ARIETE 3017 User manual

Owner’s Manual
COFFEE GRINDER

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
FEATURES
Grind Thickness
Control Dial
Bean Hopper
Ground Coee
Container
Ground Coee
Container Lid
Grinder
Head
Coffee
Grinder
Body
Container
Holder
Bean Hopper
Release Button
Bean Hopper
Holder
CoeePowder
Outlet
Grinding
Timer Dial
Grinder
Start/Stop
Button
Bean Hopper
Lid

pg 1
IMPORTANT SAFEGUARDS
This appliance is for HOUSEHOLD USE ONLY.
When using an electrical appliance, basic safety precautions should always
be taken, including the following:
1. READ ALL INSTRUCTIONS BEFORE USE.
2. Before use check that the voltage of wall outlet correspond to the one
shown on the rating plate.
3. Do not operate any appliance with a damaged cord or plug or aer
the appliance malfunctions, or is dropped or damaged in any manner.
Return appliance to the nearest authorized service facility for
examination, repair or electrical or mechanical adjustment.
4. If the supply cord is damaged it must be replaced by the manufacturer
or a authorized agent or a qualied technician in order to avoid a hazard.
5. Unplug from outlet when not in use, before putting on or taking o
parts, and before cleaning.
6. Do not let cord hang over edge of table or hot surface.
7. Do not immerse the motorized base in liquid, or place in dishwasher.
Damage to the unit will occur if submerged in liquid or lling the liquid
into the container. Only the top cover may be immersed.
8. Close supervision is necessary when your appliance is being used near
children or inrm persons.
9. Ensure ngers are kept well away from moving parts.
10. Do not remove cover until blade has completely stopped.
11. Do not attempt operation without the cover being in place.
12. The use of accessory not recommended by the manufacturer may cause
injuries to persons.
13. Check grinding chamber for presence of foreign objects before using.
14. This appliance is not intended for used by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction con-cerning use of the appliances by a person responsible for
their safety.
15. Children should be supervised to ensure that they do not play
with the appliance.
16. Do not operate the appliance for other than its intended use.
17. Do not use outdoors.
SAVE THESE INSTRUCTIONS

pg 2
OPERATION
BEFORE FIRST USE
1. Place the coee grinder on a at surface.
2. Ensure that the Grinder Head is in position inside the Bean
Hopper Holder. If it has been removed simply take the
Grinder Head by its handle, align the grove on the Grinding
Wheel with the tab in the grinding
chamber. Rotate the Grinding Wheel
clockwise until it locks into position.
(See img 1).
1. Carefully unpack your coee grinder and remove all packing
materials.
2. Remove any dust that may have accumulated during
packaging.
3. It is advisable to rst wash all removable parts: the Bean
Hopper, Bean Hop-per Lid, Ground Coee Container Lid And
Ground Coee Container with warm soapy water and so
cloth. Rinse and dry thoroughly.
4. To detach the Bean Hopper press down the Bean Hopper
Release Button and simultaneously turn the bean hopper
counter-clockwise.
5. Aer use, rinse the Bean Hopper, Bean Hopper Lid, Ground
Coee Container Lid And Ground Coee Container with
water and then dry thoroughly.
CAUTION: Never immerse the grinder body in water for cleaning
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
7
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Img 1
Grinder
Blade
Tab
Groove
Grinder
Head

pg 3
3. Attach the Bean Hopper to the Bean Hopper Holder: To
attach the Bean Hopper, align the tab on the bottom of
the Bean Hopper to the groove on the bean hopper holder
and then turn the Bean Hopper clockwise until it locks into
position. (See Img 2).
4. Pour appropriate amount of coee
beans into the bean hopper. Do not
ll the hopper with more than 2.5
cups. NOTE: This grinder can only
grind dry, brittle foods. It will not
grind anything moist, extremely hard
or gummy, such as whole ginger,
chocolate, sesame seeds or oily spices
such as cinnamon, cloves or nutmeg.
Do not grind peanuts or grains such
as wheat, rice, barley, or dried corn.
Attempting to grind any of these
foods may damage the unit. Never use
it to chop ice cubes.
NOTE: If the appliance is run without coee beans, the
appliance will stop working aer about 5 minutes. For every
5 minutes of continuous use the appliance must rest for 30
minutes.
5. Close the bean hopper lid.
6. Slide the Ground Coee Container (with
lid) in position (See Img 3) on the Container
Holder. Make sure the opening on the
Ground Coee Container aligns with the
Coee Powder Outlet.
7. The Grinder Control Dial enables
you to select the texture of your
ground coee. Select from 1 for a
very ne grind, up to 15 for a coarse
grind. Note: When dialing down to a ner grain, the unit
will only allow a maximum of 5 steps at a time. Aer every 5
steps start and stop the grinder for a few moments and then
continue dialing down.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
7
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Tab
Groove
Img 2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
8
USING YOUR COFFEE GRINDER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
8
USING YOUR COFFEE GRINDER
Img 3

pg 4
8. The amount of coee dispensed is
determined by the Grinding Timer Dial
(See Img 4). Refer to the table below to
select your desired grinding time and
grind setting. When selected, the indicator
of your selected grinding time will light
at 100% brightness. If you don’t adjust
the grinding time, the appliance will
work under the default grinding time
(Continuous Grind).
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
8
USING YOUR COFFEE GRINDER
Img 4
10 20 30 40
50
Continuous
Grind
GRIND
SETTING GRIND TIME
IN SECONDS
10 20 30 40 50
14 Tbsp 8 Tbsp 12 Tbsp 16 Tbsp 20 Tbsp
24 Tbsp 9 Tbsp 13 Tbsp 17 Tbsp 22 Tbsp
34 Tbsp 10 Tbsp 14 Tbsp 18 Tbsp 24 Tbsp
45 Tbsp 10 Tbsp 15 Tbsp 19 Tbsp 25 Tbsp
55 Tbsp 10 Tbsp 16 Tbsp 20 Tbsp 26 Tbsp
65 Tbsp 11 Tbsp 17 Tbsp 22 Tbsp 27 Tbsp
75 Tbsp 11 Tbsp 17 Tbsp 23 Tbsp 30 Tbsp
86 Tbsp 13 Tbsp 19 Tbsp 24 Tbsp 31 Tbsp
97 Tbsp 13 Tbsp 20 Tbsp 26 Tbsp 33 Tbsp
10 7 Tbsp 13 Tbsp 20 Tbsp 26 Tbsp 33 Tbsp
11 8 Tbsp 14 Tbsp 22 Tbsp 30 Tbsp 37 Tbsp
12 8 Tbsp 15 Tbsp 24 Tbsp 30 Tbsp 38 Tbsp
13 8 Tbsp 17 Tbsp 25 Tbsp 32 Tbsp 40 Tbsp
14 8 Tbsp 18 Tbsp 26 Tbsp 36 Tbsp 47 Tbsp
15 8 Tbsp 18 Tbsp 26 Tbsp 36 Tbsp 47 Tbsp
NOTE: The measurements in the table above are an approximation and may
vary. 1-2 Tbsp of ground coee is recommended per 6 oz of water. Depending on
the type of brew you make will determine the size of grind you need (refer to the
table on pg 6).

pg 5
9. Connect the appliance to the power source. The rst
indicator (the default grinding time setting) will light up at
100% brightness while the other indicators and the indicator
of Start/Stop button light up at 50% brightness. Select your
desired grinding time based on your needs. Press the Start/
Stop button. The appliance will begin to grind your coee
beans. The coee powder will dispense the ground coee
beans from the coee powder outlet into the Ground Coee
Container. The indicator Start/Stop button keeps blinking
during grinding process. NOTE: The appliance will enter into
a sleep state if no operation is selected within 90 seconds of it
being plugged in.
10. When the desired grinding time has been reached, the
coee grinder will stop working automatically and go back
to standby mode, at that time, the rst indicator (the default
grinding time setting) lights at 100% brightness while the
other indicators and the indicator of Start/Stop button light
at 50% brightness. NOTE: The maximum amount of ground
coee in container is 155g.
11. Remove the ground coee container from its holder, remove
lid and pour out the ground coee. NOTE: The container is
very tight. Li and tilt the bottom out rst to remove.
12. Unplug the appliance.
NOTE: The appliance must rest for 30 minutes if operated for
5 minutes continuously. It is suggested that you operate this
appliance for less than 90 seconds at a time with a minimum 90
seconds rest time between cycles.
You may stop the appliance from running at any time during
the grinding process, by pressing the Start/Stop button.

pg 6
FLAVOR GRIND WATER TEMP BREW TIME
SOUR Finer Decrease Increase
BITTER Coarser Increase Decrease
TIPS FOR GRINDING
The size of grind will determine the avor of your coee depending
on the type of brew you use. If the grind is too big the avor will be
under-extracted causing a sour avor. If the grind is too small the
avor will be over-extracted causing a bitter avor. Refer to the
table below for troubleshooting grind size.
GRIND
SIZE
GRIND
SETTING
BREW
METHOD
Extra
Fine
1-2 Turkish Coee
Fine 3-4 Espresso machines with an electric pump.
Medium
Fine
5-6 Cone Shaped Pour Over Brewers, Aeropress
(with 2-3 Min Brew Time)
Medium 7-8 drip coee makers and steam-type espresso
machines.
Medium
Coarse
9-10 Chemex, Clever Dripper, Cafe Solo Brewer
Coarse 11-12 French Press, Percolator, Coee Cupping,
Coee Urns
Extra
Coarse
13-15 Cold Brew Coee, Cowboy Coee

pg 7
For the freshest, most avorful coee, grind only enough for the
pot you are making. Coee beans keep up to 2 months in the
freezer in an airtight container and can be ground while still
frozen. Coee grounds le in your grinder can become stale and
aect the avor of freshly ground coee. Be sure to clean grinding
chamber, blades and grinding wheel aer each use.
Freshly ground peppercorns have a strong aroma and taste that
may aect the avor of coee beans ground later. You may
want to purchase a separate grinder if you plan to grind a lot of
peppercorns.
CLEANING AND MAINTENANCE
CAUTION: Make sure to unplug this appliance before cleaning.
To protect against electrical shock, do not immerse cord,
plug or the appliance body in water or liquid. Aer each use,
always make sure to rst remove the plug from wall outlet.
1. Disassemble the bean hopper by pressing the bean hopper
release button and twisting the bean
hopper counter clockwise (see Img 5).
Rinse the bean hopper, bean hopper
lid, ground coee container and ground
coee container lid with warm soapy
water, and dry them thoroughly.
2. Li the handle of the Grinding Wheel and
rotate it counter-clockwise to remove it
from its base. Clean the grinding blades
with a brush, rinse it thoroughly with
warm water and then dry thoroughly.
Replace the grinding wheel back in
position.
CAUTION: Use extreme caution while handling and
cleaning the Grinding Wheel as the grinding blades are
sharp.
3. Wipe the body with wet cloth and then dry it completely.
When not in use, store appliance in a secure, dry and cool
place.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
8
USING YOUR COFFEE GRINDER
Img 5
Bean
Hopper
Release
Button

De'Longhi Appliances Srl
Divisione Commerciale Ariete
Via San Quirico, 300
50013 Campi Bisenzio (FI)
Email: [email protected] |Internet: www.ariete.net
