Arlec HL15 User manual

Please read the following instructions carefully before proceeding with installation.
INSTALLATION OF THIS FITTING MUST BE CARRIED OUT BY A QUALIFIED ELECTRICIAN.
WARNING: Before attempting any installation or maintenance, ensure that the
electrical supply is switched off and the fuse removed or the circuit breaker is in the
“off” position.
Do not mount the Floodlight near flammable surfaces, as the lamp body gets
extremely hot.
Do not position the Floodlight closer than one metre from surface to be illuminated.
Do not touch the fitting whilst it is in operation - the fitting will become very hot.
The maximum rating of this floodlight is 150 Watts.
INTRODUCTION
INSTALLATION INSTRUCTIONS HL15 & HL16
Fig. 1
COMPONENTS
Tungsten
halogen tube
Mounting
bracket Terminal
Floodlight
housing
Cable gland
WARRANTY
CPIN002524
150W HALOGEN
Floodlight
150W HALOGEN
Floodlight
© This instruction leaflet is subject to copyright and must not be reproduced,
copied or otherwise used in any way or for any purpose without the consent in
writing of the owner, Arlec Australia Pty Ltd (A.C.N. 009 322 105).
CPIN002524
Arlec guarantees this product in accordance with the Australian Consumer Law.
Arlec also warrants to the original first purchaser of this product (“you”) from a retailer that
this product will be free of defects in materials and workmanship for a period of 12 months
from the date of purchase; provided the product is not used other than for the purpose, or in
a manner not within the scope of the recommendations and limitations, specified by Arlec, is
new and not damaged at the time of purchase, has not been subjected to abuse, misuse,
neglect or damage, has not been modified or repaired without the approval of Arlec and has
not been used for commercial purposes (“Warranty”).
If you wish to claim on the Warranty, you must, at your own expense, return the product, and
provide proof of original purchase and your name, address and telephone number, to Arlec
at the address below or the retailer from whom you originally purchased the product within
12 months from the date of purchase.
Arlec will (or authorise the retailer to) assess any claim you may make on the Warranty in the
above manner and if, in Arlec’s reasonable opinion, the Warranty applies, Arlec will at its own
option and expense (or authorise the retailer to) replace the product with the same or similar
product or repair the product and return it to you or refund the price you paid for the
product. Arlec will bear its own expenses of doing those things, and you must bear any other
expenses of claiming on the Warranty.
The Warranty is in addition to other rights and remedies you may have under a law in relation
to the product to which the Warranty relates.
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and for compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure.
Arlec Australia Pty. Ltd. ACN 009 322 105 (“Arlec”) gives the Warranty.
Arlec’s telephone number, address and email address are:
Customer Service: [phone]
Building 3, 31 – 41 Joseph Street, Blackburn North, Victoria, 3130
Blackburn North LPO, P.O. Box 1065, Blackburn North, 3130
Email: [email protected]
HL15_CPIN002524.indd 2 24/08/12 10:07 AM

WIRING
MOUNTING THE FITTING
FITTING THE TUNGSTEN HALOGEN TUBE
DO’S AND DON’TS
SPECIFICATIONS
Fig. 2
Fig. 3
Fig. 4
ACTIVE
(Brown or Red)
White
White EARTH (Green/Yellow)
Cable gland
To Lampholder
To AC power
230/240V
4°
4°
4°
4°
EARTH
(Green/Yellow)
NEUTRAL
(Blue or Black)
For permanent outdoor or indoor use.
Attach the mounting bracket onto wall in desired position.
The mounting bracket must be installed within +/- four degrees of the horizontal,
otherwise filament life will be reduced considerably.
1. Remove the terminal cover and feed the cable through the cable gland.
2. Tighten the cable gland to ensure a waterproof seal.
3. Wire the unit in accordance with Fig. 2.
4. Check that all connections are correct and tight.
5. Refit the terminal cover.
6. Form a drip loop in the cable to prevent moisture running into the cable gland.
7. The Floodlight must be earthed.
The tungsten halogen tube is supplied and packed separately to avoid damage.
Open the Floodlight housing by removing
the top screw. The glass front of the housing
will hinge forward and down. Insert the
tube in the holder, ensuring that you do not
touch the glass envelope of the tube with
bare hands. Use the tube wrapper to handle
tube. (Fig. 3) Oils from the hands can cause
the tube to fail or shatter. If necessary, the
tube should be carefully cleaned with
methylated spirits and dried before installation. Do not attempt to adjust or force
the tube holder with tools, but carefully push the tube into the holder contacts.
Reassemble the Floodlight housing. (Maximum 150 watt Tungsten Halogen tube).
Extreme care should be taken when installing and operating the Floodlight. Please
observe the following do’s and don’ts to ensure safe and trouble free use.
DO ensure combustible material is kept away from Floodlight.
DO install Floodlight in horizontal position +/-4°. If not used in horizontal
position,tube life will be greatly reduced (Fig. 4).
DON’T mount the Floodlight within reach of children.
DON’T touch tube with bare hands. This will shorten tube life.
DON’T position the Floodlight closer than one metre from surface to be illuminated.
DON’T touch the housing or glass whilst light is illuminated. Allow to cool before
making adjustment or changing tube.
DON’T allow overhanging shrubs or foliage to come into contact with Floodlight.
DON’T operate the Floodlight with the front housing opened.
DON’T point the Floodlight further than 45° downwards.
Power Required............230-240 volt, 50Hz.
Rating............................150 Watt load.
Replacement tube.... ....150 Watt Tungsten Halogen,
R7s Linear 78.3mm tube.
Weatherproof Rating...IP55
