Argus E25 MOD II User manual

Electric Valve Actuator
E25 MOD II
EN
English
Translation from German original

Argus E25 MOD II - Operating Instructions
Contents
Introduction ................................................................................................................... 3
Availability of the instructions .............................................................................................. 3
Types of valve actuator illustrated and described................................................................ 3
Design features in the text .................................................................................................. 4
Safety............................................................................................................................ 4
Proper use .......................................................................................................................... 4
Basic safety instructions...................................................................................................... 5
Potential causes of damage and malfunction...................................................................... 7
Qualification of personnel.................................................................................................... 7
Protective clothing............................................................................................................... 7
Design features of warning instructions in the text .............................................................. 7
Design features of instructions about damage to property .................................................. 7
Description .................................................................................................................... 8
Scope of supply, technical data and description of the unit ................................................. 8
Uses and function ............................................................................................................. 12
Storing and transporting the unit ................................................................................... 14
Storing the valve ............................................................................................................... 14
Transporting the unit ......................................................................................................... 15
Installing and connecting the unit .................................................................................. 16
Preparing for installation ................................................................................................... 16
Installing the unit ............................................................................................................... 18
Connecting the unit ........................................................................................................... 21
Operation .................................................................................................................... 26
Emergency manual operation ........................................................................................... 26
Automatic operation .......................................................................................................... 27
Correcting faults and disturbances ................................................................................ 29
After operation ............................................................................................................. 30
Cleaning to remove external dirt ....................................................................................... 30
Maintenance of the unit..................................................................................................... 30
Maintenance and replacement parts ................................................................................. 31
Taking the unit out of service........................................................................................ 37
Remove hazardous substances........................................................................................ 37
Removing the unit ............................................................................................................. 38
Reusing the unit after storage ........................................................................................... 39
Disposal of the unit ........................................................................................................... 39
Technical data ............................................................................................................. 40
Application limits ............................................................................................................... 40
CE Conformity / certification ......................................................................................... 40
Appendix: EU Declaration of Conformity........................................................................... 41
Appendix: ATEX Type Approval Examination Certificate .................................................. 42
Appendix: Certificate of Conformity IECEx....................................................................... 43
Manufacturer:
.............................................................................................................. 47

Argus E25 MOD II - Operating Instructions
3
Introduction
These Operating Instructions provide the operating personnel
with information and instructions relevant for the safe installa-
tion, commissioning and operation of the ARGUS-E25 MOD II
electric valve actuator.
In the text below, rotary actuators will be abbreviated to “units”.
The Operating Instructions are intended for all persons who
install, commission, operate, maintain, clean or dispose of this
unit. The Operating Instructions are intended in particular for
customer-service fitters, trained specialist personnel and quali-
fied and authorised operating personnel.
Each of these persons must have familiarised himself with and
understood these operating instructions.
Following the instructions contained in these Operating Instruc-
tions helps recognise and avoid potential hazards, and to in-
crease the reliability and useful life of the units. Apart from the
instructions in these operating instructions, it is essential that
the legal regulations, standards and rules relating to accident-
prevention that apply in the country and at the place where the
unit is used are observed, together with all relevant technical
regulations and rules for safe and appropriate work practices.
Availability of the instructions
Always keep these Operating Instructions with the plant docu-
mentation. Make sure that these Operating Instructions are
available to the operator.
The Operating Instructions are considered to be a part of the
unit. If you sell the unit or pass it on in some other way, these
Operating Instructions must be handed over to the new owner.
Types of valve actuator illustrated and de-
scribed
The units described in these Operating Instructions are variants
of type
E25 MOD II
The standard units are described in these operating instruc-
tions. Please contact the manufacturer for information about
additional components not described here.
It is possible that some additional equipment for the unit is not
described and illustrated in detail in these Operating Instruc-
tions. You will find information about such equipment in the
documentation supplied with the actuator.
If you have any queries, please contact the manufacturer.

Argus E25 MOD II - Operating Instructions
4
Design features in the text
Various elements in these Operating Instructions are furnished
with predetermined design features. They make it easy to dif-
ferentiate between the following elements:
Normal text
Cross-references
Listings
Sub-sections in listings
Activity steps
These
tips contain additional
inform
ation, such as special data
about
economical use of the unit.
Safety
Proper use
The ARGUS E25 MOD II actuator is intended for operating
industrial controls,
such as, e.g. valves, gate valves, butterfly valves and ball
valves.
For other applications, please consult the manufacturer. In the
event of
improper use and any resultant damage
the manufacturer accepts no liability. Such risks are borne by
the user alone.
Observing these Operating Instructions is considered to be a
part of proper use.
.
The units shall only be used within the permissible electrical
voltage and temperature limits, taking chemical and corrosive
influences into account.
Observing and complying with all instructions in these Operat-
ing Instructions, in particular the safety instructions, is implicit in
proper use.
Instructions and data in the documentation supplied with the
unit are considered to be an integral part of these Operating
Instructions.
Safety instructions on the unit or on the valve to which it
is fitted must be observed.
The operating authority must ensure that only the following
activities are carried out:
The maintenance operations described in these Operating
Instructions
Installing the unit
Connecting the unit according to the wiring diagram
Automatic operation of the unit
Manual operation of the unit
Adjusting the end positions using switching cams
Changing the timing belt
Removing the actuator
Any other activities shall only be carried out by personnel who
have been specially trained and authorised by the manufactur-
er.
Any other use of the unit is considered to be improper use.
In particular the use of ball valves to regulate the rate of flow is
improper use.
Use of the actuator on a valve for which it is not suitable is also
improper use.

Argus E25 MOD II - Operating Instructions
5
Basic safety instructions
Explosion hazards
The unit has been designed and manufactured taking the har-
monised standards EN1127-1, EN60079-0 and EN60079-1 into
account. Thus, the unit is protected against potentially-
explosive atmospheres by a pressure-resistant flameproof
enclosure “d”.
In spite of this, the following points must be observed:
An explosion hazard arises from using equipment that is
unsuitable for the environmental conditions.
Before use in an environment in which there is an explosion
hazard, observe the following points:
The surface temperature of the equipment must not ex-
ceed that permissible at the location where it is installed.
If the unit is installed so that it is electrically isolated, suit-
able measures must be adopted to discharge static elec-
tricity between valve connections.
Moving parts that are extremely resistant to movement, may
give rise to frictional heating. Ensure that moving parts move
freely.
During welding operations, there is a risk of explosion or fire
being caused by open flames, electric arcs and flying
sparks. Observe the valid legal regulations concerning pro-
tection against fire and explosions that apply where the unit
is installed.
The unit and its components shall only be assembled or
dismantled by specialist personnel.
Danger of serious injury
The unit can become hot during operation. Only take the unit
into service when contact with hot surfaces is prevented by
insulation or guards.
During operation the unit is under the influence of higher
ambient temperatures and may be hot. Do not carry out
work on the unit until the following conditions apply:
The unit has been disconnected from sources of electrical
energy.
The unit has cooled down (to about 20°C).
During any work on the unit, the higher-level plant must
be switched off and secured against unauthorised switch-
ing back on.
For units installed in contaminated areas, there is a danger
of severe or lethal injury from hazardous substances on the
unit. Do not work on the unit until it has been completely de-
contaminated. Wear the specified protective clothing during
all work in the contaminated area.
The unit and its components shall only be assembled or
dismantled by specialist personnel. Specialist personnel
must have knowledge and experience in the following sec-
tors:
Qualified electrician
The selection of lifting gear suitable for the unit, and the
safe use of such lifting gear
Working with hazardous media (contaminated, hot, or un-
der pressure)
The selection of unsuitable lifting gear, or its incorrect use,
can result in the unit or parts of it falling.
Allow only specialist personnel to lift the unit or its parts.
Make sure that there are never persons under suspended
loads.
Make sure that lifting gear has adequate load capacity for
the load it has to lift, and that such loads are properly at-
tached.
Make sure that all valid, local safety and accident-
prevention regulations are observed.
If the permissible application limits for the unit are exceeded,
the unit may be destroyed, and hot or pressurised media
may be released. Make sure that the unit is always operated
within the permissible application limits.
Details of the application limits are given on the unit’s typep-
late and in the chapter “
Technical data ”
If it is used without supports with adequate load capacity and
sufficiently stable connections to the valve, the unit may be
damaged. Allow only specialist personnel to assemble and
connect the unit.
If the unit is inadequately supported during installation, sub-
stantial injuries (e.g. crushing) are possible if the unit falls or
tips. During installation secure the unit to prevent it falling or
tipping. Wear the protective clothing specified at the location.
The unit can be installed on several different types of valve,
e.g. a ball valve or a butterfly valve. Depending on the ener-
gy source for the drive, there is a danger of severe or lethal
injuries from a variety of causes. Before starting any work on
the unit, make sure that it is disconnected from the power
supply, and that the valve and its pipework are pressure-
free. Observe and follow all hazard notes in the operating in-
structions for the valve. If you have any queries, please con-
tact the valve manufacturer.
There is a danger of severe or lethal crushing by moving
parts of the unit. During operation, make sure that no one
can be in the vicinity of the moving parts or reach into them.
Before any work on the unit, make sure the actuator is

Argus E25 MOD II - Operating Instructions
6
switched off and secured against unauthorised switching
back on.
Danger of less serious injury
Cut injuries are possible on the sharp edges of parts inside
the unit. During any work on the unit, wear protective gloves.
If the unit is inadequately supported during installation,
crushing injuries are possible if the unit falls or tips. During
installation secure the unit to prevent it falling or tipping.
Wear adequate personal protective equipment.

Argus E25 MOD II - Operating Instructions
7
Potential causes of damage and malfunction
Failure to follow the wiring diagram or making incorrect con-
nections at the terminals can result in destruction of the PCB
or individual electrical components.
The unit should only be installed on valves whose torque
requirement does not exceed the unit’s maximum permissi-
ble output torque. Failure to follow this rule can result in
breakage of the operating shaft or other components of the
unit.
Connection to a power supply of the wrong voltage can
cause damage to the unit’s electrical components.
Make sure the unit is always connected to the correct volt-
age.
Qualification of personnel
The operating authority shall only authorise qualified specialist
personnel to carry out work on the unit. This work is limited to:
Changing the limit switch plate
Setting the end-position limit switches
Changing the timing belt
Persons who work on the unit must, as a result of their training
and experience, have sufficient knowledge of the relevant regu-
lations, that apply at the location where the unit is installed, to
ensure safe operation/maintenance of the unit .
These include, in particular, the following regulations:
Legal requirements
Standards
Accident-prevention regulations
Recognised rules for safety and correct working
Special instructions issued by the operating authority
These persons must be able to recognise, assess and avoid
potential hazards.
Specialist personnel must have knowledge and experience in
the following sectors:
Valid legal regulations concerning protection against fire and
explosions, and work safety that apply where the unit is in-
stalled
Working on pressurised equipment
Work on electrical equipment
Working with hazardous media (hot, or under pressure)
Lifting and transporting loads
All Instructions in these Operating Instructions and other co-
valid documents
All other types of work are only to be carried out by the manu-
facturer or by personnel authorised to do so by the manufac-
turer.
Protective clothing
The protective clothing required depends on the legal require-
ments where the unit operates and on the media being han-
dled. For more information about suitable protective clothing
and protective equipment, see the safety data sheet for the
medium being handled.
Basic protective clothing has the following components:
Hard hat to EN 397
Safety shoes to EN ISO 20345
Robust leather gloves to EN 388
Persons within one metre of the unit while it is in operation
must wear ear defenders to EN 352
Depending on the media being handled and valid local regula-
tions, eye protection to EN 166 must also be worn.
Design features of warning instructions in the
text
DANGER
Instructions
with the word DAN-
GER
warn of a hazardous situa-
tion
that will result in death or
serious
injury.
WARNING
Instructions
with the word WARN-
ING
indicate a hazardous situa-
tion
that could possibly result in
death
or serious injury.
CAUTION
Instructions
with the word CAU-
TION
indicate a situation that
could
result in slight or moderately
severe
injuries.
Design features of instructions about damage
to property
ATTENTION!
These
instructions warn of a
situa-
tion
that will result in damage to
property.

Argus E25 MOD II - Operating Instructions
8
Description
Scope of supply, technical data and description
of the unit
Scope of supply
The following parts are included in the basic scope of supply:
Actuator E25 MOD II
These Operating Instructions
The scope of supply may also include contract-specific, addi-
tional documents, for example:
Operating instructions of the valve manufacturer
For precise details of the scope of supply for your unit, please
see the delivery note.
All units can be supplied with a hand lever as an option.
The unit can be supplied in one of several different states.
Unit supplied mounted on a valve
Unit without a valve
When the valve is part of the scope of supply, it will have been
set up already by the manufacturer.
At the customer’s request the unit can be supplied packed
individually, or several units can be packed together in any of
the following transport packages:
Transport box
Wire-mesh crate
Pallet
On reception of the delivery, compare the order number on
the delivery note with the details on the typeplate.
Check that all parts are complete and in good condition.
Contact the manufacturer without delay if there are devia-
tions or there is anything you are not clear about.
We will not accept complaints made later.
Technical data
You will find all technical data on the typeplate of the unit and in
the data sheet.
As standard the E25 MOD II is offered with one of three stand-
ard motor voltages:
Motor
:
U=110-125V DC/AC, I=2.1A, P=130W
or
U=220V DC/AC, I=0.95A, P=130W
or
three-phase
U=380-440-V 50Hz/ 460-480V 60Hz
The motors have internal thermal switches which break the
circuit at 184°C.

9
Description of the unit

Argus E25 MOD II - Operating Instructions
10
Optional components
In normal operation, the actuator oper-
ates with electric power.
It is possible to manually open and close
a valve with the actuator mounted using
the hand lever.
The unit can be installed on the following
types of valve:
Ball valve
One-way ball valve
Multi-way ball valve
Ball valve combinations
Non-return valve
Butterfly valve
Example: E25 MOD II with multi-way ball
valve
:
Example: E25 MOD II with ball valve
combination
:
Units with this type of combination can
have several different end positions
(max. 3 or 4) by using the setting cams.
Cam setting is described in detail from in
the appropriate chapter.

Argus E25 MOD II - Operating Instructions
11
Typeplate
The typeplate has the following data:
Manufacturer
Type designation
Unit number
Serial number
Nominal voltage
Type of supply
Nominal power data
Current draw
Year of manufacturer
Ambient temperature
CE marking
ATEX designation for flameproof ver-
sions
Depending on the design code, there
may be further data on the typeplate.
ATEX
According to EN-1127, the unit has po-
tential sources of ignition and so falls
under the European Directive “Equip-
ment for potentially explosive atmos-
pheres” 2014/34/EU (formerly 94/9/EC).
The unit has a pressure-resistant enclo-
sure, i.e. a flameproof enclosure “d” to
EN 60079-1.
The unit is classified as Group II, Zone 1,
and so falls into Category 2 for gas are-
as.
The unit is designated as follows:
The type approval procedure to directive
94/9/EC or 2014/34/EU was carried out
by Bureau Veritas (No. 2004) as the
notified body. The design concept, manu-
facture, quality assurance and the unit
itself were subjected to the specified
examinations. There is a copy of the “EU
Type approval examination certificate”
EPS 15 ATEX 1 05 X in the appendix to
these instructions.
After 8000 switching cycles, the unit must
be checked by the manufacturer. Failure
to do so invalidates the explosion proof
approval.
In the appendix to these operating in-
structions there is a copy of the EU dec-
laration of conformity to 2014/34/EU.
DANGER
Connection type
The
unit has two ¾“ NPT female
threads
for cable connections.
Only Ex “d” certified cable glands
may be used.
2004 II 2G Ex d IIB+H2 T3 Gb

Argus E25 MOD II - Operating Instructions
12
ATEX Directive
Units that comply with the requirements
of ATEX Directive 2014/34/EU or
94/9/EC may be used in areas in which
there is an explosion hazard if they have
been tested and approved as specified
therein.
There
is a copy of the EU Declara-
tion
of Conformity to ATEX Di-
rective
2014/34/EU in the appen-
dix
to these instructions.
IECEx
The IECEx approval is an international
standard for equipment that may be used
in a potentially-explosive atmosphere.
Bureau Veritas has subjected the design
concept, construction, quality assurance
and the finished product to the specified
examinations.
By issuing the
IECEx EPS 15.0046X
certificate, Bureau Veritas confirms con-
formity with the requirements.
You will also find a copy of this certificate
in the appendix.
For voltage and temperature
limits,
please see the typeplate.
Uses and function
Uses
The unit is intended for operating ball
valves, butterfly valves or other valves
with an operating angle between 0° and
360°.
Function
In the body of the unit (2), there are sub-
assemblies which impart a rotary motion
to the operating shaft (5).
By switching on the electric motor (7), the
gear wheel on the released electric brake
(3) is rotated by timing belt (9). This mo-
tion is transmitted by the planetary gear
(1) and gears in the lower part of the unit
to the operating shaft (5).
According to the actuator model, various
types of power supply and different volt-
ages may be used.

Argus E25 MOD II - Operating Instructions
13
The end positions are determined by
switching cams (4.11) and signalled by
mechanical limit switches (4.2).

Argus E25 MOD II - Operating Instructions
14
Storing and transporting the
unit
ATTENTION!
Incorrect
storage or transport can
damage
the unit.

Close all openings with the
covers supplied or similar co-
vers.

Make sure the unit is dry and
protected from corrosive at-
mospheres where it is stored.

Contact the manufacturer for
advice if you need to store or
transport the unit under other
conditions.
Storing the Actuator
Store the unit only under the following
conditions:
Do not store it for more than 24
months.
Close all connection openings with the
covers supplied or similar covers.
The connection surfaces and sealing
surfaces must be protected against
mechanical damage.
The unit and all its components must
be protected from blows and shocks.
Secure the unit to prevent it falling or
tipping.
The unit shall only be installed indoors
under the following environmental
conditions:
Relative humidity below 50%, non-
condensing
The room air must be clean and not
contain salt or other corrosive sub-
stance
Temperature 5 - 40 °C.
When storing, make sure these condi-
tions apply at all times.
Contact the manufacturer for advice if
you need to store the unit for longer or
under other conditions.

Argus E25 MOD II - Operating Instructions
15
Transporting the unit
For transport maintain the same con-
ditions as specified for storage.
Before transport, fit plugs to the con-
nections.
If
the plugs originally supplied are
not
available, use comparable
plugs
and covers to close the
connections.
DANGER
Danger
of crushing injury if the
unit
or its components fall or tip.

During any work on the unit,
wear suitable protective cloth-
ing.

Whenever lifting or moving the
unit or its components to work
on them, use suitable lifting
gear.

Make sure the unit cannot tip
over.

When lifting the unit, sling it
only on its body.

Make sure that there are nev-
er persons under suspended
loads.
Protective clothing must comprise at
least the following items:
Hard hat to EN 397
Safety shoes to EN ISO 20345
Robust leather gloves to EN 388
For more information about suitable safe-
ty clothing and protective equipment, see
the safety data sheet for the substances
being handled.
The lifting gear must have adequate load
capacity for the unit including the valve
on which it is mounted.
For more information about the weight of
the actuator, please see the documenta-
tion supplied with it. In the event of it
being supplied with a ball valve or ball
valve combination, you will find infor-
mation about the weight of the compo-
nents in the manufacturer’s documenta-
tion for the ball valve or the combination.
The lighter units can be carried by one
person alone or with the aid of an assis-
tant.
For heavier units you will need suitable
lifting gear to transport them.
You can transport the unit over dis-
tances of a few metres without pack-
aging.
Use the original packing when trans-
porting the unit over greater distances.
If the original packing is not available,
pack the unit so that it is protected
against corrosion and mechanical
damage.

Argus E25 MOD II - Operating Instructions
16
In the event of delivery with a ball
valve/combination, make sure that the
optional components contain no liq-
uids and have been rinsed clean.
Attach lifting gear with adequate load
capacity.
Secure the unit (without ball
valve/combination) using suitable
slings on the body.
Secure the unit (with ball
valve/combination) using suitable
slings on the valve body. Please read
the separate operating instructions for
the valve for how to do this.
Make sure the included angle between
the legs of slings is not more than 60°.
Contact the manufacturer if space is
so restricted where the valve is locat-
ed that this type of transport is not
possible.
Installing and connecting the
unit
ATTENTION!
The
unit may only be installed,
removed,
maintained and con-
nected
by authorised persons.
Pleas
e contact the manufacturer if
it
is not possible to comply with
these
conditions.
Contact
the manufacturer if you
need
help with the installation,
connections
or commissioning of
the
unit.
Preparing for installation
Take the unit out of its transport pack-
ing.
Check the unit for transport damage.
If you find transport damage, contact
the manufacturer.
As delivered, the connections may be
closed with plugs.
Remove the plugs before installation.
Keep the plugs and packing materials
in a safe place for subsequent use.

Argus E25 MOD II - Operating Instructions
17
DANGER
When
working on equipment and
components
carrying electric
voltage,
or on pipework, very
serious
injuries or death can be
caused
by electric shock, burns,
high
pressure in the system, or
poisoning.

Make sure there are no hot or
hazardous media in the pipe-
lines.

Make sure that all electric
power supplies to the unit and
connecting leads are voltage-
free.

Make sure the plant is
switched off and secured
against unauthorised switch-
ing back on.

Make sure the unit and pipe-
lines have cooled so that they
are no more than hand warm.

Make sure that all electrical
connecting leads have ade-
quate insulation.

Wear suitable protective cloth-
ing and, when necessary, use
suitable protective equipment.
For more information about suitable pro-
tective clothing and protective equipment,
see the safety data sheet for the medium
being handled.
Make sure that all electric connections
are voltage-free.
Empty the pipelines (when installing
the unit with ball valves / ball valve
combinations).
Make sure that pipelines are clean
and free of residual media (when in-
stalling the unit with ball valves / ball
valve combinations).
Switch the plant off and secure it
against unauthorised switching back
on.

Argus E25 MOD II - Operating Instructions
18
Installing the unit
Mount the unit on a ball valve, butterfly
valve or ball valve combination
Valves supplied by the manufacturer
have a drive coupling that fits the actua-
tor. For other valves, the connection must
comply with the requirements of
DIN EN ISO 5211, and the actuator must
be equipped with a suitable adapter.
For more information about available
and possible valves, please contact
the manufacturer.
Valves must be correctly mounted.
When you install the actuator on a valve,
ensure that the position of the ball / but-
terfly valve or similar device and the
position of the actuator agree. When the
valve is open, the notch in the actuator
drive shaft must be in the 90° or 270°
position (or 0° or 180° if mounted trans-
versely) (there are degree markings on
the cover of the actuator).
Regarding the position indicator of an
actuator for installation on a multi-way
valve or a valve combination, please
contact the manufacturer.
The connection between the actuator and
the valve should be either direct or by
means of a special actuator connection.
There must always be a drive coupling
on a valve. The mountings for an actua-
tor and an actuator coupling on a valve
are not always identical.
The number of mounting screws depends
on the actuator type. This section shows
the actuator mounted on a multi-way
valve.
The type of mounting on your unit is
shown on the drawings supplied.
Please contact the manufacturer if you
need more information about mount-
ing the actuator.

19
To mount the unit on a valve, proceed as follows:
Make sure that the actuator connection (21) is securely attached to the actuator
(1).
Tighten the nuts (24) to the correct torque.
Place the actuator (1) on the valve stem 23) or the extension (20).
Tighten the screws (22 or nuts 24) on the valve.

20
The torque to tighten the screws or nuts
depends on their size.
The tightening torques in the following
table [Nm] should be considered as a
guide, because in practice the coefficient
of friction may vary substantially. The
following data are based on
a coefficient of friction of 0.1-0.14.
Tighten the screws or nuts to the
specified torque.
Nominal Friction
Tightening torque in Newton meters for screw
strength grade
size coefficient
µ 5.6 6.9 8.8 10.9 12.9
M 3
0.1 0.5 0.8 1 1.5 1.8
0.14 0.6 1 1 1.9 2.2
M 4
0.1 1.2 1.9 2 3.3 4
0.14 1.4 2.3 3 4.1 4.9
M 5
0.1 2.3 3.6 5 7 8
0.14 2.8 4.5 6 8.5 10
M 6
0.1 3.9 6.3 8 12 14
0.14 4.8 7.7 10 14 17
M 8
0.1 9.5 15 20 28 34
0.14 12 19 25 35 41
M10
0.1 19 30 40 56 67
0.14 23 37 49 69 83
M12
0.1 33 52 69 98 115
0.14 40 65 86 120 145
