ARM Perfect Pod EZ-Shelf User manual

Please read the instruction booklet carefully before use.
INSTRUCTION MANUAL
©2016 ARM Enterprises, Inc.
16141 Heron Ave. La Mirada, CA 90638
Visit our Website:
www.perfectpod.com
For Customer Service:
Call 888-735-3621
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
EZ-Shelf
TM

KNOW YOUR EZ-SHELF:
(Optional) (Optional)
x1 x1
x1 set
x8
2
1
3
4
9 10
5 6
78
IMPORTANT:
Do not over tighten screws
It is recommended to use either Mounting Screws or Double Sided
Tape during install.
1. EZ-Shelf -The EZ-Shelf™is the lowest profile under cabinet
storage solution on the market. A simple magnetic catch and
unique 2-point pivot hinge system allows the EZ-Shelf™to open
easily at any position from fully retracted to fully extended.
2. Spacers with Cabinet Mounting - Spacer is used as an extension
to fit underneath cabinets that have a longer lip and or having
light fixtures.
3. Spacers without Cabinet Mounting - Extended spacer is needed
only if the desired length is not met.
4. Mounting Screws - These screws are to be used to screw in the
EZ-Shelf™to the cabinet.
5. Spacer Screws - These screws are used to only connect the EZ-
Shelf™to the Spacers.
6. Handle Screw - The screw is needed to connect the desired
Handle length and for the locking mechanism to work properly.
7. Short handle - This is a standard handle length
8. Long Handle - To be used to adapt to any cabinet style.
9. Double Sided Mounting Tape (Optional)- Can be used instead of
the Mounting Screws. For optimal results it is recommended to
NOT use both Mounting Screws and Double Sided Tape together
during install.
10. Handle Tool - This tool is to be used with the Handle Screw to
connect the desired handle to the EZ-Shelf™.
x1 set x8
x4 x1
x1

HOW TO INSTALL:
Double Sided Mounting Tape:
Be sure to align the EZ-
Shelf™. Open the EZ-Shelf™
and begin screwing in (2)
“Mounting Screws” through of
the inside of the EZ-Shelf™.
(See Figure 1)
FIGURE 1:
FIGURE 2:
FIGURE 3:
1
Move the tray forward and
use another (2)“Mounting
Screws” to mount to the
surface underneath the
cabinet. (See Figure 2)
If the EZ-Shelf™ does not
sit flush and is difficult to
operate due to the depth of
the cabinet space consider
using the Long Handle or a
combination of “Spacers”.
(See Figure 4)
NOTES:
NOTE:
2
(OPTIONAL) Double Sided
Mounting Tape is included if
you wish to not drill into the
surface under the cabinet .
There are double sided tape
indicators on the EZ-Shelf™
and the Spacer with Cabinet
Mounting.
(See Figure 3)
It is recommended to use
either Mounting Screws or
Double Sided Tape during
install.
Spacer with Cabinet Mounting
EZ-Shelf

HOW TO AND INSTALL HANDLE OPTIONS:
Place the desired handle
in the correct position on
the bottom of the tray and
attach the Handle Screw
using the Handle Tool from
the top of the tray to the
desired handle.
(See Figure 5)
Install spacers with or
without the Spacer without
Cabinet Mounting .
(See Figure 4)
If using Double Sided
Mounting Tape, attach
spacers with Spacer Screws
first than use the Double
Sided Mounting Tape on
the Spacer with Cabinet
Mounting. (See Figure 3 for
double sided tape indicators)
WHY THE SPACERS AND EXTRA HANDLES?
The EZ-Shelf™is
narrow so it will fit
in even the tightest
environments.
With the included spacers
and two different length
handles, the EZ-Shelf™
can be configured for any
cabinet style.
Cabinets are all
different, so the EZ-
Shelf™is designed to
be versatile.
Do not over tighten screws
Locking Mechanism will NOT
work until handle is installed.
FIGURE 4:
FIGURE 5:
IMPORTANT:
Short Handle
Handle Screw
Handle Tool
Long Handle (Oponal)
Extended Spacer Option:
Spacer Screws
Spacer Screws
Mounting Screws
Spacer without Cabinet Mounting
Spacer with Cabinet Mounting
EZ-Shelf Tray
