TWN4 MULTITECH NANO
LEGIC 42 M
USER MANUAL

TABLE OF CONTENTS
1INTRODUCTION.................................................................................................................................................................. 3
1.1 ABOUT THIS MANUAL ..................................................................................................................................................3
1.2 SCOPE OF DELIVERY...................................................................................................................................................3
1.2.1 COMPONENTS AND ACCESSORIES ................................................................................................................3
1.2.2 SOFTWARE .........................................................................................................................................................3
1.3 ELATEC SUPPORT........................................................................................................................................................3
1.4 REVISION HISTORY......................................................................................................................................................3
2INTENDED USE .................................................................................................................................................................. 4
3SAFETY INFORMATION ..................................................................................................................................................... 5
4TECHNICAL DATA .............................................................................................................................................................. 6
5MODE OF OPERATION ...................................................................................................................................................... 7
5.1 OPERATING MODE .......................................................................................................................................................7
5.2 POWER UP ....................................................................................................................................................................7
5.3 ENUMERATION .............................................................................................................................................................7
5.4 INITIALIZATION..............................................................................................................................................................7
5.5 NORMAL OPERATION ..................................................................................................................................................7
5.6 DETECTION OF A TRANSPONDER .............................................................................................................................7
5.7 SUSPEND MODE...........................................................................................................................................................8
6COMPLIANCE STATEMENTS ............................................................................................................................................ 9
6.1 EU...................................................................................................................................................................................9
6.2 FCC.................................................................................................................................................................................9
6.3 IC ....................................................................................................................................................................................9
6.4 UNITED KINGDOM ......................................................................................................................................................10
6.5 LABELING ....................................................................................................................................................................10
APPENDIX ..................................................................................................................................................................................... 11
A – TERMS AND ABBREVIATIONS.........................................................................................................................................11
B – RELEVANT DOCUMENTATION ........................................................................................................................................11

© 2022 ELATEC GmbH – TWN4 MultiTech Nano LEGIC 42 M user manual DocRev4 – 04/2022 Page 3of 12
1INTRODUCTION
1.1 ABOUT THIS MANUAL
This user manual is intended for the user and enables a safe and appropriate handling of the product. It gives a general overview, as
well as important technical data and safety information about the product. Before using the product, the user should read and
understand the content of this user manual.
For the sake of better understanding and readability, this user manual might contain exemplary pictures, drawings and other
illustrations. Depending on your product configuration, these pictures might differ from the actual design of your product.
The original version of this user manual has been written in English. Wherever the user manual is available in another language, it is
considered as a translation of the original document for information purposes only. In case of discrepancy, the original version in
English will prevail.
1.2 SCOPE OF DELIVERY
1.2.1 COMPONENTS AND ACCESSORIES
Depending on your product configuration, the product can be delivered alone or with different components and accessories, such as
cables or wall holders, as part of a kit. For more information about the delivered components and accessories, refer to your delivery
note, consult the ELATEC website or contact ELATEC.
1.2.2 SOFTWARE
The product is delivered ex-works with a specific software version (firmware), which can be found on the packaging label, on the
delivery note or other delivery documents.
1.3 ELATEC SUPPORT
In case of any technical questions, refer to the ELATEC website (www.elatec.com) or contact ELATEC technical support at
support-[email protected]
In case of questions regarding your product order, contact your Sales representative or ELATEC customer service at
info-[email protected]
1.4 REVISION HISTORY
VERSION
CHANGE DESCRIPTION
EDITION
04
Chapter “Compliance Statements” updated
04/2022
03
Product pictures updated
03/2022
02
Chapters “Software”, “Technical Data”, “Compliance Statements” and “Labeling” updated
01/2022
01
First edition
12/2021

© 2022 ELATEC GmbH – TWN4 MultiTech Nano LEGIC 42 M user manual DocRev4 – 04/2022 Page 4of 12
2INTENDED USE
TWN4 MultiTech Nano LEGIC 42 M is designed for integration into machines or other devices. It can be connected to an external
antenna through a printed circuit board (125 kHz, 13.56 MHz or both).
The product is intended to be integrated into a host device.
Any use other than the intended use described in this section, as well as any failure to comply with the safety information given in this
document, is considered improper use. ELATEC excludes any liability in case of improper use or faulty product installation.

© 2022 ELATEC GmbH – TWN4 MultiTech Nano LEGIC 42 M user manual DocRev4 – 04/2022 Page 5of 12
3SAFETY INFORMATION
Unpacking and installation
•The product contains sensitive electronic components that require particular attention when unpacking and handling the product.
Unpack the product carefully and do not touch any sensitive components on the product.
In case the product is equipped with a cable, do not twist or pull the cable.
•The product is an electronic product whose installation requires specific skills and expertise.
The installation of the product should be done by a trained and qualified personnel only.
Do not install the product by yourself.
Handling
•The product has been designed for a use under specific conditions (refer to the product data sheet).
Any use of the product under different conditions might damage the product or alter its reading performance.
•The use of other RFID readers or reader modules in direct vicinity to the product, or in combination with the product might damage
the product or alter its reading performance. In case of doubts, contact ELATEC for more information.
•The user is liable for the use of spare parts or accessories other than the ones sold or recommended by ELATEC.
ELATEC excludes any liability for damages or injuries resulting from the use of spare parts or accessories other than the ones sold
or recommended by ELATEC.
•Like most electronic devices, RFID systems generate electromagnetic waves that can vary in amplitude and frequency. It is
generally known and accepted that some RFID devices might potentially interfere with personal medical devices, like pacemakers
or hearing aids.
Users with a pacemaker or any other medical device should use TWN4 MultiTech Nano LEGIC 42 M carefully and refer to
the information given by the manufacturer of their medical devices before using TWN4 MultiTech Nano LEGIC 42 M or
any host device containing TWN4 MultiTech Nano LEGIC 42 M.
Maintenance and cleaning
•Any repair or maintenance work should be done by a trained and qualified personnel only.
Do not try to repair or carry out any maintenance work on the product by yourself.
Do not allow any repair or maintenance work on the product by an unqualified or unauthorized third party.
•The product does not need any special cleaning.
Do not use any detergents or other cleaning agents on the product.
Disposal
•The product must be disposed of in accordance with the EU directive on waste electrical and electronic equipment (WEEE) or any
applicable local regulations.
Product modifications
•The product has been designed, manufactured and certified as defined by ELATEC.
Any product modification without prior written approval from ELATEC is prohibited and considered improper use of the
product. Unauthorized product modifications may also result in the loss of product certifications.
If you are unsure about any part of the safety information above, contact ELATEC support.
Any failure to comply with the safety information given in this document is considered improper use. ELATEC excludes any liability in
case of improper use or faulty product installation.

© 2022 ELATEC GmbH – TWN4 MultiTech Nano LEGIC 42 M user manual DocRev4 – 04/2022 Page 6of 12
4TECHNICAL DATA
Power supply
3.3 V ± 5% (direct supply) or 4.3 V - 5.5 V (use of on-board voltage regulator)
Current consumption
RF field on: 120 mA typically / Sleep: 500 μA typ.
Antennas
TWN4 MultiTech Nano LEGIC 42 M has been tested with an external printed circuit board equipped with the following antennas:
HF antenna on external PCB, printed, one-sided
LF antenna on external PCB, glued and soldered
HF antenna (13.56 MHz)
Outer dimensions: 32 x 29.4 mm / 1.26 x 1.16 inch
Number of turns: 4
Inductance: 1.0 µH ± 20%
PCB trace width: 0.6 mm / 0.02 inch
LF antenna (125 kHz)
Outer diameter: max. 16.3 mm / 0.64 inch
Number of turns: 144
Inductance: 490 µH ± 5%
Wire diameter: 0.10 mm / 0.0039 inch
Lead free, coil fixed by using backed wire
Please note that the use of TWN4 MultiTech Nano LEGIC 42 M with other antennas than the ones described above is not part of the
approvals granted to the module. In case TWN4 MultiTech Nano LEGIC 42 M is used with other antennas, a separate approval,
additional testing or new authorization for a use with these specific antennas is required
For more information, refer to the related product data sheet or other technical documents.

© 2022 ELATEC GmbH – TWN4 MultiTech Nano LEGIC 42 M user manual DocRev4 – 04/2022 Page 7of 12
5MODE OF OPERATION
The mode of operation described in the following chapter is based on a standard ELATEC RFID reader module equipped with two
LEDs. Depending on your product (number of LEDs, installed firmware, etc.) and in case the product settings have been modified with
the AppBlaster tool, the information below might differ from your product configuration when in operation. In particular, the color and
sequence of the LEDs on your product might be different.
5.1 OPERATING MODE
In order to start operating TWN4 MultiTech Nano LEGIC 42 M, it simply has to be connected directly to a host device.
5.2 POWER UP
In case of an external power supply unit is used, the following requirements must be satisfied:
•Limited power source according to the safety standards listed in the respective declaration(s) of conformity
•Short-circuit current < 8 A
Once TWN4 MultiTech Nano LEGIC 42 M is connected to the host device, it detects the type of communications cable (e.g. USB),
with which it is connected to the host.
5.3 ENUMERATION
This is only applicable for the USB version: Once the device has been powered up, it is waiting for completion of the enumeration by
the USB host. As long as the device is not enumerated, it is entering a minimum power consumption mode, where both LEDs are
turned off.
5.4 INITIALIZATION
After powering up and enumeration (in USB mode), the device is turning on the built-in transponder reader logic. The green LED is
turned on permanently. Some RFID readers need some kind of initialization, which is performed in this step. After successful
initialization, the device sounds a short sequence, which consists of a lower tone followed by a higher tone.
5.5 NORMAL OPERATION
As soon as the reader module has completed the initialization, it is entering normal operation. During normal operation, the reader
module is searching for a transponder continuously.
5.6 DETECTION OF A TRANSPONDER
If a transponder is detected by the reader module, following actions are performed:
•Send the ID to the host. By default, the USB device sends by emulating keystrokes of a keyboard.
•Sound a beep.
•Turn off the green LED.
•Blink the red LED for two seconds.
•Turn on the green LED.
Within the two seconds timeout, where the red LED is blinking, the transponder, which just has been recognized will not be accepted
again. This prevents the reader module from sending identical IDs more than one time to the host.
If during the two seconds timeout of the red LED a different transponder is detected, the complete sequence restarts immediately.

© 2022 ELATEC GmbH – TWN4 MultiTech Nano LEGIC 42 M user manual DocRev4 – 04/2022 Page 8of 12
5.7 SUSPEND MODE
The USB version of the RFID reader module supports the USB suspend mode. If the USB host is signaling suspend via the USB bus,
the reader module is turning off most of its power consuming peripherals. During this operation mode, no detection of transponders is
possible and all LEDs are turned off. Once the host is resuming to normal operation mode, this is also signaled via the USB bus.
Therefore, the reader module will resume to normal operation too.

© 2022 ELATEC GmbH – TWN4 MultiTech Nano LEGIC 42 M user manual DocRev4 – 04/2022 Page 9of 12
6COMPLIANCE STATEMENTS
TWN4 MultiTech Nano LEGIC 42 M has been certified as a module and does not need further approval, provided that the module is
used with antennas as specified in this manual. The use of TWN4 MultiTech Nano LEGIC 42 M with other antennas than the ones
described in this manual is not part of the approvals granted to the module. In case TWN4 MultiTech Nano LEGIC 42 M is used with
other antennas, a separate approval, additional testing or new authorization for a use with these specific antennas is required.
6.1 EU
TWN4 MultiTech Nano LEGIC 42 M is in compliance with the EU directives and regulations as listed in the respective EU declaration
of conformity.
6.2 FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Caution
The Federal Communications Commission (FCC) warns the users that changes or modifications to the unit not expressly approved by
the party responsible for compliance could void the user's authority to operate the equipment.
FCC §15.105 (b)
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
FCC ID: WP5TWN4F20
6.3 IC
This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre
le fonctionnement.
IC: 7948A-TWN4F20

© 2022 ELATEC GmbH – TWN4 MultiTech Nano LEGIC 42 M user manual DocRev4 – 04/2022 Page 10 of 12
6.4 UNITED KINGDOM
TWN4 MultiTech Nano LEGIC 42 M complies with the requirements of the UK legislations and other regulations as listed in the
respective UK declaration of conformity. The importer is responsible for applying the following information to the packaging of the
product:
•the importer company’s details, including the company’s name and a contact address in the United
Kingdom.
•UKCA marking
6.5 LABELING
Packaging label (exemplary)

© 2022 ELATEC GmbH – TWN4 MultiTech Nano LEGIC 42 M user manual DocRev4 – 04/2022 Page 11 of 12
APPENDIX
A – TERMS AND ABBREVIATIONS
TERM
EXPLANATION
FCC
Federal Communications Commission
IC
Industry Canada
RFID
radio frequency identification
UKCA
UK conformity assessed
WEEE
Waste of electrical and electronic equipment.
Refers to Directive 2012/19/EU of the European Parliament and of the Council of the European Union
B – RELEVANT DOCUMENTATION
ELATEC documentation
•ELATEC quick start guide
•TWN4 MultiTech Nano LEGIC 42 M data sheet
•TWN4 MultiTech Nano LEGIC 42 M integration manual
•TWN4 MultiTech Nano technical handbook

Elatec reserves the right to change any information or data in this document without prior notice. Elatec declines all responsibility for the use of this product with any other specification but the one mentioned above. Any
additional requirement for a specific customer application has to be validated by the customer himself at his own responsibility. Where application information is given, it is only advisory and does not form part of the
specification. Disclaimer: All names used in this document are registered trademarks of their respective owners.
© 2022 ELATEC GmbH – TWN4 MultiTech Nano LEGIC 42 M user manual DocRev4 – 04/2022
ELATEC GMBH
Zeppelinstr. 1
•82178 Puchheim •Germany
P [phone]
•F [phone] •E-mail: [e-mail]
elatec.com
