessor / I.C. thermostat
Control unit Wireless remote control unit
Timer ON/OFF 24 hours & Daily program, 1-hour OFF
Fan speeds Indoor / Outdoor 3 and Auto / Auto(Hi, Lo)
Airflow direction (Indoor) Horizontal Manual
Vertical Auto
Air filter Washable
Compressor Rotary (Hermetic)
Refrigerant / Amount charged at shipment gR407c / 2,450
Refrigerant control Capillary tube
Noise Power Level Indoor – Hi / Me / Lo dB-A 58 / 55 /52
Outdoor – Hi dB-A 67
Refrigerant tubing connections Flare type
Max. allowable tubing length at shipment m 7.5
Refrigerant tube Narrow tube mm (in.) 6.35 (1/4)
diameter Wide tube mm (in.) 15.88(5/8)
Indoor Unit Outdoor Unit
Unit dimensions Height mm 285 835
Width mm 995 850
Depth mm 206 305
Package dimensions Height mm 276 913
Width mm 1,070 1000
Depth mm 363 400
Weight Net
kg 12.0 67.0
Shipping kg 15.0 76.0
Shipping volume m3
0.11 0.37
Dimensions & Weight Features Electrical Rating Performance
Indoor Unit AWR522CL
Outdoor Unit AER522SC3
Refrigerant tube kit/accessories Optional/Hanging wall bracket

DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Remarks: Rating conditions are:
Cooling: Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
Power Source.......Voltage Rating 400V - 3N - 50Hz .. ....400 V
Control Circuit V 230 V 50 Hz
Cooling
Capacity kW 5.0
BTU/h 17100
Air circulation (High) m3/h 760
Moisture removal (High) Liters/h 2.3
Available voltage range V342 to 418
Running amperes A3.6
Power input W2000
Power factor %80
C.O.P. W/W 2.5
Compressor locked rotor amperes A 21.5
Controls / Temperature control Microprocessor / I.C. thermostat
Control unit Wireless remote control unit
Timer ON/OFF 24 hours & Daily program, 1-hour OFF
Fan speeds Indoor / Outdoor 3 and Auto / Auto(Hi,LO)
Airflow direction (Indoor) Horizontal Manual
Vertical Auto
Air filter Washable
Compressor Rotary (Hermetic)
Refrigerant / Amount charged at shipment gR407c/ 1710
Refrigerant control Capillary tube
Noise Power Level Indoor – Hi / Me / Lo dB-A 55 / 51 / 49
Outdoor – Hi dB-A 64
Refrigerant tubing connections Flare type
Max. allowable tubing length at shipment m7.5
Refrigerant tube Narrow tube mm (in.) 6.35 (1/4)
diameter Wide tube mm (in.) 12.7 (1/2)
Indoor Unit Outdoor Unit
Unit dimensions Height mm 285 630
Width mm 995 830
Depth mm 206 305
Package dimensions Height mm 276 713
Width mm 1,070 994
Depth mm 363 413
Weight Net kg 12.0 52
Shipping kg 15.0 57
Shipping volume m30.11 0.29
Dimensions & Weight Features Electrical Rating Performance
Indoor Unit AWR518CL
Outdoor Unit AER518SCL3
4

5
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Remarks: Rating conditions are:
Cooling: Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
Power Source..... Voltage Rating 400V - 3N - 50Hz........ 400 V
Control Circuit 230 V 50 Hz
Cooling
Capacity
kW 6.15
BTU/h 21000
Air circulation (High) m3/h 830
Moisture removal (High) Liters/h 3.3
Available voltage range V342 to 418
Running amperes A4.8
Power input W2800
Power factor %84
C.O.P. W/W 2.20
Compressor locked rotor amperes A28
Controls / Temperature control Microprocessor / I.C. thermostat
Control unit Wireless remote control unit
Timer ON/OFF 24 hours & Daily program, 1-hour OFF
Fan speeds Indoor / Outdoor 3 and Auto / Auto(Hi, Lo)
Airflow direction (Indoor) Horizontal Manual
Vertical Auto
Air filter Washable
Compressor Rotary (Hermetic)
Refrigerant / Amount charged at shipment gR407c / 2,410
Refrigerant control Capillary tube
Noise Power Level Indoor – Hi / Me / Lo dB-A 58 / 55 /52
Outdoor – Hi dB-A 67
Refrigerant tubing connections Flare type
Max. allowable tubing length at shipment m 7.5
Refrigerant tube Narrow tube mm (in.) 6.35 (1/4)
diameter Wide tube mm (in.) 15.88(5/8)
Indoor Unit Outdoor Unit
Unit dimensions Height mm 285 835
Width mm 995 850
Depth mm 206 305
Package dimensions Height mm 276 913
Width mm 1,070 1000
Depth mm 363 400
Weight Net
kg 12.0 67.0
Shipping kg 15.0 76.0
Shipping volume m3
0.11 0.37
Dimensions & Weight Features Electrical Rating Performance
Indoor Unit AWR522CL
Outdoor Unit AER522SCL3
Refrigerant tube kit/accessories Optional/Hanging wall bracket

6
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Remarks: Rating conditions are:
Cooling: Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
Power Surce.......Voltage Rating 400V - 3N - 50Hz .. ....400 V
Control Circuit 230 V 50Hz
Cooling
Capacity
kW 5.0
BTU/h 17100
Air circulation (High) m3/h 800
Moisture removal (High) Liters/h 2.3
Available voltage range V342 to 418
Running amperes A3.6
Power input W2000
Power factor %80
C.O.P. W/W 2.50
Compressor locked rotor amperes 21.5
Controls / Temperature control Microprocessor / I.C. thermostat
Control unit Wireless remote control unit
Timer ON/OFF 24 hours & Daily program, 1-hour OFF
Fan speeds Indoor / Outdoor 3 and Auto / Auto(Hi, Lo)
Airflow direction (Indoor) Horizontal Manual
Vertical Auto
Air filter Washable, Anti-Mold
Compressor Rotary (Hermetic)
Refrigerant / Amount charged at shipment gR407c / 1710
Refrigerant control Capillary tube
Noise Power Level Indoor – Hi dB-A 59
Outdoor – Hi dB-A 64
Refrigerant tubing connections Flare type
Max. allowable tubing length at shipment m10
Refrigerant tube Narrow tube mm (in.) 6.35 (1/4)
diameter Wide tube mm (in.) 12.7 (1/2)
Refrigerant tube kit Optional
Indoor Unit Outdoor Unit
Unit dimensions Height mm 680 630
Width mm 900 830
Depth mm 190 305
Package dimensions Height mm 813 713
Width mm 1011 994
Depth mm 296 413
Weight Net
kg 23.5 52.0
Shipping kg 30.0 57.0
Shipping volume m3
0.24 0.29
Dimensions & Weight Features Electrical Rating Performance
Outdoor Unit AER518SC3
Indoor Unit FCR518CL

7
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Remarks: Rating conditions are:
Cooling: Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
Power Surce.......Voltage Rating 400V - 3N - 50Hz .. ....400 V
Control Circuit V230 50Hz
Cooling
Capacity
kW 6.15
BTU/h 21000
Air circulation (High) m3/h 900
Moisture removal (High) Liters/h 3.3
Available voltage range V342 to 418
Running amperes A4.8
Power input W2800
Power factor %84
C.O.P. W/W 2.2
Compressor locked rotor amperes A28
Controls / Temperature control Microprocessor / I.C. thermostat
Control unit Wireless remote control unit
Timer ON/OFF 24 hours & Daily program, 1-hour OFF
Fan speeds Indoor / Outdoor 3 and Auto / Auto(Hi, Lo)
Airflow direction (Indoor)
Horizontal Manual
Vertical Auto
Air filter Washable,Anti - mold
Compressor Rotary (Hermetic)
Refrigerant / Amount charged at shipment gR407c / 2,410
Refrigerant control Capillary tube
Noise Power Level Indoor – Hi dB-A 60
Outdoor – Hi dB-A 67
Refrigerant tubing connections Flare type
Max. allowable tubing length at shipment m10
Refrigerant tube Narrow tube mm (in.) 6.35 (1/4)
diameter Wide tube mm (in.) 15.88 (5/8)
Refrigerant tube kit / Accessories Optional / Hanging wall bracket
Indoor Unit Outdoor Unit
Unit dimensions Height mm 680 835
Width mm 900 850
Depth mm 190 305
Package dimensions Height mm 813 913
Width mm 1011 1000
Depth mm 296 400
Weight Net
kg 23.5 67.0
Shipping kg 30.0 76.0
Shipping volume m3
0.24 0.37
Dimensions & Weight Features Electrical Rating Performance
Indoor Unit FCR522CL
Outdoor Unit AER522SC3

8
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Remarks: Rating conditions are:
Cooling: Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
Power Surce.......Voltage Rating 400V - 3N - 50Hz .. ....400 V
Control Circuit 230 V 50Hz
Cooling
Capacity kW 5.0
BTU/h 17100
Air circulation (High) m3/h 800
Moisture removal (High) Liters/h 2.3
Available voltage range V342 to 418
Running amperes A3.6
Power input W2000
Power factor %80
C.O.P. W/W 2.50
Compressor locked rotor amperes 21.5
Controls / Temperature control Microprocessor / I.C. thermostat
Control unit Wireless remote control unit
Timer ON/OFF 24 hours & Daily program, 1-hour OFF
Fan speeds Indoor / Outdoor 3 and Auto / Auto(Hi, Lo)
Airflow direction (Indoor) Horizontal Manual
Vertical Auto
Air filter Washable, Anti-Mold
Compressor Rotary (Hermetic)
Refrigerant / Amount charged at shipment gR407c / 1710
Refrigerant control Capillary tube
Noise Power Level Indoor – Hi / Me / Lo dB-A 48 / 44 / 49
Outdoor – Hi dB-A 51
Refrigerant tubing connections Flare type
Max. allowable tubing length at shipment m10
Refrigerant tube Narrow tube mm (in.) 6.35 (1/4)
diameter Wide tube mm (in.) 12.7 (1/2)
Refrigerant tube kit Optional
Indoor Unit Outdoor Unit
Unit dimensions Height mm 680 630
Width mm 900 830
Depth mm 190 305
Package dimensions Height mm 813 713
Width mm 1011 994
Depth mm 296 413
Weight Net
kg 23.5 52.0
Shipping kg 30.0 57.0
Shipping volume m3
0.24 0.29
Dimensions & Weight Features Electrical Rating Performance
Outdoor Unit AER518SCL3
Indoor Unit FCR518CL

9
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Remarks: Rating conditions are:
Cooling: Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
Power Source.......Voltage Rating 400V - 3N - 50Hz .. ....400 V
Control Circuit V230 50Hz
Cooling
Capacity
kW 6.15
BTU/h 21000
Air circulation (High) m3/h 900
Moisture removal (High) Liters/h 3.3
Available voltage range V342 to 418
Running amperes A4.8
Power input W2800
Power factor %84
C.O.P. W/W 2.20
Compressor locked rotor amperes A28
Controls / Temperature control Microprocessor / I.C. thermostat
Control unit Wireless remote control unit
Timer ON/OFF 24 hours & Daily program, 1-hour OFF
Fan speeds Indoor / Outdoor 3 and Auto / Auto(Hi, Lo)
Airflow direction (Indoor)
Horizontal Manual
Vertical Auto
Air filter Washable,Anti - mold
Compressor Rotary (Hermetic)
Refrigerant / Amount charged at shipment gR407c / 2,410
Refrigerant control Capillary tube
Noise Power Level Indoor – Hi / Me / Lo dB-A 50 / 47 / 44
Outdoor – Hi dB-A 55
Refrigerant tubing connections Flare type
Max. allowable tubing length at shipment m10
Refrigerant tube Narrow tube mm (in.) 6.35 (1/4)
diameter Wide tube mm (in.) 15.88 (5/8)
Refrigerant tube kit / Accessories Optional / Hanging wall bracket
Indoor Unit Outdoor Unit
Unit dimensions Height mm 680 835
Width mm 900 850
Depth mm 190 305
Package dimensions Height mm 813 913
Width mm 1011 1000
Depth mm 296 400
Weight Net
kg 23.5 67.0
Shipping kg 30.0 76.0
Shipping volume m3
0.24 0.37
Dimensions & Weight Features Electrical Rating Performance
Indoor Unit FCR522CL
Outdoor Unit AER522SCL3

10
2-2. Major Component Specifications
2-2-1. Indoor Unit
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Part No. POW–K188E
Controls Microprocessor
Control circuit fuse 250 V – 3.15 A
Remote Control Unit RCS–8PS3E
Type Cross-flow
Q´ty ... Dia. and length mm 1 ... ø88 / L746
Fan motor model ... Q´ty UF2– 31A5PA–S ... 1
No. of poles ... rpm (High) 2 ... 1,305
Nominal output W 30
Coil resistance (Ambient temp. 20°C) ΩWHT – BRN : 130.4
WHT – PNK : 169.8
– : –
– : –
– : –
Safety Type Thermal protector
devices Operating temp. Open °C 130 ± 8
Close Automatic reclosing
Run capacitor µF 2.0
VAC 440
Type Stepping motor
Model MP24GA2
Rating DC 12 V
Coil resistance (Ambient temp. 20°C) ΩEach terminals (1–2, 1–3, 1–4, 1–5) 400 : ± 7%
Coil Aluminum plate fin / Copper tube
Rows 2
Fin pitch mm 1.3
Face area m2 0.250
Heat
Exch. Coil Flap Motor Fan & Fan Motor
Controller
PCB
Indoor Unit AWR518CL

11
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Part No. POW–K228E
Controls Microprocessor
Control circuit fuse 250 V – 3.15 A
Remote Control Unit RCS–8PS3E
Type Cross-flow
Q´ty ... Dia. and length mm 1 ... ø88 / L746
Fan motor model ... Q´ty UF2– 31A5PA–S ... 1
No. of poles ... rpm (High) 2 ... 1,380
Nominal output W 30
Coil resistance (Ambient temp. 20°C) ΩWHT – BRN : 130.4
WHT – PNK : 169.8
– : –
– : –
– : –
Safety Type Thermal protector
devices Operating temp. Open °C 130 ± 8
Close Automatic reclosing
Run capacitor µF 2.0
VAC 440
Type Stepping motor
Model MP24GA2
Rating DC 12 V
Coil resistance (Ambient temp. 20°C) ΩEach terminals (1–2, 1–3, 1–4, 1–5) 400 : ± 7%
Coil Aluminum plate fin / Copper tube
Rows 2
Fin pitch mm 1.3
Face area m2 0.250
Heat
Exch. Coil Flap Motor Fan & Fan Motor
Circuit
Board
Ass´y
Indoor Unit AWR522CL

12
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Part No. POW–K185GS–N
Controls Microprocessor
Control circuit fuse 250 V – 3 A
Remote Control Unit RCS – 5PN3E
Type Centrifugal
Number ... Dia. and length mm 2 ... ø 130 / L 180
Fan motor model ... Number K48410–M01417 ... 1
No. of poles ... rpm (230 V, High) 4 ... 1,140
Nominal output W 27
Coil resistance (Ambient temp. 20°C) ΩGRY – WHT : 215 ± 7%
WHT – VLT : 87 ± 7%
VLT – YEL : 87 ± 7%
WHT – PNK : 273 ± 7%
Safety Type Internal thermal fuse
devices Operating temp. Open °C 145 ± 5
Close Automatic reclosing
Run capacitor µF 2.0
VAC 440
Model M2LJ24ZE31
Rating AC 208 / 230 V, 50 / 60 Hz
No. of poles ... rpm 8 ... 2.5 / 3.0
Nominal output W 3 / 2.5
Coil resistance (Ambient temp. 20°C) kΩ16.45 ± 15%
Coil Aluminum plate fin / Copper tube
Rows 2
Fin pitch mm 1.8
Face area m20.192
Heat
Exch. Coil Flap Motor Fan & Fan Motor
Controller
PCB
Indoor Unit FCR518CL

13
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Part No. POW–K185GS–N
Controls Microprocessor
Control circuit fuse 250 V – 3 A
Remote Control Unit RCS – 5PN3E
Type Centrifugal
Number ... Dia. and length mm 2 ... ø 130 / L 180
Fan motor model ... Number K48410–M01418 ... 1
No. of poles ... rpm (230 V, High) 4 ... 1,280
Nominal output W 41
Coil resistance (Ambient temp. 20°C) ΩGRY – WHT : 95 ±7%
WHT – VLT : 73 ± 7%
VLT – YEL : 73 ± 7%
WHT – PNK : 207 ± 7%
Safety Type Internal thermal fuse
devices Operating temp. Open °C 145 ± 5
Close Automatic reclosing
Run capacitor µF 2.0
VAC 440
Model M2LJ24ZE31
Rating AC 208 / 230 V, 50 / 60 Hz
No. of poles ... rpm 8 ... 2.5 / 3.0
Nominal output W 3 / 2.5
Coil resistance (Ambient temp. 20°C) kΩ16.45 ± 15%
Coil Aluminum plate fin / Copper tube
Rows 2
Fin pitch mm 1.8
Face area m20.192
Heat
Exch. Coil Flap Motor Fan & Fan Motor
Controller
PCB
Indoor Unit FCR522CL

DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Part No. POW-C181BL (Only CLR model)
Control circuit fuse 250V – 5A (Only CLR model)
Type Rotary (Hermetic)
Compressor model C-2RN173H8W 80807088
Source 380 – 400 V – 3N
~ 50 Hz
Nominal output W 1,700
Compressor oil ... Amount cc FV68S ... 800
Coil resistance (Ambient temp. 25°C) ΩC – R : 6.369
C – S : 6.073
R – S : 6.217
Type Internal protector External protector
Safety Overload relay —HE-10TB TH-5A
devices Operating temp. Open °C Automatic opening —
Close °C Automatic reclosing —
Operating amp.(Ambient temp. 25°C) — 5A
Run capacitor µF —
VAC —
Crank case heater 240V 30W
Type Propeller
Q´ty ... Dia. mm 1 ... ø400
Fan motor reference model ... Q'ty SMEN 19 TFB6047 ... 1
Source 220 – 230 V
~ 50 Hz
No. of poles ... rpm (220 V, High) 6 ... 910
Nominal output W43
Coil resistance (Ambient temp. 20°C) ΩWHT – BRN : 83.4
WHT – PNK : 218.7
Safety Type Internal type
devices Operating temp. Open °C 130 ± 5
Close Automatic reclosing
Run capacitor µF 2.0
VAC 440
Coil Aluminum plate fin / Copper tube
Rows 2
Fin pitch mm 1.8
Face area m20.508
External Finish Acrylic baked-on enamel finish
Controller
PCB
Heat
Exch. Coil Compressor
Fan & Fan Motor
14
Outdoor Unit AER518SC3 / AER518SCL3
2-2-2. Outdoor Unit

DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Part No. Johnson Control (Only CLR model)
Type Rotary (Hermetic)
Compressor model C-RN223H8A80244088B
Source 380 – 400 V – 3N
~ 50 Hz
Nominal output W2200
Compressor oil ... Amount cc FV68S ... 1350
Coil resistance (Ambient temp. 25°C) ΩC – R : 4.97
C – S : 4.64
R – S : 4.88
Type Internal protector External protector
Safety Overload relay HE-10TB TH-7A —
devices Operating temp. Open °C Automatic opening —
Close °C Automatic reclosing —
Operating amp.(Ambient temp. 25°C) 7A —
Run capacitor µF —
VAC —
Crank case heater 240V 30W
Type Propeller
Q´ty ... Dia. mm 1 ... ø460
Fan motor reference model ... Q´ty SMEN 1STFB6064 ... 1
Source 220 – 230 V
~ 50 Hz
No. of poles ... rpm (220 V, High) 6 ... 840
Nominal output W 50
Coil resistance (Ambient temp. 20°C) ΩWHT – BRN : 99.5 / WHT - YEL : 252
WHT – PNK : 63.2
Safety Type Internal type
devices Operating temp. Open °C 130 ± 5
Close Automatic reclosing
Run capacitor
µF5.0
VAC 440
Coil Aluminum plate fin / Copper tube
Rows 2
Fin pitch mm 2.0
Face area m2
0.610
External Finish Acrylic baked-on enamel finish
Controller
PCB
Heat
Exch. Coil Compressor
Fan & Fan Motor
15
Outdoor Unit AER522SC / AER522SCL3

2-3. Other Component Specifications
16
Thermistor (Room sensor) DTN-TKS142B
Resistance kΩ25°C 5.0 ± 3%
Thermistor (Coil sensor) DTN-TKS131B
Resistance kΩ0°C 15.0 ± 2%
Transformer (TR) ATR-J105
Rating Primary AC 230V, 50/60Hz
Secondary 19V, 0.526A
Capacity 10VA
Coil resistance Ω(at 21°C) Primary (WHT – WHT): 205 ± 10%
Secondary (BRN – BRN): 2.0 ± 10%
Thermal cut-off temp. 150°C
Indoor Unit AWR518CL
AWR522CL
