ARKSEN 005-PBK-FH2-SD User manual

Item# 005-PBK-FH2-SD
Hitch Mounted Foldable Bike Rack Platform
Style (2 Bike) w/Built-in Anti-Wobble Lock
Manufacturer and seller expressly disclaim any and all liability for personal injury, property
damage or loss, whether direct, indirect, or incidental, resulting from the incorrect attachment,
improper use, inadequate maintenance, unapproved modification,or neglect of this product.
WARNING:
OWNER’S MANUAL

owner’s manual
2
Thank you for purchasing our product.
This manual covers operation and maintenance information about the product. Read carefully and
understand all instruction before using the product.
All information in this publication is based on the latest product information available at the time of
approval for printing.
We reserve the right to make changes at any time without notice and without any obligation.
Table of Contents
03
03
06-15
04-05
16-20
Warning and Precaution --------------------------------------------------------------
Assembly Instruction -------------------------------------------------------------------
Hardware list ------------------------------------------------------------------------------
User Instruction --------------------------------------------------------------------------

owner’s manual
3
READ ALL INSTRUCTION BEFORE USE
• Inspect the product before use. Do not use if damaged or with missing parts.
• Do not use the product for anything other than intended use.
• Do not exceed the maximum load capacity of the hitch rating, vehicle load limit, or more than 2
bikes.
• Always distribute the weight on the rack evenly.
• Ensure the rack and the load do not block taillight or any vehicle safety equipment.
• Always ensure the loads on the rack and check frequently.
• Make sure all pins are secured before use.
•
SAVE THESE INSTRUCTIONS
SPECIFICATION
Model Number 005-PBK-FH2-SD
Load Capacity 2 bikes
150 lbs
Fitting Fit 2”steel hitch tube
WARNING! CAUTION!
There are small components used in the construction of this product.Loose items should be
kept away from pets and children to avoid a choking hazard.
Keep all plastic bags and packaging lm away from pets and children to avoid suocation.

owner’s manual
4
ASSEMBLY INSTRUCTION
HARDWARE LIST
1
5
9
6
78
23
4
Folding Bracket
1x
2x 1x
1x 2x
1x 1x
1x
Connecting Bracket Red Pin
Vertical Tube Horizontal Tube Short Hook
Long Hook Wheel holders-L
2x
Wheel holders-R

10 11 12
13 14 15
16 17 18
19 22
21
20
owner’s manual
5
HARDWARE LIST
M1 0x55 Bolt x4
10 Flat Washer x4
M10 Lock Nut x4
Triangle Pin x1
M12x80 Boltx1
12 Flat Washerx2
M12 Lock Nutx1
Screw x1
Clamping Coverx12
Tie Down Strap x1
Screw x2 Reector Stickerx3 Keyx1 Buckle Pinx1
M10x60 Boltx1
10 Flat Washerx2
M10 Lock Nutx1
M8x70 Bolt x6
8 Spring Washer x6
8 Flat Washer x6
Lock Knob x6
M4x15
M10x16

owner’s manual
6
ASSEMBLY INSTRUCTION
NOTE: The nuts supplied with the rack have nylon thread locker at the end of each nut. Once the threads
of the bolt reach the thread locker, you will feel resistance as you tighten the nut and bolt. Continue to
tighten until it is secured.
1
13
1x
1x
14
1x
M4x15
Insert the folding bracket(1) into the hitch receiver of the car, Then align the upper hole on receiver and
insert the triangle pin (13), Use screw (14) to cover the pull rope of traingle pin (13) according to the
gure, and then tighten screw(14).
1
1
13
14
1
2
3
Required tools for assembly (Not included)

owner’s manual
7
ASSEMBLY INSTRUCTION
Tighten knob until there is no more play between the tongue and receiver.
NOTE: Lock must be in unlocked position to tighten or loosen knob.
2
The use of security locks

owner’s manual
8
ASSEMBLY INSTRUCTION
When the knob is tightened and folding bracket(1) is not shaken, insert the key and turn counter
clockwise to enter the security anti-theft mode.
Similarly,if you want to remove the bike rack from the car. Please insert the key and turn it clock wise,
and then turn the knob anticlockwise with your hand until folding bracket (1) is loose, Remove triangle
pin(13), you can remove the bike rack.
3
21
1x
The use of security locks

owner’s manual
9
USER INSTRUCTION
2
2
1
1x
1x
22
1x
16
16
22
M12x80 Boltx1
Insert the connecting bracket (2)into folding bracket (1).
Line up the hold with long bolt(16) and insert bolt throngh each hole.Threads the nuts onto the
bolt and securely tighten.
Finally,hitch the buckle pin(22) to secure the rack.
4
M12x80

owner’s manual
10
USER INSTRUCTION
5
2
55
2x
10
10 10 1010
Insert the end of tubes (5) on both side of connecting bracket (2).
Line up each holes on bracket (2)with bolts (10) and threads the nuts onto the
bolt and securely tighten.
5
M1 0x55 Bolt x4
10 Flat Washer x4
M10 Lock Nut x4

owner’s manual
USER INSTRUCTION
19
19 19
2x
5
2
5
M10x16
Insert bolts (19) connect with bottom side of connecting bracket (2).
6
11

12
4
4
1x
3
3
2
1x
15 15
M10x60 Boltx1
10 Flat Washerx2
M10 Lock Nutx1
owner’s manual
ASSEMBLY INSTRUCTION
7
Install the bolt (15) through the top hole in connecting bracket (2) and the tube (4).
Use bolt（15）to cover the pull rope of red pin （3）according to the gure，and Tighten the bolt
securely using wrench.
Insert the vertical tube (4) into the second hole of connecting bracket (2) with pin(3).

9
8
8
9
11
12
11
11
17
9
9
8
8
12
17
20
M8x70 Bolt x4
8 Spring Washer x4
8 Flat Washer x4
Note: Put the reector
stickers in place where
you need.
13
owner’s manual
ASSEMBLY INSTRUCTION
Install the covers (17) on the tube (5) and line up them with wheel holder (8,9) into the groove on
the cover and tighten the knobs (12) of the wheel holders .
8
Attention: Please remember to put lock washer and at washer on it, then the
knobs (12)can be tighten.
2x
4x
2x
8x
3x
20
20
20
5

6
6
7
7
6
7
12
17
17
11
M8x70 Bolt x2
8 Spring Washer x2
8 Flat Washer x2
14
owner’s manual
ASSEMBLY INSTRUCTION
Install the covers (17) on the tube (4) and install bolts (11) through the holes with hooks (6,7)
into the groove on the cover and tighten the knobs (12) of the hooks.
9
NOTE：The long hook must be installed rst.
Short Hook
Long Hook
1x
1x
2x
4x
11
12
4

15
owner’s manual
ASSEMBLY INSTRUCTION
NOTE: Please remember to put lock washer and at washer on it, then the
knobs (12)can be tighten.

Adjust the wheel holder (8,9) in position, and put the bike on the rack.
Make sure the padded hooks (6,7) are pressing the bike frames, so that bikes are held tightly.
In the end, secure the bike wheel to the bike with the stabilizer straps.
Safety strap is required at all time during transport.
Make sure the knobs(12) on the hooks are locked after adjusting.
Load the heavier bike closer to the vehicle.Make sure the total weight of the bike load is
within the weight capacity of the rack or the vehicle.Overloading may result in damaging
the product.
owner’s manual
16
USER INSTRUCTION
LOADING THE BIKES
ATTENTION!

17
Put the bike on the rack and secure in plack with tie-down strap (18) to provide extra security.
owner’s manual
USER INSTRUCTION

It's not recommended to tilt down the carrier when it carries bikes.
Do not attempt to lower the rack when bikes are loaded on the rack.
Heavy load.Two person lift recommended for smart tilt feature.Improper technique may case
muscle strain or back injury.
Only use smart tilting feature when parked.
Always return the rack to the level position and ensure it's locked into plack before transport.
Do not allow the rack to fall freely into tilt position.
WARNING:
18
owner’s manual
USER INSTRUCTION
LOWERING THE RACK FOR TAILGATE / BACK DOOR
Remove the buckle pin(22), tilt down the carrier.
When using this feature, open the tailgate / back-door slowly and make sure there is enough
clearance between the tailgate / back-door and the rack to prevent any damage on the vehicle.
The rack is not completely xed after tilting,
please pay attention to safety.
WARNING:

22
Fold Function：Remove the buckle pin (22) and replace it to fold up when no carring bikes
19
owner’s manual
USER INSTRUCTION
1. Remove the pin (3) and fold down the tube (4).
NOIE: Insert the Red pin (3) into the other hole according to the gure to x the vertical tube (4).
2. Removethe buckle pin (22), tilt up the carrier, and then secure the position by replacing pin,
insert the buckle pin into the upper hole.
4
12

22 22
Failure to install the rack to the car receiver properly may result in the rack separating
from the receiver and fall onto the road way, causing potential road hazard.
ATTENTION! WARNING!
owner’s manual
USER INSTRUCTION
20
