Aria Child urbini User manual

1
Read all instructions before use.
If these instructions are not followed, the safety of a child
may be severely endangered. Keep instructions for future use.
©2013 IM0004A 11/2013
www.urbinibaby.com

2
1. Registering Your Child Restraint.......................4
For Recall Information ...............................................5
Certification ...................................................................5
If You Need Assistance or Have Questions........5
2. Warnings and Important Information ....6-10
3. Child Height and Weight Limits......................11
4. Base Features.................................................... 12-13
5. Carrier Features .............................................. 14-17
6. LATCH Location.......................................................18
7. Vehicle Installation Locations..........................19
UNSAFE Vehicle Seat Belt Types.................. 20-21
SAFE Vehicle Seat Belt Types........................ 22-23
8. Base Installation
With LATCH................................................ 24-27
With Lap/Shoulder Belt ....................... 28-31
With Lap Belt ............................................ 32-35

3
1. Registering Your Child Restraint.......................4
For Recall Information ...............................................5
Certification ...................................................................5
If You Need Assistance or Have Questions........5
2. Warnings and Important Information ....6-10
3. Child Height and Weight Limits......................11
4. Base Features.................................................... 12-13
5. Carrier Features .............................................. 14-17
6. LATCH Location.......................................................18
7. Vehicle Installation Locations..........................19
UNSAFE Vehicle Seat Belt Types.................. 20-21
SAFE Vehicle Seat Belt Types........................ 22-23
8. Base Installation
With LATCH................................................ 24-27
With Lap/Shoulder Belt ....................... 28-31
With Lap Belt ............................................ 32-35
9. Child Restraint Installation WITHOUT Base
Using the Vehicle Belt
Lap Belt ................................................................ 36-37
Lap/Shoulder Belt.............................................. 38-39
Lap/Shoulder Belt (Alternate Method)...... 40-41
10. Checking the Recline..................................... 42-43
11. Adjusting the Recline.................................... 44-45
12. Placing Your Child in the Carrier............. 46-48
Changing the Buckle Strap Position.........49
Changing the Waist Strap Position .... 50-53
Using the Body Support................................54
Using the Preemie Insert...............................55
13. Securing Your Child in the Restraint..... 56-57
14. LATCH Storage ........................................................58
15. Instruction Manual Storage..............................58
16. Care and Maintenance.........................................59
17. Warranty Information and
Replacement Parts.................................................60

4
Child restraints could be recalled for safety reasons.
You must register this restraint to be reached in a
recall. Send your name, address, e-mail address if
available and the restraint’s model number and
manufacturing date to:
Aria Child Inc.
P.O. Box 1415
New York, NY 10102-2195
or call 1-888-569-7288
or register online at:
http://www.urbinibaby.com/carseatregistration
1. Registering Your Child Restraint
FOR YOUR CHILDS CONTINUED SAFETY
Please take a few moments to promptly ll out and return the
attached card or register online.
Although child restraint systems undergo testing and evaluation, it is
possible that a child restraint could be recalled.
In case of recall, we can reach you only if we have your name and
address, so please send in the card or register online to be on our
recall list.
Please ll this card out and mail it NOW, or register
online at http://www.baybini.com/productregistration
while you are thinking about it.
This card is already addressed and we/ve paid the postage.
Tear o and mail this part
Consumer: Just ll in your name and address and e-mail address (optional).
Model Number xxxxx-xxxx
Model Name Petal Infant Car Seat
Manufacture Date xxxx/xx/xx
CHILD RESTRAINT REGISTRATION CARD
Name
City State Zip Code
Mailing address
Telephone number
E-mail address
Please complete the pre-paid registration card that
is attached to your child restraint and send the
portion shown below in today.

5
Child restraints could be recalled for safety reasons.
You must register this restraint to be reached in a
recall. Send your name, address, e-mail address if
available and the restraint’s model number and
manufacturing date to:
Aria Child Inc.
P.O. Box 1415
New York, NY 10102-2195
or call 1-888-569-7288
or register online at:
http://www.urbinibaby.com/carseatregistration
Call the U.S. Government’s Vehicle Safety Hotline
at 1-888-327-4236 (TTY:1-800-424-9153), or go to
http://www.NHTSA.gov
Aria Child Inc.
530 Harrison Ave.
Boston, MA 02118
1-888-569-7288
www.urbinibaby.com
For helpful information regarding child restraints :
www.NHTSA.gov
www.saferproducts.gov
www.seatcheck.org
This child restraint conforms to all applicable Federal
motor vehicle safety standards. This Restraint is
Certified for Use in Motor Vehicles and Aircraft.
It is not intended to be used in low-speed vehicles such
as golf carts, ATV’s or any other non-certified vehicle.
Certification
For Recall Information
If You Need Assistance or Have Questions
If you have any questions regarding installation of your
seat , please contact us at:

6
DO NOT place rear-facing child seat
on front seat with air bag. DEATH
OR SERIOUS INJURY can occur.
The back seat is the safest place
for children 12 and under.
WARNING
ADVERTENCIA
• Owners of vehicles with side airbags should refer to
their owner’s manual for child restraint installation
instructions.
• ACCORDING TO ACCIDENT STATISTICS, children
are safer when properly restrained in rear vehicle
seating positions, rather than in the front seating
positions.
• REGISTER YOUR CHILD RESTRAINT with the
manufacturer.
• READ AND UNDERSTAND the instructions in this
manual and in your vehicle owner’s manual before
installing your child restraint and base.
• IMPROPER USE OF THIS CHILD RESTRAINT and
base could increase the risk of a serious injury or
death in a sudden stop or car crash.
• FOLLOW ALL INSTRUCTIONS on this child restraint
and in the written instructions located under the seat
pad.
WHEN USED IN YOUR VEHICLE
2. Warnings and Important Information

7
• USE ONLY WITH children who weigh between
4 - 35 lbs (1.8 - 15.9 kg) and whose height is 32 inches
(81cm) or less. Child’s head MUST be 1” (2.5 cm) or
more below the top of the seat.
• FOR LOW BIRTH-WEIGHT INFANT, you must always
use the preemie insert in the body support. The
preemie insert must be used for infants who weigh
less than 6 lbs (2.7 kg). Only use the body support
when the harness is used in the bottom 2 sets of
harness slots.
• SOME CHILDREN WITH SPECIAL NEEDS, such as
preemies or those who have tested positive for
positional apnea, may be at increased risk of suffering
breathing or other difficulties in a child restraint.
Please consult a physician to determine what type of
child restraint should be used for your child before
using this product.
• SNUGLY ADJUST the belts provided with this child
restraint around your child.
• NEVER LEAVE CHILD UNATTENDED in or around
the vehicle. Vehicle backovers can happen in any type
of vehicle. Vehicles have blind spots, the areas around
the vehicle that you can not see from the driving
position. Always check around the vehicle before
moving your vehicle.
• ONLY PLACE THIS CHILD RESTRAINT IN A
REARFACING DIRECTION on a forward facing
vehicle seat when using it in a vehicle. Refer to page 19.
WARNING
ADVERTENCIA

8
• NEVER place this child restraint on side-facing or
rear facing vehicle seats.
• SECURE THIS CHILD RESTRAINT with the vehicle’s
child restraint anchorage system (LATCH) if available
or with a vehicle belt, never both.
• ALWAYS TIGHTLY INSTALL THE CHILD
RESTRAINT AND BASE TO THE VEHICLE SEAT,
since in a crash an unsecured child restraint system
may injure other occupants.
• TO PREVENT EJECTION, SECURELY ATTACH the
child restraint to the base and LIFT UP TO CHECK that
it is attached.
• MAKE SURE nothing interferes with the carrier
attachment to the base.
• ALWAYS store the LATCH connectors when they are
not being used for installation.
• NEVER place two LATCH connectors on one vehicle
LATCH anchor.
• AFTER INSTALLING CARRIER WITHOUT BASE
INTO THE VEHICLE, check the RED level line
beneath the handle to make sure that it is level with
the ground.
• DO NOT allow children to play with the vehicle seat
belts. A child within reach of a seat belt may become
entangled if he or she pulls the seat belt all the way
out and wraps the belt around his or her head, neck,
or waist.
WARNING
ADVERTENCIA

9
• NEVER LEAVE child unattended.
• SUFFOCATION HAZARD: Infant carrier can roll over
on soft surfaces and suffocate child. NEVER place
carrier on beds, sofas or other soft surfaces.
• STRANGULATION HAZARD: Child can strangle in
loose restraint straps. Always use harness. NEVER
leave child in carrier when straps are loose or undone.
• Children have STRANGLED in loose or
partially buckled harness straps. Fully
restrain the child even when carrier is
used outside the vehicle.
• FALL HAZARD: Child’s movements can slide
carrier. NEVER place carrier near edges of counter
tops, tables, or other elevated surfaces. DO NOT use
on shopping carts.
• NEVER USE INFANT CARRIER OR BASE IF IT
HAS BEEN DAMAGED OR BROKEN OR ANY
COMPONENT IS MISSING. DO NOT use a cut, frayed
or damaged child restraint harness, vehicle seat belt
or LATCH belt.
•WHEN USING THIS CHILD RESTRAINT WITH A
STROLLER, ONLY USE with the Urbini Touri Travel
System. Refer to your stroller USER GUIDE for stroller
attachment instructions. NEVER use this child restraint
with other manufacturer’s strollers or with strollers for
which it was not intended.
WHEN NOT USED IN A VEHICLE
WARNING ADVERTENCIA
Children have STRANGLED in loose or partially
buckled harness straps. Fully restrain the child even
when carrier is used outside the vehicle.
Niños se han ESTRANGULADO con correas del
arnés sueltas o parcialmente trabadas. Refrene
completamente al niño, incluso cuando use el
transportador fuera del vehículo.
WARNING
ADVERTENCIA

10
• DO NOT allow children to play with the child
restraint.
• ALWAYS MAKE SURE handle is locked in the upright
carrying position before lifting. An unlocked handle
could result in serious injury to your child from falling
from the child restraint.
• ALWAYS REPLACE THE CHILD RESTRAINT AND
BASE AFTER A CRASH OF ANY KIND EVEN IF IT
WAS UNOCCUPIED. A crash can cause unseen
damage to the child restraint that may not be visible.
• DO NOT MODIFY YOUR CHILD RESTRAINT OR
BASE or use any accessories or parts not supplied by
the manufacturer of your child restraint.
•THE CHILD RESTRAINT MAY BECOME VERY HOT
IF LEFT IN THE SUN OR HOT AREAS. Always make
sure to check the temperature of any metal or plastic
parts before placing your child in the child restraint.
• NEVER allow someone else to use this infant restraint
and base without also passing along this manual to
them.
•NEVER use a second-hand child restraint or base
or a child restraint or base that you do not know its
history.
• DISCONTINUE USE of this child restraint after 6
years from the manufacture date. The manufacture
date can be found on the underside of your child
restraint.
IMPORTANT INFORMATION

11
Your child MUST meet the height and weight
requirements listed:
4 - 35 lbs. (1.8 kg-15.9 kg)
32 inches (81 cm) or less in height.
CHILD’S HEAD MUST be 1” (2.5 cm) or
more below the top of the seat as shown below:
1" (2.5 cm)
WEIGHT:
HEIGHT:
3. Child Height and Weight Limits
The American Academy of Pediatrics recommends
children should ride rear-facing for as long as possible
up to 2 years in age, or until they reach maximum
height and weight for their seat. Do not use this child
restraint beyond the expiration date or if the child
exceeds the limits of this seat.

12
4. Base Features
123
4
7
89
13
6
12
11
8
10
5

13
Release Handle
Level Indicator
Belt Lock-Off
LATCH Anchor Strap Guides
LATCH Anchor Strap
LATCH Storage Compartment
Belt Path
BASE
Carrier to Base Indicators
LATCH Adjustment Strap
LATCH Release Button
LATCH Belt Connector
Recline Foot
1
2
3
4
5
6
7
8
9
8
10
11
12
13

14
5. Carrier Features
8
1
2
3
4
5
6
7
8
9
8
10
11
12
8
15
16
17
18
19
8
20
21
8
22
23
8
24
13
14
WA0009
WARNING
Toprevent suffocation, always
placepreemie insert into the
pocketlocated on the back of the
bodysupport exactly as shown.
ADVERTENCIA
THIS TEXT
FACESUP ESTA CARA
HACIA ARRIBA
12
Paraprevenir la asxia, ponga siempre
elaccesorio para bebés prematuros en
elbolsillo de atrás del soporte
exactamentecomo se indica.
THISTEXT
FACESUP
THISTEXT
FACESUP
THISTEXT
FACESUP
Installingthe
PreemieInsert
Instalación
delaccessorio para
bebésprematuros
3
Using the Preemie Insert
To preventejec tion or serious injury:
• For low birth-weight infant, you must always use the
preemie insert in the body support.
The preemie insert must be used for infants who weigh
less than 6 lbs (2.7 kg).
into the pocket located on the back of the body
support exactly as shown.
WARNING
ADVERTENCIA
12
THISTEXT
FACESUP
THISTEXT
FACESUP
THISTEXT
FACESUP
3
The preemie insert is designed to only be inserted into
pocket one way. Thewords “ THIS TEXT MUST FACE UP”
on the label must be visible when inserting it into the
pocket.

15
8
Handle
Canopy
Seat Pad
Stroller Release
Button
Lap Belt Guide
Harness Cover
Chest Clip
Body Support
Buckle
Buckle Strap Cover
Harness
Adjustment
Strap
Harness
Adjustment
Button (under
seat pad)
Buckle Tongue
Preemie Insert
(in plastic bag with
instruction sheet)
Shoulder Belt Guide
Harness Slots
Base Attachment Rods
Harness Strap
Splitter Plate
Waist Strap
Harness Adjustment Strap
Buckle Retainer
Waist Strap Slots
Handle Adjustment Button
1
2
3
4
5
6
7
8
9
8
10
11
12
13
14
8
15
16
17
18
19
8
20
21
22
23
24

16
There are 4 positions:
- Carrying position (A),
- Middle positions (B - C),
- Stationary position (D).
To adjust, squeeze handle
release buttons on both
sides, then rotate the handle.
The handle will lock into
position.
You should hear a click when
the handle button is engaged
and handle is locked into
position. Always check to
make sure handle is locked
into place after adjusting.
ALWAYS make sure the handle is securely locked in
the upright carrying position (A) before carrying.
ANY locked position can be used in vehicle.
WARNING
ADVERTENCIA
Handle
CLICK!

17
To attach canopy, insert
the canopy bow into the
canopy mounts on both
sides of the seat until the
button clicks into place.
Fasten snap to canopy
mount as shown.
To remove, press tab as
shown, canopy can be
removed for washing.
Canopy
CLICK!
SNAP!

18
LATCH stands for Lower Anchors and Tethers
for Children.
It makes installation easier without using the
vehicle’s seat belts. LATCH is a way to secure your
child restraint to your vehicle by using the LATCH
connectors on your child restraint base. These
connectors attach to the lower anchor points in
certain vehicle seating positions.
The child restraint base is designed to be used at the
standard spacing of 11” from the center of one anchor
point to the center of another anchor point. Please
refer to your vehicle owner’s manual for information
about using LATCH in certain seating positions.
LATCH may be used
for spacing larger
than 11” ONLY if your
vehicle manufacturer
allows it.
If your vehicle does
not have lower
anchor points you can
still install your child
restraint with the
vehicle’s belt system.
11” 11”
6. LATCH Location

19
Failure to place the child restraint in the correct
seating positions increases the risk of serious
injury or death. DO NOT place rear-facing child seat
on front seat with air bag. DEATH OR SERIOUS INJURY
can occur. The back seat is the safest place for children
12 and under. Owners of vehicles with airbags should
refer to their owner’s manual for child restraint
installation instructions.
The VEHICLE seat
must face forward.
NEVER place the child restraint on any vehicle seat that
does not lock.
Folding seats can fall forward and could cause serious
injury to your child in a vehicle crash.
WARNING
ADVERTENCIA
7. Vehicle Installation Locations

20
Motorized Shoulder Belt with
Lap Belt
Motorized belts will not keep
a child restraint in its seating
position in a sudden stop or
crash.
Lap or Shoulder Belt
Mounted on Vehicle Door
These belts are mounted to a
door and will not keep a child
restraint in its seating position
in a sudden stop or crash.
If you have any of these types of vehicle belt systems
listed, NEVER use any of these to install your child
restraint in the vehicle. These vehicle belt systems are
UNSAFE to use to install your child restraint in the
vehicle.
If available, LATCH can be used IN PLACE OF these
vehicle belt types. Refer to your vehicle owner’s manual
for LATCH locations.
UNSAFE Vehicle Seat Belt Types
