Sven SPS-607 User manual

www.sven.fi
OPERATION
MANUAL
2.0 Multimedia Speaker System
SPS-607
SPS-609

Congratulations on your purchase of the Sven speaker system!
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The
information in this Manual is given on “as is” terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. BUYER RECOMMENDATIONS ..................................................
.............
2. PACKAGE CONTENTS............................................................. ............
3. SAFETY PRECAUTIONS .................................................. ...................
4. TECHNICAL DESCRIPTION .................................................... ................
5. PREPARATION AND OPERATION .......................................... ......................
6. TROUBLESHOOTING................................. ...............................................
7. TECHNICAL SPECIFICATIONS .................................................... ...........
1
2
2
2
3
4
5
1. BUYER RECOMMENDATIONS
•Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the firm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
•Check up the package contents and availability of the warranty card. Make sure the warranty card
has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the goods
number corresponds to that in the warranty card. Remember: in case of warranty card loss or
discrepancy of numbers you forfeit the right for warranty repairs.
• Do not switch on the speaker system immediately after you bring it into a room from environment
with negative temperature! After unpacking, the speaker system should be kept in conditions of
room temperature for at least 4 hours.
•Before installing and using the speaker system, read this Manual carefully and keep it for future
reference.
Technical support is on www.sven.fi.
ENG
1
Operation Manual SPS-607
SPS-609

2. PACKAGE CONTENTS
• Speakers — 2 pcs
• Operation manual — 1 pc
• Warranty card — 1 pc
3. SAFETY PRECAUTIONS
•To avoid electric shock, do not open the MSS and do not perform repairs by yourself. Service and
repairs should be performed only by qualified specialists in an authorized service center. The list of
authorized service centers is available on www.sven.fi.
•Do not allow the circuit of wires (including the grounded ones) between the speakers, on the
power amplifier or the ground, for it causes damage to the power amplifier output stage.
•Do not touch the MSS power cord plug pins for 2 seconds after unplugging it from the mains.
•Do not put foreign objects inside the holes of the MSS.
•Protect the MSS from high humidity, water and dust.
•Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose
it to direct sunlight.
•Do not place any open flame sources on or close to MSS.
•Do not place the MSS in poorly ventilated areas. Leave an air gap of 10 cm or more. When
operating the MSS, do not put any devices on it, do not cover it with cloth or other objects pre-
venting it from cooling.
•Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
4. TECHNICAL DESCRIPTION
SPS-607/SPS-609 2.0 Multimedia Speaker Systems (MSS) are designed to play music and sound
games, movies, etc. The MSS has a built-in power amplifier allowing to connect it to virtually any
audio source. One speaker is active (it has a built-in power amplifier and a control panel), while the
other one is passive. The passive speaker is connected to the active speaker with an audio cable.
The signal cable and the power cable are built into the active speaker.
Special features
•Simple and elegant design
•Built-in transformer power supply
•Speaker system is compatible with PCs, DVD/Media-players, mobile devices and other sound
sources
•Master volume and timbre control knobs
•Control knobs on the front side of the active speaker
•Power LED
•The increased stroke of the driver coil provides practically distortionless sound reproduction
•Magnetic shielding
•MDF speaker cabinets
Caution! High voltage inside! To avoid the risk of electric
shock do not open or touch elements inside.
ENG
2
2.0 Multimedia Speaker System

Fig. 1. Control panel
ab c d
TONE VOLUME POWER
Active speaker front side
aPower LED
bTONE: timbre control knob
cVOLUME: volume control knob
dPOWER: power switch
5. PREPARATION AND OPERATION
Speaker placement
•Place the speakers symmetrically to the listener
at least one meter away.
•Since the speaker system has a bass reflex port
on the rear panel, place the speakers 20-30 cm
away from a wall or any other obstacle.
•Place MSS far away from monitors and TV sets,
as insignificant image distortion in these super-
sensitive devices is possible.
MSS Connecting
SPS-607/SPS-609 Multimedia Speaker Systems can
be connected to virtually any audio source: DVD/CD,
PC sound card, etc. (Fig. 2).
• Before making any connections, make sure that
the MSS is unplugged.
Fig. 2. Connection diagram
Active speaker Passive speaker
Power cord
CD
PC
DVD
Player
L-SPK
Audio
cable
ENG
3
Operation Manual SPS-607
SPS-609

• Then connect the speakers by means of the audio cable built into the passive speaker (see Fig. 2).
• Insert the mini-jack of the signal cable built into the active speaker into the output jack of your PC
sound card, CD/MP3-players, etc.
Note. To connect the MSS to a CD/DVD player use a built-in stereo signal cable with
a mini-jack to 2RCA adapter (not included), as shown in Fig. 2.
• Plug the power cord built into the active speaker into a mains outlet.
• Adjust the volume level to the minimum by turning the VOLUME control knob bcounterclock-
wise until it stops.
• Switch on the MSS using the POWER switch d. The power LED awill light up on the front panel
of the active speaker. Then turn on your audio source.
• Set the volume and timbre level by turning the knobs cand brespectively clockwise.
Notes:
• If the MSS is left unused for a long period of time, make sure the device is turned off and
unplugged.
• Use the soundcard Line-Out port to improve the sound quality.
Problem
The MSS does not
turn on.
No sound.
There is too quiet
sound of speakers.
Distortion of
sound.
Cause
The MSS isn’t connected to a mains outlet.
The power switch is off.
The volume level is set at minimum value.
Improperly connected audio source.
The volume level is set at minimum value.
Large amplitude of the input signal.
Solution
Check the connection.
Turn on the switch.
Adjust the volume control knob.
Connect the audio sources
correctly.
Adjust the volume control knob.
Turn down the audio source
volume and the MSS volume.
6. TROUBLESHOOTING
If none of the above mentioned solutions removes the problem, please refer to your nearest
authorized service center. Never try to repair the device on your own.
4
ENG
2.0 Multimedia Speaker System

Output power (RMS), W
Frequency range, Hz
Speaker diameter, mm
Power supply, V/Hz
Dimensions (one speaker) (W × H × D), mm
Weight, kg
2 × 3
80 – 18 000
Ø 76
~220/50
117 × 207 × 105
1.9
2 × 5
70 – 18,000
Ø 76
~220/50
115 × 225 × 155
2.25
SPS-607 SPS-609
Value Value
Мodels
Parameter, measurement unit
7. TECHNICAL SPECIFICATIONS
Notes:
• Technical specifications given in this table are supplemental information and cannot give
occasion to claims.
• Technical specifications and package contents are subject to change without notice due
to the improvement of SVEN production.
ENG
5
Operation Manual SPS-607
SPS-609

Модели: SPS-607/SPS-609
Импортер вРоссии: ООО «СКАНДИТРЕЛ»,
111024, РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес.
Срок службы: 5 лет.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано вКитае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
