Aria Aria-24 Owner's manual

Aria-24/130c/130 /300 /600ipe
Digital Key Telephone System
Programming
Manual
LG Electronics, Inc.
Aria Communications
Quadrant Business Park
Unit 3 / 15 Pickering Road
Mulgrave
VIC 3170
ABN : 22 090 723 925

II
Aria-24/130c/130/300/600ipe
DIGITAL KEY TELEPHONE SYSTEM
CONFIDENTIALITY
The information contained in this manual is the property of Aria
Communications Pty. Limited.
The contents of this manual must not be copied, distributed or
made available to any third party without the prior written
consent of Aria Communications Pty. Limited.
Every effort has been made to ensure that this manual
documents the operation of the Aria-24/130c/130/300/600ipe
Digital Key Telephone System.
However, due to the on-going improvement and update of
software, Aria Communications cannot guarantee the
accuracy of printed material after the date of publication, nor
can Aria Communications accept responsibility for errors or
omissions.
Revised manuals will be published as needed.
This manual supersedes all previous issues.

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
III
CONTENTS
1CUSTOMER DATABASE PROGRAMMING .......................................................8
1.1 INTRODUCTION.........................................................................................................................8
1.2 TO ENTER THE PROGRAMMING MODE ................................................................................. 9
1.3 PERMANENT UPDATE PROCEDURE ......................................................................................9
1.4 NUMBERING PLAN ..................................................................................................................10
1.5 ADMIN PROGRAMMING INDEX..............................................................................................16
1.6 DEFAULT VALUES...................................................................................................................19
TABLE 1.6.1 LOCATION PROGRAM ...........................................................................................19
TABLE 1.6.2 RACK SLOT ASSIGNMENT....................................................................................19
TABLE 1.6.3 WTIB PORT NUMBER ASSIGNMENT....................................................................19
TABLE 1.6.4 LOGICAL SLOT ASSIGNMENT ..............................................................................20
TABLE 1.6.5 NUMBERING PLAN TYPE ......................................................................................20
TABLE 1.6.6 FLEXIBLE NUMBERING PLAN............................................................................... 21
TABLE 1.6.7 IP SETTING .............................................................................................................23
TABLE 1.6.8 EXPANDED FLEXIBLE NUMBERING PLAN..........................................................23
TABLE 1.6.9 STATION ID ASSIGNMENT .................................................................................... 23
TABLE 1.6.10 STATION ATTRIBUTE I/II/III ...............................................................................24
TABLE 1.6.11 ISDN STATION ATTRIBUTE...............................................................................25
TABLE 1.6.12 FLEXIBLE BUTTON ASSIGNMENT ...................................................................26
TABLE 1.6.13 STATION BASE PROGRAM...............................................................................26
TABLE 1.6.14 TABLE COPY DSS BUTTON..............................................................................27
TABLE 1.6.15 DISPLAY STATION NUMBER BY COS..............................................................27
TABLE 1.6.16 DISPLAY STATION NUMBER BY CO ACCESSS..............................................27
TABLE 1.6.17 CO LINE BASE PROGRAM ................................................................................28
TABLE 1.6.18 CO MSN Mapping Table......................................................................................31
TABLE 1.6.19 ISDN CO BASE PROGRAM................................................................................32
TABLE 1.6.20 SYSTEM TIMER PROGRAM ..............................................................................36
TABLE 1.6.21 DCOB ATTRIBUTE..............................................................................................38
TABLE 1.6.22 STATION GROUP ASSIGNMENT ......................................................................38
TABLE 1.6.23 STATION GROUP PROGRAM ...........................................................................38
TABLE 1.6.24 ISDN ATTRIBUTES............................................................................................. 40
TABLE 1.6.25 LCR TABLE ASSIGNMENT................................................................................. 42
TABLE 1.6.26 TOLL TABLE ASSIGNMENT...............................................................................43
TABLE 1.6.27 OTHER TABLES..................................................................................................43
TABLE 1.6.28 NETWORKING ATTRIBUTE............................................................................... 45
TABLE 1.6.29 VOIB NET ATTRUBUTE...................................................................................... 45
TABLE 1.6.30 NATION SPECIFIC..............................................................................................49
TABLE 1.6.31 INITIALIZATION...................................................................................................54
TABLE 1.6.32 PRINT PROT DATABASE...................................................................................55
2PRE-PROGRAMMED DATABASE....................................................................56
2.1 LOCATION PROGRAM (PGM 100).........................................................................................57
2.2 RACK SLOT ASSIGNMENT (PGM 101)..................................................................................58
2.3 WTIB PORT NUMBER ASSIGNMENT (PGM 102) .................................................................59
2.4 LOGICAL SLOT ASSIGNMENT (PGM 103)............................................................................59

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
IV
2.5 NUMBERING PLAN TYPE (PGM 104)....................................................................................60
2.6 FLEXIBLE NUMBERING PLAN (PGM 105).............................................................................61
2.7 FLEXIBLE NUMBERING PLAN (PGM 106-107) ..................................................................... 62
2.8 IP SETTING (PGM 108)...........................................................................................................65
2.9 EXPANDED FLEXIBLE NUMBERING PLAN (PGM 109)........................................................66
2.10 HOTDESK AGENT ATTRIBUTE (PGM 250)............................................................................67
3STATION PROGRAMMING...............................................................................68
3.1 STATION ID (PGM 110)...........................................................................................................68
3.2 STATION ATTRIBUTE –I (PGM 111) .....................................................................................71
3.3 STATION ATTRIBUTE - II (PGM 112).....................................................................................72
3.4 STATION ATTRIBUTE - III (PGM 113)....................................................................................75
3.5 ISDN STATION ATTRIBUTE (PGM 114).................................................................................77
3.6 FLEX BUTTON ASSIGNMENT (PGM 115) ............................................................................. 79
3.7 STATION COS (PGM 116).......................................................................................................81
3.8 CO LINE GROUP ACCESS (PGM 117)...................................................................................83
3.9 INTERNAL PAGE ZONE (PGM 118).......................................................................................84
3.10 CONFERENCE PAGE ZONE (PGM 119)................................................................................85
3.11 ICM TENANCY GROUP (PGM 120)........................................................................................86
3.12 PRESET CALL FORWARD (PGM 121)................................................................................... 87
3.13 HOT LINE / WARM LINE (PGM 122).......................................................................................88
3.14 CTI STATION ATTRIBUTE (PGM 123)....................................................................................89
3.15 SMDR ACCOUNT GROUP (PGM 124) ................................................................................... 90
3.16 COPY DSS BUTTON (PGM 125).............................................................................................91
3.17 DISPLAY STATION NUMBER BY COS (PGM 130).................................................................91
3.18 DISPLAY STATION NUMBER BY CO ACCESS GROUP (PGM 131).....................................92
4CO LINE PROGRAMMING................................................................................93
4.1 CO SERVICE TYPE (PGM 140) ..............................................................................................93
4.2 CO LINE ATTRIBUTE –I (PGM 141).......................................................................................96
4.3 CO LINE ATTRIBUTE –II (PGM 142)......................................................................................98
4.4 ISDN CO LINE ATTRIBUTE I (PGM 143)..............................................................................100
4.5 CO RING ASSIGNMENT (PGM 144)..................................................................................... 102
4.6 CO RING ASSIGNMENT DISPLAY (PGM 145) .....................................................................103
4.7 ISDN CO LINE ATTRIBUTE II (PGM 146)..............................................................................104
4.8 CO MSN MAPPING TABLE (PGM 147)..................................................................................105
5SLOT PROGRAMMING...................................................................................106
5.1 BOARD ATTRIBUTE (PGM 155) ............................................................................................106
6SYSTEM DATA PROGRAMMING...................................................................107
6.1 SYSTEM ATTRIBUTE - I (PGM 160).....................................................................................107
6.2 SYSTEM ATTRIBUTE - II (PGM 161)....................................................................................110
6.3 ADMIN PASSWORD (PGM 162) ...........................................................................................112
6.4 ALARM ATTRIBUTES (PGM 163).........................................................................................112
6.5 ATTENDANT ASSIGNMENT (PGM 164)...............................................................................113

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
V
6.6 AUTO ATTENDANT VMIB ANNC ASSIGNMENT (PGM 165) ..............................................114
6.7 CO-TO-CO COS (PGM 166)..................................................................................................115
6.8 DID/DISA DESTINATION (PGM 167)....................................................................................116
6.9 EXTERNAL CONTROL CONTACT (PGM 168).....................................................................118
6.10 LCD TIME/DATE/LANGUAGE DISPLAY MODE (PGM 169) ................................................120
6.11 MODEM (PGM 170) ...............................................................................................................121
6.12 MUSIC (PGM 171)..................................................................................................................122
6.13 PBX ACCESS CODE (PGM 172)...........................................................................................124
6.14 PLA PRIORITY SETTING (PGM 173).................................................................................... 124
6.15 RS-232C PORT SETTING (PGM 174)...................................................................................125
6.16 PRINT PORT SELECTION (PGM 175).................................................................................. 126
6.17 PULSE DIAL RATIO (PGM 176)............................................................................................127
6.18 SMDR ATTRIBUTES (PGM 177)...........................................................................................128
6.19 SYSTEM TIME/DATE SETTING (PGM 178) ......................................................................... 131
6.20 LINKED STATION PAIRS TABLE (PGM 179).......................................................................132
6.21 CIDU SETTINGS (PGM 185) .................................................................................................. 133
7SYSTEM TIMERS ............................................................................................134
7.1 SYSTEM TIMERS - I (PGM 180) ...........................................................................................134
7.2 SYSTEM TIMERS - II (PGM 181) ..........................................................................................136
7.3 SYSTEM TIMERS - III (PGM 182) .........................................................................................138
7.4 CIDU SETTING (PGM 185).................................................................................................... 139
8DCOB ATTRIBUTE (PGM 186 - PGM 187)....................................................140
9STATION GROUP PROGRAMMING (PGM 190 - PGM 191)..........................141
9.1 STATION GROUP ASSIGN (PGM 190)................................................................................. 141
9.2 STATION GROUP ATTRIBUTE (PGM 191)..........................................................................143
10 ISDN PROGRAM .............................................................................................152
10.1 ISDN ATTRIBUTE (PGM 200) ............................................................................................... 152
10.2 COLP TABLE (PGM 201)....................................................................................................... 154
10.3 MSN TABLE (PGM 202).........................................................................................................155
10.4 ISDN ATTRIBUTES II (PGM 203) ARIA-24 ONLY .................................................................156
11 LCR..................................................................................................................157
11.1 LCR ATTRIBUTES (PGM 220) .............................................................................................. 157
11.2 LEADING DIGIT TABLE (PGM 221)......................................................................................159
11.3 DIGIT MODIFICATION TABLE (PGM 222)............................................................................161
11.4 LCR TABLE INITIALIZATION (PGM 223)..............................................................................163
12 TOLL TABLE ...................................................................................................165
12.1 TOLL EXCEPTION TABLE (PGM 224).................................................................................. 165
12.2 CANNED TOLL TABLE (PGM 225) .......................................................................................167
12.3 EMERGENCY CODE TABLE (PGM 226)..............................................................................168
13 TABLES ...........................................................................................................169

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
VI
13.1 AUTHORIZATION CODE TABLE (PGM 227)........................................................................169
13.2 CUSTOM CALL ROUTING (PGM 228)..................................................................................170
13.3 EXECUTIVE / SECRETARY TABLE (PGM 229)...................................................................172
13.4 FLEXIBLE DID TABLE (PGM 231).........................................................................................173
13.5 SYSTEM SPEED ZONE (PGM 232)......................................................................................175
13.6 WEEKLY TIME TABLE (PGM 233)........................................................................................176
13.7 VOICE MAIL DIALING TABLE (PGM 234) ............................................................................ 177
13.8 TIE ROUTING TABLE (PGM 235) .........................................................................................178
13.9 MOBILE EXTENSION TABLE (PGM 236).............................................................................179
14 NETWORKING ATTRIBUTE ...........................................................................180
14.1 NETWORKING BASIC ATTRIBUTE (PGM 320) ...................................................................180
14.2 NETWORKING SUPPLEMENTARY ATTRIBUTE (PGM 321).............................................. 181
14.3 NETWORKING CO LINE ATTRIBUTE (PGM 322)................................................................182
14.4 NETWORKING ATTENDANT ASSIGNMENT (PGM 323)......................................................183
14.5 NETWORKING ROUTING TABLE (PGM 324).......................................................................184
15 VOIB ATTRIBUTE............................................................................................185
15.1 VOIP IP SETTING (PGM 340) ...............................................................................................185
16 RSG/IP PHONE PROGRAMMING...................................................................186
16.1 VOIB SLOT ASSIGNMENT FOR RSG/IP PHONE (PGM 380) .............................................. 186
16.2 RSG/IP PHONE PORT NUMBER ASSIGNMENT (PGM 381) ...............................................187
16.3 RSG / IP PHONE ATTRIBUTE (PGM 382)............................................................................188
16.4 RSG ATTRIBUTE 1 (PGM 383) ............................................................................................. 189
16.5 RSG ATTRIBUTE 2 (PGM 384) ............................................................................................. 190
16.6 RSG ALARM ASSIGNMENT (PGM 385)...............................................................................192
16.7 RSG ATTRIBUTE 1 (PGM 386) ............................................................................................. 193
16.8 RSG DKT RX GAIN CONTROL (PGM 390) .......................................................................... 194
16.9 RSG DKT TX GAIN CONTROL (PGM 391)........................................................................... 195
16.10 RSG SLT RX GAIN CONTROL (PGM 392)...........................................................................196
16.11 RSG SLT TX GAIN CONTROL (PGM 393)............................................................................197
16.12 RSG LCO RX GAIN CONTROL (PGM 394) .......................................................................... 198
16.13 RSG LCO TX GAIN CONTROL (PGM 395)...........................................................................199
16.14 RSG IP PHONE RX GAIN CONTROL (PGM 396) ................................................................200
16.15 RSG IP PHONE TX GAIN CONTROL (PGM 397).................................................................201
17 NATION SPECIFIC PROGRAMMING .............................................................202
17.1 DTIB RX GAIN CONTROL (PGM 400) .................................................................................. 202
17.2 SLIB RX GAIN CONTROL (PGM 401)...................................................................................203
17.3 CTR SLIB RX GAIN CONTROL (PGM 402) ..........................................................................204
17.4 WTIB RX GAIN CONTROL (PGM 403).................................................................................. 205
17.5 ACOB RX GAIN CONTROL (PGM 404) ................................................................................206
17.6 CTR ACOB RX GAIN CONTROL (PGM 405)........................................................................ 207
17.7 DCOB RX GAIN CONTROL (PGM 406)................................................................................208
17.8 VMIB RX GAIN CONTROL (PGM 407)..................................................................................209

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
VII
17.9 DTMF RCVR RX GAIN CONTROL (PGM 408) ..................................................................... 210
17.10 EXT PAGE RX GAIN CONTROL (PGM 409) ........................................................................211
17.11 CPT RX GAIN CONTROL (PGM 410) ...................................................................................212
17.12 MODEM RX GAIN CONTROL (PGM 411).............................................................................213
17.13 SYSTEM TONE FREQUENCY (PGM 420) ...........................................................................214
17.14 DIFFERENTIAL RING FREQUENCY (PGM 421).................................................................. 215
17.15 DISTINCT RING FREQUENCY (PGM 422)...........................................................................216
17.16 ACNR TONE CADENCE (PGM 423) .....................................................................................217
18 INITIALIZATION (PGM 450) ...........................................................................218
19 PRINT PROT DATABASE (PGM 451)............................................................219
20 INITIALIZE BY MPB VERSION (PGM 452).....................................................220

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
8
1CUSTOMER DATABASE PROGRAMMING
1.1 INTRODUCTION
The ARIA Key Telephone System can be programmed to meet each customer's individual need. All
programming is done at station 100 (station port # 00) using KD-36D, LKD-30DS, LDP-7024D and
LDP-7024 LD digital key telephone. (You cannot program with the KD Large Display ) Additional
programming stations may be assigned (PGM 113-BTN 1), but only 1 keyset can be active in
programming mode at any one time.
Upon entering the program mode, the key telephone at station 100 cannot operate as a normal
telephone but as a programming instrument with all of the buttons redefined. The keys of the dial pad
are used to enter the various data fields and to enter numerical information. The 24 buttons located at
the top of the phone (Flexible Buttons) are used to indicate the specific data field and to enter
information. Sometimes the [SPEED] button and „*‟ of the dial pad is used to delete the data or to
indicate end of data input and the [REDIAL] button is used to delete one digit or character from the
end of entered digits or characters.
See TABLE 1.6.1 - 1.6.27 for default data. If this pre-programming suits the customer, additional
admin program is not necessary. To change admin data, the user enters the admin programming
mode and select program code. During admin programming, other keysets operate normally. (While
activating ARIA Admin, no keyset can enter Admin mode and the reverse also.)
When Admin programming, LCD and LEDs indicate the current programmed data and status. If the
programmer enters correct data, then LCD and LEDs show the entered data and the data is stored in
the temporary buffer area. Real system database is not changed and has no effect on telephone
operation unless permanent updating procedure is executed. Pressing the [HOLD/SAVE] button, all
data in the temporary buffer (same as LCD and LEDs show their status) is saved into permanent
memory. Tones are provided to let the programmer know data entry is correct (confirmation tone) or
not (error tone).
To return the parent state while admin programming, press the [CONF] button. Pressing the [CONF]
button, temporary data fields are cleared.
To reset the system, enter PGM 450 –BTN 15 and press [HOLD/SAVE] button. Or, the system will be
reset automatically after programming PGM100 –BTN 1 (Nation Code Assign)

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
9
1.2 TO ENTER THE PROGRAMMING MODE
1. Lift handset or press the [MON] button on the admin station, and hear ICM dial tone (optional).
2. Press the [TRANS/PGM] button and dial ＊#(Confirmation tone is heard).
3. Enter admin password if the password has been set. This places the station into the admin
programming mode (Confirmation tone is heard).
4. Each program is accessed by pressing the [TRANS/PGM] button and dialing the three-digit
program number. If an error is made while entering data, the [TRANS/PGM] button can go the
previous status. When the [TRANS/PGM] button is pressed, the LCD will display;
ENTER PROGRAM CODE
1.3 PERMANENT UPDATE PROCEDURE
When the data has been entered, the [HOLD/SAVE] button is used to store the data permanently. If
all data was entered correctly, confirmation tone is heard when pressing the [HOLD/SAVE] button. If
there were any errors in the entry, then an error tone is presented and data is not stored in the
permanent memory.

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
10
1.4 NUMBERING PLAN
The following numbering plan can be changed by Admin Programming 104-107 depending on the
user's needs.
NUMBER
ITEM
REMARK
Aria-24
Aria-
130/130c
Aria-300
Aria-600
10-37
100-227
100 –399
1000-1599
Intercom Call
620-629
620-634
620 –667
620-667
Group Pilot Number
#01 –#10
#01 –#15
#01 –#35
#01-#35
Internal Page Zone
#5
#5
#5
# 5
Internal All Call Page
##
##
##
# #
Meet Me Page
#6
#6
#6
# 6
External Page Zone 1
N/A
#7
#7
# 7
External Page Zone 2
N/A
#8
#8
# 8
External Page Zone 3
N/A
#9
#9
# 9
External All Call Page
#00
#00
#00
# 00
All Call Page (Int & Ext)
550
550
550
550
SMDR Account Code Enter
SLT
551
551
551
551
Flash Command to CO Line
SLT
552
552
552
552
Last Number Redial
SLT
553
553
553
553
DND (Toggle On/Off)
SLT
554
554
554
554
Call Forward
SLT
555
555
555
555
Speed Dial Programming
SLT
556
556
556
556
Message Wait/Callback
Enable
SLT
557
557
557
557
Message Wait/Callback
Return
SLT
558
558
558
558
Speed Dial Access
SLT
559
559
559
559
Cancel DND/FWD/Pre-MSG
SLT
560
560
560
560
System Hold
SLT
N/A
561
561
561
Station Relocation Backup
N/A
562
562
562
Station Relocation Retrieve
563
563
563
563
Programming Mode Enter
Code
SLT
564
564
564
564
ACD Reroute
565
565
565
565
Alarm Reset
**
**
**
**
Group Call Pickup
568
568
568
568
UCD DND
577
577
577
577
Night Answer
601-608
601-610
601 - 619
601-619
Call Parking Locations
*7
*7
*7
*7
Direct Call Pickup
801-808
801-824
801-872
801-872
CO Group Access
8801-8840
8801-8840
88001-
88200
8801-88400
Individual CO Access
8901
8901
8901
8901
Tie Routing Access

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
11
NUMBER
ITEM
REMARKS
Aria-24
Aria-
130c/130
Aria-300
Aria-600
8*
8*
8*
8*
Retrieve Held CO Line
8#xx
8#xx
8#xxx
8#xxx
Retrieve Held Individual CO
Line
9
9
9
9
Access CO Line In the 1st
available CO Group
0
0
0
0
Attendant Call
#*1
#*1
#*1
#*1
1st Door Open
#*2
#*2
#*2
#*2
2nd Door Open
N/A
#*3
#*3
#*3
3rd Door Open
N/A
#*4
#*4
#*4
4th Door Open
N/A
#*5
#*5
#*5
5th Door Open
N/A
#*6
#*6
#*6
6th Door Open
N/A
N/A
#*7
#*7
7th Door Open
N/A in ARIA-
130
*8
*8
*8
*8
VM Message Waiting Enable
*9
*9
*9
*9
VM Message Waiting Disable
NUMBER
ITEM
REMARKS
Aria-24
Aria-
130c/130
Aria-300
Aria-600
*0
*0
*0
*0
MCID Request
*1
*1
*1
*1
RSG Door Open 1
*2
*2
*2
*2
RSG Door Open 2
*57
*57
*57
*57
Enter Conference Room
*58
*58
*58
*58
SLT Conference Page Join
*##
*##
*##
*##
Unsupervised Conf Tmr Extend

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
12
To enter user programming mode, press the [TRANS/PGM] button
in a keyset or dial 5 6 3 (Programming enter code) in a SLT.
The following numbering plan is fixed, so it cannot be changed by Admin Programming.
1) For the stations
NUMBER
ITEM
REMARK
11
Differential Ring
Keyset
12
Intercom Answer Mode (1 HF / 2 TONE / 3 PV)
Keyset
13
SMS Message Display
14
Enblock Mode
15
SMS/Notice Display
16
Scroll Speed
17
Ear-Mic Headset
18
Intercom Bell
19
CO Bell
21
Station COS Down
22
Station COS Restore
23
Walking COS
Keyset
24
COS CHANGE
31
Authorization Code Registration
32
Authorization Code Change
33
Register Mobile Extension
34
Activate Mobile Extension
41
Wake-up Time Registration (One-time/ Continuous)
42
Wake-up Time Cancel
43
Activate Conference Room
44
Deactivate Conference Room
51
Pre-selected MSG Activation
52
Set Custom Message
61
Record VMIB User Greeting
62
Listen VMIB Time & Date
63
Listen VMIB Station Number
64
Listen VMIB Station Status
65
Record VMIB Page Message
66
Erase VMIB User Greeting
67
Erase VMIB Page Message
71
LCD Display Mode (English/Domestic Language)
Keyset
72
MPB Version Display
Keyset
73
Background Music
Keyset
74
Station User Name Registration
75
Headset/Speakerphone Mode
Keyset
76
Headset Ring Mode
Keyset
77
WTU Station Number Receive
Keyset
78
Serial No/SW Packages
Keyset with LCD
79
PC-Phone Lock Key
**
Hot Desk Logout

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
13
*0
Hot Desk Login
*1
Station Relocation Out
*2
Station Relocation In
*3
Register Bluetooth
*4
Bluetooth Usage
2) For the attendant
NUMBER
ITEM
REMARK
0111
Print SMDR (Station Base)
System Attendant
0112
Delete SMDR (Station Base)
System Attendant
0113
Print SMDR (Group Base)
System Attendant
0114
Delete SMDR (Group Base)
System Attendant
0115
Display Call Charge
System Attendant
0116
Abort Printing
System Attendant
0117
Print Lost Call
System Attendant
0118
Delete Lost Call
System Attendant
0121
Print All Summary
System Attendant
0122
Print All Periodically
System Attendant
0123
Abort Periodic Printing
System Attendant
0124
Print ATD Traffic
System Attendant
0125
Print Call Summary
System Attendant
0126
Print All Hourly
System Attendant
0127
Print H/W Usage
System Attendant
0128
Print CO Summary
System Attendant
0129
Print CO Hourly
System Attendant
021
Station COS Down (COS 7)
Attendant
022
Station COS Restore
Attendant
031
Authorization Code Cancel
System Attendant
041
System Date/Time Setting
Attendant
042
Wake-up Time Registration (One-time /Continuous)
Attendant
043
Wake-up Time Cancel
System Attendant
044
LCD Date Mode Change
System Attendant
045
LCD Time Mode Change
System Attendant
046
Use Network Time & Date
System Attendant
047
Monitor Conference Room
Attendant
051
Pre-select MSG Activation
Attendant
052
Pre-select MSG Deactivation
Attendant
053
Custom Display Message Program (11-20)
System Attendant
054
Erase VM MSG
Attendant
055
ATD DEL ALL CLI MSG
06
Record VMIB System Greeting
System Attendant
071
DND/Call Forward/Pre-selected MSG Cancel
Attendant
072
Register Station Name
Attendant
073
Disable CO Outgoing
System Attendant
074
Automatic Day/Night/Weekend Mode Program
Attendant
075
ICM BOX BGM Channel select
Attendant
076
External Page Music -1 Assignment/Cancel
Attendant
077
External Page Music -2 Assignment/Cancel
Attendant
078
External Page Music -3 Assignment/Cancel
Attendant

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
14
079
Prepaid Call
07*
LCD Display Language
0#
WHTU Subscription
0*
Board Service Switch –Enter slot number
Attendant
3) Flexible Button Programming Code
NUMBER
ITEM
REMARK
11
Differential Ring
18
ICM RING
19
CO RING
21
Station COS Down
22
Station COS Restore
23
Walking COS
24
COS CHANGE
31
Authorization Code Registration
32
Authorization Code Change
41
Wake-up Time Registration (One-time /Continuous)
42
Wake-up Time Cancel
43
CONF –ROOM ACTIVE
44
CONF –ROOM DEACTIVE
51
Pre-selected MSG Activation
52
Set Custom Message
53
CLIR Key
54
Two Way Recording
55
Attendant DND
Networking Only
56
Attendant CampOn(Queue) BTN Assignment
Attendant
57
Call Log Button
61
Record VMIB User Greeting
62
PLAY DATE TIME
63
PLAY STA NUMBER
64
Listen VMIB Station Status
65
RECORD PAGING MESSAGE
66
Erase VMIB User Greeting
67
DELETE PAGING MESSAGE
68
ANSWER MACHINE - RING
69
ANSWER MACHINE - SPEAKER
71
LCD Display Mode (English/Domestic Language)
73
Background Music
74
Station User Name Registration
75
Headset/Speakerphone Mode
76
HeadSet Ring Mode
80
Account Code Activation
81
DID Call Wait
83
[ICM Hold] BTN Assignment
84
[LOOP] BTN Assignment

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
15
84#
MSN Button
85
[Camp-on] BTN Assignment
86
[INTRUSION] BTN Assignment
System Attendant
87
[UCD DND] BTN Assignment
+ Hunt Grp No.
89
Keypad Facility Key
8*
{ACD STATUS} BTN Assignment
8#
PAGER CALL
91
[CONF] BTN Assignment
2/8 BTN Keyset
92
[CALLBK] BTN Assignment
2/8 BTN Keyset
93
[DND/FWD] BTN Assignment
2/8 BTN Keyset
94
[FLASH] BTN Assignment
2/8 BTN Keyset
95
[MUTE] BTN Assignment
2/8 BTN Keyset
96
[MON] BTN Assignment
2/8 BTN Keyset
97
[REDIAL] BTN Assignment
2/8 BTN Keyset
98
DID RESTRICTION
99
DISA RESTRICTION
9*
CALL RECORD
**
AGENT LOGOUT
*0
AGENT LOGIN
*3
Blue Tooth REGISTER
*4
Blue Tooth USAGE

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
16
1.5 ADMIN PROGRAMMING INDEX
MAIN MENU
PGM
ITEM
PRE-PROGRAMMED DATABASE
100
Location Program
101
Rack Slot Assignment
102
WTIB Port number Assignment
103
Logical Slot Assignment
104
Numbering Plan Type
105
Flexible Number Plan –Station Number
106
Flexible Number Plan A
107
Flexible Number Plan B
108
IP Setting
109
Expanded Flexible Numbering Plan
250
Hot Desk Attributes
STATION BASE PROGRAM
110
Station ID
111
Station Attribute I
112
Station Attribute II
113
Station Attribute III
114
ISDN Station Attribute
115
Flex Button Assignment
116
Station COS
117
CO Line Group Access
118
Internal Page Zone
119
Conference Page Zone
120
ICM Tenancy Group
121
Preset Call Forward
122
Hot/Warm Line Selection
123
CTI Station Attribute
124
SMDR Account Group
125
Copy DSS button
130
Display station number by COS
131
Display Station Number by CO access group
CO LINE BASE PROGRAM
140
CO Service Type
141
CO Line Attribute I
142
CO Line Attribute II
143
ISDN CO Line Attribute I
144
CO Ring Assignment
145
CO Ring Assignment Display
146
ISDN CO Line Attribute II
147
CO MSN Mapping
SLOT BASE PROGRAM
155
Slot Attribute
SYSTEM BASE PROGRAM
160
System Attribute –I
161
System Attribute –II
162
Admin Password
163
Alarm Attributes
164
Attendant Assignment
165
Auto Attendant VMIB Annc. Assignment
166
CO-to-CO COS
167
DID/DISA Destination
168
External Control Contact

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
17
169
LCD Date/Time/Language Display Mode
170
Modem
171
Music
172
PBX Access Code
173
PLA Priority Setting
174
RS-232C Port Setting
175
Print Port Selection
176
Pulse Dial Ratio
MAIN MENU
PGM
ITEM
SYSTEM BASE PROGRAM
177
SMDR Attributes
178
System Date/Time Setting
179
Linked Station Pairs Table
180
System Timers –I
181
System Timers –II
182
System Timers –III
DCOB
186
DCOB System attribute
187
DCOB CO Line Attribute
STATION GROUP
190
Station Group Assign
191
Station Group Attribute
ISDN SYSTEM BASE PROGRAM
200
System ISDN Attributes
201
COLP Table
202
MSN Table
203
ISDN Attributes II (Aria-24 ONLY)
TABLES
220
LCR Attributes
221
LCR –Leading Digit Table
222
LCR –Digit Modification Table
223
LCR Table Initialization
224
Toll Exception Table –Allow A (Entry no:01-30)
Toll Exception Table –Deny A (Entry no:01-30)
Toll Exception Table –Allow B (Entry no:01-30)
Toll Exception Table –Deny B (Entry no:01-30)
225
Canned Toll Table –Allow (Entry no:01-10)
Canned Toll Table –Deny (Entry no:01-10)
226
Emergency Code Table
227
Authorization Code Table
228
Customer Call Routing
229
Executive/Secretary Table
231
Flexible DID Table
232
System Speed Zone
233
Weekly Time Table
234
Voice Mail Dialing Table
235
Tie Routing Table
236
Mobile Extension
NETWORKING
320
Networking Basic Attribute
321
Networking Supplementary Attribute
322
Networking CO Line Attribute
323
Networking Attendant Assignment
324
Networking Routing Table

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
18
VOIB
340
VOIB IP Setting
NATION SPECIFIC
400
DTIB Rx Gain Control
401
SLIB Rx Gain Control
402
SLIB12 Rx Gain Control
403
WTIB Rx Gain Control
404
ACOB Rx Gain Control
405
ACOB8 Rx Gain Control
406
DCOB Rx Gain Control
407
VMIB Rx Gain Control
408
DTMF Receiver Rx Gain Control
409
EXT Page Rx Gain Control
MAIN MENU
PGM
ITEM
NATION SPECIFIC
410
CPTU Rx Gain Control
411
Modem Rx Gain Control
412
Short SLIB Gain Control
413
Long SLIB Gain Control
414
Far SLIB Gain Control
415
Short ACO Gain Control
416
Long ACO Gain Control
420
System Tone Frequency
421
Differential Ring Frequency
422
Distinct CO Ring Frequency
423
ACNR Tone Cadence
425
Singular Table (Korea Only)
INITIALIZATION (DB INIT)
450
Initialization
PRINT DATABASE
451
Print Prot Database

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
19
1.6 DEFAULT VALUES
TABLE 1.6.1 LOCATION PROGRAM
PGM
BTN
ITEM
DEFAULT
REMARK
100
1
Nation Code
61
Max 4 digits
2
Customer Site Name
.
Max 23 digits
TABLE 1.6.2 RACK SLOT ASSIGNMENT
PGM
BTN
ITEM
RANGE
DEFAULT
REMARK
101
-
Slot Assignment
Refer to Note 2
Refer to Note 1
In case of PRIB assignment,
it is possible to program
logical port number.
Note.1) If the DIP switch of the manual board detection (DIP Switch 8) is ON, system will detect the installed
board type automatically. If the DIP switch 8 is OFF, the board type code must be entered at each slot.
After manual Rack Slot assignment, user should reset the system manually.
Note.2) Board Type Code Table:
STA
CODE
COL
CODE
STA & COL
CODE
Etc
CODE
DTIB12
DTIB24
SLIB6
SLIB12
WTIB
DSIB
11
12
13
14
15
18
PRIB
BRIB
LCOB4
LCOB8
CLCOB4
TLIB
EMIB
VOIB
NPRIB
NBRIB(8)
NBRIB(4)
31
32
33
34
49
37
38
41
42(ARIA-130)
43(ARIA-130)
44(ARIA-130)
STIB
51
VMIB
MISB
61
71
TABLE 1.6.3 WTIB PORT NUMBER ASSIGNMENT
PGM
BTN
ITEM
RANGE
DEFAULT
REMARK
ARIA-
300/600
ARIA-130
102
-
WTIB Port
Number
Assignment
008 –192
(Multiple of 8)
08-80
(Multiple of 8)
8
When ARIA-130 has
one rack : 08-40

Aria-24/130c/130/300/600ipe Digital Key Telephone System Issue: 1.6
Programming Manual
20
TABLE 1.6.4 LOGICAL SLOT ASSIGNMENT
PGM
BTN
ITEM
DEFAULT
REMARK
103
1
COL Board
Refer to Note
2
STA Board
Refer to Note
3
VMIB
Not Assigned
Note) If the DIP switch of the manual board detection DIP Switch 8) is ON, system will detect the
logical slot assign in sequence as increase order automatically. If the DIP switch 8 is OFF, the
logical slot assignment must be entered at each board type. After manual logical slot
assignment, user should reset the system manually.
TABLE 1.6.5 NUMBERING PLAN TYPE
PGM
BTN
ITEM
STA RANGE
REMARK
ARIA-300
ARIA-130
ARIA-600
104
3
Number Set Type
3
100 –399
100 –227
1000 –1599
