JVC CS-SR100 User manual

Cautions
READ ALL THE SAFETY AND OPERATING PRECAUTIONS THOROUGHLY BEFORE USE.
• Retain this INSTRUCTIONS for future reference.
• All WARNINGS and CAUTIONS should be carefully observed.
WARNINGS
• Disconnect the AC adapter in the event of accident.
Should the accident occur with the system such as smoking, smelling, sounding
abnormally, dropped or damaged, disconnect the AC adapter from the AC outlet, and
consult your dealer immediately.
• Disconnect from the AC outlet, if anything gets inside.
Otherwise, it may cause a fire or an electrical shock.
• Do not repair the system by yourself. Never modify the system.
Otherwise, it may cause a fire or an electrical shock.
There are no user serviceable parts inside.
• Never connect to the AC power of different voltage. Never use any AC adapter other
than the one supplied.
Otherwise, it may cause a fire or an electrical shock.
• Do not use the system in the place where the water can splash on the system such as
bath room, shower room, or kitchen.
Otherwise, it may cause a fire or an electrical shock.
• Never use the AC adapter when the AC plug is dirty.
Clean it with dry cloth, or ask your dealer for service; otherwise, it may cause a fire or an
electrical shock.
CAUTIONS
• Do not operate or leave the system:
1) in an area that is constantly exposed to the direct sunlight.
2) near a heat source.
3) in an area that is dusty, humid, or exposed to the water or smoke.
4) in the car.
• Never place the system on an unstable place such as shaky desk, inclined surface, or
on a high place.
• Never place anything on top of the system.
• Disconnect the AC adapter when not in use.
• Do not place magnetic media near the system.
Even speakers are magnetically shielded, it may affect the media and make it unreadable.
• Never pull out the cords.
When disconnecting the AC adapter, hold the adapter itself, not the cord.
When disconnecting the cords, hold the plug, not the cable.
Never put anything heavy on the cord, and never break or hurt the cord; otherwise, it may
cause malfunction, an electrical shock, or a fire.
Caution––Power Switch!
Disconnect the AC adapter to shut the power off
completely. The power switch in any position does
not disconnect the mains line.
LVT1255-001B
[J]
POWERED SPEAKER SYSTEM CS-SR100
INSTRUCTIONS
0504MNMMDWMNB
EN
© 2004 VICTOR COMPANY OF JAPAN, LIMITED
Having TROUBLE with operation?
USA ONLY
Call 1-800-252-5722
http://www.jvc.com
We can help you!
http://www . j v cmobile.c om
Visit us on-line for
Technical Support & Customer Satisfaction Survey.
US RESIDENTS ONLY
VICTOR COMPANY OF JAPAN, LIMITED
Features
•Stereo (left and right) speaker system, magnetically shielded to provide the greatest
protection against image distortion on a monitor.
•Built-in amplifier of total 3 W power, equipped with the power switch, volume control, and
headphone jack.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
CS-SR100_f.p65 04.6.2, 1:51 PM1

Parts Identification
7Front
7Rear
Left speaker Right speaker
Power lamp
Headphone jack
Power switch
(volume control) knob
Left speaker
Right speaker
DC IN jack
L SPKR (left speaker) jack
(brown connector)
Line-input cord
(green plug):
2 m (6.5 ft)
Left speaker cord
(brown plug):
2 m (6.5 ft)
Troubleshooting
Check the following if you think the system is not working correctly.
•If the problem should persist, unplug the AC adapter from the AC outlet, and refer servicing
to the qualified service personnel.
Symptom
Power lamp is
turned off.
Power lamp is turned
on, but no sound.
Sound is distorted.
Sound level is too low.
Sound comes out of
only one speaker.
Possible Cause
•AC adapter is not connected.
•No power is supplied.
•Line-input cord is not connected.
•Volume level is too low.
•Volume level is too high.
•Input sound level is too high.
•Input sound level is too low.
•Line-input cord is not connected firmly.
•Left speaker is not connected to the
right speaker.
Remedy
•Plug in adapter firmly.
•Try another AC outlet.
•Plug in the cord firmly.
•Turn up the volume control.
•Turn down the volume control.
•Adjust it to the optimum level.
•Adjust it to the optimum level.
•Plug in the cord firmly.
•Plug in Speaker cord firmly.
Specifications
7Amplifier: Power output 1.5 W per channel (at 10 % THD)
Input impedance 12 kΩ(nominal)
Input sensitivity 200 mV/1 kHz/1 W
Power supply DC 9 V 500 mA (by AC adapter)
Power consumption 12 W
Signal-to-noise ratio 72 dB
7Power Requirements: AC 120 V , 60 Hz
7Speaker System: Enclosures Plastic molded
Frequency response 100 Hz –20 000Hz
Speaker uint 90 mm x 50 mm (3-9/16 in. x 2 in.) cone type,
magnetically shielded
7Dimensions (H/W/D): Right speaker: 200 mm x 80.5 mm x 112 mm
(7-7/8in. x 3-1/4in. x 4-7/16 in.)
Left speaker: 200 mm x 80.5 mm x 99.3 mm
(7-7/8in. x 3-1/4in. x 3-15/16 in.)
7Mass: Right speaker: 400 g(0.89 lbs) Left speaker: 345 g(0.77 lbs)
* Design and specifications are subject to change without notice.
Connection Diagram
Audio Output (Green connector)
Green plug
(stereo mini:
φ3.5 mm)
Line input cord
Black plug AC adapter
(AC 120 V , 60 Hz)
To an AC outlet
After completing all other connections,
plug in the AC adapter.
Brown connector
Brown plug (mini: φ2.5 mm)
Left speaker cord
Home Docking Cradle for JVC Sirius tuner
Left Speaker
Right Speaker
REAR VIEW
Although the speakers are magnetically shielded, they may affect some monitors if installed
nearby. Should color deterioration occur on a monitor, place the speakers slightly away.
Turn off the monitor, and keep it turned off for about 15 to 20 minutes.
By doing this, normal color will be restored.
Using the Speaker System
1 Connect the speakers and AC adapter as shown in the Connection Diagram.
2 Turn the power switch knob clockwise to turn the power on.
A click sound is heard and the power lamp lights up in green.
3 Turn the power switch knob further to obtain the optimum sound level.
•In case the sound level is not sufficient though the knob is turned up fully clockwise,
increase the output level of the signal source as it may be set too low.
•When using the headphones, plug it into the headphone jack. No sound comes out of the
speakers.
Turn the knob fully counterclockwise before connecting the headphones, not to damage
the speakers and your ears.
To turn off the speakers, turn the power switch knob fully counterclockwise.
•Never turn it on or off by any other means to ensure safe operation of the speakers.
Maintenance
If cleaning is required, disconnect the AC adapter from AC outlet, and wipe off with soft cloth.
For removing heavy stain, use the cloth moistened with neutral detergent.
Do not use inflammable or harmful fluid such as benzine or thinner.
REAR VIEW
