ARJAY ENGINEERING 4200-IG-2 User manual

MODEL 4200-IG-2 (Up to 2 Sensors)
MODEL 4200-IG-6 (Up to 6 Sensors)
MODEL 4200-IG-10 (Up to 10 Sensors)
Industrial Grade Gas Monitor
User Manual
Technical Support
Continental North America Toll Free 1-[phone]
Ph: [phone] Fx: [phone]
A Product of Arjay Engineering Ltd.
Oakville, Ontario, Canada
www.ArjayEng.com
MODEL:
HARDWARE NO.:
SOFTWARE NO.:
SERIAL NO.:

Model: 4200-IG User Manual Rev: 3.0
2
TABLE OF CONTENTS
1.0 INSTRUMENT OVERVIEW ............................................................................................ 3
1.1 Features ............................................................................................................. 5
1.2 Model Numbers .................................................................................................. 5
1.3 Specifications ..................................................................................................... 6
2.0 INSTALLATION ............................................................................................................... 7
2.1 Main and Remote Panel Installation .................................................................. 7
2.2 Sensor Installation.............................................................................................. 7
2.3 Electrical Installation .......................................................................................... 8
2.4 Glossary of Symbols .......................................................................................... 10
3.0 STARTUP AND CALIBRATION ...................................................................................... 11
3.1 Startup ................................................................................................................ 11
3.2 Screen Menu Background Information .............................................................. 12
3.2.1 Keypad Main Menu Entry .................................................................... 12
4.0 SYSTEM CONFIGURATION .......................................................................................... 13
4.1 Diagnostic Information ....................................................................................... 13
4.2 Relay Setup ........................................................................................................ 14
4.3 Sensor Setup ..................................................................................................... 15
4.4 Zone Setup (only for 4200-IG-6 & 4200-IG-10 models)..................................... 16
4.4.1 Sensor Value Average Filter ............................................................... 16
4.4.2 Fan Overide Switch ............................................................................. 16
4.5 Calibration Date and Time ................................................................................. 17
4.6 Alarm Test .......................................................................................................... 17
4.7 Log Off ............................................................................................................... 17
4.8 Analog Output (Optional) ................................................................................... 18
5.0 SENSOR CALIBRATION ................................................................................................ 19
6.0 TROUBLESHOOTING .................................................................................................... 20
7.0 DETAILED ELECTRICAL AND DIMENSIONAL DRAWINGS ....................................... 21
TABLE OF FIGURES
Figure 1 – System Overview ......................................................................................................................... 3
Figure 2 – Electrical Installation Overview .................................................................................................... 8
Figure 3 – Startup Main Screen View With Keypad .................................................................................... 11
Figure 4 – Secondary Main Screen View .................................................................................................... 11
Figure 5 – System Configuration Main Screen View .................................................................................. 13
Figure 6 – Diagnostic Information Screen View .......................................................................................... 13
Figure 7 – Alarm Setup Screen View .......................................................................................................... 14
Figure 8 – Sensor Setup Screen View ........................................................................................................ 15
Figure 9 – Zone Setup Screen View ........................................................................................................... 16
Figure 10 – Date & Time Screen View ........................................................................................................ 17
Figure 11 – System Test Screen View ........................................................................................................ 17
Figure 12 – Analog Output Screen View ..................................................................................................... 18

Model: 4200-IG User Manual Rev: 3.0
3
1.0 INSTRUMENT OVERVIEW
The Arjay Model 4200-IG monitors the inputs from various field sensors to provide a gas
concentration display, alarms and interlocks.
The monitoring system is comprised of one main control panel and a minimum of one remote alarm
sensor transmitter. The panel can support multiple sensor inputs and signal types as per the part
number ordered.
Optional Remote alarm panels can also be added that will display and provide audio/visual alarms.
Local or site specific regulations may apply to your application. Be aware and to comply with all
applicable regulations for your installation.
Figure 1 – System Overview

Model: 4200-IG User Manual Rev: 3.0
4
Main Panel
The main panel is a wall mounted touch screen monitor in a general purpose (non-hazardous)
location that is accessible for set-up and observation of the display and alarms.
There are 3 models available to order:
1. 4200-IG-2: This system has up to 2 zones to configure.
2. 4200-IG-6: This system has up to 4 zones to configure. If more then 4 sensors are ordered
then several sensors can be grouped into one zone.
3. 4200-IG-10: This system has up to 4 zones to configure. If more then 4 sensors are ordered
then several sensors can be grouped into one zone
For example: Zone 1 can be set for Sensors 1-4 while Zone 2 can be set for Sensors 5-6.
A low alarm relay for each zone is activated at a low setpoint and is indicated by the touch screen
flashing yellow by pressing the zone icon. The screen text also shows the sensor number, gas
concentration and “LO” indication. The relay resets automatically when the concentration clears
below the determined differential setpoint.
A high alarm relay for each zone is activated at a high setpoint and is indicated by the touch screen
flashing red by pressing the zone icon. The screen text also shows the sensor number, gas
concentration and “Hi” indication. The relay resets automatically when the concentration clears below
the determined differential setpoint.
A high/high alarm relay common to all zones is activated at a high/high setpoint and is indicated by
the screen text “Hi/Hi”. An optional beacon and/or buzzer is also available to activate at this setpoint.
The high/high alarm maybe latched to be acknowledged and reset after the gas concentration clears.
If user is not using zone 4 Hi alarm then this relay can be selected as a common Fault alarm.
If latched, the buzzer can be silenced during an alarm condition but the beacon will only turn off when
a gas alarm has cleared and has been acknowledged.
Pressing each zone icon (e.g. Zone 1) will allow user to view which sensor was in alarm in that
particular zone as well as type of sensor (e.g. CO) and concentration.
The main panel screen provides additional user interface menus for diagnostics, set-up and general
Help information. Menus can be accessed for viewing but a password entry is required to make any
changes.
Remote Panel
Remote panels are available to mimic the screen and audio/visual alarms of the main panel. Access
to the touch screen menus are password protected on the remote panels. The main panel will accept
up to 6 remote panels depending on the model ordered.
Remote Sensor
The panel will accept one or more sensor inputs depending on the model ordered. Typical inputs are
4-20 mA signals proportional to the gas concentration.
Refer to your sensor transmitter manual for details. Routine testing and calibration is recommended
to ensure the sensor is responsive and accurate.

Model: 4200-IG User Manual Rev: 3.0
5
1.1 Features
 Microprocessor based Controller
 Up to 10 sensor inputs based on the model ordered
 Concentration Display
 Relay alarms on low and high for each zone and common high/high
 Available analog outputs and RS-485 communication
 Touch Screen interface with password protection
 Diagnostic, set-up and Help menus on all screens
1.2 Model Numbers
4200 - IG - x - a b c d e - f
Example:
4200 - IG - 6 - 1 1 0 0 0 - z
x
-
# of Sensors
2 – Up to Two
Sensors
6 – Up to Six
Sensors
10 – Up to Ten
Sensors
a - Buzzer
0 – No
1 – Yes
b
-
Strobe
0
–
No
1
–
Yes
c
–
4
-
20mA Output*
0
–
No
1 – Yes, for single sensor
2 – Yes, for two sensor
3 – Yes, for upto 6 sensor
4 – Yes, for upto 10 sensor
d – RS-485 Modbus
Communication
0 – No
1 – RS-485 Modbus RTU
2
–
BACNet IP (Siemens)
e – Ethernet Hub For
Remote Panels
0
–
No
1 – Yes, up to 3 mimic panel
2
–
Yes, up to 6 mimic panel
*Per Zone
f – Custom vs.
Standar
x – Custom**
z – Standard
**Fill in the custom
requirement below.
x – Custom
Description
8 Sensors
Selected
Buzzer
Selected
Strobe
Selected
No 4-20mA
Selected
No RS-485
Selected
Standard Configuration
Selected
No Ethernet
Hub Selected
**

Model: 4200-IG User Manual Rev: 3.0
6
1.3 Specifications
Power Input: 100-240 vac, 50/60 Hz,
1.22A maximum for 4200-IG-2 Model
1.95A maximum for 4200-IG-6 Model
4.00A maximum for 4200-IG-10 Model
User Interface:
Touch Screen Full Colour 6 “ display on Main Panel
Monochrome 4” on Remote Panel
Outputs:
Relay Output DPDT relay, 8 A @ 250 vac dry contacts
- 5x Relays for Mdoel 4200IG-2
- 10x Relays for Model 4200IG-6 and 4200IG-10
Selectable failsafe or non-failsafe
Programmable time delay: 0 – 1 hour; ON and/or OFF
One relay each for:
 Low Setpoint per zone *
 High Septoint per zone *
 High/High common
*Max. 4 zones with 4200IG
-
6 & 4200IG
-
10
Sensor Accepts various sensor types
Refer to your sensor manual for specifications
Environmental:
Ambient Temperature 0 to +55 °C
Relative humidity 0 to 95% (non-condensing)
Installation Category II
Pollution Degree 2
Mechanical Specification: Refer to dimensional drawing

Model: 4200-IG User Manual Rev: 3.0
7
2.0 INSTALLATION
NOTE: If any damage to the instrument is found, please notify an Arjay Engineering
representative as soon as possible prior to installation.
2.1 Main and Remote Panel Installation
Choose a mounting location in accordance with good instrument practice. Extremes of ambient
temperature and vibration should be avoided (see specifications and installation drawing).
Remote panels can be mounted up to 300 meters away from the main panel. Sensors can be
mounted up to 4500 feet (using 14AWG wire) away from the main panel.
Important Note: The controller is set in Failsafe mode (Factory Default). This means that the
relays are in an energized state during normal operation. The N.O. relay contact will be held closed
and the N.C. relay contact will be held open during a normal condition. This will allow the relay to
return to it’s non-energized (shelf) state during an alarm, fault or power failure condition. Wire
accordingly.
2.2 Sensor Installation
Refer to sensor manual for more specification on location and wire type.
The sensor is to be mounted near the targeted gas source and protected from extremes of
temperature and damage. Keep the sensor accessible for routine calibration. Do not block with
equipment or store materials or containers in front of the sensor.
Gases may have densities greater than or less than air. Sensors should be mounted accordingly.
Sensors targeting heavier than air gases should be mounted so the bottom of the sensor housing is
approximately 250mm to 450mm (10” to18”) above floor grade to protect it from damage from
cleaning equipment and minor washdown. The sensor should be mounted above any risk of flooding.
Sensors targeting lighter than air gases should be mounted near the ceiling in a location that will be
accessible for routine testing.
Sensor location is application specific and may need to be in accordance with local regulations or
engineered recommendations.

Model: 4200-IG User Manual Rev: 3.0
8
2.3 Electrical Installation
Refer to the drawings provided by the contractual engineer for your project and the drawings
included with this manual.
Figure 2 – Electrical Installation Overview

Model: 4200-IG User Manual Rev: 3.0
9
Wiring Chart (Depends on Sensor Selection)
Two wire Loop Powered Transmitters (Sensor)*
Transmitter Model
Transmitter Wire Terminal
Panel Wire Terminal
HLM-2000-TX
+ 24VDC Power Input
- Signal Output
24VDC Power Output
(-) Common (Not Used)
(S) + 4-20mA Input
Three wire Loop Powered Transmitters (Sensor)*
Transmitter Model
Transmitter Wire
Terminal
Panel Wire Terminal
HLM-2000-EX + 24VDC Power Input
-Negative
+ 4-20mA Output
+ 24VDC Power Output
(-) Common
(S) + 4-20mA Input
EC-Gold
EC-Gold Dual
IR-200
Four wire Loop Powered Transmitters (Sensor)*
Transmitter Model
Transmitter Wire Terminal
Panel Wire Terminal
IR-350
+ 24VDC Power Input
-Negative
+ 4-20mA Output
-Negative
+ 24VDC Power Output
(-) Common
(S) + 4-20mA Input
*Shielded wire is recommended on all installation.
Maximum wire length 4,500 feet (Using 14AWG wire).

Model: 4200-IG User Manual Rev: 3.0
10
2.4 Glossary of Symbols
Attention, consult accompanying documents
Attention, veuillez consulter les documents ci-joints.
Protective Earth
Terre de protection
Fuse
Coupe-circuit; fusible
Direct Current (DC)
Courant continu
Normally open relay contacts
Contacts travail
Normally closed relay contacts
Contacts Repos
Power off
ArróÕ (mise hors tension)
Power on
Marche (mise sous tension)
L
Live
Sous tension
N
Neutral
Neutre
G
Ground
Terre

Model: 4200-IG User Manual Rev: 3.0
11
3.0 STARTUP AND CALIBRATION
3.1 Startup
Check that the power wiring, sensor and remote panel connections, and interfaced equipment
are wired in accordance with the electrical installation drawings.
Power On the unit.
The main screen will light up and run through initialization. After any operator power start up or
power interruption, the display will indicate it was non-gas power-up condition and that it must
be acknowledged by an operator to proceed.
The main and remote panels are set to factory defaults or customer specifications. The sensor
is factory tested prior to shipment. As such, the system will be operational upon start-up.
After the power-up is acknowledged, confirm the screen reads similar to the following.
Figure 3 – Startup Main Screen View With Keypad
Pressing each zone icon (e.g. Zone 1) will allow user to view which sensor was in alarm in that
particular zone as well as type of sensor (e.g. CO) and concentration as shown below in Figure 4.
Figure 4 – Secondary Main Screen View

Model: 4200-IG User Manual Rev: 3.0
12
3.2 Screen Menu Background Information
3.2.1 Keypad Main Menu Entry
Below the touch screen are 4 touch keys. See Figure 3 on previous page.
Home
At any time, you can press the Home Key to return directly to the Home Screen
Help
This provides an overview of the system operation and components. Contact details for
technical help are included at the end of the text.
Tools
Access this section to view or configure the screen and control settings, view diagnostics or to
do a system alarm test.
Silence
During an alarm condition the audio can be silenced. Silencing at any panel will silence all
panels. The audio alarm will automically re-set when the alarm clears.

Model: 4200-IG User Manual Rev: 3.0
13
4.0 SYSTEM CONFIGURATION
This section describes the screen, alarm and interface features accessed through the Tools
on the Main Panel. The following screens shots are based on a 4200-IG-6 with all options
ordered. Screen shots may be different on other models.
Press
Figure 5 – System Configuration Main Screen View
*Some configuration required password. The password is “2000”
4.1 Diagnostic Information
Figure 6 – Diagnostic Information Screen View
This is a View Only screen. It provides the alarm and sensor setup details that have been
entered for this unit. It also shows real time voltage and mA reading. Setup and sensor changes
can be made through the password protected Zone and Sensor Setup menu.
*

Model: 4200-IG User Manual Rev: 3.0
14
4.2 Relay Setup
Figure 7 – Alarm Setup Screen View
The Password “2000” will be required to make changes in this section.
There are three alarm settings: Low alarm, High Alarm and Common High/High alarm
The low alarm is typically used as a warning level that gas is present but at a safe level. It is not
unusual to have trace levels of gas present during maintenance or process operations. A relay
is provided for each zone. Determine your application requirement such as fan ventilation.
The high alarm is typically used as an alarm condition for action. A relay is provided for each
zone.
The high/high alarm is common to all sensors and will activate the buzzer and strobe if ordered.
There are 2 common relays for strobe and buzzer options.
FAULT ALARM SETUP
User has the option to use relay 8 as a Common Fault alarm instead of zone 4 High Alarm.
ALARM DELAY SETUP
The low, high and high/high alarm delay for all zones are as follows:
Delay ON. This is the time, in minutes and seconds, that the relays will delay before activating
when the ppm setpoint has been reached. Delay ON is used to suppress a nuisance alarm that
may be caused by a spurious or momentary alarm of gas.
Delay OFF. The time, in minutes and seconds, that the relays will stay on after the ppm has
dropped below the setpoint. Delay OFF is used to keep ventilation fans running after the sensor
has cleared to assist ventilating any areas that may not be clear due to poor ventilation.
RELAY FAILSAFE SETUP (Press to move to next page)
Failsafe will determine if the relays are energized or de-energized during a normal operating
state (no alarm condition).
If Failsafe is YES, the relay will be energized during a normal operating condition. An alarm or
power failure will de-energize the relay to the alarm state.
When in Failsafe mode and during a normal condition, the N.O. contact is closed and the N.C.
contacts is open. WIRE ACCORDINGLY.
COMMON Hi/Hi ALARM RELAY LATCH

Model: 4200-IG User Manual Rev: 3.0
15
Select YES to latch the Hi/Hi relay when it alarms. In this mode, the alarm will need to be
manually acknowledged by the Reset button on the Main screen after the gas condition has
cleared.
Note: Buzzer silence time out option is only available on 4200-IG-6 model. When enabled the
buzzer will come back on after set time
4.3 Sensor Setup
Figure 8 – Sensor Setup Screen View
The Password “2000” will be required to make changes in this section.
Gas Name
You can enter the gas name for each sensor. This will show on the secondary screen adjacent
to the sensor #. This has been factory set according to the sensor shipped with this panel.
Press zone # on main screen to get to sensor status within the zone.
Gas Unit
This is the unit used for each sensor e.g. % * or PPM you can enter the gas name for each
sensor.
* Use shift key to get to other keyboard which display %.
Span
This will determine the full concentration level of sensor. This is determined by the sensor type
and is factory set according to the sensor shipped with this panel.
Low Alarm ON
This will determine the concentration at which the low alarm relay activates. At this setpoint, the
screen will flash yellow.
Low Alarm OFF
This will determine the concentration at which the low alarm will turn off. This differential is used
to suppress chattering of alarms if the gas concentration is hovering at the setpoint.
The low alarm will clear automatically if the concentration levels drop below the alarm levels.
High Alarm ON
This will determine the concentration at which the high alarm relays activate. At this setpoint,
the screen will flash red.
High Alarm OFF

Model: 4200-IG User Manual Rev: 3.0
16
This will determine the concentration at which the screen will indicate the gas condition has
cleared. The high alarm will clear automatically if the concentration levels drop below the alarm
levels.
High/High Alarm
This will determine the concentration at which the high/high alarm relay and alarms activate.
This relay can be latched to be acknowledged after the gas clears.
4.4 Zone Setup (only for 4200-IG-6 & 4200-IG-10 models)
Sensor Start
This sets up how many sensors required per zone (up to 10 sensors) e.g. 3 sensors in zone is
set as sensor start: 1 , end: 3. Set up each zone sequentially starting with Zone 1.
Figure 9 – Zone Setup Screen View
4.4.1 Sensor Value Average Filter
Sensor filtering is used to smooth data from a sudden change and minimize fluctuating reading.
Minimum is 1 and maximum value is 100. Higher the filter value, slower the response.
4.4.2 Fan Overide Switch
This button will enable or disable the fan override function. If selected the switch will show on
main screen. When fans are hooked up thru the low alarm relay, the operator would be able to
manually operate the fans for all zones.

Model: 4200-IG User Manual Rev: 3.0
17
4.5 Calibration Date and Time
The 4200-IG has a real time clock to remind users of impending calibration duties.
The calibration reminder frequency can be entered here. When a calibration is performed, Press
the Record calibration icon to initiate reminder countdown timer.
Figure 10 – Date & Time Screen View
4.6 Alarm Test
The Low, High and Common HI/HI & Fault relays can be tested for each zone by pressing
appropriate Icon which will turn green if selected. Push the appropriate alarm level for test. “Test
in Progress Push to finish” Icon will start flashing, press again to finish the test.
Figure 11 – System Test Screen View
4.7 Log Off
Once logged in with the password, the system will allow user to make changes. If no activity for
more than 20 minutes the password will be expired. Log off feature will terminate the password
right away with the push of the log off button.

Model: 4200-IG User Manual Rev: 3.0
18
4.8 Analog Output (Optional)
If ordered this feature will show up in configuration menu. Each sensor can be setup for 20mA
equals the sensor span.
The force 20mA output feature will allow user to test the equipment.
Figure
12
–
Analog Output Screen View

Model: 4200-IG User Manual Rev: 3.0
19
5.0 SENSOR CALIBRATION
Refer to the specific sensor Instruction Manual attached to this manual for the sensor calibration
details.
The sensor is factory calibrated and will operate upon installation, however, the sensor
response should be verified after installation with a calibration or test gas. Re-calibrate if
necessary.
Routine verification of the sensor response and confirmation of the panel alarms and interlocks
is recommended. A minimum verification every 4 to 6 months is recommended. Re-calibrate
as necessary.

Model: 4200-IG User Manual Rev: 3.0
20
6.0 TROUBLESHOOTING
Main Panel
 Confirm the power supply LED is active
(Green).
 Confirm the Power Input is 100-240VAC
using a meter.
 Confirm if input fuse has blown.
 Confirm that sensor is wired according to
electrical wiring drawing for each sensor.
Green LED
