Armytek WIZARD C2 User manual
2 ENG USER MANUAL WIZARD C2 REV_00-0000
ENG USER MANUAL
Thank you for choosing the products of Armytek Optoelectronics Inc.
Please read this manual carefully before using the flashlight.
Specifications
Headlamp: simple one-hand operation, reliable headmount for
running. Solid body without long wires, weak rubber connectors and
unnecessary boxes.The flashlight is easily installed, removed and 180°
rotatable in the mount. Quick-release rubber ring provides additional
fixation
Every Day Carry light: compact design, convenient side button,
special matt anti-abrasive finish without rough knurling. Strong built-in
magnet and robust steel clip. Constant light without flickering
Bicycle light: made from aircraft-grade aluminium, optional durable
quick-release mount
• Total protection from water, dirt and dust — flashlight continues to
work even at 10 meters depth
• Convenient wide beam of the TIR-optics, protected from scratches by
tempered glass with anti-reflective coating
• Innovative technology allows to use any 18650 Li-Ion batteries and
provides full protection against short circuit even in case of contact
between magnetic connector and metal objects
• Active real-time temperature control to prevent overheating above
58 °C and warning indication of low battery level
• Robust and water resistant magnetic connector
Set description
Flashlight, 18650 Li-Ion battery, magnetic USB charger, clip, head-
mount, 2 spare O-rings, user manual.
The flashlight and accessories can inconsiderably dier from the
pictures in the manual.The producer reserves the right to change
the package at his own discretion without modifying this manual.
Specifications are subject to change without notice.
Model Wizard C2 (White)
LED/Optics Samsung LH351D/TIR
Brightness stabilization type DIGITAL (CPU brightness control)
Light output 1200 lm
Peak beam intensity 2890 cd
Hotspot : Spill 70°:120°
Beam distance 108 m
Modes,light output (OTF
lumens) and runtimes
(measured with 18650 Li-Ion
3200 mAh battery until the
light output drops to 10% of
the initial value)
Turbo 1200 lm/2 h 45 min (580 lm after 4 min)
Main3 390 lm/4 h 45 min
Main2 180 lm/11 h
Main1 40 lm/51 h
Firefly2 2 lm/26 d
Firefly1 0.11 lm/200 d
Power source 1x18650 Li-Ion
Length/Body diameter/Head diameter 112 mm/20.4 mm/33 mm
Weight without/with battery 64 g/114 g
Submersion and Impact resistance IP68, 10 m for 2 h.Height up to 10 m
* Light output for flashlights with Warm light is about 7% less, beam distance is about 3% less.
**All the above specifications are test results based on ANSI/NEMA FL1-2009 Standard.The tests are performed using the battery included in the set.
The data may vary due to environment, heat dissipation and other factors.
3WIZARD C2 USER MANUAL ENG
REV_00-0000
Initial Service
TO SET/REPLACE BATTERY
1. Unscrew the tailcap.
2. Place the battery with the positive contact (+) facing the head of the
flashlight.
3. Adjust the tailcap and tighten it as far as it can go.
The flashlight is ready for operation.
HOWTO CONNECTTHE MAGNETIC CHARGER
Unscrew the tailcap for 1/4 of a circle and adjust the magnetic charger
to the tailcap.
CHARGER COLOR INDICATION
Charger not plugged in:
• Green — device is in waiting mode.
Charger plugged in:
• Green blinking — evaluation of battery voltage.
• Red blinking — unscrew the tailcap for 1/4 for charging.
• Orange blinking — USB power source voltage is too low for correct
continuation of charging or bad contact between charger and battery.
Try cleaning the tailcap and the threads of the flashlight parts or use a
dierent power source.
• Red — charging is going on, charging current is 1A.
• Orange — USB power source voltage is too low, charging current has
been reduced by half.
• Green — charging is finished.
Operation
Before use: Tighten the tailcap.
In OFF state:
1 click: To turn on the last used mode.
Press and hold: To start cycling through Firefly modes. Release to
select. Keeping button pressed will start cycling through Main modes.
In ON state:
1 click: To turn o the flashlight.
Press and hold: To start cycling through Main modes from any mode. In
Firefly1 cycling through Main modes starts after cycling through Firefly
modes. Release to select.
2 clicks: To turn on Turbo mode from any mode.The second double click
brings back last used mode.
MOMENTARYACCESS
Firefly. Press and hold the button in OFF state to start cycling through
Firefly modes. Release to select. Keeping button pressed will start
cycling through Main modes.
Main. Short click from OFF state activates Main mode if it was the last
used mode.
Turbo. Double click in any mode in ON state.The second double click
brings back last used mode.
Cycling through Main modes. In ON state press and hold the button
in any mode.Main modes will start switching cyclically. In Firefly1
cycling through Main modes starts after cycling through Firefly modes.
Release to select.
Automemorizing. After switching o the last used mode is memorized
for quick access at next switching on.
Active temperature control. When the temperature of the flashlight
becomes close to 58 °С, brightness decreases to safe value, allowing
the flashlight to avoid overheating for a long period of time. In condi-
tions of good air-cooling the flashlight delivers light without stepping
down.
Low battery level. When the brightness is approximately <25% from
the nominal value, the LED will flash 2 times. If you are not sure wheth-
er or not it flashed, switch the flashlight
o and on: in case the battery is low, the flashes will repeat after 30 sec
from switching on. At critical level light output decreases to Firefly1."
Lock-out function. Unscrew the tailcap to 1/4 for the protection from
accidental switching on. State Indication will be turned o.
4 ENG USER MANUAL WIZARD C2 REV_00-0000
Warnings
For eective operation of the flashlight we recommend branded 18650
Li-Ion batteries without PCB (unprotected) no more than 70 mm long.
The flashlight can get hot in Turbo modes quickly and discharge the
battery with high current. Don’t leave it without your attention as very
bright light might heat objects and cause fire.
1. Always follow the instructions from this manual and recommenda-
tions on battery usage.
2. Apply only the recommended power sources.
3. Do not reverse battery polarity.
4. Do not modify or recast the flashlight and its components as it will
deprive you of the warranty.
5. Do not allow water or any other liquid to leak into the flashlight.
6. Do not aim a switched-on flashlight at people's or animals' eyes – it
can cause temporary blindness.
7. Do not allow children to use the flashlight without your assistance.
The producer will not be liable forany harm done to the userif it
was caused by improperuse of the product.
Care and Storage
It is recommended to clean the threads and O-rings o dirt and old
grease once or twice per year. Remember that reliable protection from
water and dust cannot be provided by worn out sealing.The fouling
as well as lack of lubricant cause fast wear-out of threads and sealing
rings.
To clean the threads do the following:
1. Unscrew the tailcap and remove the sealing ring carefully with a
toothpick (do not use sharp metal things as they can damage the
ring).
2. Wipe the sealing ring thoroughly with a soft cloth (or tissue). Do not
use solvents. If the sealing ring is worn out or damaged replace it by
a new one.
3. Clean the metal threads with a brush using ethanol. Be careful not to
allow the applied liquid to get inside the flashlight or tailcap as it can
cause fails in functionality of the flashlight.
After cleaning lubricate the thread and the sealing ring with polyal-
phaolefin-based silica grease, e.g. Nyogel 760G.The application of
other types of grease is unacceptable. In case of active operation and
exploitation in dusty environments, it is recommended to perform
cleaning and lubricating of the parts as often as required.
WE DO NOTRECOMMEND to leave power sources inside the flash-
light for a long storage period, as batteries (especially non-recharge-
able) can leak for various reasons and damage the inner parts of the
flashlight. If you want to keep your flashlight in a stand-by state with
batteries in, previously install new and high-quality batteries, store
the flashlight in acceptable for batteries operational temperature and
revise the batteries' state at least once a month. If you have noticed any
signs of defects, withdraw the batteries from the flashlight and dispose
of them.
Warranty and Service
Armytek provides free warranty repairs for 10 years (excluding bat-
teries, chargers, switches and connectors, which have 2-year warran-
ty) from the date of purchase if there is a document confirming the
purchase.The warranty does not extend to damage during:
1. Improper usage.
2. Attempts to modify or repair the flashlight by nonqualified
specialists.
3. Long-term application in chlorinated and contaminated liquids or
sea water.
4. Exposure to high temperatures and chemicals (including the liquids
from defected batteries).
5. Usage of low-quality batteries.
Armytek Optoelectronics Inc.
Germany, 10551 Berlin,Jonasstraße 6
www.armytek.com
