M100PFEVP Hardware Manual
Release 1
ARIES Embedded GmbH
October 17, 2019

CONTENTS
1 About this manual 1
1.1 Imprint .................................................. 1
1.2 Disclaimer ................................................ 1
1.3 Copyright ................................................. 1
1.4 Registered Trademarks .......................................... 1
1.5 Care and Maintenance .......................................... 2
1.6 Change Log ............................................... 2
2 Overview 3
2.1 Block Diagram .............................................. 4
2.2 Feature Set ................................................ 4
2.3 Dimensions ................................................ 5
2.4 Parts Location .............................................. 6
2.5 Handling Recommendations ....................................... 6
3 Resources 7
3.1 Ethernet .................................................. 7
3.2 UART ................................................... 7
3.3 USB-OTG ................................................ 7
3.4 CAN ................................................... 8
3.5 JTAG (P8) ................................................ 8
3.6 Pmod Module Connectors ........................................ 8
3.7 HSMC Connector (J2) .......................................... 9
3.8 Samtec Connector ............................................ 12
4 Appendix 17
4.1 Schematics ................................................ 17
4.2 Layout Diagram ............................................. 27
i

ii

CHAPTER
ONE
ABOUT THIS MANUAL
1.1 Imprint
Adress:
ARIES Embedded GmbH
Schöngeisinger Str. 84
D-82256 Fürstenfedbruck
Germany
Phone:
+49 (0) 8141/36 367-0
Fax:
+49 (0) 8141/36 367-67
1.2 Disclaimer
ARIES Embedded does not guarantee that the information in this document is up-to-date, correct, complete or of good
quality. Liability claims against ARIES Embedded, referring to material or non-material related damages caused,
due to usage or non-usage of the information given in this document, or due to usage of erroneous or incomplete
information, are exempted, as long as there is no proven intentional or negligent fault of ARIES Embedded. ARIES
Embedded explicitly reserves the rights to change or add to the contents of this Preliminary User’s Manual or parts of
it without notification.
1.3 Copyright
This document may not be copied, reproduced, translated, changed or distributed, completely or partially in any form
without the written approval of ARIES Embedded GmbH.
1.4 Registered Trademarks
The contents of this document may be subject of intellectual property rights (including but not limited to copyright,
trademark, or patent rights). Any such rights that are not expressly licensed or already owned by a third party are
reserved by ARIES Embedded GmbH.
1

M100PFEVP Hardware Manual, Release 1
1.5 Care and Maintenance
• Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can contain minerals that will
corrode electronic circuits. If your device does get wet, allow it to dry completely.
• Do not use or store the device in dusty, dirty areas. Its moving parts and electronic components can be damaged.
• Do not store the device in hot areas. High temperatures can shorten the life of electronic devices, damage
batteries, and warp or melt certain plastics.
• Do not store the device in cold areas. When the device returns to its normal temperature, moisture can form
inside the device and damage electronic circuit boards.
• Do not attempt to open the device.
• Do not drop, knock, or shake the device. Rough handling can break internal circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the device.
• Do not paint the device. Paint can clog the moving parts and prevent proper operation.
• Unauthorized modifications or attachments could damage the device and may violate regulations governing
radio devices.
1.6 Change Log
Revision Date Revised Comment
1.0 05.09.2019 aw Initial creation
2 Chapter 1. About this manual

CHAPTER
TWO
OVERVIEW
M100PFEVP represents the flexible Evaluation Platform for working with the M100PF SoM for PolarFire FPGAs.
The system helps developers to have a smooth start with the M100PF SoMs, it can be used for designing IP, developing
software as well as implementing prototypes.
3

M100PFEVP Hardware Manual, Release 1
2.1 Block Diagram
2.2 Feature Set
For supporting development projects and fast prototyping in the best possible way M100PFEVP supplies:
• 2x Gigabit Ethernet on a RJ45 connector
• USB on a mini-USB connector
• 2x UART on a DUSB-9 connector each
• 2x CAN on a DUSB-9 connector each
• TFT with Touch
• HSMC extension connector
• 3x PMOD extension connectors
• microSD-card slot
• JTAG pin header
• flexible supply voltage 7V to 36V DC
4 Chapter 2. Overview

M100PFEVP Hardware Manual, Release 1
2.3 Dimensions
2.3. Dimensions 5

M100PFEVP Hardware Manual, Release 1
2.4 Parts Location
The available functional blocks can be found on the baseboard as follows:
2.5 Handling Recommendations
The populated Samtec connectors require certain mechanical force to insert the SoM into its mating baseboard con-
nectors. To avoid mechanical damage to the components populated on M100PF it is strongly recommended not to
apply mechanical force on the Ball Grid Array (BGA) components. The BGA components are marked as shaded in
the figure below:
6 Chapter 2. Overview

CHAPTER
THREE
RESOURCES
3.1 Ethernet
M100PFEVP offers two Ethernet Ports in RGMII mode to be controlled by the PolarFire FPGA. These ports can be ac-
cessed via the RJ45 connectors P500 and P600 supported by Microchip KSZ903 Ethernet physical-layer transceivers.
3.2 UART
Two UARTs are available on a RS232 signal level.
The interface jumpers can be set vertical or horizontal so that the interface complies with straight- or cross-type RS232
cables. The following table shows the signal for horizontal jumper setting, in case of vertical jumper settings RX and
TX signals are swapped accordingly.
3.2.1 UART 1 (P21)
Pin Function Connector FPGA Pin
2 UART0_TX P2-132 K8
3 UART0_RX P2-138 J8
5 GND
3.2.2 UART 2 (P22)
Pin Function Connector FPGA Pin
2 UART1_TX P1-75 K6
3 UART1_RX P1-77 J7
5 GND
3.3 USB-OTG
M100PFEVP supports an USB-OTG port. The Microchip USB3320 USB-OTG Phy drives the physical connection.
The respective connector on M100PFEVP can be found at position P201.
Note: USB-OTG is not supported by the current version of the M100PF SoM.
7

M100PFEVP Hardware Manual, Release 1
3.4 CAN
Two CAN ports are available on M100PFEVP. The signals on the DSUB connector can optionally be terminated by
120 Ohms. This is done by setting the jumpers at position P19 and P20.
Function Connector FPGA Pin
CAN0_TX P2-129 F17
CAN0_RX P2-137 G17
CAN1_TX P2-135 F16
CAN1_RX P2-130 F15
3.4.1 CAN1 (P23)
Pin Function
2 CAN-L
3 GND
7 CAN-H
3.4.2 CAN2 (P24)
Pin Function
2 CAN-L
3 GND
7 CAN-H
3.5 JTAG (P8)
P8 provides the JTAG signals of the FPGA to the outer world. The JTAG connector complies with the standard pinout,
the FlashPro5 can be directly connected. The following signals are available:
Function Connector FPGA Pin Pin Pin FPGA Pin Connector Function
TCK P1-6 F8 1 2 – – GND
TDO P1-4 F6 3 4 – – 3.3V
TMS P1-10 F7 5 6 – – –
– – – 7 8 – – –
TDI P1-8 G8 9 10 – – GND
3.6 Pmod Module Connectors
Three 2x6 angled pin headers are available on the M100PFEVP board which fit the requirements for Pmod modules.
To support a wider range of possible modules, each connector has its own level shifter. A corresponding jumper allows
the selection between 3.3V or 5V module voltage.
8 Chapter 3. Resources

M100PFEVP Hardware Manual, Release 1
3.6.1 Pmod J4:
Function Connector FPGA Pin Pin Pin FPGA Pin Connector Function
GPIO_R1 P1-120 R1 1 7 T1 P1-118 GPIO_T1
GPIO_N1 P1-133 N1 2 8 P1 P1-131 GPIO_P1
GPIO_R3 P1-115 R3 3 9 T5 P1-113 GPIO_T5
GPIO_E11 P2-70 E11 4 10 F11 P2-71 GPIO_F11
GND – – 5 11 – – GND
3.3V – – 6 12 – – 3.3V
3.6.2 Pmod J5:
Function Connector FPGA Pin Pin Pin FPGA Pin Connector Function
GPIO_M8 P2-136 M8 1 7 N6 P2-127 GPIO_N6
GPIO_T6 P1-162 T6 2 8 N7 P2-121 GPIO_N7
GPIO_B17 P1-17 B17 3 9 M9 P2-128 GPIO_M9
GPIO_A13 P1-15 A13 4 10 N5 P2-123 GPIO_N5
GND – – 5 11 – – GND
3.3V – – 6 12 – – 3.3V
3.6.3 Pmod J6:
Function Connector FPGA Pin Pin Pin FPGA Pin Connector Function
GPIO_K4 P2-93 K4 1 7 L3 P2-125 GPIO_L3
GPIO_L7 P2-80 L7 2 8 M4 P2-122 GPIO_M4
GPIO_M7 P2-90 M7 3 9 M5 P2-133 GPIO_M5
GPIO_K5 P2-97 K5 4 10 F10 P2-155 GPIO_F10
GND – – 5 11 – – GND
3.3V – – 6 12 – – 3.3V
3.7 HSMC Connector (J2)
M100PFEVP hosts a High Speed Mezzanine Card (HSMC) connector. Its pinout is shown in the following table.
Function Connector FPGA pin Pin Pin FPGA pin Connector Function
– – – 1 2 – – –
– – – 3 4 – – –
GND – – 5 6 – – GND
– – – 7 8 – – –
– – – 9 10 – – –
GND – – 11 12 – – GND
GXB_TX_L5_P P2-40 H22 13 14 F22 P2-34 GXB_RX_L5_P
GXB_TX_L5_N P2-42 H21 15 16 F21 P2-36 GXB_RX_L5_N
GND – – 17 18 – – GND
GXB_TX_L4_P P2-28 D22 19 20 C20 P2-22 GXB_RX_L4_P
GXB_TX_L4_N P2-30 D21 21 22 C19 P2-24 GXB_RX_L4_N
GND – – 23 24 – – GND
GXB_TX_L3_P P2-16 B22 25 26 A20 P2-10 GXB_RX_L3_P
Continued on next page
3.7. HSMC Connector (J2) 9

M100PFEVP Hardware Manual, Release 1
Table 3.1 – continued from previous page
Function Connector FPGA pin Pin Pin FPGA pin Connector Function
GXB_TX_L3_N P2-18 B21 27 28 A19 P2-12 GXB_RX_L3_N
GND – – 29 30 – – GND
GXB_TX_L2_P P2-39 Y22 31 32 W20 P2-33 GXB_RX_L2_P
GXB_TX_L2_N P2-41 Y21 33 34 W19 P2-35 GXB_RX_L2_N
GND – – 35 36 – – GND
GXB_TX_L1_P P2-27 V22 37 38 T22 P2-21 GXB_RX_L1_P
GXB_TX_L1_N P2-29 V21 39 40 T21 P2-23 GXB_RX_L1_N
GND – – 41 42 – – GND
GXB_TX_L0_P P2-15 P22 43 44 M22 P2-9 GXB_RX_L0_P
GXB_TX_L0_N P2-17 P21 45 46 M21 P2-11 GXB_RX_L0_N
GND – – 47 48 – – GND
HPS_GPIO51 P2-134 M3 49 50 F13 P2-131 HPS_GPIO52
TCK P1-6 F8 51 52 F7 P1-10 TMS
GND – – 53 54 – – GND
HSMC_TDO – – 55 56 – – HSMC_TDI
CLK25_HSMC – – 57 58 – – –
GND – – 59 60 – – GND
IOB4A11 P1-132 – 61 62 – P1-156 IOB4A0/CLK3p
IOB4A10 P1-134 – 63 64 – P1-154 IOB4A1/CLK3n
3.3V – – 65 66 – – VIN
IOB4A28 P1-94 – 67 68 – P1-152 IOB4A2
IOB4A29 P1-92 – 69 70 – P1-150 IOB4A3
3.3V – – 71 72 – – VIN
IOB4A30 P1-90 – 73 74 – P1-148 IOB4A4
IOB4A31 P1-88 – 75 76 – P1-146 IOB4A5
3.3V – – 77 78 – – VIN
IOB4A32 P1-84 – 79 80 – P1-144 IOB4A6
IOB4A33 P1-82 – 81 82 – P1-142 IOB4A7
3.3V – – 83 84 – – VIN
IOB4A40 P1-143 – 85 86 – P1-136 IOB4A9
IOB4A41 P1-141 – 87 88 – P1-138 IOB4A8
3.3V – – 89 90 – – VIN
IOB4A42 P1-137 – 91 92 – P1-128 IOB4A13
IOB4A43 P1-135 – 93 94 – P1-130 IOB4A12
3.3V – – 95 96 – – VIN
IOB4A48 P1-125 – 97 98 – P1-124 IOB4A15
IOB4A49 P1-123 – 99 100 – P1-126 IOB4A14
3.3V – – 101 102 – – VIN
IOB4A50 P1-119 – 103 104 – P1-116 IOB4A18
IOB4A51 P1-117 – 105 106 – P1-114 IOB4A19
3.3V – – 107 108 – – VIN
IOB4A54 P1-111 – 109 110 – P1-21 IOB8A0
IOB4A55 P1-109 – 111 112 – P1-19 IOB8A1
3.3V – – 113 114 – – VIN
CLKEXT_P P2-160 – 115 116 U19 P2-3 REFCLK0L_P
CLKEXT_N P2-162 – 117 118 U20 P2-5 REFCLK0L_N
3.3V – – 119 120 – – VIN
IOB4A56 P1-107 – 121 122 – P1-108 IOB4A22
IOB4A57 P1-105 – 123 124 – P1-106 IOB4A23
Continued on next page
10 Chapter 3. Resources

M100PFEVP Hardware Manual, Release 1
Table 3.1 – continued from previous page
Function Connector FPGA pin Pin Pin FPGA pin Connector Function
3.3V – – 125 126 – – VIN
IOB4A58 P1-101 – 127 128 – P1-102 IOB4A24
IOB4A59 P1-99 – 129 130 – P1-100 IOB4A25
3.3V – – 131 132 – – VIN
IOB4A62 P1-93 – 133 134 – P1-98 IOB4A26
IOB4A63 P1-91 – 135 136 – P1-96 IOB4A27
3.3V – – 137 138 – – VIN
IOB4A64 P1-89 – 139 140 – P1-155 IOB4A34
IOB4A65 P1-87 – 141 142 – P1-153 IOB4A35
3.3V – – 143 144 – – VIN
IOB4A66 P1-83 – 145 146 – P1-151 IOB4A36
IOB4A67 P1-81 – 147 148 – P1-149 IOB4A37
3.3V – – 149 150 – – VIN
IOB3B24 P1-59 – 151 152 – P1-147 IOB4A38
IOB3B25 P1-57 – 153 154 – P1-145 IOB4A39
3.3V – – 155 156 – – VIN
IOB3B19 P1-71 – 157 158 – P1-129 IOB4A46
IOB3B18 P1-73 – 159 160 – P1-127 IOB4A47
3.3V – – 161 162 – – VIN
IOB3B20 P1-69 – 163 164 – P1-97 IOB4A60
IOB3B21 P1-67 – 165 166 – P1-95 IOB4A61
3.3V – – 167 168 – – VIN
IOB3B22 P1-65 – 169 170 – P1-24 IOB5B0/CLK4p
IOB3B23 P1-63 – 171 172 – P1-22 IOB5B1/CLK4n
3.3V – – 173 174 – – VIN
IOB5B2/CLKOUTp P1-20 – 175 176 – P1-16 IOB5B4/CLK5p
IOB5B3/CLKOUTn P1-18 – 177 178 – P1-14 IOB5B5/CLK5n
3.3V – – 179 180 L8 P2-156 HPS_GPI0
GND – – 181 182 – – GND
GND – – 183 184 – – GND
GND – – 185 186 – – GND
GND – – 187 188 – – GND
GND – – 189 190 – – GND
GND – – 191 192 – – GND
3.7. HSMC Connector (J2) 11

M100PFEVP Hardware Manual, Release 1
3.8 Samtec Connector
The M100PF SoM connects to the M100PFEVP Baseboard using two Samtec QSH-090-01-F-D-A connectors.
3.8.1 Connector P1
Function FPGA Pin Pin Pin FPGA Pin Function
3.3V – 1 2 G7 GND
3.3V – 3 4 F6 JTAG_TDO
3.3V – 5 6 F8 JTAG_TCK
3.3V – 7 8 G8 JTAG_TDI
3.3V – 9 10 F7 JTAG_TMS
3.3V – 11 12 – 2.5V / 3.3V
2.5V / 3.3V (*) – 13 14 – HSMC 178 (*)
PMod J5 3 A13 15 16 – HSMC 176 (*)
PMod J5 4 B17 17 18 – HSMC 177 (*)
HSMC 112 (*) – 19 20 – HSMC 175 (*)
HSMC 110 (*) – 21 22 – HSMC 172 (*)
2.5V / 3.3V (*) – 23 24 – HSMC 170 (*)
3.3V – 25 26 – 2.5V / 3.3V (*)
SD_DATA2 C9 27 28 C20 LCD_CLK
SD_DATA3 B10 29 30 A3 LCD_R0
SD_CMD B9 31 32 D3 LCD_R1
SD_CLK A2 33 34 E3 LCD_R2
SD_DATA0 C12 35 36 B3 LCD_R3
SD_DATA1 C11 37 38 B2 LCD_R4
SD_DETECT C10 39 40 E5 LCD_R5
LCD_T_RESET A12 41 42 F5 LCD_R6
3.3V (*) – 43 44 – 3.3V (*)
LCD_B4 E8 45 46 C4 LCD_R7
LCD_B5 B5 47 48 D4 LCD_G0
LCD_B6 C5 49 50 E4 LCD_G1
LCD_B7 C6 51 52 F3 LCD_G2
LCD_DIM C7 53 54 A6 LCD_G3
LCD_DISP D7 55 56 B4 LCD_G4
HSMC 153 (*) – 57 58 D6 LCD_G5
HSMC 151 (*) – 59 60 E6 LCD_G6
3.3V (*) – 61 62 – 3.3V (*)
HSMC 171 (*) – 63 64 G2 LCD_G7
HSMC 169 (*) – 65 66 H2 LCD_B0
HSMC 165 (*) – 67 68 J2 LCD_B1
HSMC 163 (*) – 69 70 L2 LCD_B2
HSMC 157 (*) – 71 72 M2 LCD_B3
HSMC 159 (*) – 73 74 H1 LCD_HSYNC
UART1_TX K6 75 76 J1 LCD_VSYNC
UART1_RX J7 77 78 K1 LCD_DE
3.3V (*) – 79 80 – 3.3V (*)
HSMC 147 (*) – 81 82 – HSMC 81 (*)
HSMC 145 (*) – 83 84 – HSMC 79 (*)
Continued on next page
12 Chapter 3. Resources

M100PFEVP Hardware Manual, Release 1
Table 3.2 – continued from previous page
Function FPGA Pin Pin Pin FPGA Pin Function
3.3V (*) – 85 86 – 3.3V (*)
HSMC 141 (*) – 87 88 – HSMC 75 (*)
HSMC 139 (*) – 89 90 – HSMC 73 (*)
HSMC 135 (*) – 91 92 – HSMC 69 (*)
HSMC 133 (*) – 93 94 – HSMC 67 (*)
HSMC 166 (*) – 95 96 – HSMC 136 (*)
HSMC 164 (*) – 97 98 – HSMC 134 (*)
HSMC 129 (*) – 99 100 – HSMC 130 (*)
HSMC 127 (*) – 101 102 – HSMC 128 (*)
3.3V (*) – 103 104 – 3.3V (*)
HSMC 123 (*) – 105 106 – HSMC 124 (*)
HSMC 121 (*) – 107 108 – HSMC 122 (*)
HSMC 111 (*) – 109 110 R5 ETH1_RXC
HSMC 109 (*) – 111 112 F1 P3 26
Pmod J4 9 T5 113 114 – HSMC 106 (*)
Pmod J4 3 R3 115 116 – HSMC 104 (*)
HSMC 105 (*) – 117 118 T1 Pmod J4 7
HSMC 103 (*) – 119 120 R1 Pmod J4 1
3.3V (*) – 121 122 – 3.3V (*)
HSMC 99 (*) – 123 124 – HSMC 98 (*)
HSMC 97 (*) – 125 126 – HSMC 100 (*)
HSMC 160 (*) – 127 128 – HSMC 92 (*)
HSMC 158 (*) – 129 130 – HSMC 94 (*)
Pmod J4 8 P1 131 132 – HSMC 61 (*)
Pmod J4 2 N1 133 134 – HSMC 63 (*)
HSMC 93 (*) – 135 136 – HSMC 86 (*)
HSMC 91 (*) – 137 138 – HSMC 88 (*)
3.3V (*) – 139 140 – 3.3V (*)
HSMC 87 (*) – 141 142 – HSMC 82 (*)
HSMC 85 (*) – 143 144 – HSMC 80 (*)
HSMC 154 (*) – 145 146 – HSMC 76 (*)
HSMC 152 (*) – 147 148 – HSMC 74 (*)
HSMC 148 (*) – 149 150 – HSMC 70 (*)
HSMC 146 (*) – 151 152 – HSMC 68 (*)
HSMC 142 (*) – 153 154 – HSMC 64 (*)
HSMC 140 (*) – 155 156 – HSMC 62 (*)
2.5V / 3.3V (*) – 157 158 – 2.5V / 3.3V (*)
ETH1_GTXCLK P4 159 160 F2 P3 28
ETH1_MDC N8 161 162 T6 Pmod J5 2
ETH1_TXD1 P3 163 164 P7 ETH1_MDIO
ETH1_RX_DV P8 165 166 R4 ETH1_TXD3
P3 10 L1 167 168 R6 ETH1_RXD2
ETH1_RXD0 R8 169 170 P9 ETH1_RXD1
ETH1_TXD2 N4 171 172 T3 ETH1_TX_EN
ETH1_RXD3 P6 173 174 T2 ETH1_TXD0
2.5V / 3.3V (*) – 175 176 – 2.5V / 3.3V (*)
3.3V – 177 178 – 3.3V
3.3V – 179 180 – 3.3V
Ground Plate – 181 182 – Ground Plate
Continued on next page
3.8. Samtec Connector 13

M100PFEVP Hardware Manual, Release 1
Table 3.2 – continued from previous page
Function FPGA Pin Pin Pin FPGA Pin Function
Ground Plate – 183 184 – Ground Plate
Ground Plate – 185 186 – Ground Plate
Ground Plate – 187 188 – Ground Plate
Ground Plate – 189 190 – Ground Plate
Ground Plate – 191 192 – Ground Plate
Note: Functions marked with (*) are not connected on the M100PF SoM side.
3.8.2 Connector P2
Function FPGA Pin Pin Pin FPGA Pin Function
GND – 1 2 – GND
HSMC 116 U19 3 4 J19 REFCLK1_P
HSMC 118 U20 5 6 J20 REFCLK1_N
GND – 7 8 – GND
HSMC 44 M22 9 10 A20 HSMC 26
HSMC 46 M21 11 12 A19 HSMC 28
GND – 13 14 – GND
HSMC 43 P22 15 16 B22 HSMC 25
HSMC 45 P21 17 18 B21 HSMC 27
GND – 19 20 – GND
HSMC 38 T22 21 22 C20 HSMC 20
HSMC 40 T21 23 24 C19 HSMC 22
GND – 25 26 – GND
HSMC 37 V22 27 28 D22 HSMC 19
HSMC 39 V21 29 30 D21 HSMC 21
GND – 31 32 – GND
HSMC 32 W20 33 34 F22 HSMC 14
HSMC 34 W19 35 36 F21 HSMC 16
GND – 37 38 – GND
HSMC 31 Y22 39 40 H22 HSMC 13
HSMC 33 Y21 41 42 H21 HSMC 15
GND – 43 44 – GND
– AA20 45 46 L20 –
– AA19 47 48 L19 –
GND – 49 50 – GND
– AB22 51 52 K22 –
– AB21 53 54 K21 –
GND – 55 56 – GND
– – 57 58 – –
– – 59 60 – –
3.3V – 61 62 – 3.3V
– – 63 64 – –
– – 65 66 – –
Continued on next page
14 Chapter 3. Resources

M100PFEVP Hardware Manual, Release 1
Table 3.3 – continued from previous page
Function FPGA Pin Pin Pin FPGA Pin Function
– – 67 68 – –
– – 69 70 E11 Pmod J4 4
Pmod J4 10 F11 71 72 – –
– – 73 74 – –
3.3V – 75 76 – 3.3V
1.8V (*) – 77 78 – 2.5V (*)
P3 5 E14 79 80 L7 Pmod J6 2
USB_DIR (*) – 81 82 – USB_D6 (*)
USB_CLK (*) – 83 84 – USB_D7 (*)
USB_D4 (*) – 85 86 – USB_D5 (*)
USB_D1 (*) – 87 88 – USB_NXT (*)
P3 3 C14 89 90 M7 Pmod J6 3
P32 Boot Mode J6 91 92 D14 P3 7
Pmod J6 1 K4 93 94 L6 Pmod J6 10
USB_STP (*) – 95 96 C15 P3 2
Pmod J6 4 K5 97 98 – USB_D2 (*)
USB_D3 (*) – 99 100 – USB_D0 (*)
1.8V (*) – 101 102 – 2.5V (*)
3.3V – 103 104 – 3.3V
ETH0_TXD3 H13 105 106 C16 ETH0_TXD0
ETH0_TXD1 A16 107 108 A15 ETH0_TXD2
ETH0_RXD3 D16 109 110 G15 ETH0_RXD0
ETH0_RXD2 D17 111 112 B15 ETH0_MDC
ETH0_GTXCLK B14 113 114 C17 ETH0_TX_EN
ETH0_MDIO A17 115 116 H15 ETH0_RXD1
ETH0_RX_DV E16 117 118 G14 ETH0_RXC
3.3V – 119 120 – 3.3V
Pmod J5 8 N7 121 122 M4 Pmod J6 8
Pmod J5 10 N5 123 124 – LCD_T_INT (*)
Pmod J6 7 L3 125 126 H6 I2C0_SDA
Pmod J5 7 N6 127 128 M9 Pmod J5 9
CAN0_TX F17 129 130 F15 CAN1_RX
HSMC 50 F13 131 132 K8 UART0_TX
Pmod J6 9 M5 133 134 M3 HSMC 49
CAN1_TX F16 135 136 M8 Pmod J5 1
CAN0_RX G17 137 138 J8 UART0_RX
I2C0_SCL H5 139 140 – 3.3V
3.3V – 141 142 – 3.3V
P3 23 E13 143 144 J3 P3 9
P3 25 D13 145 146 E10 P3 13
P3 17 F12 147 148 – ETH1_INT (*)
P3 11 D11 149 150 K3 P3 15
– – 151 152 G12 P3 27
P3 19 D12 153 154 G13 ETH0_INT
P3 21 F10 155 156 L8 HSMC 180
3.3V – 157 158 – 3.3V
RST_N – 159 160 – OCLK_P
VBAT – 161 162 – OCLK_N
3.3V – 163 164 – 2.5V (*)
Continued on next page
3.8. Samtec Connector 15

M100PFEVP Hardware Manual, Release 1
Table 3.3 – continued from previous page
Function FPGA Pin Pin Pin FPGA Pin Function
PIC_SDA – 165 166 – CLKEXT_P (*)
PIC_SCL – 167 168 – CLKEXT_N (*)
IDT_SEL0 – 169 170 – 2.5V (*)
IDT_SEL1 – 171 172 L5 CLKEXTF
IDT_SEL2 – 173 174 – CLK25_3
3.3V – 175 176 – 3.3V
3.3V – 177 178 – 3.3V
3.3V – 179 180 – 3.3V
Ground Plate – 181 182 – Ground Plate
Ground Plate – 183 184 – Ground Plate
Ground Plate – 185 186 – Ground Plate
Ground Plate – 187 188 – Ground Plate
Ground Plate – 188 190 – Ground Plate
Ground Plate – 191 192 – Ground Plate
Note: Functions marked with (*) are not connected on the M100PF SoM side.
16 Chapter 3. Resources
