array K Python KP52-54 Mark I User manual

KP52-54 I - KP102-54 I Ver. 1.0
KP52-54 Mark I
KP102-54 Mark I
USER GUIDE
English
Python

KP52-54 I - KP102-54 I Ver. 1.0
2
TABLE OF CONTENTS
SYMBOLS ................................................................................ 3
1. INTRODUCTION ..................................................................... 4
2. KEY FEATURES ...................................................................... 4
3. SAFETY INFORMATION............................................................ 5
4. UNPACKING ......................................................................... 6
5. PHYSICAL ............................................................................. 6
5.1 KP52-54 I LAYOUT .............................................................................. 6
5.2 KP102-54 I LAYOUT............................................................................. 7
6. WIRING ................................................................................ 8
6.1 IMPEDANCE SWITCH ............................................................................ 8
6.2 COVERAGE SWITCH ............................................................................. 9
7. HANGING ON THE WALL.........................................................10
8. SERVICE ............................................................................. 11
9. TECHNICAL SPECIFICATIONS ................................................... 12
10. EN54-24 DATA .................................................................... 13

KP52-54 I - KP102-54 I Ver. 1.0
3
SYMBOLS
This symbol alerts the user to the presence of recommendations about
product’s use and maintenance.
This symbol alerts the user to the presence of recommendations about the
product’s use and maintenance.
K-array declares that this device is in compliance with applicable CE
standards and regulations. Before putting the device into operation, please
observe the respective country-specific regulations!
Waste Electrical and Electronic Equipment (WEEE)
Please dispose of this product at the end of its operational lifetime by bringing
it to your local collection point or recycling center for such equipment.
This device complies with the Restriction of Hazardous Substances Directive.
Warning: DANGEROUS VOLTAGE.
Terminals marked with this symbol carry a risk of electric shock, therefore
external wiring connected to these terminals requires installation by a
qualified professional or the use of ready-made leads or cords.

KP52-54 I - KP102-54 I Ver. 1.0
4
1. INTRODUCTION
2. KEY FEATURES
The K-array KP52-54 I and KP102-54 I are specifically designed to be included in voice alarm systems.
The K-array Pythons are passive speaker systems, comprised of 3.15” neodymium magnet transducers
housed in an elegant and sturdy stainless steel chassis. Available in two lengths, the KP52-54 I features
6 drivers in a 0.5 m (20”) chassis, while the KP102-54 I features 12 drivers in a 1 m (40”) chassis.
The Pythons’s closely spaced cone drivers provide phase coherence, low distortion and focused listening
both up close and at a distance.
To accommodate a range of applications, the vertical dispersion pattern can be switched for either wide
or narrow coverage.
For integration with other speakers or amplifiers, the KP52-54 I and KP102-54 I offer selectable
impedance (8Ω/32Ωfor the KP52-54 I and 4Ω/16Ωfor the KP102-54 I).
Pythons are able to reproduce the entire vocal frequency range with excellent intelligibility, starting from
100 Hz.
Integrating powered K-array subwoofers (KMT12, KMT18, KMT21, KMT218) ensures excellent coverage of
the entire musical frequency range. K-array’s KA amplifier series also features custom presets, optimized
for use with the Python series.
All Python components are designed by K-array and custom-made under K-array’s quality control system.
• EN54-24 compliant
• Unique performance-to-size ratio
• Vertical and Horizontal applications
• Multiple 3.15” long-excursion full-range cone drivers
• Wide horizontal coverage
• Selectable vertical pattern (Spot/Flood)
• Electronically protected
• Selectable impedance (KP52-54 I: 8/32 Ω, KP102-54 I: 4/16 Ω)
• Weather proof, suitable for outdoor installations - IP54
• Available in black or white

KP52-54 I - KP102-54 I Ver. 1.0
5
3. SAFETY INFORMATION
Warning: failure to follow these safety instructions could result in injury
or damage to the device or other property.
IMPORTANT SAFETY INSTRUCTIONS
• Read these instructions.
• Keep this instructions.
• Heed all warnings.
• Follow all instructions and keep all warnings.
• Only use attachments/accessories specified by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or
sold with the apparatus.
• When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
• Avoiding hearing damage. Professional loudspeakers are capable of producing extremely high sound
levels and should be used carefully. Never stand close to loudspeakers driven at high volume. Set
the volume to a safe level. You can adapt over time to a higher volume of sound that over time
may sound normal but can be damaging to your hearing. Hearing loss worsens after exposure to a
sound level of 90 dB or over for an extended period of time. If you experience ringing in your ears
or muffled speech, stop listening and have your hearing checked. The louder the volume, the less
time is required before your hearing could be affected.
• Choking Hazards. This device contains small parts, which may present a choking hazard to small
children. Keep the device and its accessories away from small children.
• Do not make repairs yourself. Never attempt to disassemble, repair or modify the system yourself.
Disassembling the unit may cause damage that is not covered under the warranty. The device contains
no user-serviceable parts. Repairs should only be performed by factory trained service personnel.
• Sound distortion. Do not operate speakers for an extended period of time with sound distortion. This
is an indication of malfunction, which in turn can generate heat and result in a fire.
• Carrying, handling and installing the device. The device contains sensitive components. Do not drop,
disassemble, open, crush, bend, deform, puncture, shred, incinerate, paint, or insert foreign objects
into it. If your device has been dropped or damaged unplug the power cable immediately.
• Set up. Set up your device on a stable retaining horizontal surface. If combined or mechanically
connected with other products, always verify the stability of the resulted system. Install the unit only
in a location that can structurally support the weight of the unit and far away from people who can
interfere with the stability of the system. Assure that the wind does not interfere with the system’s
stability, taking extra securities like chains, weights, ropes or any other certified anchoring systems.
Doing otherwise may result in the unit falling down, causing personal injury or property damage
or even death. The system should only be suspended by qualified personnel following safe rigging
practices. Secure fixings to the building structure are vital. To clarify any doubt you may have, seek
help from architects, structural engineers or other specialists.

KP52-54 I - KP102-54 I Ver. 1.0
6
4. UNPACKING
Each K-array speaker is built to the highest standard and thoroughly inspected before leaving the
factory. Upon arrival, carefully inspect the shipping carton, then examine and test your new amplifier.
If you find any damage, immediately notify the shipping company. Only the consignee may institute a
claim procedure regarding the system’s electronic equipment.
5. PHYSICAL
Weight
5.8 kg (12.8 lbs)
5,9in
150mm
8,7in
220mm
5,9in
150mm
20,5in
520mm
3,5in
88,5mm
5,0in
127mm
4,6in
118mm
0,8in
21mm
4,8in
121,8mm
0,8in
21mm
5.1 KP52-54 I LAYOUT

KP52-54 I - KP102-54 I Ver. 1.0
7
5.2 KP102-54 I LAYOUT
3,5in
88,5mm
ni0,5
mm821
4,6
118mm
5,9in
150mm
27,6in
700mm
5,9in
150mm
1,1in
27,5mm
1,1in
27,5mm
4,8in
121,8mm
39,4in
1000mm
Weight
12 kg (26.5 lbs)

KP52-54 I - KP102-54 I Ver. 1.0
8
6. WIRING
KP52-54 I and KP102-54 I feature a 2x2.5 cable coming out from the chassis, ready to be connected to
the cable coming from the amplifier.
6.1 IMPEDANCE SWITCH
KP52-54 I and KP102-54 I feature a switch which allows users to select the impedance of the speaker
(KP52-54 I: 8/32 Ω, KP102-54 I: 4/16 Ω).
The value to be selected depends mainly on the amplifier you use to drive the unit. Impedance must
be set to high (32 Ωfor KP52-54 I and 16 Ωfor KP102-54 I) when speakers are driven by KMT active
modules or by the KA84 amplifier. Low impedance may be used when speakers are driven by a KA24
amplifier.
Please refer to your amplifier’s specifications to select the correct speaker impedance for your
configuration.
IMPEDANCE SWITCH COVERAGE SWITCH
KA24 amp KA84 amp KMT sub
KP52-54 I @ 8 ΩYES NO NO
KP52-54 I @ 32 ΩNO YES YES
KP102-54 I @ 4 ΩYES NO NO
KP102-54 I @ 16 ΩNO YES YES
Red +
Black -

KP52-54 I - KP102-54 I Ver. 1.0
9
KP52-54 I and KP102-54 I feature a switch which allows users to select the vertical coverage of the
speaker.
Flood coverage sets a wide vertical diffusion. Flood coverage is suggested for single speakers in diffused
short throw applications to obtain maximum diffusion with a minimum footprint.
Spot coverage sets a narrower vertical diffusion angle and is recommended for long throw or monitoring
application.
SPOT Coverage
FLOOD Coverage
6.2 COVERAGE SWITCH

KP52-54 I - KP102-54 I Ver. 1.0
10
7. HANGING ON THE WALL
The K-WALL2 and K-WALL2L accessories are used to mount a speaker on a wall.

KP52-54 I - KP102-54 I Ver. 1.0
11
8. SERVICE
To obtain service:
1) Contact the official K-array distributor in your country. Your local distributor will direct you to the
appropriate service center.
2) If you are calling for service, please have the serial number(s) of the unit(s) available for reference.
Ask for Customer Service and be prepared to describe the problem clearly and completely.
3) If the problem cannot be resolved over the phone, you may be required to send the unit in for
service. In this instance, you will be provided with an RA (Return Authorization) number which should
be included on all shipping documents and correspondence regarding the repair. Shipping charges are
the responsibility of the purchaser.
Any attempt to modify or replace components of the device will invalidate your warranty. Service must
be performed by an authorized K-array service center.
Cleaning:
Use only a soft, dry cloth to clean the product. Do not use any solvents, chemicals, or cleaning
solutions containing alcohol, ammonia, or abrasives. Do not use any sprays near the product or
allow liquids to spill into any openings.

KP52-54 I - KP102-54 I Ver. 1.0
12
9. TECHNICAL SPECIFICATIONS
Notes for data
1. With dedicated preset;
2. Measured @8 mt then scaled @1 mt;
3. Measured with musical signal
New materials and design are introduced into existing products without previous notice.
Present systems may differ in some respects from those presented in this catalogue.
KP52-54 I KP102-54 I
ACOUSTICS
Power handling 720 W(AES)
Max power 1200W
Frequency Range 100 Hz – 20 kHz (- 10dB) (1)
Impedance 4 Ω/ 16 Ω(selectable)
SPL 1W/1mt 99 dB (2)
Maximum SPL 128 dB (cont.) – 134 dB (peak)
COVERAGE
Horizontal 90°
Vertical 7°- 30° (selectable)
CROSSOVER
Type External Crossover required
Frequency 100 Hz, 24 dB/oct
suggested minimum
TRANSDUCERS
Full range 12 x 3.15” Neodymium magnet with 1”
voice coil
SELECTION SWITCHES
Impedance 4 Ω/ 16 Ω
Coverage Spot / Flood
POWER AUDIO INPUT
Wiring + Red; - Black
RECOMMENDED AMPLIFIERS
Type KA24, KA84
CERTIFICATION
IP 54
PHYSICAL
Dimensions 8.9 x 100.0 x 11,8 cm
(3.5” x 39.37” x 4.64”)
Weight 12.0 kg (26.5 lbs)
ACOUSTICS
Power handling 360 W(AES)
Max power 600W
Frequency Range 100 Hz – 20 kHz (- 10dB) (1)
Impedance 8 Ω/ 32 Ω(selectable)
SPL 1W/1mt 96 dB (2)
Maximum SPL 122 dB (cont.) – 128 dB (peak)
COVERAGE
Horizontal 90°
Vertical 10°- 45° (selectable)
CROSSOVER
Type External Crossover required
Frequency 100 Hz, 24 dB/oct
suggested minimum
TRANSDUCERS
Full range 6 x 3.15” Neodymium magnet with 1”
voice coil
SELECTION SWITCHES
Impedance 8 Ω/ 32 Ω
Coverage Spot / Flood
POWER AUDIO INPUT
Wiring + Red; - Black
RECOMMENDED AMPLIFIERS
Type KA24, KA84
CERTIFICATION
IP 54
PHYSICAL
Dimensions 8.9 x 52.0 x 11,8 cm
(3.50” x 20.47” x 4.64”)
Weight 5.8 kg (12.78 lbs)

KP52-54 I - KP102-54 I Ver. 1.0
13
The contents of this manual are furnished for informational purposes only. K-array s.u.r.l. assumes no responsibility for any errors or inaccuracies that may
appear in this manual. K-array s.u.r.l. reserves the right to make modifications without prior notice.
10. EN54-24 DATA
Power handling 360 W
SPL 1W/1m 96 dB
Maximum SPL 122 dB
Connector IN + Red ; - Black
Vmax In (Pink Noise) 13.40 V @ 8 Ohm
26.80 V @ 32 Ohm
Frequency Range 100 Hz - 20 kHz
Coverage Horizontal
180° @ 500 Hz
170° @ 1000 Hz
130° @ 2000 Hz
120° @ 4000 Hz
Coverage Vertcal
50° @ 500 Hz
25° @ 1000 Hz
12° @ 2000 Hz
20° @ 4000 Hz
KP52-54 I KP102-54 I
KP52-54 I I and KP102-54 I I are EN54-24 compliant. Consider the specifications below when either
model is used in a voice alarm system.
K-array
0068-CPR-xxx /2017
EN 54-24 : 2008
Loudspeaker for voice alrm systems for fire
detection and fire alarms systems for buildings
KP52-54 I
TYPE B
K-array
0068-CPR-xxx /2017
EN 54-24 : 2008
Loudspeaker for voice alrm systems for fire
detection and fire alarms systems for buildings
KP102-54 I
TYPE B
Power handling 720 W
SPL 1W/1m 99 dB
Maximum SPL 128 dB
Connector IN + Red ; - Black
Vmax In (Pink Noise) 13.40 V @ 4 Ohm
26.80 V @ 16 Ohm
Frequency Range 100 Hz - 20 kHz
Coverage Horizontal
180° @ 500 Hz
170° @ 1000 Hz
130° @ 2000 Hz
120° @ 4000 Hz
Coverage Vertcal
20° @ 500 Hz
12° @ 1000 Hz
7° @ 2000 Hz
10° @ 4000 Hz
