Art’s-Way Manufacturing Co., Inc.
Model JR50 & JR75
Compact Grinder Mixer
Illustrated Parts List
642550
Issued June 2018
ILLUSTRATED PARTS LIST

This symbol means ATTENTION! BECOME ALERT! YOUR SAFETY IS IN-
VOLVED. The message that follows the symbol contains important information
about your safety. Carefully read the message. Make sure you fully understand the
causes of possible injury or death.
IF THIS MACHINE IS USED BY AN EMPLOYEE, IS LOANED, OR IS RENTED, MAKE
SURE THAT THE OPERATOR UNDERSTANDS THE TWO INSTRUCTIONS BELOW.
BEFORE THE OPERATOR STARTS THE ENGINE:
GIVE INSTRUCTIONS TO THE OPERATOR ON SAFE AND CORRECT USE OF THE
MACHINE.
MAKE SURE THE OPERATOR READS AND UNDERSTANDS THE OPERATOR’S MANU-
AL FOR THIS MACHINE.
WARNING
IMPROPER OPERATION OF THIS MACHINE CAN CAUSE INJURY OR DEATH.
BEFORE STARTING THE ENGINE, DO THE FOLLOWING:
1. READ THE OPERATOR’S MANUAL.
2. READ ALL SAFETY DECALS ON THE MACHINE.
3. CLEAR THE AREA OF OTHER PERSONS.
4. LEARN AND PRACTICE SAFE USE OF MACHINE CONTROLS IN A SAFE AND
CLEAR AREA BEFORE YOU OPERATE THIS MACHINE ON A JOB SITE.
It is your responsibility to observe pertinent laws and regulations and to follow manufac-
turer’s instructions on machine operation and maintenance.
See your Authorized Art’s-Way Manufacturing Co., Inc. dealer or
Art’s-Way Manufacturing Co., Inc. for additional operator’s manuals, illustrated parts cata-
logs, and service manuals.

Art’s-Way Manufacturing Co., Inc.. Manual No. 642550
TO THE OWNER 1
Congratulations on the purchase of your new Art’s-Way Compact Grinder Mixer. You have selected a top
quality machine that is designed and built with pride to ensure you have many years of efficient and reliable
service.
Many people have worked on the design, production, and delivery of this Compact Grinder Mixer. The
information in this manual is based on the knowledge, study, and experience through years of specializing
in the manufacturing of farm machinery. This manual is designed to provide you with important information
regarding safety, maintenance, and machine operation so you can and will get the best possible performance
from your Compact Grinder Mixer.
Even if you are an experienced operator of this or similar equipment, we ask that you read this manual
before operating this Compact Grinder Mixer. The way you operate, adjust, and maintain this unit will have
much to do with its successful performance. Any further questions you may have about this product of Art’s-
Way equipment should be directed to your local Art’s-Way dealer or to Art’s-Way Manufacturing Co., Inc.
Armstrong, Iowa, 50514, [phone].
SPECIFICATIONS AND DESIGN ARE SUBJECT TO CHANGE WITHOUT NOTICE
Art’s-Way Manufacturing Co., Inc. is continually making product improvements. In doing so, we reserve
the right to make changes and/or add improvements to our products without obligation for the equipment
previously sold.
Modifications to this Compact Grinder Mixer may affect the performance, function, and safety of its operation.
Therefore, no modifications are to be made without the written permission of Art’s-Way Manufacturing Co., Inc.
Any modification made without the written permission of Art’s-Way Mfg. Co. Inc. shall void the warranty of this
product.
In the interest of continued safe operation of this Compact Grinder Mixer, pay particular attention to the safety
alert symbol(s) throughout this manual.
Art’s-Way Manufacturing Co., Inc. STATEMENT OF PRODUCT LIABILITY
Art’s-Way Manufacturing Co., Inc. recognizes its responsibility to provide customers with a safe and efficient
product. Art’s-Way Manufacturing Co., attempts to design and manufacture its products in accordance with
all accepted engineering practices effective at the date of design. This statement should not be interpreted
to mean that our products will protect against the user’s own carelessness or failure to follow common safety
practices nor will Art’s-Way Manufacturing Co., be liable for any such act. In addition, Art’s-Way Manufacturing
Co., assumes no liability for any altered product or any modified product by users or anyone other than an
authorized dealer.
IMPORTANT WARRANTY INFORMATION
The warranty for this Compact Grinder Mixer appears on page 6 of this manual. In order to establish proper
warranty registration, the Warranty Registration must be completed and returned to the factory. Failure to
comply with this requirement will result in invalidating the warranty!
LIMITATIONS OF THIS MANUAL
This manual contains operating instructions for your JR50 & JR75 Compact Grinder Mixer only. Any mention
of other machinery in this manual other than the JR50 & JR75 Compact Grinder Mixer is for reference only.
This manual does not replace nor is it to be used for any machinery that may be attached to or used in
conjunction with the JR50 & JR75 Compact Grinder Mixer.
TO THE OWNER

Manual No. 642550 Art’s-Way Manufacturing Co., Inc.
2 PARTS & SERVICE
As the purchaser of your new grinder mixer, it is very important to consider the following
factors:
A. Original Quality
B. Availability of Service Parts
C. Availability of Adequate Service Facilities
Art’s-Way Manufacturing Co., Inc. has an excellent dealership network ready to answer any
questions you may have about your grinder mixer. Parts for your machine may be ordered
through our dealers. When placing a parts order, please have the model and serial number
ready. This will allow the dealer to fill your order as quickly as possible.
For your convenience, we have provided this space for you to record your model number,
serial number, and the date of purchase, as well as your dealer’s name and address.
PARTS & SERVICE

Art’s-Way Manufacturing Co., Inc.. Manual No. 642550
TABLE OF CONTENTS 3
TO THE OWNER 1
SPECIFICATIONS AND DESIGN ARE SUBJECT TO CHANGE WITHOUT NOTICE 1
Art’s-Way Manufacturing Co., Inc. STATEMENT OF PRODUCT LIABILITY 1
IMPORTANT WARRANTY INFORMATION 1
LIMITATIONS OF THIS MANUAL 1
PARTS & SERVICE 2
TABLE OF CONTENTS 3-5
LIMITED WARRANTY 6
SAFETY FIRST 7
NOTICES OF DANGER, WARNING, AND CAUTION 7
Safety Instructions 8
GENERAL 8
BEFORE OPERATING 9
DURING OPERATION 9
MAINTENANCE SAFETY 9
HYDRAULIC SAFETY 10
TRANSPORTATION SAFETY 10
STORAGE SAFETY 10
TIRE SAFETY 11
ASSEMBLY SAFETY 11
TABLE OF CONTENTS

Manual No. 642550 Art’s-Way Manufacturing Co., Inc.
4 TABLE OF CONTENTS
TABLE OF CONTENTS
NAME PAGE
HITCH ASSEMBLY 14
MIX MILL & AUGER ASSEMBLY 16
WINDOWS & ETC. ASSEMBLY 18
HAMMERMILL OUTER ASSEMBLY 20
MILL MIX DRIVE ASSEMBLY 22
FRONT SHIELD ASSEMBLY 24
AIR SYSTEM ASSEMBLY 26
HYDRAULIC ASSEMBLY 28
DISCHARGE ELBOW ASSEMBLY 30
DISCHARGE SWING ASSEMBLY 32
DISCHARGE HOOD ASSEMBLY 34
SHIELDS & ADDITIONAL PARTS ASSEMBBLY 36
MIXING AUGER ASSEMBLY 38
WEIGHBARS AND GEARBOX ASSEMBLY 40
WEIGHBARS AND GEARBOX ASSEMBLY (CONTINUED) 42
AUGER FEEDER MOUNT ASSEMBLY 44
AUGER FEEDER ASSEMBLY 46

Art’s-Way Manufacturing Co., Inc.. Manual No. 642550
TABLE OF CONTENTS 5

Manual No. 642550 Art’s-Way Manufacturing Co., Inc.
6 LIMITED WARRANTY
SEE OPERATORS MANUAL
FOR
WARRANTY INFORMATION

Art’s-Way Manufacturing Co., Inc.. Manual No. 642550
SAFETY FIRST 7
SAFETY
INSTRUCTIONS
“A careful operator is the best insurance against an
accident.” Quote from the National Safety Council.
Most accidents can be prevented if the operator:
1. Fully understands how the machine functions.
2. Can anticipate situations which may produce
problems.
3. Can make necessary corrections before
problems develop.
THIS SYMBOL MEANS ATTENTION!
BECOME ALERT!
YOUR SAFETY IS INVOLVED!
- Universal Safety Alert Symbol
The American Society of Agricultural Engineers has
adopted the Universal Safety Alert Symbol as a way
to identify areas of potential danger if the equipment
is not operated correctly. Please be alert whenever
you see this symbol in the manuals or on your
grinder mixer.
Art’s-Way Manufacturing Co., Inc. strives to
make our equipment as safe as possible. The
Art’s-Way JR50 & JR75 Compact Grinder Mixer
conforms to applicable safety standards at the time
of manufacturing. A safety conscious equipment
operator makes an effective accident-prevention
program complete.
Safety features and instructions for the grinder mixer
are detailed in the Safety Guidelines section of
this Operator’s Manual. It is the responsibility of
the owner to ensure that all operators read and
understand the manual before they are allowed to
operate the Grinder Mixer. (Occupational Safety and
Health Administration (OSHA) regulations 1928.57).
NOTICES OF DANGER, WARNING, AND CAUTION
Signal Words: Note the use of signal words DANGER,
WARNING, and CAUTION on the grinder mixer and
in this manual. The appropriate signal word for each
has been selected using the following guidelines:
DANGER
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if
not avoided, could result in minor or moderate injury.
NOTICE
NOTICE is used to address practices not related to
physical injury.
SAFETY
INSTRUCTIONS
Safety instructions (or equivalent) signs indicate
specific safety-related instructions or procedures.
Note: Contains additional information important
to a procedure and will be found within the
regular text body of this manual.
SAFETY FIRST

Manual No. 642550 Art’s-Way Manufacturing Co., Inc.
8 SAFETY INSTRUCTIONS
GENERAL
Most work related accidents are caused
by failure to observe basic safety rules
or precautions. An accident can often
be avoided by recognizing potentially
hazardous situations before an accident
occurs. As you operate and maintain
the Grinder Mixer you must be alert to
potential hazards. You should also have
the necessary training, skills, and tools to
perform any assembly procedure.
Improper operation and/or maintenance
of this unit could cause a dangerous
situation that results in injury or death.
Do not use this unit until you read and
understand the information contained in
this manual. Do not use this equipment
for anything other than its intended
purpose.
Safety precautions and warnings
are provided in this manual and on
the unit. If these hazard warnings
are not heeded, bodily injury or
death could occur to you or to other
persons.
Art’s-Way Manufacturing Co., Inc.
cannot anticipate every possible
circumstance that might involve
a potential hazard. The warnings
in this manual and on the product
are, therefore, not all-inclusive. If a
method of operation not specifically
recommended by us is used, you must
satisfy yourself that it is safe for you
and for others. You should also ensure
that the unit will not be damaged or be
made unsafe by the methods that you
choose.
The information, specifications, and
illustrations in this manual are based on
the information that was available at the
time this material was written and can
change at any time.
Safety Alert Symbols
This is the safety alert symbol. It
is used to alert you to potential
personal injury hazards. Obey all
safety messages that follow this
symbol to avoid possible injury or
death.
This manual contains DANGERS,
WARNINGS, CAUTIONS, NOTICES,
SAFETY INSTRUCTIONS, and NOTES
which must be followed to prevent the
possibility of improper service, damage to
the equipment, personal injury, or death.
The following key words call the readers
attention to potential hazards.
Hazards are identified by the “Safety
Alert Symbol” and followed by a signal
word such as “DANGER”, “WARNING”, or
“CAUTION”.
SAFETY
INSTRUCTIONS
Remember:
“The Best Operator is a Safe Opera-
tor”
CAUTION
Read and understand the opera-
tor’s manual and all the safety
decals before operating the
grinder mixer. Review all safety in-
structions with all operators annually.
SAFETY INSTRUCTIONS

Art’s-Way Manufacturing Co., Inc.. Manual No. 642550
SAFETY INSTRUCTIONS 9
BEFORE OPERATING
SAFETY
INSTRUCTIONS
Do not wear loose fitting clothing as it may
catch in moving parts.
Make sure all guards and shields are
installed, including the tractor power take-
off (PTO) master shield, before starting or
operating the grinder mixer.
OEM
Be sure that the correct implement driveline
parts are used and that they are properly
secured.
Lower the lifter wheels when the grinder mixer is
not in use.
Install safety chain when
attaching the grinder mixer to the
tractor.
Clear the area of bystanders, especially
children, when making repairs, adjustments,
or performing maintenance on the
grinder mixer.
Do not allow riders.
Put all tractor and machine controls in “neutral”
and disengage the PTO before starting. Follow the
starting instructions according to the OEM tractor
manual.
Operate the grinder mixer only while seated
on the tractor seat.
Make sure the unit is adequately supported
with safety blocks or safety stands when
changing tires or performing maintenance.
DURING OPERATION
CAUTION
STOP
Entanglement Hazard
Keep hands, feet, hair, and
clothing away from moving
parts. Wait for all movement to
stop before approaching equipment.
Before making adjustments:
1. Shut off the tractor,
2. Set parking brake,
3. Put machine in neutral, and
4. Remove key while making adjustments.
Keep all shields and guards in place and in
good working condition.
Keep all bystanders, especially children,
away from the grinder mixer while in
operation.
Do not allow riders while the grinder mixer
is in operation.
Do not attempt to unclog, clean, or adjust
the grinder mixer while it is running.
Stay away from overhead power lines.
Electrocution can occur even without direct
contact.
Keep all hydraulic lines, fittings, and
couplers tight and free of leaks. (Refer to
Safety Guidelines – Hydraulic Safety).
Use caution when ascending or descending
on the grinder mixer. Wet shoes or boots
are slippery.
MAINTENANCE SAFETY
SAFETY
INSTRUCTIONS
Follow all operating, maintenance, and safety
instructions found in this Manual.
STOP
Before servicing, adjusting,
repairing, or unclogging the
machine, always make sure
the tractor engine is stopped,
key in your pocket, the machine is lowered to the
ground, all controls are placed in neutral, the
parking brake is set, and all the moving parts have
stopped.
Use sufficient tools, jacks, and hoists that
have the capacity for the job.
Use support blocks or safety stands when
changing tires or performing maintenance.
Follow good shop practices of
keeping the service area clean and
dry, and use adequate light for the
job at hand.
Before applying pressure to the hydraulic
system, make sure all lines, fittings, and
couplers are tightly secured and in good
condition.
Make sure all shields/guards are in place
and properly secured when performing
maintenance.

Manual No. 642550 Art’s-Way Manufacturing Co., Inc.
10 SAFETY INSTRUCTIONS
HYDRAULIC SAFETY
SAFETY
INSTRUCTIONS
Follow all operating, maintenance, and
safety instructions found in this Manu-
al.
Make sure components in
the hydraulic system are kept
clean and in good working condition.
0
Relieve pressure from the hydraulic system
before servicing or disconnecting from the
tractor.
Keep all hydraulic lines, fittings, and
couplers tightly secured and free of leaks.
Replace any worn, cut, abraded, flattened,
or crimped hoses.
Do not make any temporary repairs to the
hydraulic lines, fittings, or hoses using
tape, clamps, or cement. The hydraulic
system operates under extremely high
pressure and temporary repairs may fail suddenly
and create a hazardous/dangerous situation.
Wear proper hand and eye
protection when searching
for a high-pressure
hydraulic leak. Use a piece
of wood or cardboard as a backstop instead of
hands to identify and isolate a leak. If injured by a
concentrated high-pressure stream of hydraulic
fluid, seek medical attention immediately. Serious
infection or toxic reaction can develop if hydraulic
fluid penetrates the surface of the skin.
Before applying pressure to the system,
make sure all components are tight and
that the hydraulic lines, hoses, and
couplings are not damaged.
TRANSPORTATION SAFETY
SAFETY
INSTRUCTIONS
Follow all operating and safety instructions found in
this manual when transporting this equipment.
Make sure the grinder mixer complies with all local
regulations regarding transporting equipment on
public roads and highways.
Make sure the Slow Moving Vehicle (SMV)
emblem and all lights and reflectors
required by local highway and transportation
authorities are properly in place, clean, and
clearly visible to traffic.
Do not allow riders on any machinery
during transport.
Make sure the grinder mixer is securely attached
to the tractor and install a safety chain to the
grinder mixer.
Make sure the tractor brake pedals are latched
together.
Do not exceed 20 mph (32 km/h) when transporting
the grinder mixer. Always reduce speed on rough
roads and surfaces, or when going down inclines.
Use caution when turning and always use the
turn signals on the tractor to indicate your turning
intentions to the other traffic.
The weight of the trailed machine should NEVER
exceed the weight of the towing vehicle.
Check all clearances carefully whenever the
machine is towed.
Lower the elevator into the transport position before
transporting the grinder mixer on the highway .
Stay away from overhead obstructions and
power lines during transport. Electrocution
can occur even without direct contact.
STORAGE SAFETY
SAFETY
INSTRUCTIONS
Follow all operating and safety instructions found in
this manual when storing this equipment.
Store the grinder mixer in an area away
from human activity.
Do not permit children to play on or around
the stored machine at any time.
Make sure that the grinder mixer is stored in an
area with a firm and level base to prevent the
machine from tipping or sinking into the ground.
Block the wheels to prevent the machine
from rolling.

Art’s-Way Manufacturing Co., Inc.. Manual No. 642550
SAFETY INSTRUCTIONS 11
TIRE SAFETY
SAFETY
INSTRUCTIONS
Follow all operating and safety instruc-
tions found in this manual when work-
ing around tires.
Have only a qualified tire dealer or tire
repair service perform tire repairs.
Do not attempt to install a tire on a wheel or
rim unless you have the proper equipment
and experience to do the job.
Do not substitute tires with a lesser road
rating and/or capacity for the original
equipment tires.
WARNING
Explosive Force Hazard
Tire replacement, repair, and/or
maintenance should be done by
a qualied tire dealer or qualied repair
service.
Failure to follow proper procedures
when installing a tire on a wheel or rim
can produce an explosive force that
will result in serious injury or death.
Do not attempt to install a tire without
proper equipment and experience to
perform the job.
ASSEMBLY SAFETY
SAFETY
INSTRUCTIONS
Follow all assembly, operating, and
safety instructions found in this manu-
al when assembly this equipment.
Use adequate manpower to perform
assembly procedures safely.
Assemble the grinder mixer in an area with
sufficient space to maneuver the largest
components and allow easy access to all
sides of the machine.
Use only forklifts, lift cranes, jacks,
and tools with sufficient capacity for
the loads.
Do not allow spectators, especially
children, in the working area.

Manual No. 642550 Art’s-Way Manufacturing Co., Inc.
12 SAFETY INSTRUCTIONS
THIS PAGE
LEFT
INTENTIONALLY
BLANK

Art’s-Way Manufacturing Co., Inc.. Manual No. 642550
SECTION 1: ILLUSTRATED PARTS LIST 13
SECTION 1: ILLUSTRATED PARTS LIST

Manual No. 642550 Art’s-Way Manufacturing Co., Inc.
14 SECTION 1: ILLUSTRATED PARTS LIST
HITCH ASSEMBLY
UNLESS OTHERWISE SPECIFIED
2393.27
DRAWING NO.
640000
640000
ASSEMBLY
1:8
LISTED
E.C.N.DATEAPPRDESCRIPTION
LTR
MATERIAL
REV.
EP#
REVISIONS
DRAWN
CHK
APPR
WHEELS-TIRES-JACK
ALL BURRS & SHARP EDGES.
MODEL
NOTE: DO NOT SCALE
MACHINING DRAWINGS: REMOVE
DIMENSIONS ARE IN INCHES
ONE PLACE
TWO PLACE
THREE PLACE
ANGLES ± 1°
OR SALE OF APPARATUS WITHOUT PERMISSION.
TITLE
DATE
SCALE
DRAWING NO.
SIZE
Art's-Way Manufacturing Co., Inc.
Phone: [phone]
Fax: [phone]
Armstrong, Iowa 50514-0288
±.010
±.O30
±.060
(.XXX)
(.XX)
(.X)
EXCEPT AS MAY BE OTHERWISE PROVIDED BY
CONTRACT. THESE DRAWINGS AND SPECIFI-
CATIONS ARE THE PROPERTY OF ARTS-WAY
MFG. CO., ARE ISSUED IN STRICT CONFIDENCE,
AND SHALL NOT BE REPRODUCED OR COPIED,
OR USED AS THE BASIS FOR THE MANUFACTURE
WEIGHT
BEW
02/19/18
B. WEGNER
-
-
D
-
-NEW RELEASE ON SOLIDWORKS
-
SIMILAR PART(S):
12/19/17
ITEM PART NO. DESCRIPTION QTY
1 018716 WHEEL, 15"X8" 2
2 020730 NUT, LUG 12
3 164420 STEM, VALVE 2
4 626050 JACK ASSY, SIDEWINDER 1
5 I1980928C1 TIRE, 9.5L-15 8 PLY 2
6 V63037 WHEEL/TIRE ASSY 2
2
6
4
1
3
5

Art’s-Way Manufacturing Co., Inc.. Manual No. 642550
SECTION 1: ILLUSTRATED PARTS LIST 15
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 018716 WHEEL, 15"X8" 2
2 020730 NUT, LUG 12
3 164420 STEM, VALVE 2
4 626050 JACK ASSY, SIDEWINDER 1
5 I1980928C1 TIRE, 9.5L-15 8 PLY 2
6 V63037 WHEEL/TIRE ASSY 2

Manual No. 642550 Art’s-Way Manufacturing Co., Inc.
16 SECTION 1: ILLUSTRATED PARTS LIST
19
15
12
2
16 3
13 3
23
4
9
6
4
20
28
20
96
18
20
5
30
17
9
6
21
4
4
27
3
1
20
422 11
10 29
25
20
24
4
16
13
26
6
932
31
8
9
6
7
24
14
1:10
UNLESS OTHERWISE SPECIFIED
2393.27
DIMENSIONS ARE IN INCHES
MACHINING DRAWINGS: REMOVE
DRAWING NO.
640000
ASSEMBLY
LISTED
E.C.N.DATEAPPRDESCRIPTION
LTR
MATERIAL
REV.
EP#
REVISIONS
DRAWN
CHK
640000
MILL-MIX AUGER
ALL BURRS & SHARP EDGES.
MODEL
APPR
ONE PLACE TWO PLACE THREE PLACE ANGLES ± 1°
(.X)
NOTE: DO NOT SCALE
OR SALE OF APPARATUS WITHOUT PERMISSION.
TITLE
DATE
SCALE
DRAWING NO.
SIZE
Art's-Way Manufacturing Co., Inc.
Phone: [phone]
Fax: [phone]
Armstrong, Iowa 50514-0288
±.010 ±.O30 ±.060
(.XXX) (.XX)
EXCEPT AS MAY BE OTHERWISE PROVIDED BY CONTRACT. THESE DRAWINGS AND SPECIFI- CATIONS ARE THE PROPERTY OF ARTS-WAY MFG. CO., ARE ISSUED IN STRICT CONFIDENCE, AND SHALL NOT BE REPRODUCED OR COPIED, OR USED AS THE BASIS FOR THE MANUFACTURE
WEIGHT
BEW
SIMILAR PART(S):
02/19/18
-
B. WEGNER
-
D
-
-NEW RELEASE ON SOLIDWORKS
-
12/19/17
*REFERENCE ONLY.
ITEM NO. PART NUMBER DESCRIPTION QTY
1 006880 BOLT, HHCS 5/16-18x5/8 2 2 012410 BOLT, CRG 5/16-18x3/4 2 3 019150 FLG, 1-1/8 BRG 4 4 020190 NUT, LOCK 5/16-18 FLG 26
5 020700 COTTER PIN, 3/16 X 2 1/2 1 6 021180 WASHER, LOCK 3/8 12
7 021190 WASHER, FLAT 3/8 STD 2
8 021240 SCREW, THMS 1/4-20 2 9 027260 NUT, HEX 3/8-16 GR5 12
10 027660 NUT, HEX 1/4-20 GR5 ZN 2 11 029440 WASHER, LOCK 1/4 SAE 2 12 049290 BOLT, CRG 5/16-18x3/4 SSN ZN 2
13 108850 BEARING ASSY, 2 14 120590 NUT, HEX 10-24 GR2 ZN 2
15 120600 WASHER, LOCK #10 x 21/64 x 3/6 2 16 128040 PLATE, HOLE COVER 2 17 165020 BRACKET WLDT, 1 18 165030_b BEARING, 1.12 SPLIT 1
19 169340 BOLT, CRG 5/16-18 x .50 SSN gr 2 ZN 4
20 170530 BOLT, CRG 3/8-16 X 1" 12 21 365150 AUGER WLDT, 1 22 365190 BRACKET, SHORT 1 23 590980 BRACKET, IDLER MTG 1 24 641220 HOPPER WLDT, 1 25 641320 GRATE, SUPPLEMENT 1
26 641350 DOOR WLDT, SUPP. 1 27 641380 PLATE, SUPP. COVER 1 28 641400 AUGER WLDT, 1 29 E180006 CLIP, WIRE 2 30 I21037R1 Pin, Clevis 3/8 x 2-1/4 Hardened Gr5
ZN+ 1
31 I159920 SCREW, PHMS 10-24 2 32 I669184R1--- CLAMP, SHIELD LATCH 1
MIX MILL & AUGER ASSEMBLY

Art’s-Way Manufacturing Co., Inc.. Manual No. 642550
SECTION 1: ILLUSTRATED PARTS LIST 17
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 006880 BOLT, HHCS 5/16-18X5/8 2
2 012410 BOLT, CRG 5/16-18X3/4 2
3 019150 FLG, 1-1/8 BRG 4
4 020190 NUT, LOCK 5/16-18 FLG 26
5 020700 COTTER PIN, 3/16 X 2 1/2 1
6 021180 WASHER, LOCK 3/8 12
7 021190 WASHER, FLAT 3/8 STD 2
8 021240 SCREW, THMS 1/4-20 2
9 027260 NUT, HEX 3/8-16 GR5 12
10 027660 NUT, HEX 1/4-20 GR5 ZN 2
11 029440 WASHER, LOCK 1/4 SAE 2
12 049290 BOLT, CRG 5/16-18X3/4 SSN ZN 2
13 108850 BEARING ASSY, 2
14 120590 NUT, HEX 10-24 GR2 ZN 2
15 120600 WASHER, LOCK #10 X 21/64 X 3/6 2
16 128040 PLATE, HOLE COVER 2
17 165020 BRACKET WLDT, 1
18 165030 BEARING, 1.12 SPLIT 1
19 169340 BOLT, CRG 5/16-18 X .50 SSN GR 2 ZN 4
20 170530 BOLT, CRG 3/8-16 X 1" 12
21 365150 AUGER WLDT, 1
22 365190 BRACKET, SHORT 1
23 590980 BRACKET, IDLER MTG 1
24 641220 HOPPER WLDT, 1
25 641320 GRATE, SUPPLEMENT 1
26 641350 DOOR WLDT, SUPP. 1
27 641380 PLATE, SUPP. COVER 1
28 641400 AUGER WLDT, 1
29 E180006 CLIP, WIRE 2
30 I21037R1 PIN, CLEVIS 3/8 X 2-1/4 HARDENED GR5 1
31 I159920 SCREW, PHMS 10-24 2
32 I669184R1 CLAMP, SHIELD LATCH 1

Manual No. 642550 Art’s-Way Manufacturing Co., Inc.
18 SECTION 1: ILLUSTRATED PARTS LIST
WINDOWS & ETC. ASSEMBLY
ITEM NO. PART NUMBER DESCRIPTION STAGE
7/QTY.
1 020190 NUT, LOCK 5/16-18 FLG 68
2 205910 ELBOW, BLOWER 1
3 036090 DOOR, CLEANOUT 2
4 MP907739 TUBE - OP MAN HOLDER 1
5 012050 GLASS, 4.5 X 12.0 4
6 012020 RUBBER, WINDOW 4
7 575940 CLIP, MIX TANK 8
8 022920 WASHER, FLAT 5/16 STD 31
9 009790 NUT, WING 5/16-18 12
10 005900 BOLT, HHCS 5/16-18 X 1" 6
11 023620 WASHER, LOCK 5/16 10
12 023630 NUT, HEX 5/16-18 10
13 205920 CLAMP, 4-1/8 X 5 2
14 581950 PLATE, LH SHIELD 1
15 518940 TUBE, DOOR HINGE 1
16 581960 PLATE, SHIELD STOP 1
17 205870 ANCHOR, LATCH 2
18 110920 NUT, WELD 5/16-18 SPOT 2
19 582550 STRAP, STOP 1
2673.84
DRAWING NO.
640000
640000
UNLESS OTHERWISE SPECIFIED
ASSEMBLY
1:8
LISTED
E.C.N.DATEAPPRDESCRIPTION
LTR
MATERIAL
REV.
EP#
REVISIONS
DRAWN
CHK
APPR
WINDOWS-MANUAL,
ALL BURRS & SHARP EDGES.
MODEL
NOTE: DO NOT SCALE
MACHINING DRAWINGS: REMOVE
DIMENSIONS ARE IN INCHES
ONE PLACE
TWO PLACE
THREE PLACE
ANGLES ± 1°
OR SALE OF APPARATUS WITHOUT PERMISSION.
TITLE
DATE
SCALE
DRAWING NO.
SIZE
Art's-Way Manufacturing Co., Inc.
Phone: [phone]
Fax: [phone]
Armstrong, Iowa 50514-0288
±.010
±.O30
±.060
(.XXX)
(.XX)
(.X)
EXCEPT AS MAY BE OTHERWISE PROVIDED BY
CONTRACT. THESE DRAWINGS AND SPECIFI-
CATIONS ARE THE PROPERTY OF ARTS-WAY
MFG. CO., ARE ISSUED IN STRICT CONFIDENCE,
AND SHALL NOT BE REPRODUCED OR COPIED,
OR USED AS THE BASIS FOR THE MANUFACTURE
WEIGHT
02/19/18
B. WEGNER
-
-
D
-
-NEW RELEASE ON SOLIDWORKS
-
BEW
SIMILAR PART(S):
12/19/17
8
10
10
4
12
11
2
13
3
8
9
6
5
7
1
