Aritech ACL800FLW-RDMF Assembly instructions
© 2022 Carrier 1 / 4 P/N 1073499-EN • REV B • ISS 23JUN22
ACL800FLW-RDMF Flush Mount Mifare Reader
Installation Sheet
Description
These ACL800FLW-RDMF flush mount Mifare readers are
designed to fit a DIN electrical gang box and are available in
three different color finishes. The reader includes a buzzer and
a tri-color LED for state indication (access granted, access
denied or idle).
ACL800FLW-RDMF has an automatic Wiegand output (32 or
56 bit) and is capable of reading Mifare cards/fobs
(13.56 MHz).
Mounting
Figure 1: Mounting instructions
Note: Wall mount box is notsupplied.
Wiring
Figure 2: Wiring instructions
1. + 12 V: 9 to14 VDC
2. GND: Ground
3. D0: Data 0
4. D1: Data 1
5. LG−: LED Green minus
6. LR−: LED Red minus
7. tamp: Tamper
8. tamp: Tamper
Jumpers
Backlight in
idle mode
Buzzer on card
read On/Off
Connection to
keypad and
biometric reader
1. +12 V
2. GND
3. D0
4. D1
5. LG−
6. LR−
7. Tamper
8. Tamper
2 / 4 P/N 1073499-EN • REV B • ISS 23JUN22
Tricolor LED and DIP switch LED
Figure 3: LED
Orange (Idle Mode): “LG-” and “LR-” not
connected
Green: “LG-” connected to GND
Red: “LR-” connected to GND
No light: “LG-” and “LR-” connected to GND
Backlight and Buzzer
•Jumper J1: Backlight in idle mode ON/OFF
•Jumper J2: Buzzer on read card ON/OFF
On
Off
Settings in TruPortal software
Go to System Administration > Card formats. Create custom
Wiegand format for Wiegand 56 bit and Wiegand 32 bits.
The reader will send the Wiegand format according to the card
format. If the card presented has 56 bit number, the reader will
send Wiegand 56 bit. If the card presented has 32 bit number,
the reader will send Wiegand 32 bit.
Settings in pcProxConfig software
Select Mifare CSN (Philips, NXP) as card type. Use these
settings in the pcProxConfig software when readingMifare card
via the TP-RDR-LRN desktop reader.
Specifications
Supply voltage
9 to 14 VDC
Current consumption
100 mA at 12 VDC
Wiegand interface
Wiegand 32 or 56 bit, according to the ID
length of the card
Wiegand 32 description
32 data bits
Pulse width: 100 µs, pause: 1 ms
Wiegand 56 description
56 data bits
Pulse width: 100 µs, pause: 1 ms
Operating frequency
13.56 MHz
Card technology
CSN only for the technology: Mifare
Classic, Mifare Plus, Mifare Ultralight,
Mifare DESFire
P/N 1073499-EN • REV B • ISS 23JUN22 3 / 4
Read range
Up to 6 cm, depending on the card type
and quality
Buzzer ON/OFF
Yes, by jumpers
LED
Tricolor
LED control
Yes, by wires
Backlight ON/OFF
Yes, by jumper
Tamper
Yes, activated on frame removal
Cable distance
50m according to Wiegand standard
Panel connection
Terminal blocks
Material of design housing
ABS
Dimensions of housing (W
x H x D)
80 x 80 x 9 mm
Operating temperature
−20 to +50°C
Relative humidity
0 to 95% noncondensing
IP rating
IP40
Shipping weight
120 g
Product weight
50 g
Regulatory information
Manufacturer
PLACED ON THE MARKET BY:
Carrier Fire & Security Americas Corporation Inc.
13995 Pasteur Blvd
Palm Beach Gardens, FL 33418, USA
AUTHORIZED EU REPRESENTATIVE:
Carrier Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Product warnings
and disclaimers
THESE PRODUCTS ARE INTENDED FOR
SALE TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. CARRIER FIRE &
SECURITY CANNOT PROVIDE ANY
ASSURANCE THAT ANY PERSON OR ENTITY
BUYING ITS PRODUCTS, INCLUDING ANY
“AUTHORIZED DEALER” OR “AUTHORIZED
RESELLER”, IS PROPERLY TRAINED OR
EXPERIENCED TO CORRECTLY INSTALL
FIRE AND SECURITY RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/ or scan the QR code.
European Union
directives
Carrier Fire & Security hereby declares that this
device is in compliance with the applicable
requirements and provisions of all applicable
rules and regulations, including but not limited to
the Directive 2014/53/EU. For more information
see: firesecurityproducts.com
REACH
Product may contain substances that are also
Candidate List substances in a concentration
above 0.1% w/w, per the most recently published
Candidate List found at ECHA Web site.
Safe use information can be found at
https://firesecurityproducts.com/en/content/intrusi
on-intro
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information see:
recyclethis.info
