ArtDio SS-168 User manual

1
INDEX
Index
Product Features
Product Overview
Connection
Controls
Installing the Software
Uninstalling The Software
Trouble Shooting
Frequently Asked
Questions
Product Specifications
Important Safety
Instructions
1
2
3
4
4
6
11
15
18
20
22
SS-168 / SS-168B
TRUE USB VoIP
(Voice Over Internet Protocol) SPEAKER
with Built-in Microphone
USER’S GUIDE
Please read and understand all safety instructions before use.

32
2.5mm
Headphone Jack
Power Indicator
Volume Controls
Call Button
Call Indicator
Built-in Microphone
Microphone Mute
PRODUCT FEATURES
The ARTDIO SS-168 VoIP SPEAKER is a full duplex stereo speaker with
built-in microphone,DSP (Digital Sound Processing) technology,echo
cancellation and noise suppression,for you to listen to music and enjoy
conversations through the Internet with a hands free experience.
Designed to support VoIP soft phones such as Skype™
(Installation CD-ROM is included).
• Easy access to Call Button (make/ answer/ disconnect a call).
• Auto Music Pause and Resume with Windows Media Player™ and
Winamp™ for incoming/ outgoing calls.
Designed to enhance Stereo Sound Effect provided by C-Media™ USB
Sound (Installation CD-ROM is included).
* All tradenames are registered trademarks of their respective companies
in the United States and/ or other countries.
PRODUCT OVERVIEW
FRONT VIEW
BACK VIEW
True USB Connector

54
(1) Call Indicator
Incoming Call:Green LED will flash for incoming calls, it will light when
the call is connected.
Outgoing Call:Green LED will light when the call is connected.
CONNECTION
1. Plug in the USB cable from the speakers to the USB port on your
computer.
2.The red LED will light to indicate the power for SS-168 speaker is on.
(8)
(7) (6)
(5)
(2)
(1)
(3 & 4)
CONTROLS (please refer to picture [A] on page 5)
(2) Call Button ( support Skype™ only )
(3 & 4) Volume Up & Down
Press and hold“ ”button to increase the volume.
Press and hold“ ”button to decrease the volume.
(5) 2.5mm Headphone Jack
Connect to headphones with a 2.5mm connector for private conversations.
Note:a stereo headphone with microphone is included with the package
(6) Power Indicator
Red LED will light to indicate the power is on.
(7) Microphone Mute
Press to mute the microphone, the blue LED will light.
(8) Built-in Microphone picture [A]
Talk directly with the
built-in microphone on the
speaker to enjoy your
conversations hands free.
Make a Call: Press to make an outgoing call.
Answer a Call: Press to answer an incoming call.
Disconnect a Call: Press to disconnect a call.

76
INSTALLING THE SOFTWARE
Note:You must connect the SS-168 speaker to your computer before installing
the software.
1. Place the installation CD-ROM into the CD-ROM drive on your computer.
2.The setup program will start automatically; if the auto run does not start, please
install manually by double-click on the setup (.exe file) on the CD-ROM drive.
3. Please follow the instructions in the setup program to complete the
installation.
INSTALLATION SCREENSHOTS
3) Select the items to be installed
in your computer, including:
ɛSS-series Driver and Utility
ɛControl Utility
Click“Next” to continue the setup.
1) Click“Next” to continue setup.
2) Note:Please connect the
SS-168 speaker to your
computer before installation.
Then click“Next”to continue the
setup.
4) Select or create a folder to
install your SS-series Driver, or
the setup program will install in
the following folder C:\Program
Files\ArtDio
Click“Next” to continue the setup.

98
6) The installation for Control
Utility begins, which will take
less than 1 minute.
5) Click“Next” to begin installation,
or“Back”to re-enter the
information.
9) Select or create a folder to install
ArtDio driver, or the setup
program will install in the
following folder C:\Program
Files\ArtDio
Click“Next” to continue the setup.
8) Select the items to be installed in
your computer, including:
ɛInstall ArtDio Driver
ɛInstall Demo Program
Click“Next” to continue the setup.
7) Then, continue with the
installation for ArtDio driver.
Click“Next” to continue the setup.
10) Click“Next” to continue the
setup, or “Back” to change any
settings.

1110
12) The Installation is completed.
Please restart your computer
when the installation is
completed.
11) The Installation for ArtDio
Driver begins, which takes
about 1-2 minutes.
2) Select uninstall method:
ǷAutomatic: to automatically uninstall
the software (default), this option
may remain some files in the folder.
ǷCustom: to choose which
modifications to make during the
uninstall, then “Select All” to remove
all the files and folders.
ǷRepair: to reinstall changed files/
registry keys.
Click“Next” to continue uninstalling.
1) Go to Windows Start > All Programs >
ArtDio, click on “Uninstall” to uninstall
the SS-series Driver and Control
Utility.
UNINSTALLING THE SOFTWARE
NOTE: Please exit all programs before uninstalling the software.
UNINSTALL SS-SERIES DRIVER AND CONTROL UTILITY
Please follow the on-screen instructions to uninstall the software.
UNINSTALLING SCREENSHOTS

1312
5)“Remove Shared Component”
window will display if the installed
files are shared by other programs,
which ask for permission to delete
shared files.
If you are sure,select“Yes”or “Yes to
All”; if you are not sure,select “No”or
“No to All”.
4) Click“Finish” to perform uninstalling,
or“Back” to change any settings.
6)The software has been successfully uninstalled.
Please restart your computer after the software is uninstalled.
1) Go to Windows Start > All Programs >
ArtDio, click on “Uninstall ArtDio”to
uninstall the ArtDio Driver.
3) Note: Please go to the next step, if this
window does not display. Perform
rollback will restore the computer to
the state it was before the last
installation or upgrade of this
software by restoring any backed up
files.
Select “Yes” to perform rollback, or “No”
to continue uninstalling,then click “Next”.
UNINSTALLING ARTDIO DRIVER
Please follow the on-screen instructions to uninstall the software.
UNINSTALLING SCREENSHOTS

1514
3)The software has been successfully
uninstalled.
Please restart your computer after
the software is uninstalled.
2) Click“OK”to continue uninstallling. TROUBLE SHOOTING
Symptom Possible Problem Solutions
No.
No Power LED (Red) is
lit.
The USB cable isn’t
connected to the USB
port on the computer
and/ or it is loosened.
Connect the USB cable
to the USB port on the
computer.
No sound is coming
from speakers.
1
2The power isn’t
turned on.
The computer does not
detect the C-media™
USB Sound as Sounds
and Audio Device.
Repeat the step 1 - No
power LED is lit.
The volume is set too
low.
Press and hold the
“ ”button to increase
the volume.
Go to control panel,
click on Sounds and
Audio Devices, under
the Volume Output/
Input Control, choose
C-media USB Sound
device.
The USB driver is not
functioning.
Download the USB
driver from your
computer
manufacturer’s
website, or install the
software CD-ROM
included.

1716
Symptom Possible Problem Solutions
4
5
3There is echo sound
coming from speakers
when the music is
playing or while
making phone calls.
The software CD- ROM
is not installed.
Follow the steps for
installing the software.
Speaker volume is
set too high.
The Call Button on the
speaker does not
function.
The software CD-ROM
is not installed.
Follow the steps for
installing the software.
7 When 2 parties are
talking over the
internet phone call, the
Call Button on the
speaker doesn’t answer
the 3rd party incoming
call.( with Skype™)
The Call Button on the
speaker does not
support to answer 3rd
party incoming call.
Please use the mouse
and click directly on
the Answer Call button
on the program to
answer 3rd party
incoming call.
(with Skype™)
The VoIP soft phone
program used is not
Skype™.
The Call Button only
supports Skype™
currently.
Voice is breaking up
while talking through
the Internet.
Too far from the
speaker.
Internet is busy or poor
bandwidth quality.
Please consult with
your Internet Service
Provider.
Be in the range of 2-5
feet from the speaker
for best performance.
Press and hold
“ ”button to decrease
the volume.
8 Windows stop
responding when
connecting the speaker
to the computer while
the music is playing or
while making internet
phone calls.
The speaker is
connected while the
music is playing or
while making internet
phone calls.
Please connect the
speaker to the
computer while all the
programs and
applications are close.
9 Once you connected
the speaker and run
Windows Media
Player™, it doesn’t play
the music.
Windows Media
Player™ is executed
under“skin mode”
view.
Please exit and restart
Windows Media
Player ™ again.
The software CD- ROM
is not installed.
No.No.
6
TROUBLE SHOOTING (con’t)
Music doesn’t stop
automatically for
incoming and/or
outgoing calls.
Follow the steps for
installing the software.
The media players
used is not Windows
Media Player™ or
Winamp™.
The Auto Music Pause
and Resume feature
only support Windows
Media Player™ or
Winamp™ currently.
The USB connector is
loosened.
Reconnect the USB
connector to the USB
port on the computer.
Symptom Possible Problem Solutions

1918
FREQUENTLY ASKED QUESTIONS
1. Does the SS-168 VoIP speaker support instant messengers such as MSN
Messenger, Yahoo Messenger, QQ and more,other than Skype™?
Yes, the SS-168 VoIP speaker works just like any multimedia speaker to support
instant messengers as stated above and more, for you to talk to friends and
family through the Internet and listen to music.
2.Why there is no power on/ off button on SS-168?
The SS-168 VoIP speaker is powered by USB. When the USB cable is fully
connected to the USB port as the computer is turned on, the power for the
SS-168 VoIP speaker is turned on and the red LED will light.
The SS-168 speaker is powered off at the below stages:
• Before the computer start-up is ready.
• Before the computer enters the operating system and be ready to use.
• When the computer is standing by, hibernated or turned off.
• When the SS-168 VoIP Speaker is unplugged from the computer.
3.There is a 2.5mm headphone jack on the SS-168 speaker, can I connect with
any multimedia headphones?
The headphone jack on SS-168 speaker is able to connect with any
headphones with a 2.5mm connector, which is mostly compatible with cell
phones.Included with the package,is a specially designed 2.5mm stereo
headphone with a microphone, for you to use it to listen to music and enjoy
your conversations through the Internet.
4. Does the feature of auto music pause and resume for incoming/ outgoing
calls support Mac or Linux operating system?
No,the software included only supports with Windows operating systems, and
does not support Mac or Linux operating systems.
5.Why after uninstalling the software, the SS-168 VoIP speaker still support the
function of Auto Music Pause and Resume for incoming/ outgoing call?
Possible Problem:
a) The users did not exit SS-series program before uninstalling the software,
therefore, the uninstalling program only remove the related documents in
the system but did not remove the function.
- Please close and exit the SS-series program before uninstalling the software
b) The users did not restart the computer after the software is uninstalled.
- Please restart the computer after the software is uninstalled.

2120
Built-in Speaker Total Power Output 1W + 1W = 2Watts
Frequency Response 120HZ-18KHZ
Driver 1 1/4 inches 4NdFEB
Magnet
Built-in Microphone Coverage 5 M (±60 degree)
Audio Output Max Output Power 100mW
Sensitivity -40dB
Frequency Response 50HZ-10KHZ
Digital Sound
Processing
Echo Cancellation 50dB
Noise Suppression 13dB
Microphone Auto
Volume Control
Support
Full Duplex Satellite Support
Function Keys Volume Up Support
Volume Down Support
Microphone Mute Support
Call Button Make/ answer/
disconnect call
Other Headphone Input
Connection
2.5mm Headphone Jack
Connection Type
Physical Outlook
Compatible Operating
Systems
Windows 2000,Windows XP,Windows 2003
Accessories Included
• SS-series Driver and Utility
• Control Utility
• C-Media™ USB Sound
Installation Software CD-ROM
Stereo Headset with Microphone
Quick installation Guide
USB - Audio Support USB 2.0
Dimensions W1.86”x H 6.75”x D2.75”
Weight 520mg
SPEAKER SPECIFICATIONS
SOFTWARE SPECIFICATIONS

2322
IMPORTANT SAFETY INSTRUCTIONS
Please read and understand all safety instructions before use.
1. Read Instructions – All the safety and operating instructions should be read
before the appliance is operated.
2. Retain Instructions – The operating instructions should be retained for future
reference.
3. Heed Warning – All warnings on the appliance and in the operating instructions
should be adhered to.
4. Follow Instructions – All operating and use instructions should be followed.
5.Water and Moisture – The appliance should not be used near water – for example,
near a bathtub, washbowl,kitchen sink,laundry tub, in a wet basement,or near a
swimming pool, etc.
6. Outdoor Use – Warning:To reduce the risk of fire or electric shock,do not expose
this appliance to rain or moisture.
7. Location – The appliance should be installed in a stable location.
8. Heat – The appliance should be situated away from heat sources such as
radiators,heat registers, stoves, or other appliances (including amplifiers) that
produce heat.
9. Cleaning – The appliance should be cleaned only with a polishing cloth or a soft
dry cloth.Never clean with furniture wax,benzene,insecticides or other volatile
liquids since they may corrode the cabinet.
10. Object and Liquid Entry – Care should be taken so that objects do not fall and
liquids are not spilled into the enclosure through openings.
11. Accessories – Only use attachment accessories specified by ArtDio Co, Inc.
12. Damage Requiring Service – The appliance should be serviced by qualified service
personnel when:
• Objects have fallen, or liquid has been spilled into the appliance.
• The appliance has been exposed to rain.
• The appliance does not appear to operate normally or exhibits a marked change
in performance.
• The appliance has been dropped or the enclosure damaged.
13. Servicing – The user should not attempt to service the appliance.Servicing should
be referred to qualified service personnel or returned to the dealer or call the
ArtDio service line for assistance.
