Ariston NIV 320B User manual

1
NIV 320B lnduction Hob Instruction Manual

2
CONTENTS
IMPORTANT SAFETY INSTUCTIONS
p.3-8
SAFEGUARDING THE ENVIRONMENT
p.8
BEFORE USE
p.8
COOKWAVE
p.8
DESCRIPTIONS OF PRODUCT
p.9
DESCRIPTIONS OF CONTROL PANEL
p.10
INSTALLATION
p.10
ELECTRICAL CONNECTION
p.12-13
INSTRUCTIONS FOR USE
p.13-16
CLEANING
p.17
TROUBLESHOOTING GUIDE
p.17
POWER LEVEL TABLE
p.18

3
IMPORTANT SAFETY INSTUCTIONS
READ THESE INSTRUCTIONS CAREFULLY AND COMPLETELY BEFORE USING
YOUR APPLIANCE, AND KEEP IT IN A CONVENIENT PLACE FOR REFERENCE
WHEN NECESSARY.
THIS MANUAL IS PREPARED FOR MORE THAN ONE MODEL IN COMMON. YOUR
APPLIANCE MAY NOT HAVE SOME OF THE FEATURES THAT ARE EXPLAINED IN
THIS MANUAL. PAY ATTENTION TO THE EXPRESSIONS THAT HAVE FIGURES,
WHILE YOU ARE READING THE OPERATING MANUAL.
General Safety Warnings
- This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
-WARNING: The appliance and its accessible parts become hot
during use. Care should be taken to avoid touching heating
elements. Children less than 8 years of age shall be kept away

4
unless continuously supervised.
-WARNING: Unattended cooking on a hob with fat or oil can be
dangerous and may result in fire. NEVER try to extinguish a fire
with water, but switch off the appliance and then cover flame e.g.
with a lid or a fire blanket.
-WARNING: Danger of fire: do not store items on the cooking
surfaces.
-WARNING: If the surface is cracked, switch off the appliance to
avoid the possibility of electric shock.
- For induction hobs, metallic objects such as knives, forks,
spoons and lids should not be placed on the hob surface since
they can get hot.
- For induction hobs, after use, switch off the hob element by its
control and do not rely on the pan detector.
- For hobs incorporating a lid, any spillage should be removed
from the lid before opening. And also the hob surface should be
allowed to cool before closing the lid.
- The appliance is not intended to be operated by means of an
external timer or separate remote-control system.

5
- Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the oven door glass and other surface since they can
scratch the surface, which may result in shattering of the glass or
damage to the surface.
- Do not use steam cleaners for cleaning the appliance.
- Your appliance is produced in accordance with all applicable local and international
standards and regulations.
- Maintenance and repair work must be made only by authorized service technicians.
Installation and repair work that is carried out by unauthorized technicians may
endanger you. It is dangerous to alter or modify the specifications of the appliance in
any way.
- Prior to installation, ensure that the local distribution conditions (nature of the gas and
gas pressure or electricity voltage and frequency) and the requirements of the appliance
are compatible. The requirements for this appliance are stated on the label.
- CAUTION: This appliance is designed only for cooking food and is intended for indoor
domestic household use only and should not be used for any other purpose or in any
other application, such as for non-domestic use or in a commercial environment or
room heating.
- All possible security measures have been taken to ensure your safety. Since the glass

6
may break, you should be careful while cleaning to avoid scratching. Avoid hitting or
knocking on the glass with accessories.
- Ensure that the supply cord is not wedged during the installation. If the supply cord is
damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to prevent a hazard.
Installation Warnings
- Do not operate the appliance before it is fully installed.
- The appliance must be installed by an authorized technician and put into use. The
producer is not responsible for any damage that might be caused by defective
placement and installation by unauthorized people.
- When you unpack the appliance, make sure that it is not damaged during
transportation. In case of any defect; do not use the appliance and contact a qualified
service agent immediately. As the materials used for packaging (nylon, staplers,
styrofoam...etc) may cause harmful effects to children, they should be collected and
removed immediately.
- Protect your appliance against atmospheric effects. Do not expose it to effects such as
sun, rain, snow etc.
- The surrounding materials of the appliance (cabinet) must be able to withstand a
temperature of min 100°C.

7
- The temperature of the bottom surface of the hob might rises during the operation.
Therefore, a board must be installed underneath the product.
During usage
- Do not put flammable or combustible materials, in or near the appliance when it is
operating.
- Do not leave the cooker while cooking with solid or liquid oils. They may catch fire on
condition of extreme heating. Never pour water on to flames that are caused by oil.
Cover the saucepan or frypan with its cover in order to choke the flame that has occured
in this case and turn the cooker off.
- Always position pans over the centre of the cooking zone, and turn the handles to a
safe position so they cannot be knocked or grabbed.
- If you will not use the appliance for a long time, plug it off. Keep the main control
switch off. Also when you do not use the appliance, keep the gas valve off.
- Make sure the appliance control knobs are always in the "0" (stop) position when it is
not used.
During cleaning and maintenance
- Always turn the appliance off before operations such as cleaning or maintenance. You
can do it after plugging the appliance off or turning the main switches off.
- Do not remove the control knobs to clean the control panel.

8
TO MAINTAIN THE EFFICIENCY AND SAFETY OF YOUR APPLIANCE, WE RECOMMEND
YOU ALWAYS USE ORIGINAL SPARE PARTS AND TO CALL ONLY OUR AUTHORIZED
SERVICE AGENTS IN CASE OF NEED.
SAFEGUARDING THE ENVIRONMENT
Scrapping the product
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product.
Energy saving tips
For optimum results, it is advisable to:
-Use pots and pans with bottom width equal to that of the cooking zone.
-Only use flat-bottomed pots and pans.
-When possible, keep pot lids on during cooking.
-Use a pressure cooker to save even more energy and time.
-Place the pot in the middle of the cooking zone marked on the hob.
BEFORE USE
IMPORTANT: The cooking zones will not switch on if pots are not the right size. Only use pots
bearing the symbol “INDUCTION SYSTEM”. Place the pot on the required cooking zone before
switching the hob on.
COOKWAVE
-Use thick cookware with flat and smooth bottom. Cookware with same diameter as the
cooking zone will help reduce cooling times.
-Cookware made of enameled steel or aluminum or copper bottoms can cause a metallic
residue on the glass. Clean the hob after every use.
-Use a magnet to check if the pot is suitable for the induction hob: pots and pans are
unsuitable if not magnetically detectable.
-Cookware must be placed centrally on the cooking zone in order to work property.
-When using certain pans, you may get various noises from the pans, this is due to the
design of the pans and does not affect the performance or safety of the hob.

9
-The minimum cookware diameter that elements can detect are Q110mm for 160mm -
210mm hobs and Q160mm for 290mm hob. Cooking performance improves with the
increase of the diameter.
DESCRIPTIONS OF PRODUCT
Induction heating element
Control panel

10
DESCRIPTIONS OF CONTROL PANEL
INSTALLATION
After unpacking the product, check for any damage during transport. In the event of problems,
contact the dealer or the Whirlpool After-Sales Service.
- The electrical connection of this hob must be carried out by qualified
technician, according to the instructions in this user manual and in
compliance with the local regulations. In the event of any damage that
occurs as a result of improper connection or installation, the warranty will
not be valid.
- This appliance must be earthed.
Installation Safety
- Cookerhood needs to be installed at least 65cm above the hob.
- Extractor fans must be fitted in accordance with the manufacturer’s instructions.
- The wall in contact with the rear of the hob must be made of flameproof material.
Fitting the hob into a work surface
- The hob can be inserted into any worktop provided it is heat resistant up to at least 90°C.
- Induction hob may be built in 25 to 40mm thick worktops.
- Create an opening with the dimension shown in the pictures below.

11
Installation
1. Apply the one-sided self-adhesive sealing tape supplied all the way round the lower glass
edge of the cooking surface along the outer edge of the ceramic glass panel. Do not stretch
it.
2. Screw the 4 worktop mounting brackets on the side walls of product as picture shown
below.
3. Secure the hob in place by putting it into cutout on the work surface.
When installed above oven, it is necessary to remove the rear kitchen element panel in the area
of the oven opening, in order to supply ventilation. Also, the front part of the kitchen element
must have an opening of no less than 5 mm tall.
W (mm)
290
min. A (mm)
50
D (mm)
520
min. B (mm)
50
H (mm)
56
E (mm)
100
C1 (mm)
270
min. F (mm)
64
C2 (mm)
490
G (mm)
20

12
ELECTRICAL CONNECTION
- Disconnect the appliance from the power supply.
- Installation must be carried out by qualified personnel who know the
current safety and installation regulations.
- The manufacturer declines all liability for injury to persons or animals and for damage to
property resulting from failure to observe the regulations provided in this chapter.
- The power cable must be positioned away from direct heat sources and long enough to allow
the hob to be removed from the worktop.
- Make sure the voltage specified on the data plate located on the bottom of the appliance is the
same as that of the home.
For the electrical connection, use an H05VV-F 3X1,5mm²cable as specified in the electrical

13
connection
diagram below. Electrical connection diagram is located on the bottom of the appliance.
Electrical Connection Diagram
INSTRUCTIONS FOR USE
- Use the induction cooking zones with suitable cookware.
- After mains voltage is applied, all displays are on for a moment. When this time is over, the
hob is in the standby mode and it is ready for operation.
- The hob is controlled with electronic sensors which are operated by touching the related
sensors. Each sensor activate is followed by a sound signal (buzzer).
Switching the hob ON
Switch the hob on by touching the ON/OFF button until all heater displays show a
static“0”and the bottom right dots blink. (If no cooking-zone is selected within 20 seconds, the
hob will switch off automatically.)
Switching the hob OFF
Switch the hob off at any time by touching button . button always has the priority in
the switch off function.
Switching the cooking-zones ON
After switching the hob on and placing the pot on the chosen cooking zone, adjust the power
level by
pressing the button. There is a static dot indication on the selected heater display. Each

14
cooking zone has various power levels, adjustable with or buttons, going from “1”:
minimum power, to “9”: maximum power.
Switching the cooking-zones OFF
Select the cooking zone to be switched off by pressing the button. Press the button to
set the
level to “0”.The cooking zone can also be switched off by pressing the and buttons at
the
same time. The cooking zone switches off and the residual heat indicator “H”lights up.
If the cooking zone is hot, “H”will be lighted up instead of “0”.
Booster function
A cooking zone has to be selected, cooking level set to “desired cooking level”and press
button.
button will be displayed on the corresponding display.
Activating the booster can exceed the maximum power and the integrated power management
will be activated.
The necessary power reduction is shown by blinking of the corresponding cooking zone display.
It will blink for 3 seconds and power will be adjusted accordingly.
Smart Pause
Smart pause pause the power during cooking process. Power will be resumed to previous
cooking level when smart pause is deactivated. If the Smart pause is not de-activated, the
cooktop will turn off after 30 minutes
Touch button to activate smart pause. The power for the activated heater(s) will reduce to
level 1 and“II”will appear at all displays.
Touch button again to deactivate smart pause. “II”will disappear and the heaters will now
run at the level previously set.
Child Lock
This function locks the hob controls to prevent accidental switching on. To activate the child lock,

15
press the and buttons simultaneously and then press the buttons, “L”meaning
LOCKED will appear in all displays and the control panel is locked. (If a cooking zone is in hot
condition,“L”and “H”will be displayed in alternation.)
The hob will remain in a locked condition, even if the control panel has been switched off and on.
To deactivate the child lock, first switch on the hob, press the and buttons
simultaneously and then press the button. “L”will disappear in the display and the hob
will be switched off.
Key Lock
Key lock functionality is for blocking and set the appliance into save mode during operation.
Adjusting power level is prohibited when key lock is activated. Only ON/OFF button is allowed in
this mode. Press button for 2 seconds to activate the key lock and an acoustic signal sound
and the key lock indicator flashes and the heater is locked.
Timer (1 to 99mins)
The timer can be used to set cooking time for each zone. Select the cooking zone to be used with
the timer, then select the desired temperature setting and set the desired cooking time by
pressing the button. LED located around the timer indicated which timer has been activated.
10 seconds after the set time has elapsed, an acoustic signal sounds and the timer display
changes to the timer that will run out next (in case of programming more that 1 cooking zone.)
or timer display shows“00”statically, the assigned cooking zone timer LED blinks when no
other timer is set..The programmed cooking zone will be switched off and the “H”will be
displayed if the cooking zone is hot.
The sound signal and the blinking of the timer LED will be stopped automatically after 30
seconds and/or by operating any button.
Minute minder (1 to 99mins)
The minute minder can be used if the cooking zones are switched off. The timer display
shows“00”with a blinking dot.
Press the button to increase the time or press the button to decrease the time

16
between 0 to 99mintues. If there is no operation in 10 seconds, the minute minder will be sent
and the blinking dot will disappear.
Once the set time has elapsed, an acoustic signal sounds and the display blinks and timer begins
the countdown. Acoustic signal will sounds for 30 seconds or be stopped by pressing any button.
The minute minder can be changed or switched off any time by pressing or button.
Switching off the hob by pressing button at any will also switch off the minute minder.
Residual heat indicator
Residual heat indicator indicates that the cooking zone is still hot
After switching off the cooking zone, the respective display shows “H”until the assigned cooking
zone cools down
Safety switch off function
Each cooking zone will be switched off after a defined maximum operation time if the heat
setting is not modified. Every change in the cooking zone puts back the maximum operation
time to the initial value of the operating time limitation. The maximum operation time depends
on the selected temperature level.
Heat Setting
Safety Switch Off After
1-2
6 Hours
3-4
5 Hours
5
4 Hours
6-9
1.5 Hours
Buzzer
While the hob is in operation, the following activities will be signaled by means of a buzzer:
- Normal button activation with a short sound signal
- Continuous operation of buttons over a longer period of time (10 seconds) with a longer,
intermitted sound signal.

17
glass.
- After each use, clean the hob (when it is cool) to remove any deposits and stains due to
food residuals.
-Sugar or foods with a high sugar content damage the hob and must be immediately
removed.
- Salt, sugar and sand could scratch the glass surface.
- Use a soft cloth, absorbent kitchen paper or a specific hob cleaner (follow the
Manufacturer’s instructions).
TROUBLESHOOTING GUIDE
-Read and follow the instructions given in the section “IMPORTANT SAFETY
INSTUCTIONS”.
- Make sure there is not a power outage.
- Dry the hob thoroughly after cleaning it.
- If, when the hob is switched on, alphanumeric codes appear on the display, consult the
following table for instructions.
- If the hob cannot be switched off after using it, disconnect it from the power supply.
CLEANING
- Do not use steam cleaners.
- Before cleaning, make sure the cooking zones are switched off and that the
residual heat indicator“H”is not displayed.
IMPORTANT: Do not use abrasive sponges or scouring pads. Their use could eventually ruin the

If there is an error, error code will be showed at the heater displays.
ERROR CODE POSSIBLE CAUSES ERROR ELIMINATION
E1 Cooling Fan is disabled Contact Whirlpool After Sale Service
E3 Supply voltage is over than rated
values
Turn the hob off, wait until“H”disappears for all
zones and then turn the hob on. If same error is
appeared again, contact Whirlpool After Sale
Service
E4 Supply frequency is different from
rated values
Turn the hob off, wait until“H”disappears for all
zones and then turn the hob on. If same error is
appeared again, disconnect the hob from the
mains supply and connect it again. If same error is
still appeared, contact Whirlpool After Sale
Service
E5 Hob inside temperature is too high Turn the hob off and wait for hob to cool down.
E6 Communication error between
touch control and heater
Contact Whirlpool After Sale Service
E7 Coil temperature sensor is disabled
E8 Cooler temperature sensor is
disabled
E9 Calibration error
18

19
POWER LEVEL TABLE
The information given in below table is for reference.
Power level
Type of cooking
Level use
(Indicating cooking experience and habits)
Max. power
Boost
Fast heating
Ideal for rapidly increasing the temperature of food to
fast boiling in the case of water or rapidly heating
cooking liquids
8-9
Frying - boiling
Ideal for browning, starting to cook, frying deep frozen
products, fast boiling
High power
7-8
Browning - sautéing -
boiling - grilling
Ideal for sautéing, maintaining a lively boil, cooking
and grilling (for a short period of time, 5-10 minutes)
6-7
Browning - cooking -
stewing - sautéing -
grilling
Ideal for sautéing, maintaining a light boil, cooking
and grilling (for a medium period of time, 10-20
minutes), preheating accessories
Medium
power
4-5
Cooking - stewing -
sautéing - grilling
Ideal for stewing, maintaining a gentle boil, cooking
(for a long period of time). Creaming pasta
3-4
Cooking - simmering -
thickening - creaming
Ideal for long-cooking recipes (rice, sauces, roasts,
fish) with liquids (e.g. water, wines, broth, milk),
creaming pasta
2-3
Ideal for long-cooking recipes (less than a litre in
volume: rice, sauces, roasts, fish) with liquids (e.g.
water, wines, broth, milk)
Low power
1-2
Melting - defrosting -
keeping food warm -
creaming
Ideal for softening butter, gently melting chocolate,
thawing small products and keeping just-cooked food
warm (e.g. sauces, soups, minestrone)
1
Ideal for keeping just-cooked food warm, for creaming
risottos and for keeping serving dishes warm (with
induction-suitable accessory)
OFF
Zero
power
Support surface
Hob in stand-by or off mode (possible end-of-cooking
residual heat, indicated by an “H”)

20
The symbol on the product or on its packaging indicates that this product may not be treated as household
waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and
electronic equipment. By ensuring this product is disposed of correctly , you will help prevent potential
negative consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. For more detailed information about recycling of this
product, please contact your local city of fice, your household waste disposal service or the shop where you
purchased the product.
Declaration of conformity
We declare that our products meet the applicable Europen Directives, Decisions and Regulations and the
requirements listed in the standards referenced.
