MSI PRO H610M-G DDR4 User manual

PRO H610M-G DDR4
PRO H610M-B DDR4
PRO B660M-E DDR4
B660M BOMBER DDR4
H610M BOMBER DDR4
Motherboard
User Guide
󻺞󼒛󻡷󻼎
Manuel d’utilisation
Benutzerhandbuch

󱣎󵭡󳩿󱱧
󱣎󵭡󳩿󱱥
󲀮󾉣󸔆󴃬󴉩

1
Thank you for purchasing the MSI® motherboard. This User Guide gives
information about board layout, component overview, BIOS setup and software
installation.
Contents
Safety Information........................................................................................................ 2
Specifications................................................................................................................ 3
Special Features........................................................................................................... 6
Back Panel Connectors ............................................................................................... 7
LAN Port LED Status Table .................................................................................... 7
Overview of Components............................................................................................. 8
CPU Socket ............................................................................................................. 9
DIMM Slots............................................................................................................ 10
M2_WIFI1: M.2 Slot (Key E) .................................................................................. 10
PCI_E1~2: PCIe Expansion Slots.......................................................................... 11
JFP1, JFP2: Front Panel Connectors................................................................... 11
M2_1: M.2 Slot (Key M)......................................................................................... 12
SATA5~8: SATA 6Gb/s Connectors....................................................................... 12
CPU_PWR1, ATX_PWR1: Power Connectors....................................................... 13
JAUD1: Front Audio Connector ............................................................................ 14
CPU_FAN1, SYS_FAN1: Fan Connectors............................................................. 14
JCI1: Chassis Intrusion Connector....................................................................... 15
JBAT1: Clear CMOS (Reset BIOS) Jumper........................................................... 15
JUSB2: USB 3.2 Gen 1 Connector ........................................................................ 16
JUSB1: USB 2.0 Connector .................................................................................. 16
JTPM1: TPM Module Connector........................................................................... 17
JRGB1: RGB LED connector ................................................................................ 17
JRAINBOW1~2: Addressable RGB LED connectors ........................................... 18
EZ Debug LED....................................................................................................... 18
Installing OS, Drivers & MSI Center.......................................................................... 19
UEFI BIOS.................................................................................................................... 20
BIOS Setup............................................................................................................ 21
Resetting BIOS...................................................................................................... 22
Updating BIOS....................................................................................................... 22

2
Safety Information
The components included in this package are prone to damage from electrostatic
discharge (ESD). Please adhere to the following instructions to ensure successful
computer assembly.
Ensure that all components are securely connected. Loose connections may cause
the computer to not recognize a component or fail to start.
Hold the motherboard by the edges to avoid touching sensitive components.
It is recommended to wear an electrostatic discharge (ESD) wrist strap when
handling the motherboard to prevent electrostatic damage. If an ESD wrist strap
is not available, discharge yourself of static electricity by touching another metal
object before handling the motherboard.
Store the motherboard in an electrostatic shielding container or on an anti-static
pad whenever the motherboard is not installed.
Before turning on the computer, ensure that there are no loose screws or metal
components on the motherboard or anywhere within the computer case.
Do not boot the computer before installation is completed. This could cause
permanent damage to the components as well as injury to the user.
If you need help during any installation step, please consult a certified computer
technician.
Always turn off the power supply and unplug the power cord from the power outlet
before installing or removing any computer component.
Keep this user guide for future reference.
Keep this motherboard away from humidity.
Make sure that your electrical outlet provides the same voltage as is indicated on
the PSU, before connecting the PSU to the electrical outlet.
Place the power cord such a way that people can not step on it. Do not place
anything over the power cord.
All cautions and warnings on the motherboard should be noted.
If any of the following situations arises, get the motherboard checked by service
personnel:
• Liquid has penetrated into the computer.
• The motherboard has been exposed to moisture.
• The motherboard does not work well or you can not get it work according to user
guide.
• The motherboard has been dropped and damaged.
• The motherboard has obvious sign of breakage.
Do not leave this motherboard in an environment above 60°C (140°F), it may damage
the motherboard.

3
Specifications
CPU
Supports 12th Gen Intel® Core™ Processors, Pentium®
Gold and Celeron® Processors
Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new processors
are released.
Chipset
Intel® B660 Chipset (PRO B660M-E DDR4/ B660M BOMBER
DDR4)
Intel® H610 Chipset (PRO H610M-G DDR4/ PRO H610M-B
DDR4/ H610M BOMBER DDR4)
Memory
2x DDR4 memory slots, support up to 64GB*
Supports 1R 2133/ 2666/ 3200 MHz (by JEDEC & POR)
Max overclocking frequency: (For B660 chipset only)
• 1DPC 1R Max speed up to 4600+ MHz
• 1DPC 2R Max speed up to 4000+ MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP) (For B660
chipset only)
* Please refer to www.msi.com for more information on compatible memory.
Expansion Slots
1x PCIe x16 slot (From CPU)
• Supports up to PCIe 4.0 x16
1x PCIe x1 slot (From B660/ H610 chipset)
• Supports PCIe 3.0 x1
1x M.2 slot with E-key for PCIe WiFi module only (M2_
WIFI1)(For PRO H610M-G DDR4 & PRO H610M-B DDR4)
Onboard Graphics
1x HDMI 2.1 with HDR port, supports a maximum
resolution of 4K 60Hz*/**
1x VGA port, supports a maximum resolution of
2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz*/**
1x DisplayPort 1.4 port, supports a maximum resolution of
4K 60Hz*/**
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
SATA Ports 4x SATA 6Gb/s ports (From B660/ H610 chipset)*
* SATA7 will be unavailable when installing M.2 SATA SSD in the M2_1 slot.
Continued on next page

4
Continued from previous page
M.2 SSD Slot
1x M.2 slot (Key M, from B660/ H610 chipset)*
• Supports up to PCIe 3.0 x4
• Supports up to SATA 6Gb/s
• Supports 2242/ 2260/ 2280 storage devices
• Support Intel® Optane™ Memory (For B660 chipset)
• Supports Intel® Smart Response Technology for Intel
Core™ processors
* SATA7 will be unavailable when installing M.2 SATA SSD in the M2_1 slot.
RAID Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices (For B660 chipset)
Audio Realtek® ALC892/ ALC897 Codec
7.1-Channel High Definition Audio
LAN 1x Intel® I219V 1Gbps LAN controller
Power Connectors 1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
Internal USB
Connectors
1x USB 3.2 Gen 1 5Gbps connector (From B660/ H610
chipset)
• Supports additional 2 USB 3.2 Gen 1 5Gbps ports
1x USB 2.0 connector (From B660/ H610 chipset)
• Supports additional 2 USB 2.0 ports
Fan Connectors 1x 4-pin CPU fan connector
1x 4-pin system fan connector
System Connectors
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
Jumpers 1x Clear CMOS jumper
LED Features
1x 4-pin RGB LED connector (For PRO H610M-G DDR4
only)
2x 3-pin RAINBOW LED connectors (For PRO H610M-G
DDR4 only)
4x EZ Debug LED
Continued on next page

5
Continued from previous page
Back Panel
Connectors
1x HDMI port
1x VGA port
1x DisplayPort port (For PRO H610M-G DDR4 only)
1x PS/2 keyboard/ mouse combo port
4x USB 2.0 Type-A ports (From B660/ H610 chipset)
2x USB 3.2 Gen 1 5Gbps Type-A ports (From B660/ H610
chipset)
1x LAN (RJ45) jack
3x audio jacks
I/O Controller NUVOTON NCT5887D-M Controller Chip
Hardware Monitor
CPU/ System/ Chipset temperature detection
CPU/ System/ Pump fan speed detection
CPU/ System/ Pump fan speed control
Form Factor M-ATX Form Factor
9.3 in. x 8.0 in. (24.4 cm x 21.1 cm)
BIOS Features
1x 256 Mb flash
UEFI AMI BIOS
ACPI 6.4, SMBIOS 3.4
Multi-language
Software
Drivers
MSI Center
Intel Extreme Tuning Utility
CPU-Z MSI GAMING
Google Chrome™, Google Toolbar, Google Drive
Norton™ Internet Security Solution

6
Special Features
MSI Center Features
• Mystic Light (For PRO H610M-G
DDR4 only)
• LAN Manager
• User Scenario
• Hardware Monitor
• Frozr AI Cooling
• True Color
• Live Update
• Speed Up
• Super Charger
Audio
• Audio Boost
Network
• LAN Manager
LED
• Mystic Light Extension (RAINBOW/
RGB) (For PRO H610M-G DDR4 only)
• Mystic Light SYNC (For PRO
H610M-G DDR4 only)
• Ambient Devices Support (For PRO
H610M-G DDR4 only)
• EZ DEBUG LED
Performance
• Memory Boost
• Core Boost
• Lightning Gen 4 PCI-E Slot
Protection
• PCI-E Steel Armor
Experience
• Click BIOS 5
• EZ M.2 Clip
• CPU Cooler Tuning

7
Back Panel Connectors
1
8 8
2 3 4 5 76
Item Description
1HDMI port
2 VGA port
3 DisplayPort (For PRO H610M-G DDR4 only)
4 PS/2 keyboard/ mouse combo port
5 USB 3.2 Gen 1 5Gbps Type-A ports (From B660/ H610 chipset)
6 1 Gbps LAN ports
7 Audio jacks
8 USB 2.0 Type-A ports (From B660/ H610 chipset)
LAN Port LED Status Table
Link/ Activity LED
Status Description
Off No link
Yellow Linked
Blinking Data activity
Speed LED
Status Speed
Off 10 Mbps
Green 100 Mbps
Orange 1 Gbps

8
BAT1
JUSB2
ATX_PWR1
SYS_FAN1
CPU_FAN1


Processor
Socket
CPU_PWR1
JFP2 JTPM1
JCOM1
JRAINBOW2**
JBAT1 JUSB1 JRGB1** JAUD1
PCI_E2
*M2_WIFI1
PCI_E1
JCI1
M2_1
JFP1
DIMMB1
JRAINBOW1**
DIMMA1
Overview of Components
* M2_WIFI1 (For PRO H610M-G DDR4/ PRO H610M-B DDR4)
** JRAINBOW1, JRAINBOW2 and JRGB1 (For PRO H610M-G DDR4)
(For PRO H610M-G
DDR4 only)

9

Important
 Always unplug the power cord from the power outlet before installing or removing
the CPU.
 Please retain the CPU protective cap after installing the processor. MSI will deal
with Return Merchandise Authorization (RMA) requests if only the motherboard
comes with the protective cap on the CPU socket.
 When installing a CPU, always remember to install a CPU heatsink. A CPU heatsink
is necessary to prevent overheating and maintain system stability.
 Confirm that the CPU heatsink has formed a tight seal with the CPU before booting
your system.
 Overheating can seriously damage the CPU and motherboard. Always make sure the
cooling fans work properly to protect the CPU from overheating. Be sure to apply an
even layer of thermal paste (or thermal tape) between the CPU and the heatsink to
enhance heat dissipation.
 Whenever the CPU is not installed, always protect the CPU socket pins by covering
the socket with the plastic cap.
 If you purchased a separate CPU and heatsink/ cooler, Please refer to the
documentation in the heatsink/ cooler package for more details about installation.
CPU Socket
Please install the CPU into the CPU socket as shown below.
1
23
4
5
6
7
8
9

10
DIMM Slots
Please install the memory module into the DIMM slot as shown below.

Important
 To ensure system stability for Dual channel mode, memory modules must be of the
same type, number and density.
 Some memory modules may operate at a lower frequency than the marked value
when overclocking due to the memory frequency operates dependent on its Serial
Presence Detect (SPD). Go to BIOS and find the DRAM Frequency to set the memory
frequency if you want to operate the memory at the marked or at a higher frequency.
 It is recommended to use a more efficient memory cooling system for full DIMMs
installation or overclocking.
 The stability and compatibility of installed memory module depend on installed CPU
and devices when overclocking.
 Please refer to www.msi.com for more information on compatible memory.
132
2
M2_WIFI1: M.2 Slot (Key E, for PRO H610M-G DDR4 &
PRO H610M-B DDR4 )
Please install PCIe Wi-Fi module into M2_WIFI1 slot as shown below.
30º
30º
13
2

11
BAT1
PCI_E1~2: PCIe Expansion Slots
PCI_E1: PCIe 4.0 x16 (From CPU)
PCI_E2: PCIe 3.0 x1 (From B660/ H610 chipset)

Important
 If you install a large and heavy graphics card, you need to use a tool such as MSI
Graphics Card Bolster to support its weight to prevent deformation of the slot.
 When adding or removing expansion cards, always turn off the power supply and
unplug the power supply power cable from the power outlet. Read the expansion
card’s documentation to check for any necessary additional hardware or software
changes.
JFP1, JFP2: Front Panel Connectors
The JFP1 connector controls the power on, power reset, and the LEDs on your PC
case/chassis. Power Switch/ Reset Switch headers allow you to connect power button/
reset button. Power LED header connects to LED light on the PC case, and HDD LED
header indicates the activity of the hard disk. The JFP2 connector is for Buzzer and
Speaker. To connect the cables from PC case to the right pins, please refer to the
following images below.
1
2 10
9
Power LED
Reserved
Power Switch
JFP1
Reset SwitchHDD LED
1
JFP2
Buzzer
Speaker

Important
Please note that Power LED and HDD LED have positive and negative connection,
you need to link up the cable to the corresponding positive and negative port on the
motherboard. Otherwise, LEDs won’t work properly.

12
30º30º
M2_1: M.2 Slot (Key M)
Please install the M.2 solid-state drive (SSD) into the M.2 slot as shown below.
1
3
4
2
SATA5~8: SATA 6Gb/s Connectors
These connectors are SATA 6Gb/s interface ports. Each connector can connect to one
SATA device.
SATA5
SATA7
SATA6
SATA8

Important
 Please do not fold the SATA cable at a 90-degree angle. Data loss may result during
transmission otherwise.
 SATA cables have identical plugs on either sides of the cable. However, it is
recommended that the flat connector be connected to the motherboard for space
saving purposes.
 SATA7 will be unavailable when installing M.2 SATA SSD in the M2_1 slot.

13

Important
Make sure that all the power cables are securely connected to a proper ATX power
supply to ensure stable operation of the motherboard.
CPU_PWR1, ATX_PWR1: Power Connectors
These connectors allow you to connect an ATX power supply.
CPU_PWR1
Pin Signal Name Pin Signal Name
1 Ground 2 Ground
3 Ground 4 Ground
5 +12V 6 +12V
7 +12V 8 +12V
ATX_PWR1
Pin Signal Name Pin Signal Name
1 +3.3V 2 +3.3V
3 Ground 4 +5V
5 Ground 6 +5V
7 Ground 8 PWR OK
9 5VSB 10 +12V
11 +12V 12 +3.3V
13 +3.3V 14 -12V
15 Ground 16 PS-ON#
17 Ground 18 Ground
19 Ground 20 Res
21 +5V 22 +5V
23 +5V 24 Ground
5
4 1
8
CPU_PWR1
24
131
12
ATX_PWR1

14
JAUD1: Front Audio Connector
This connector allows you to connect audio jacks on the front panel.
1
2 10
9
Pin Signal Name Pin Signal Name
1 MIC L 2 Ground
3 MIC R 4 NC
5 Head Phone R 6 MIC Detection
7 SENSE_SEND 8 No Pin
9 Head Phone L 10 Head Phone Detection
CPU_FAN1, SYS_FAN1: Fan Connectors
Fan connectors can be classified as PWM (Pulse Width Modulation) Mode or DC Mode.
PWM Mode fan connectors provide constant 12V output and adjust fan speed with
speed control signal. DC Mode fan connectors control fan speed by changing voltage.
1
PWM Mode pin definition
Pin Signal Name Pin Signal Name
1 Ground 2 +12V
3 Sense 4 Speed Control Signal
1
DC Mode pin definition
Pin Signal Name Pin Signal Name
1 Ground 2 Voltage Control
3 Sense 4 NC
Fan connector specifications
Connector Default fan mode Max. current Max. power
CPU_FAN1 PWM mode 2A 24W
SYS_FAN1 DC mode 2A 24W

Important
You can adjust fan speed in BIOS > HARDWARE MONITOR.

15
JCI1: Chassis Intrusion Connector
This connector allows you to connect the chassis intrusion switch cable.
JBAT1: Clear CMOS (Reset BIOS) Jumper
There is CMOS memory onboard that is external powered from a battery located on
the motherboard to save system configuration data. If you want to clear the system
configuration, set the jumpers to clear the CMOS memory.
Keep Data
(default)
Clear CMOS/
Reset BIOS
Resetting BIOS to default values
1. Power off the computer and unplug the power cord.
2. Use a jumper cap to short JBAT1 for about 5-10 seconds.
3. Remove the jumper cap from JBAT1.
4. Plug the power cord and Power on the computer.
Normal
(default)
Trigger the chassis
intrusion event
Using chassis intrusion detector
1. Connect the JCI1 connector to the chassis intrusion switch/ sensor on the chassis.
2. Close the chassis cover.
3. Go to BIOS > SETTINGS > Security > Chassis Intrusion Configuration.
4. Set Chassis Intrusion to Enabled.
5. Press F10 to save and exit and then press the Enter key to select Yes.
6. Once the chassis cover is opened again, a warning message will be displayed on
screen when the computer is turned on.
Resetting the chassis intrusion warning
1. Go to BIOS > SETTINGS > Security > Chassis Intrusion Configuration.
2. Set Chassis Intrusion to Reset.
3. Press F10 to save and exit and then press the Enter key to select Yes.

16
JUSB2: USB 3.2 Gen 1 Connector
This connector allows you to connect USB 3.2 Gen 1 5Gbps ports on the front panel.

Important
Note that the Power and Ground pins must be connected correctly to avoid possible
damage.
Pin Signal Name Pin Signal Name
1 Power 2 USB3_RX_DN
3 USB3_RX_DP 4 Ground
5 USB3_TX_C_DN 6 USB3_TX_C_DP
7 Ground 8 USB2.0-
9 USB2.0+ 10 Ground
11 USB2.0+ 12 USB2.0-
13 Ground 14 USB3_TX_C_DP
15 USB3_TX_C_DN 16 Ground
17 USB3_RX_DP 18 USB3_RX_DN
19 Power 20 No Pin
1
10 11
20
JUSB1: USB 2.0 Connector
This connector allows you to connect USB 2.0 ports on the front panel.

Important
 Note that the VCC and Ground pins must be connected correctly to avoid possible
damage.
 In order to recharge your iPad, iPhone and iPod through USB ports, please install
MSI Center utility.
Pin Signal Name Pin Signal Name
1 VCC 2 VCC
3 USB0- 4 USB1-
5 USB0+ 6 USB1+
7 Ground 8 Ground
9 No Pin 10 NC
1
2 10
9

17
JTPM1: TPM Module Connector
This connector is for TPM (Trusted Platform Module). Please refer to the TPM security
platform manual for more details and usages.
Pin Signal Name Pin Signal Name
1 SPI Power 2 SPI Chip Select
3Master In Slave Out
(SPI Data) 4Master Out Slave In (SPI Data)
5 Reserved 6 SPI Clock
7 Ground 8 SPI Reset
9 Reserved 10 No Pin
11 Reserved 12 Interrupt Request
1
2 12
11

Important
 The JRGB connector supports up to 2 meters continuous 5050 RGB LED strips
(12V/G/R/B) with the maximum power rating of 3A (12V).
 Always turn off the power supply and unplug the power cord from the power outlet
before installing or removing the RGB LED strip.
 Please use MSI’s software to control the extended LED strip.
JRGB1: RGB LED connector (For PRO H610M-G DDR4)
The JRGB connector allows you to connect the 5050 RGB LED strips 12V.
Pin Signal Name Pin Signal Name
1 +12V 2 G
3 R 4 B
1

18

CAUTION
Do not connect the wrong type of LED strips. The JRGB connector and the JRAINBOW
connector provide different voltages, and connecting the 5V LED strip to the JRGB
connector will result in damage to the LED strip.

Important
 The JRAINBOW connector supports up to 75 LEDs WS2812B Individually
Addressable RGB LED strips (5V/Data/Ground) with the maximum power rating of
3A (5V). In the case of 20% brightness, the connector supports up to 200 LEDs.
 Always turn off the power supply and unplug the power cord from the power outlet
before installing or removing the RGB LED strip.
 Please use MSI’s software to control the extended LED strip.
JRAINBOW1~2: Addressable RGB LED connectors (For
PRO H610M-G DDR4)
The JRAINBOW connectors allow you to connect the WS2812B Individually
Addressable RGB LED strips 5V.
Pin Signal Name Pin Signal Name
1 +5V 2 Data
3 No Pin 4 Ground
1
EZ Debug LED
These LEDs indicate the status of the motherboard.
CPU - indicates CPU is not detected or fail.
DRAM - indicates DRAM is not detected or fail.
VGA - indicates GPU is not detected or fail.
BOOT - indicates booting device is not detected or fail.

19
Installing OS, Drivers & MSI Center
Please download and update the latest utilities and drivers at www.msi.com
Installing Windows 10/ Windows 11
1. Power on the computer.
2. Insert the Windows 10/ Windows 11 installation disc/USB into your computer.
3. Press the Restart button on the computer case.
4. Press F11 key during the computer POST (Power-On Self Test) to get into Boot
Menu.
5. Select the Windows 10/ Windows 11 installation disc/USB from the Boot Menu.
6. Press any key if screen shows Press any key to boot from CD or DVD... message. If
not, please skip this step.
7. Follow the instructions on the screen to install Windows 10/ Windows 11.
Installing Drivers
1. Start up your computer in Windows 10/ Windows 11.
2. Insert MSI® USB Drive into the USB port.
3. Click the Select to choose what happens with this disc pop-up notification, then
select Run DVDSetup.exe to open the installer. If you turn off the AutoPlay feature
from the Windows Control Panel, you can still manually execute the DVDSetup.exe
from the root path of the MSI USB Drive.
4. The installer will find and list all necessary drivers in the Drivers/Software tab.
5. Click the Install button in the lower-right corner of the window.
6. The drivers installation will then be in progress, after it has finished it will prompt
you to restart.
7. Click OK button to finish.
8. Restart your computer.
MSI Center
MSI Center is an application that helps you easily optimize game settings and
smoothly use content creation softwares. It also allows you to control and synchronize
LED light effects on PCs and other MSI products. With MSI Center, you can customize
ideal modes, monitor system performance, and adjust fan speed.
MSI Center User Guide
If you would like to know more information about MSI Center, please refer to
http://download.msi.com/manual/mb/MSICENTER.pdf
or scan the QR code to access.

Important
Functions may vary depending on the product you have.
