ARLEE LIGHTING BELLA ARCHITECTURAL LINEAR Series User manual

WWW.ARLEELIGHTING.COM
INSTALLATION GUIDE
BELLA ARCHITECTURAL
LINEAR SERIES
INSTALLATION FOR PENDANT INDEPENDENT
STEP 1
|
INSTALL MOUNTING POINT
STEP 2
|
HANG LUMINAIRE
NOTES:
• INDOOR USE ONLY
• AVOID FALLING
• IF IN DOUBT CONSULT A QUALIFIED ELECTRICIAN.DO NOT DISASSEMBLE IT AT YOUR OWN DISCRETION.
• UNDER NO CIRCUMSTANCES CAN THE LIGHTING FIXTURE BE COVERED WITH HEAT INSULATION GASKET OR SIMILAR MATERIALS.
• THE MAXIMUM CONNECTION OF EACH INPUT LINE IS LESS THAN 80FT(2400CM) IN 230AC,
LESS THAN 100FT(3000CM) IN 277AC, LESS THAN 40FT(1200CM) IN 120AC
BELLA ARCHITECTURAL
LINEAR SERIES

WWW.ARLEELIGHTING.COM
INSTALLATION GUIDE
BELLA ARCHITECTURAL
LINEAR SERIES
INSTALLATION FOR PENDANT CONTINUOUS RUN
STEP 1
|
TAKE OFF THE END CAP AND TAKE OUT THE LED MODULAR
STEP 2
|
INSTALL THE CANOPIES, CONNECTORS AND FORE AND AFT END CAPS
STEP 3
|
INSTALL THE FIRST LUMINAIRE,THEN WIRING
BELLA ARCHITECTURAL
LINEAR SERIES

WWW.ARLEELIGHTING.COM
INSTALLATION GUIDE
BELLA ARCHITECTURAL
LINEAR SERIES
STEP 4
|
CONNECT THE REST LUMINAIRES IN TURN
STEP 5
|
PRESS THE LED MODULAR INTO HOUSING
STEP 5*
|
IF CUSTOMIZE THE DIFFUSER, PRESS IT INTO THE LED MODULAR, THEN CLIPPING IN PLACE

WWW.ARLEELIGHTING.COM
INSTALLATION GUIDE
BELLA ARCHITECTURAL
LINEAR SERIES
INSTALLATION FOR SURFACE MOUNTED INDEPENDENT
STEP 1
|
MAKE HOLE IN THE CEILING STEP 2
|
INSTALL THE HOUSING IN THE CEILING
STEP 3
|
PRESS THE LED MODULAR INTO HOUSING AND STEP 4
|
INSTALL THE END CAP INTO HOUSING
CONNECT WIRES PROPERLY

WWW.ARLEELIGHTING.COM
INSTALLATION GUIDE
BELLA ARCHITECTURAL
LINEAR SERIES
INSTALLATION FOR SURFACE MOUNTED CONTINUOUS RUN
STEP 1
|
ACCORDING TO THE “INDEPENDENT LUMINAIRE” STEP 2
|
INSERT THE LINE CONNECTION KIT INTO FIRST HOUSING
STEPS TO INSTALL THE FIRST HOUSING
STEP 3
|
CONNECT THE REST LUMINAIRES IN TURN, THEN WIRING
STEP 4
|
PRESS THE LED MODULAR INTO HOUSING, THEN INSTALL THE END CAP
STEP 4*
|
IF CUSTOMIZE THE DIFFUSER, PRESS IT INTO THE LED MODULAR, THEN CLIPPING IN PLACE

WWW.ARLEELIGHTING.COM
INSTALLATION GUIDE
BELLA ARCHITECTURAL
LINEAR SERIES
WIRING DIAGRAM
STEP 1
For 120/230/277V applications make the following Electrical Connections:
a. Connect the black luminaire lead to the supply lead.
b. Connect the white luminaire lead to the neutral supply lead.
c. Connect the green or green/yellow ground lead to the green supply lead
STEP 2P 1
|
INSTALL MOUNTING POINT
a. If Dimming is an option; connect the violet dimming positive lead to the supply dimming positive lead. If dimming
is not being used, ensure to cap off the violet lead.
b. If Dimming is an option; connect the grey dimming negative lead to the supply dimming negative lead. If dimming
is not being used, ensure to cap off the grey lead.
