Argus Security SG100 User manual

SG100
WIRELESS OPTICAL SMOKE DETECTOR
ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it
GENERAL DESCRIPTION
The wireless optical smoke detector samples the air in the protected area. An alarm condition is raised when the detected environmental
smoke quantity exceeds the alarm threshold.
DETECTOR VISUAL LED INDICATOR
The wireless optical smoke detector is equipped with a LED that provides visual
indication for functional modes, battery faults and other fault types (see table 1).
LINKING THE DEVICE TO THE SYSTEM
This detector must be linked to the fire security system before installation; specifi-
cally it must be linked to its translator or expander module as per installation plan.
For more detailed information about wireless linking refer to “Guide to
wireless system installation” document (APN-W0001) or refer to your sys-
tem supplier.
This manual gives the specific linking procedure applicable only to this detector.
STANDARD LINKING PROCEDURE
When the Wirelex program or the translator module is waiting for this device to be
linked, perform the following actions:
1) Check that the link switch is on the “ON” position.
2) Extract the isolating tab from the back of the detector (picture 2).
Device LED will indicate “operating mode”.
3) Move the switch in position “1” to start the linking phase.
Device LED will indicate “linking mode”.
4) If linking went ok, the LED will indicate “normal operating mode”.
The link switch MUST be left on “1” from now!
5) If linking failed, the LED will indicate “linking failure mode”; perform the
“RECOVERY LINKING PROCEDURE”.
1. Detector
2. Mounting base
3. Visual LED indicator
4. Link switch
5. Tamper switch
6. Batteries housing
7. Secondary battery
8. Main battery
9. Battery cover
Picture 1
Picture 2
Extract the isolating tab from the
back of the detector Table 1
LED SIGNAL MEANING LED VISUAL SIGNAL
“Power up mode”.
The isolating tab has just been
extracted or the main battery
has just been inserted.
Green LED blinks;
Orange LED on for 2 seconds;
Red LED blinks.
“Linking mode”.
Linking phase has been
started.
Green LED blinks;
Red LED blinking 1 second on
and 0.1 second off;
Green and red LED alternat-
ing for 1 second.
“Linking failure mode”. Red LED continuously on.
“Normal operating mode”. LED off.
“Alarm mode”. Red LED blinking: 0.5 second
on and 0.5 second off.
Device unpowered. LED off.
Main battery fault (low charge) Orange blinking: 0.1 second
on and 5 seconds off.
Secondary battery fault (low
charge)
Green LED blinking: 0.1
second on and 5 seconds off.
Both batteries fault
Sequential orange-green LED
blinking: 0.1 second on and 5
seconds off.
Tamper fault LED off.
Other fault type
Sequential orange-green LED
blinking: 0.5 second each
colour.
928k/01

[email protected] SPNK-754431-114 (v3.0)
RECOVERY LINKING PROCEDURE
1) Uninstall the battery housing cover.
2) Take out the main battery from its housing.
3) Alternate the link switch on “ON” / “1” five times.
4) Move the link switch to position “ON”.
When the Wirelex program or the translator module is waiting for this device to be linked, perform the following actions:
1) Insert the main battery (Ensure battery’s polarity is correct!).
Device LED will indicate “operating mode”.
2) Move the switch in position “1” to start the linking phase.
Device LED will indicate “linking mode”.
3) If linking went ok, the LED will indicate “normal operating mode”; reinstall the battery housing cover.
The link switch MUST be left on “1” from now!
4) If linking failed, the LED will indicate “linking failure mode”; perform this procedure again.
CHECKING THE WIRELESS LINK QUALITY
It is possible to check wireless link quality between the detector and its linked-to translator or expander module in this way:
1) Move the link switch onto the “ON” position.
2) Detector’s LED indicator will start blinking according to table 2:
3) Move the link switch to position “1” again; device will NOT WORK if the link switch is on position “ON”!
DETECTOR INSTALLATION
For detector spacing, placement and special applications refer to your specific national standards.
Mount the detector as far as possible from metal objects, metal doors, metal window openings, etc. as well as cable conductors,
cables (especially from computers), otherwise the operating distance may greatly drop. The detector must NOT be installed near
electronic devices and computer equipment that can interfere with its wireless link quality.
1) Choose for the detector a placement position that:
a) Compliances with your specific standards.
b) Is reached by a strong wireless signal from its linked-to translator or expander module.
c) Is not interfered by environmental factors (as per note above).
2) Install and fix the base, in the selected position, with the screws provided (picture 3).
3) Install the detector onto the base (picture 3).
4) Carry out a test of the device to meet local regulations (see TESTING).
5) If the detector fails the test:
- Clean it if dirty (see MAINTENANCE - CLEANING).
- Change batteries if low battery is indicated on the translator (see MAINTENANCE - BATTERY CHANGING).
6) Test the detector again (see TESTING).
7) If the detector fails the test again replace it (see WARRANTY).
LINK QUALITY EVALUATION DEVICE’S INDICATION
No connection Fail Two red blinks
Link margin is less than 10 dB Poor One red blink
Robust communication with link margin from 10 dB to 20 dB Good One green blink
Robust communication with link margin over 20 dB Excellent Two green blinks Table 2
Picture 3
From the moment you switch
on “1” to the moment linking
comes to an end, the detector
must be only a few inches
away from the translator or expander
you are linking to.
Dust covers DO NOT provide
complete protection against
contamination: detectors
should be removed before construc-
tion, major re-decoration or other dust
producing work is started.
Dust covers MUST be removed before
the system can be made operational.

DETECTOR BLOCK
To lock the detector to the base:
1) Cut off the small plastic lug on the plastic blocking grip on the detector base (picture 4).
2) Install the detector onto the base.
3) Check if the detector is effectively locked!
To unlock the detector from the base:
1) Insert the tip of a small screwdriver into the side hole of the supporting base (picture 5).
2) Push and keep down, with the tip of the screwdriver, the blocking grip on the base.
3) Uninstall the detector from the base.
TAMPER DETECTION CAPABILITY
The wireless optical smoke detector is provided with a tamper switch: in case of removal of the detector from its base, a tamper detection
message is sent to the control panel.
TESTING
All detectors must be tested after installation and, successively, on a periodic basis.
After each test reset the fire security system from the control panel, as per your control panel instructions.
TEST 1 - MAGNET TEST
Purpose: checking the alarm capability of the detector by using the built-in test circuitry;
no alarming agent (aerosol) is used.
1) Hold a suitable magnet in correspondence of the indicated area (picture 6).
2) Wait a few seconds.
3) If it works, the detector will switch into “Alarm mode” (as indicated by the LED indicator).
TEST 2 - AEROSOL TEST
Purpose: checking the alarm capability of the detector by using aerosol.
Use only suitable aerosol testers supplied by approved manufacturers.
1) By following its specific instructions, apply the aerosol test device to the detector.
2) Wait a few seconds.
3) If it works, the detector will switch into “Alarm mode” (as indicated by the LED indicator).
MAINTENANCE - CLEANING
1) Remove the detector from its base.
2) Smoke entry areas: use a small, soft bristle brush to dislodge any obvious contaminants such as insects, spider webs, hairs, etc.
3) Smoke entry areas: use a small vacuum tube or dry, clean, compressed air to suck up or blow any remaining small particles away.
4) Wipe the exterior housing of the detector with a clean, damp, lint-free cloth to remove any surface film that can later attract airborne
contaminants.
5) Install the detector onto its base again.
6) Test the detector.
ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it
Picture 4
Detector blocking
grip Picture 5
Unlocking tool (screwdriver)
Access to detector’s block
Picture 6

MAINTENANCE - BATTERY CHANGING
When a low battery condition is indicated, both, main and secondary, batteries must be changed altogether.
During this procedure the linking switch must NOT be touched at all!
1) Remove the detector from its base.
2) Remove the battery cover.
3) Remove the old primary battery.
4) Remove carefully the old secondary battery with the aid of the tip of a small screwdriver: damage must not be made to the detector’s
internal printed circuit board.
5) Insert the new CR2032А secondary battery.
Positive pole facing up.
6) Insert the new CR123A primary battery.
Ensure that battery polarity is correct.
7) Reinstall the battery cover.
8) Install the detector onto its base again.
9) Test the detector.
[email protected] SPNK-754431-114 (v3.0)
WARNINGS AND LIMITATIONS
Our devices use high quality electronic components and plastic materials that are highly resistant to environmen-
tal deterioration. However, after 10 years of continuous operation, it is advisable to replace the devices in order to
minimize the risk of reduced performance caused by external factors. Ensure that this device is only used with
compatible control panels. Detection systems must be checked, serviced and maintained on a regular basis to
confirm correct operation. Smoke sensors may respond differently to various kinds of smoke particles, thus
application advice should be sought for special risks. Sensors cannot respond correctly if barriers exist between
them and the fire location and may be affected by special environmental conditions. Refer to and follow national
codes of practice and other internationally recognized fire engineering standards. Appropriate risk assessment
should be carried out initially to determine correct design criteria and updated periodically.
WARRANTY
All devices are supplied with the benefit of a limited 3 year warranty relating to faulty materials or manufacturing
defects, effective from the production date indicated on each product. This warranty is invalidated by mechanical
or electrical damage caused in the field by incorrect handling or usage. Product must be returned via your author-
ized supplier for repair or replacement together with full information on any problem identified. Full details on our
warranty and product’s returns policy can be obtained upon request.
The warranty does not cover the provided batteries.
ARGUS SECURITY S.R.L.
Via del Canneto, 14
34015 Muggia (TS)
Italy
10
SG0110CPR20130901
EN 54-25:2008
EN 54-7:2000+
A1:2002+A2:2006
SG100
For use in compatible fire
detection and alarm system
0832
Table 3
* When a low battery condition is indicated, both, main and secondary, batteries must be
changed altogether.
** Check latest version of document TDS-SG100 for further data, obtainable from your
supplier.
TECHNICAL SPECIFICATIONS **
Communication range with the
translator or expander 200 m Open space
Operating frequency 868 MHz
Modulation type FSK
Operating frequency channels 7
Radiated power 5 dBm (3 mW) Typical
Transmission message period 60 sec Default
Main battery *Type CR123A (3 Vdc) 5 years typical
Secondary battery *Type CR2032А (3 Vdc) 2 months typical
Dimensions 110 mm x 65 mm Including adaptor wall
base
Weight 130 g Including adaptor wall
base
IP rating 40
Max tolerated humidity
(no condensing) 95% RH
Operating temperature range From –10 °C to +55 °C
