Aries Embedded MCV Series User manual

MCV Quick Start Guide
Release 2
ARIES Embedded GmbH
April 28, 2020

CONTENTS
1 About this manual 1
1.1 Imprint .................................................. 1
1.2 Disclaimer ................................................ 1
1.3 Copyright ................................................. 1
1.4 Registered Trademarks .......................................... 1
1.5 Care and Maintenance .......................................... 2
2 Intial Operation 3
2.1 Apply Correct Jumper Settings ..................................... 3
2.2 Mount the MxxDK Displaykit on MCVEVP .............................. 4
2.3 Start your Linux Computer and install ckermit ............................. 6
2.4 Configure kermit ............................................. 7
2.5 Start kermit and connect ......................................... 7
2.6 Connect the console cable ........................................ 7
2.7 Connect power to your kit ........................................ 8
2.8 Have fun ! ................................................ 10
2.9 Shut down your kit ............................................ 10
3 Update eMMC Memory 11
3.1 Perform initial operation ......................................... 11
3.2 Connect MCVEVP to your PC ...................................... 11
4 Recovery 15
4.1 Modify boot settings ........................................... 15
4.2 Connect USB Blaster and USB A-miniB cable ............................. 15
4.3 Open a Console .............................................. 15
4.4 Power up the board ............................................ 15
4.5 Start Quartus Programmer ........................................ 15
4.6 Use USB Mass Storage ......................................... 16
i

ii

CHAPTER
ONE
ABOUT THIS MANUAL
1.1 Imprint
Adress:
ARIES Embedded GmbH
Schöngeisinger Str. 84
D-82256 Fürstenfeldbruck
Germany
Phone:
+49 (0) 8141/36 367-0
Fax:
+49 (0) 8141/36 367-67
1.2 Disclaimer
ARIES Embedded does not guarantee that the information in this document is up-to-date, correct, complete or of good
quality. Liability claims against ARIES Embedded, referring to material or non-material related damages caused,
due to usage or non-usage of the information given in this document, or due to usage of erroneous or incomplete
information, are exempted, as long as there is no proven intentional or negligent fault of ARIES Embedded. ARIES
Embedded explicitly reserves the rights to change or add to the contents of this Preliminary User’s Manual or parts of
it without notification.
1.3 Copyright
This document may not be copied, reproduced, translated, changed or distributed, completely or partially in any form
without the written approval of ARIES Embedded GmbH.
1.4 Registered Trademarks
The contents of this document may be subject of intellectual property rights (including but not limited to copyright,
trademark, or patent rights). Any such rights that are not expressly licensed or already owned by a third party are
reserved by ARIES Embedded GmbH.
1

MCV Quick Start Guide, Release 2
1.5 Care and Maintenance
• Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can contain minerals that will
corrode electronic circuits. If your device does get wet, allow it to dry completely.
• Do not use or store the device in dusty, dirty areas. Its moving parts and electronic components can be damaged.
• Do not store the device in hot areas. High temperatures can shorten the life of electronic devices, damage
batteries, and warp or melt certain plastics.
• Do not store the device in cold areas. When the device returns to its normal temperature, moisture can form
inside the device and damage electronic circuit boards.
• Do not attempt to open the device.
• Do not drop, knock, or shake the device. Rough handling can break internal circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the device.
• Do not paint the device. Paint can clog the moving parts and prevent proper operation.
• Unauthorized modifications or attachments could damage the device and may violate regulations governing
radio devices.
2 Chapter 1. About this manual

CHAPTER
TWO
INTIAL OPERATION
The following steps guide you to the correct settings of your MCVEVP.
2.1 Apply Correct Jumper Settings
Pin 1 of each header is marked with a yellow dot in the picture.
1. place jumpers on P25 and P29 to activate the UART0 interface
2. leave jumper P32 open to select eMMC boot mode for MCV
3. place jumper to connect pin 1 and pin 2 on connector JP4 to connect VCCIO3B4A to 3.3V
4. Insert the MCV SoM into the Samtec connectors on MCVEVP
3

MCV Quick Start Guide, Release 2
! CAUTION ! |
Electronic components are sensitive against mechanical pressure. Certain contacts/housings may mechanically break
when mechanical force is applied to the board. Due to the insertion force that has to be applied to the two board-to-
board connectors the user has to press on the MCV pcb to insert it on a baseboard.
The following image shows the do not touch area when inserting the board on a baseboard.
DO NOT APPLY ANY MECHANICAL PRESSURE TO THE MARKED AREAS
Disregard of this provision may break the components and/or the contacts of the BGA components.
Please make sure that the TOP side of the Altera logo on the CPU is facing the ethernet connector when inserting the
SoM into the EVK.
2.2 Mount the MxxDK Displaykit on MCVEVP
Note: MxxDK is compatible with MCVEVP V1.0. For MCVEVP V2.0 please refer to the MxxDK2.
Open the FPC connector on the backside of your MxxDK carefully
4 Chapter 2. Intial Operation

MCV Quick Start Guide, Release 2
Place the FPC cable in the FPC connector on MxxDK, the contact side has to be placed towards the TFT PCB so that
the isolation of the cable is on top. Close the FPC connector on the MxxDK carefully.
Place the FPC cable in the FPC connector on MCVEVP, the contact side has to be placed towards the TFT PCB so
that the isolation of the cable is on top. Close the FPC connector on the MCVEVP carefully.
2.2. Mount the MxxDK Displaykit on MCVEVP 5

MCV Quick Start Guide, Release 2
Place the MxxDK Displaykit on MCVEVP without twisting or disconnecting the FPC cable. Mount the MxxDK
Displaykit on MCVEVP by using four screws.
2.3 Start your Linux Computer and install ckermit
Boot your Linux Computer and log in. Open a console port and install ckermit (if not already installed):
sudo apt-get install ckermit
After typing in your sudo password ckermit will be installed.
6 Chapter 2. Intial Operation

MCV Quick Start Guide, Release 2
2.4 Configure kermit
Configure ckermit by creating the file .kermit in your home directory:
cd
nano .kermit
Copy into .kermit:
set line /dev/ttyS0
set speed 115200
set carrier-watch off
set handshake none
set flow-control none
robust
set file type bin
set file name lit
set rec pack 1000
set send pack 1000
set window 5
Save the file by typing:
<ctrl> + o
Exit nano by typing:
<ctrl> + x
2.5 Start kermit and connect
Start kemit by typing:
kermit
Connect by ty typing:
c
2.6 Connect the console cable
Connect the console cable to the UART port P21 of your MCVEVP and the serial port of your Computer as specified
below
2.4. Configure kermit 7

MCV Quick Start Guide, Release 2
2.7 Connect power to your kit
Connect the wall plug to P901 on MCVEVK
MCV will start booting:
U-Boot SPL 2013.01.01-00110-g3cbaeae-dirty (Oct 24 2014 - 18:54:05)
BOARD : Altera SOCFPGA Cyclone V Board
CLOCK: EOSC1 clock 25000 KHz
CLOCK: EOSC2 clock 25000 KHz
CLOCK: F2S_SDR_REF clock 0 KHz
CLOCK: F2S_PER_REF clock 0 KHz
CLOCK: MPU clock 800 MHz
CLOCK: DDR clock 333 MHz
CLOCK: UART clock 100000 KHz
CLOCK: MMC clock 50000 KHz
CLOCK: QSPI clock 3125 KHz
8 Chapter 2. Intial Operation

MCV Quick Start Guide, Release 2
RESET: COLD
INFO : Watchdog enabled
SDRAM: Initializing MMR registers
SDRAM: Calibrating PHY
SEQ.C: Preparing to start memory calibration
SEQ.C: CALIBRATION PASSED
SDRAM: 1024 MiB
ALTERA DWMMC: 0
U-Boot 2014.10 (Oct 24 2014 - 18:54:19)
CPU: Altera SoCFPGA Platform
BOARD: Altera SoCFPGA Cyclone5 Board
DRAM: 1 GiB
MMC: SOCFPGA DWMMC: 0
In: serial
Out: serial
Err: serial
Net: dwmac.ff700000
** File not found boot.scr **
Hit any key to stop autoboot: 0
After booting the kernel the login will appear:
Starting Bootlog daemon: bootlogd.
Populating dev cache
Fri Oct 24 17:31:00 UTC 2014
INIT: Entering runlevel: 5
Configuring network interfaces... [ 5.259856] eth0: device MAC address c0:e5:4e:NN:NN:NN
udhcpc (v1.22.1) started
Sending discover...
[ 8.328723] libphy: stmmac-0:01 - Link is Up - 1000/Full
Sending discover...
Sending select for 192.168.0.131...
Lease of 192.168.0.131 obtained, lease time 43200
/etc/udhcpc.d/50default: Adding DNS 192.168.1.254
done.
Starting system message bus: dbus.
Starting OpenBSD Secure Shell server: sshd
generating ssh RSA key...
generating ssh ECDSA key...
generating ssh DSA key...
generating ssh ED25519 key...
done.
Starting rpcbind daemon...done.
Starting Distributed Compiler Daemon: distcc.
Starting syslogd/klogd: done
[ ok ]rting Avahi mDNS/DNS-SD Daemon: avahi-daemon
Starting OProfileUI server
Stopping Bootlog daemon: bootlogd.
ELDK 5.6 mcvevk /dev/ttyS0
mcvevk login: root
root@mcvevk:~#
2.7. Connect power to your kit 9

MCV Quick Start Guide, Release 2
2.8 Have fun !
Start hacking, developing your application, setting up benchmarks.......
2.9 Shut down your kit
To avoid damage of the SD-card alway shut down your kit properly by typing:
root@mcvevk:~# poweroff
Broadcast message from root@mcvevk (ttyS0) (Fri Oct 24 17:32:06 2014):
The system is going down for system halt NOW!
INIT: Sending processes the TERM signal
Stopping OpenBSD Secure Shell server: sshdstopped /usr/sbin/sshd (pid 296)
.
*Stopping Avahi mDNS/DNS-SD Daemon: avahi-daemon
[ ok ]rofile-server:332): WARNING **: Avahi error: Daemon connection failed
Stopping system message bus: dbus.
Stopping Distributed Compiler Daemon: distcc/etc/rc0.d/K20distcc: stop failed with error code 1
Stopping OProfileUI server
Error opening /dev/fb0: No such file or directory
Stopping syslogd/klogd: stopped syslogd (pid 312)
stopped klogd (pid 315)
done
Stopping rpcbind daemon...
done.
Deconfiguring network interfaces... done.
Sending all processes the TERM signal...
Sending all processes the KILL signal...
Unmounting remote filesystems...
Deactivating swap...
Unmounting local filesystems...
[ 78.018275] EXT4-fs (mmcblk0p3): re-mounted. Opts: (null)
[ 80.153444] reboot: System halted
10 Chapter 2. Intial Operation

CHAPTER
THREE
UPDATE EMMC MEMORY
This guide explains how to update the content of the eMMC memory on MCV.
This instruction is based on the assumption that MCV is operational and hosts on a valid image in the eMMC memory,
i.e. U-Boot and Linux provided in default configuration, provided by the factory.
3.1 Perform initial operation
The Initial Operation, explained in this guide must be performed. The kit must still be powered off after completing
the initial operation.
3.2 Connect MCVEVP to your PC
Open a console1 on your host PC.
Connect a USB A-miniB cable from your PC to the USB-connector P201 on MCVEVP
Connect the serial port of your PC to the UART0 on the P21 DSUB9 connector on MCVEVP
Open a console2 on your host PC and start kermit/minicom, connect to your target:
mcv@aries-lp-01:~$ minicom
Willkommen zu minicom 2.7
Optionen: I18n
Übersetzt am Feb 7 2016, 13:37:27.
Port /dev/ttyUSB0, 12:10:31
Drücken Sie CTRL-A Z für Hilfe zu speziellen Tasten
Connect the power supply to your MCVEVP, MCV starts booting and you will get something like the following output.
Interrupt the boot countdown in U-Boot:
U-Boot SPL 2016.11 (Jan 10 2017 - 20:16:15)
sdram_calibration_full: Preparing to start memory calibration
debug_mem_calibrate: CALIBRATION PASSED
debug_mem_calibrate: Calibration complete
Trying to boot from MMC1
U-Boot 2017.09 (Dec 05 2017 - 17:00:45 +0100)
11

MCV Quick Start Guide, Release 2
CPU: Altera SoCFPGA Platform
FPGA: Altera Cyclone V, SE/A2 or SX/C2, version 0x0
BOOT: SD/MMC Internal Transceiver (3.0V)
Watchdog enabled
I2C: ready
DRAM: 1 GiB
MMC: dwmmc0@ff704000: 0
*** Warning - bad CRC, using default environment
In: serial
Out: serial
Err: serial
Model: Aries MCVEVK
Net:
Error: ethernet@ff700000 address not set.
No ethernet found.
Hit any key to stop autoboot: 0
=>
Activate the USB mass storage function of U-Boot:
=> ums 0 mmc 0
UMS: LUN 0, dev 0, hwpart 0, sector 0x0, count 0x734000
\
A rotating dash will appear on the screen.
Change to the other console1. Check for mounted partitions:
mcv@aries-lp-01:~$ lsblk
NAME MAJ:MIN RM SIZE RO TYPE MOUNTPOINT
sdb 8:16 1 3,6G 0 disk
sdb2 8:18 1 16M 0 part /media/aw/boot
sdb3 8:19 1 32,1M 0 part /media/aw/root
sdb1 8:17 1 2M 0 part
sr0 11:0 1 1024M 0 rom
sda 8:0 0 111,8G 0 disk
sda2 8:2 0 1K 0 part
sda5 8:5 0 2G 0 part [SWAP]
sda1 8:1 0 109,8G 0 part /
Carefully identify the partitions related to MCV, in case any of the are mounted. In this special case all sdax partitions
are related to the host PC, sdb2 and sdb3 are mounted on MCV. Unmount the partitions which are mounted on MCV:
mcv@aries-lp-01:~$ sudo umount /dev/sdb2
mcv@aries-lp-01:~$ sudo umount /dev/sdb3
NOTE:
USING THE WRONG PARTITIONS FOR PROGRAMMING MCV WILL DESTROY THE CONTENT OF
YOUR HOST PCS STORAGE
Copy the SD-card image from your host PC to the eMMC memory of MCV:
mcv@aries-lp-01:~$ sudo dd if=/home/MCV/core-image-full-cmdline-mcvevk-20171205152219.rootfs.wic of=/dev/sdb bs=512
311714+0 Datensätze ein
311714+0 Datensätze aus
159597568 bytes (160 MB, 152 MiB) copied, 1,2931 s, 123 MB/s
12 Chapter 3. Update eMMC Memory

MCV Quick Start Guide, Release 2
This process will take some minutes, depending on the size of the SD-card image you program.
After the programming process is terminated switch back to console2 and terminate the USB mass storage function of
U-Boot by pressing <Ctrl-C>:
=> ums 0 mmc 0
UMS: LUN 0, dev 0, hwpart 0, sector 0x0, count 0x734000
CTRL+C - Operation aborted
=>
Now, still at the U-Boot prompt, reboot MCV by typing:
=> reset
The MCV starts booting:
=> reset
resetting ...
U-Boot SPL 2016.11 (Jan 10 2017 - 20:16:15)
sdram_calibration_full: Preparing to start memory calibration
debug_mem_calibrate: CALIBRATION PASSED
debug_mem_calibrate: Calibration complete
Trying to boot from MMC1
U-Boot 2017.09 (Dec 05 2017 - 17:00:45 +0100)
CPU: Altera SoCFPGA Platform
FPGA: Altera Cyclone V, SE/A2 or SX/C2, version 0x0
BOOT: SD/MMC Internal Transceiver (3.0V)
Watchdog enabled
I2C: ready
DRAM: 1 GiB
MMC: dwmmc0@ff704000: 0
*** Warning - bad CRC, using default environment
In: serial
Out: serial
Err: serial
Model: Aries MCVEVK
Net:
Error: ethernet@ff700000 address not set.
No ethernet found.
Hit any key to stop autoboot: 0
3666596 bytes read in 384 ms (9.1 MiB/s)
Loading kernel from FIT Image at 10000000 ...
Using 'conf@socfpga_cyclone5_mcvevk.dtb' configuration
Trying 'kernel@1' kernel subimage
Description: Linux kernel
Created: 2017-12-05 15:47:10 UTC
Type: Kernel Image
Compression: uncompressed
Data Start: 0x1000011c
Data Size: 3638576 Bytes = 3.5 MiB
Architecture: ARM
OS: Linux
3.2. Connect MCVEVP to your PC 13

MCV Quick Start Guide, Release 2
Load Address: 0x00008000
Entry Point: 0x00008000
Hash algo: sha1
Hash value: 867ce5f1e3aa5eff24f507066be43981818f3303
Verifying Hash Integrity ... sha1+ OK
Loading fdt from FIT Image at 10000000 ...
Using 'conf@socfpga_cyclone5_mcvevk.dtb' configuration
Trying 'fdt@socfpga_cyclone5_mcvevk.dtb' fdt subimage
Description: Flattened Device Tree blob
Created: 2017-12-05 15:47:10 UTC
Type: Flat Device Tree
Compression: uncompressed
Data Start: 0x10378758
Data Size: 26032 Bytes = 25.4 KiB
Architecture: ARM
Hash algo: sha1
Hash value: 2b3a9d68c6aa9cc3ed67951682a0ba63dae2fbf4
Verifying Hash Integrity ... sha1+ OK
Booting using the fdt blob at 0x10378758
Loading Kernel Image ... OK
reserving fdt memory region: addr=0 size=1000
Loading Device Tree to 03ff6000, end 03fff5af ... OK
Starting kernel ...
Unitil the login prompt appears:
No lease, forking to background
done.
Starting system message bus: dbus.
Starting OpenBSD Secure Shell server: sshd
done.
Starting rpcbind daemon...done.
starting statd: done
Starting atd: OK
hwclock: can't open '/dev/misc/rtc': No such file or directory
exportfs: can't open /etc/exports for reading
NFS daemon support not enabled in kernel
Starting system log daemon...0
Starting kernel log daemon...0
Starting crond: OK
umount: /mnt/.psplash: not mounted.
Poky (Yocto Project Reference Distro) 2.4 mcvevk /dev/ttyS0
mcvevk login:
MCV now runs your newly programmed image.
14 Chapter 3. Update eMMC Memory

CHAPTER
FOUR
RECOVERY
Recovery for software components on MCV.
4.1 Modify boot settings
Close Jumper P32 on MCVEVP.
4.2 Connect USB Blaster and USB A-miniB cable
On MCVEVP connect the USB blaster to header P8 (pin 1 of P8 is closest to the SoM) and to a host PC. Connect the
USB A-miniB cable to the USB miniB connector P201 and a host PC.
4.3 Open a Console
Open a console2 on your host PC and start kermit/minicom, connect to your target:
mcv@aries-lp-01:~$ minicom
Willkommen zu minicom 2.7
Optionen: I18n
Übersetzt am Feb 7 2016, 13:37:27.
Port /dev/ttyUSB0, 12:10:31
Drücken Sie CTRL-A Z für Hilfe zu speziellen Tasten
4.4 Power up the board
Connect power supply to the board. The board will produce no console output, yet.
4.5 Start Quartus Programmer
Start Altera Quartus II software , from the Tools drop-down menu, select the “Programmer” tool. In the newly invoked
“Programmer”:
15

MCV Quick Start Guide, Release 2
1. Click ‘Auto-Detect’ in the left hand panel
2. In the ‘Select Device’ dialog, select ‘5CSXFC2C6’ or ‘5CSXFC6C6’ (depending on the SoM) and click OK
3. In the top part of main pane, right-click ‘5CSXFC2C6’ or ‘5CSXFC6C6’ (depending on the SoM) and select
‘Change File’
4. In the ‘Select New Programming File’, select the file ‘Recovery-C2.sof’ or ‘Recovery-C6.sof’ (depending on
the SoM).
5. In the top part of main pane, check the ‘Program/Configure’ box for the ‘5CSXFC2C6’ or ‘5CSXFC6C6’
(depending on the SoM)
6. Click ‘Start’ in the left hand panel
Note
Please contact ARIES Embedded to obtain your version of the correct rescue image for MCV.
4.6 Use USB Mass Storage
After the programming finished, the board comes up and immediately starts USB Mass Storage mode. The USB Mass
Storage is backed by the eMMC integrated on the MCV SoM. The host PC will detect a new USB storage device,
which can be used as a regular USB stick. The data on the eMMC can be read and written using usual methods.
Installation of a new software image from the host PC to the MCVEVK is performed using the usual:
=> dd if=software_image.img of=/dev/sdX
16 Chapter 4. Recovery
