Artopex NANO User manual

Installation Guide
NANO
Table of Contents :
- Installation of a Hybrid Uni-T and Nano Station pg. 1
- Installation of a Hybrid TakeOff and Nano Station pg. 2
- Installation of a Wall Connector pg. 3
- Installation of a Privacy Screen pg. 4
- TakeOff Surfaces in the Nano Series pg. 5

Déc. 2007
"N" Connector
Uni-T Uni-T
Nano Installation Guide
Uni-T Nano Hybrid
a)
d)
b)
c)
e)
pg.1
a) Use the "N" connector to join
2 Uni-T panels side by side
b) Remove the top cap from the Nano screen
c) Install the Uni-T brackets in the vertical
profile of the Nano screen, being careful to
follow the direction of the teeth as in the
drawing to the left. Tighten them only
enough to allow them to stay in place.
d) Bring the Nano screen towards the Uni-T
panel and insert the brackets in the "N"
connector. Lift the bottom bracket and
tighten the screws, then tighten the screws
in the top bracket.
Top bracket with
teeth facing downward
Bottom bracket with
teeth facing upwards
e) Finishing:
Install the vertical connector
(if necessary) and the top cap.
Top Cap
Connector Cover

Déc. 2007
d)
b)
c)
Bottom bracket with
teeth facing upwards
Top cap cover
(PECN180)
Double
face tape
e)
a)
a)
Nano Installation Guide
TakeOff Nano Hybrid
pg.2
a) Use the Nano junction plates to join the 2 TakeOff
panels side by side.
b) Remove the top cap from the Nano screen
c) Install the hybrid TakeOff brackets into the vertical
profile of the Nano screen, being careful to follow the
direction of the teeth as in the drawing to the left.
Tighten them only enough to allow them to stay in place.
d) Bring the Nano screen towards the TakeOff panel and
insert the TakeOff brackets in the connector of the
TakeOff panel. Lift the bottom bracket and tighten the
screws, then tighten the screws in the top bracket.
Top bracket with teeth
facing downward
e) Finishing:
Install the two top caps, the vertical connectors
and the top cap cover.
Vertical Cap
This junction plate
is to be inserted
between the panels.

d)
e)
c)
Déc. 2007
Nano Installation Guide
Wall Connector
pg.3
a) a) Screw the connectors to the wall. Install the first
connector to the "base" section of the Nano screen
(underneath the work surface area), and the second
connector attaches in line with the top of the screen.
b) Take off the top cap of the Nano screen.
c) Carefully lower the flat plates into the vertical profile
of the Nano screen, screw them in enough just to hold
them in place, do not tighten them completely.
d) Bring the Nano screen forward and insert it into the
wall connectors. Loosen the flat plates one at a time,
and then position them into the inside of the indents
of the wall connectors. Tighten the screws while
leveling the panel.
e) Use the central hole only when the wall is not level
or straight.
Position of the
flat plates
b) Top Cap

Déc. 2007
b)
f)
e)
d)
Connecting
strip
Nano Installation Guide
Privacy Screens
a)
Bottom cap cover
c)
pg.4
a) Screw the L bracket onto the privacy screen. Positioning it
over the pre-drilled holes. Be sure to place the L bracket by
the bottom cap cover. (cover C1356).
b) On a mobile table, bring the screen toward the table, be sure
that the screen is centered and screw the L bracket into the
underside of the surface.
c) On a freestanding table, create a space between the surface
and the legs (and or the modesties) and slightly loosen the
screws holding the table together, now insert and tighten the
L bracket under the surface. Now re-tighten the screws on
the modesties and legs.
d) Before installing the 2nd privacy screen, take off the top cap
of the Nano screen, install the post and the connecting strip.
e) Loosen the screw that you will find under the vertical profile
of the screen and insert the small support plate. Install it in
such a way that it will hold up the post, now tighten the screw.
f) Now install the 2nd privacy screen, connect it to the post with
a connecting strip, tighten the screws under the surface.
Note: Always install 2 privacy screens at
90 degrees to assure stability

Déc. 2007
,375"
48" TakeOff panel
48" Nano screen
(24")
(24")
Take Off Surfaces
,375
Nano Installation Guide
With TakeOff surfaces
(48 3/8")
(48 3/8")
pg.5
Space created between
Nano screen and
TakeOff panel
The screen is positioned at
the end of the oblong slots in
the bracket, this gives the
3/8 inch spacing.
The Nano screens adapt to the TakeOff System, even when the TakeOff surfaces
are 3/8" longer than Uni-T and Nano.
It is the TakeOff bracket in the Nano system, that allows the Nano screen to be adjusted, so that this
screen will cover the full length of the surface.
