Arrow 1750 DIGITAL User manual

260 P ENNSYLVANIA A VE ., H ILLSIDE , NJ 07205
TEL: [phone] -- FAX: [phone]
EMAIL: [email protected]
Website - http://www.arrowmixingproducts.com
Arrow 1750 D I G I T A L
OPERATING INSTRUCTIONS EN
Conforms to
UL STDs 61010-1 & 61010-2-051
Certified to
CSA STDs C22.2
No. 61010-1-12 & 61010-2-51
0000000


A B C D (behind unit)
I
E F
G H
Fig. 1 see Fig. 2
OPERATING INSTRUCTIONS
1. Set variable speed control knob (A) to min.
2. Set power switch (B) to “off” position
3. Plug in unit into outlet specified on label (E)
4. Set power switch (B) to “on position”
5. Slowly turn variable speed control knob (A)
clockwise to desired speed
SHUT-DOWN INSTRUCTIONS
1. Set variable speed control knob (A) to min.
2. Set power switch (B) to “off” position
3. Unplug unit from outlet
A) Variable Speed Control Knob
B) Power Switch
C) Digital Speed Display (rpm)
D) Manually Resettable Circuit Breaker (behind unit)
-Gently Press Button on Back to Reset Breaker
E) Voltage and Cycle Requirements for Unit
F) Amperage Draw of Unit
G) Model Number
H) Unique Serial Number of your Unit*
I) Motor Brush Housing (x2)
Motor Spec 1/14 HP
–
120 vac 60 hz
Speed Range 0-2000 rpm
Torque Constant** 2.25 in-lb / 36 in-oz
Shipping Weight 10 lbs. / 4.5 kg
Shipping Dimensions 14” x 12” x 7”
* Please reference this serial number (H) when ordering
replacement parts
** Torque value at maximum rpm
Coupling Chuck
Fi
g. 2 (optional)
Attaching a Coupling or a Chuck to the Mixer Unit
When attaching a chuck or coupling, always align and tighten
the set screws, (J) see Fig. 3, only onto the flat surface of the
motor shaft (shaded area) see Fig. 2.
Failure to do so could cause damage to the shaft and prevent
the coupling or chuck from being removed.
J
K
Fig. 3
SHAFT-COUPLING-PROPELLER
ASSEMBLY
As with the motor shaft, always
align and tighten the set screws,
(K) see Fig. 3, only onto the flat
surface of the propeller shaft.
When removing the propeller,
grasp shaft tightly, preferably in a
vise, and gently tap the propeller
counterclockwise at the base of
the blade (L). The propeller is
threaded onto the shaft.
L (propeller style varies by model)


SAFEFTY INSTRUCTIONS
Readtheoperatinginstructionsinfullbeforestarting
upandfollowthesafetyinstructions.
•Keeptheoperatinginstructionsinaplacewhereitcanbe
accessedbyeveryone.
•Ensurethatonlytrainedstaffworkwiththeinstrument.
•Followthesafetyinstructions,guidelines,occupational
healthandsafetyandaccidentpreventionregulations.
•Becausetheoptionsforcombiningproducts,tools,stirring
vessel,experimentandmediumarenearlyendless,
usersafetycannotbeensuredsimplywithdesignrequirements
onthepartoftheproduct.Forthisreason,itmay
becomenecessaryforuserstotakeotherprecautionary
safetymeasures.Forexample,glassapparatusorother
stirringvesselsthataresensitivetomechanicalstresscan
bedamagedorshatteredbyanimbalance,increasingthe
speedtooquicklyortoolittledistancebetweenthestirring
elementandthestirringvessel.Userscansufferserious
injuryfromglassbreakageorfromthefreelyrotating
stirringelement.
•Uncontrolledreactionscanbetriggeredbymixingthe
heatedmaterialinsufficientlyorbytheenergygenerated
byselectingaspeedthatistoohigh.Incaseofthese
andotherincreasedoperationalhazards,usersmusttake
additionalappropriatesafetyprecautions(e.g.shatter
protection).Inanycase,whenusingcriticalorhazardous
materialsinyourprocesses,Arrow
 recommendsusing
additionalappropriatemeasurestoensuresafetyinthe
experiment.Forexample,userscanimplementmeasures
thatinhibitfireorexplosionsorcomprehensivemonitoring
equipment.Furthermore,usersmustmakesurethat
theOFFswitchoftheArrow
 productcanbeaccessed
immediately,directlyandwithoutriskatanytime,and
aboveall,incaseoffault.

Ifmainsswitchcannotensure
thisaccessatalltimes,anadditionalEMERGENCYSTOPswitch
thatcanbeeasilyaccessedmustbeinstalledintheworkarea.

•Onlyprocessmediathatwillnotreactdangerouslytothe
extraenergyproducedthroughprocessing.Thisalsoapplies
toanyextraenergyproducedinotherways,e.g.
throughlightirradiation.
•Donotoperatetheinstrumentinexplosiveatmospheres,
withhazardoussubstancesorunderwater.
•Theinstrumentisnotsuitableformanualoperation.
•Thehightorquedevelopedbythe1750digitalrequires
particularcareinthechoiceofstand,crosssleeve
andanti‐rotationelementfortheagitatingvessel.
•Setupthestandinaspaciousareaonaneven,stable,
clean,non‐slip,dryandfireproofsurface.
•Youmustensurethatthestirringelementissecurely
clampedinthecouplingorchuck.

Whenusingachuck,makesuretoremovethe
chuckkeyfromthechuckbeforeturningonthedevice.

•Usestirringshaftprotectiveequipment!
•Theagitatedvesselsusedforstirringhavetobesecured.
Consideronagoodstabilityoftheentirestructure.
•Protecttheinstrumentandaccessoriesfrombumping
andimpacting.
•Checktheinstrumentandaccessoriesbeforehandfor
damageeachtimeyouusethem.Donotusedamaged
components.
•AlwaysswitchthemainsswitchintheOFFpositionor
disconnectthepowerbeforechangingstirringelement
andfittingallowedaccessories.
•Theinstrumentcanonlybedisconnectedfromtheelectrical
outletsupplybypullingontheplug.Donotpullonthecordto
disconnectpower.
•Thesocketfortheelectriccordmustbeeasilyaccessible.
•Theelectricaloutletmustbegrounded(protectiveground
contact).
•Thevoltagestatedonthelabel(seeFig.1‐E)mustcorrespond
totheelectricaloutlet’svoltage.
•Pleaseobservethepermittedspeedforthestirringelement.
Neversetathigherspeed.
•Makecertainthattheunitissetatthelowestspeedbefore
turningthepowerswitchon;otherwise,theunitwill
immediatelybeginrunning.Graduallyincreasetorequired
speed.
•Payattentionwhensettingthespeedtoanyimbalanceof
thestirrertoolsandpossiblesprayingofthemediumto
bestirred.

Neveroperatetheinstrumentwiththestirrer
toolsrotatingfreely.Ensurethatpartsofthebody,hair,jewelry
oritemsofclothingcannotbetrappedbytherotatingparts.

Theoperationofafreerotatingshaftendis
dangerous,therefore,forsafetyreasons,onlyinsertthestirring
toolintotheupperedgeofstirringvesselwiththemotoroff.
Whenfinished,turnthemotoroffbeforeliftingthestirringtool
outofthevessel.
NOTE:
ArrowMixingProductsoffersrepairandmaintenanceonall
equipment.AnRMAmustberequestedandincludedwithall
returns.Arrowwillinspecttheunitandcallyouwithaquote
beforeanyworkisdone.


Wearyourpersonalprotective
equipmentinaccordancewith
thehazardcategoryofthemedium
tobeprocessed.Otherwisethereisariskof:

‐splashingofliquids
‐projectileparts
‐bodyparts,hair,clothingandjewelrygettingcaught.

Bewareoftheriskof:

‐flammablematerials
‐glassbreakageasaresultofmechanicalshakingpower.

Reducethespeedif:

‐themediumsplashesoutofthevesselbecausethe
speedistoohigh
‐theinstrumentisnotrunningsmoothly
‐theinstrumentbeginstomovearoundbecauseofdynamic
forces
‐anerroroccurs.

Donottouchrotatingpartsduringoperation!

•Theremaybeelectrostaticactivitybetweenthemedium
andtheoutputshaftwhichcouldcauseadirectdanger.
•Itisimportanttonotethatthesurfacesofthemotorand
certainpartsofthebearingmaygetveryhotduringoperation.
•Avoidknockingandimpactingonthelowerendofthe
shaftandthechuckgearteeth.Evenminor,invisibledamage
canleadtoimbalanceandunevenshaftaction.
•Ensurethatthestanddoesnotstarttomove.
•Imbalanceoftheoutputshaft,thechuckandinparticular
thestirringtoolscanleadtouncontrolledresonant
vibrationalbehavioroftheinstrumentandthewhole
assembly.Glassapparatusandstirrercontainerscanbe
damagedorshatteredbythis.Itcancauseinjurytothe
operator,alsocandamagetherotatingstirringtool.In
thiscase,exchangethestirringtoolforonewithoutimbalance
orremedythecauseoftheimbalance.Ifthereis
stillimbalance,returnittothedealerorthemanufacturer
alongwithadescriptionofthefault.
•Iftheinstrumentisoperatedaboveitscapabilities,thereset
buttonwilltrip.
•Themachinemustonlybeopenedbytrainedspecialists,
evenduringrepair.Theinstrumentmustbeunplugged
fromthepowersupplybeforeopening.Livepartsinside
theinstrumentmaystillbeliveforsometimeafterunplugging
fromthepowersupply.

Coveringorpartsthatarecapableofbeing
removedfromtheunitwithoutaccessoryequipmenthavetobe
reattachedtotheunitforsafeoperationinordertoprevent,for
example,theingressoffluids,foreignmatter,etc.

CORRECT USE
•Use:
Formixing/stirringliquidswithlowtohighviscosityby
usingvariousstirringtools.

Intendeduse:Standdevice(MotorShaftdownward).

•Rangeofuse(indooruseonly):
‐Laboratories‐Schools
‐Pharmacies–Universities
‐R&DandProductionFacilities
Thesafetyoftheusercannotbeguaranteed:
‐Iftheinstrumentisoperatedwithaccessoriesthatarenot
suppliedorrecommendedbythemanufacturer
‐Iftheinstrumentisoperatedimproperlyorcontrarytothe
manufacturer’sspecifications
‐Iftheinstrumentortheprintedcircuitboardaremodified
bythirdparties.
MAINTENANCE
•MotorBrushes
Motorbrusheseventuallywearoutandneedtobe
replaced.Frequencywillvarydependingonusage.
Foratutorialonhowandwhentoreplacebrushes,visit:
https://www.youtube.com/watch?v=Sp8L6DED1Ig
orfollowthisQRcode.
•Cleaning
Motorscanbewipeddownwithadampcloth.Avoidsprayingliquids
directlyontothemotor.



•Warranty
Allunitscomewithaone‐yearwarrantyagainstmanufacturing
defects.Openingormodifyingthemotorwillvoidthewarranty.



