Aristel AN1801 User manual

AN1801 LTE - 4G Smoke Detector
Aristel Networks. E1.2 1/8
AN1801
LTE -4GCommunicator
withSmokeDetector
AccessoryforSmokeAlarm

AN1801 LTE - 4G Smoke Detector
Aristel Networks. E1.2 2/8
ImportantSafetyInstructions
Thisusermanualcontainsimportantguidelinesfortheinstallationandusageofthe LTEdevicein
combinationwiththeSD360smokealarm.
Pleasereadthemanualthoroughlybeforeyoustartusingthedevice.Itcontainsvitalinformation
onunitoperationandinstallation.Ifyouareinstallingthisdevicethemanualmustbegiventothe
householder.
Theusermustregularlychecktheproperfunctioningofthedevice.Themanufacturercannotbe
heldliableforanydamageorlosscausedbyanyincorrectuseorincorrectoperationofthe
device.
Incaseofdamagecausedbydisregardingtheguidelines,thewarrantybecomesinvalid.
Safetyguidelines
‧Theoperationtemperaturerangeisfrom0°Cto49°C(32°Fto120°F).
‧Thedeviceisintendedforuseindryandcleanplaceswitharesidentialfunction.
‧Protectthedevicefrommoisture,heatandwatersplashing.
‧Theguidelinesforthebatteryusagemustberegarded.
‧Donotexposethedevicetostrongvibrations.
‧Donotletitfallfromheight.
‧Donotuseinanenvironmentwhereanyinflammablegases,vaporsordustarepresentor
couldbepresent.
‧Repairofthedevicemayonlybecarriedoutbypeople,trainedforrepair.
‧Ifthedevicemustberepaired,onlyoriginalreplacementcomponentsmaybeused.
Useinaccordancewiththeregulations
ThepurposeofthisdeviceinaccordancewiththeregulationsissendingSMStextmessagesand
makingtelephonecallsafteranalarmsituation.Otherusesarenotpermittedandmayannulthe
warranty.
Productandbatteryrecycling
Whendisposingofthisproduct,separatetheproductandtheCR123Abatteriesfromotherwaste
streamstoensurethatitcanberecycledinanenvironmentallysoundmanner.Formore
informationoncollectionandproperdisposal,pleasecontactyourlocalgovernmentofficeorthe
retailerwhereyoupurchasedthisproduct.

AN1801 LTE -4G Smoke Detector
Aristel Networks . E1.2 3/8
TABLEOFCONTENTS
1. GENERAL DESCRIPTION ............................................................................................................ 4
2. GETTING STARTED ...................................................................................................................... 4
2.1 Open the cover ....................................................................................................................... 5
2.2 Insert a SIM card .................................................................................................................... 5
2.3 Insert the battery..................................................................................................................... 5
2.4 Close the cover ..................................................................................................................... 6
2.5 Insert the battery of SD360 .................................................................................................... 6
2.6 Mount the AN1801 to the ceiling ............................................................................................ 6
2.7 Set up by SMS and program at least one telephone number and perform a test ................... 7
3 SMS Command ................................................................................................................................. 8
4 Function Codes ................................................................................................................................. 8

AN1801 LTE - 4G Smoke Detector
Aristel Networks. E1.2 4/8
1. GENERALDESCRIPTION
The4GcommunicatorAN1801isabatteryoperated4Gmoduleusedtosendoutanalarmafter
theinputistriggeredbythesmokedetectorSD360.
The4GSmokeDetector, AN1801isacombinationoftheAN1801Radio module connectedwith a
SD360smokealarm. 
Thedefaultsettingsforstandarduseare:
‐  IncasetheoutputalarmofSD360smokedetectorisactivated,the4Gcommunicatorsends
analarmSMStextmessageandcallsthephonenumbersasprogrammedbytheuser.
‐  Incasethebatteriesneedtobereplaced,the4Gcommunicatorsendsa
｀batterylow＇ SMStextmessagetothephonenumbersasprogrammedbytheuser.
PleaserefertothemanualoftheSD360smokealarmforinstallationinstructionsandthe
descriptionofthebehaviorofthesmokealarm.
2. GETTINGSTARTED
TogetstartedwiththeAN1801atleastthefollowingstepsneedtobetakeninfollowingorder:
1. Openthecover
2. InsertaSIMcard(withoutPINcode)
3. InsertthebatteryonAN1801
4. Closethecover
5. InsertthebatteryofSD360
6. MounttheAN1801totheceiling
7. SetupbySMSandprogramatleastonetelephonenumberandperforma
test
8. LEDindicators
Thesestepsarefurtherexplainedinthischapter.

AN1801 LTE - 4G Smoke Detector
E1.2 5/8
2.1Openthecover
Pushthebottomsof3bucklesandopenthecover
2.2InsertaSIMcard
Pushtheblackcoveroutwardslightlytoopentheholder.BeforeinstallingtheSIMcardshould
havePINcoderemoved.InsertaSIMcardintothemodule.
(APINcodecanbechangedorremovedbyputtingtheSIMcardintoanymobilephoneand
enteringthe'security'menu).
Note:MakesuretheSIMcardisinsertedbeforethebatteriesareinserted.IncaseofaSIMcard
change,pleasefirstremovethebatteries(andremoveanyotherexternalpowersupply). 
2.3Insertthebattery
Insertthebatteries(CR123A)inthemodule.Usethe+/‐indicationforthecorrectplacement.
battery
SIM card
Fig 2
Fig 1

AN1801 LTE - 4G Smoke Detector
Aristel Networks . E1.2 6/8
2.4Closethecover(Fig3)
2.5InsertthebatteryofSD360
Insert the batteries in the SD360. Use the + / - indication for the correct placement.
2.6MounttheAN1801totheceiling
2.6.1 
MounttheBaseinwhichtheAN1801isfixedtothedesiredplacetotheceiling,andscrews
whichcanbefoundinsidetheAN1801box.PleaserefertothemanualoftheSD360smokealarm
fortheideallocationandinstallationinstructions.
2.6.2
BringtheAN1801andthebasemoduletoeachotheratthecorrectpositionandturnthe
detectorgentlyclockwiseuntilitisclosedandlocked. 
Fig 3 Fig 4
Fig 5 Fig 6

AN1801 LTE - 4G Smoke Detector
Aristel Networks . E1.2 7/8
2.7SetupbySMSandprogramatleastonetelephonenumberandperformatest
2.7.1Bootingupthedevice
Pressthetestbuttonfivetimestowakeupthe4Gmoduletobootupandentersstandby
mode.
2.7.2SettingSMScommand
YoucanprogrammanydifferentfunctioncodesinonetextmessagewithSMScommandformat.
*12*1234#[functionCode1]#[functionCode2]#[functionCode3]#........
(Pleasereferthepage8:3.SMSCommand&4.FunctionCodes)
2.7.3TestSmokeAlarm
Pressandholdthebuttonforaround4secondsuntilthehornsoundsduringstandby,AN1801
willautomaticallysendSMStoallthenumbersyousetthencalltoallnumbersinsequence.
SMScontentis“TestmodeAlarm”
Ifthedeviceisnotinstandbymode,pressthetestbuttonwillnotactivethe3Gmodule.  
Note:
Wake up 4G modules before
performing any SMS setup
and testing
Pressthetestbutton5times
Fig 7
Press and hold the button
Fig 8
2.7.4 
Whenthebatteryvoltageislow,AN1801willautomaticallysendSMStoallthenumbersyou
set.
Example:Storethenumbers,maximum3numbers.
1. SendthetextSMStothenumberofdevice.
2. TheformatoftextSMSis:
*12*1234#11[number1]#12[number2]#13[number3]#
3. Whenthesettingisfinished,thesenderwillreceivethereplyasbelow.
11
[
number1
]
#12
[
number2
]
#13
[
number3
]
#OK

AN1801 LTE - 4G Smoke Detector
Aristel Networks .
www.aristel.com.au
E1.2 8/8
2.8 LED Indicators
Status GreenLED BlueLED ModuleGreenLED(HideonPCB)
Bootingup 0.5sON/1.5sOFF OFF Unregisteredthenetwork:
0.5sON/0.5sOFF
Registeredthenetwork: 
0.3sON/2.7sOFF
Standby OFF 0.5sON/1.5sOFF
Notification OFF 0.1sON/0.1sOFF
nonumber 0.5sON/0.5sOFF 0.5sOFF/0.5sON
Sleep OFF OFF OFF
3. SMSCommand
FeatureSMSCommandDefaultSMScontentNOTE:
CheckDeviceVersion *20*[password] #
Checkstorednumbers *21*[password] #
Alarmcontent *30*[password] #[SMScontent]# SmokeAlarm ChecktheSMS
content,please
leftitempty. 
TestModecontent *31*[password] #[SMScontent]# TestmodeAlarm
LowBatterycontent *32*[password] #[SMScontent]# LowBattery
4. NotificationSMScontent
IssuesNotificationSMScontent
EnterTestMode(pressSwitch) TestmodeAlarm
Smokedetection SmokeAlarm
Batterylowvoltage LowBattery‐Detector/LowBattery‐Communicator
AutoReplySMS Module auto test
Smokerdetectorcaseopen Detector case is opene
d
Smokerdetectorcaseclose Detector case is close
d
5. FunctionCodes
You can program many different function Codes in one text message with programming SMS.
The programming SMS format: (the character limit for a single SMS is 160 characters)
*12*[Password] # [Function Code 1] # [Function Code 2] # [Function Code 3] #........
FeatureFunctionCodeDescriptionDefault
Modifypassword 01[password]# Passwordaccepts4digitsonly 1234
Storethenumbers 1[Y][phonenumber]# Y=phonenumber1,2or3
phonenumberaccepts3to15digits None
Deletestorednumbers 1[Y]*# Y=phonenumber1,2or3 None
Wakeupstandbytime 20[StandbyTime]# StandbyTime:1to20mins 3
Callwaitingtime 21[Callwaitingtime]# Callwaitingtime:10to99sec 20
Interval“AutoReplySMS” 22+[Time]#, Time:1to99days 30
Reset 999# Recoverythedefaultsettingvalues
Green&blueLEDflashinteractively.
NOTE:
1. Ifthepasswordiswrong,SMSreplyis"PasswordError".
2. IftheSMScommandiswrong,SMSreplyis"ControlCodeError".
3. Ifthefunctioncodeiswrong,SMSreplyis"2320#Error".
