ARTronic ARTon Plus series Installation guide

SERVICE TRAINING NOTES
ARTon Plus
SERİSİ
UPS
10-15-20-30-40 kVA
3 Faz Giriş - 3 Faz Çıkış

CONTENTS
SAFETY..............................................................................................................................1
I. GENERAL DESCRIPTION..................................................................................................2
1.1 Introduction..................................................................................................................2
1.2 Design Concept............................................................................................................3
1.2.1 Operating modes of UPS....................................................................................4
1.3 Technical specifications................................................................................................7
1.4 ARTonPlus Series UPS Basic Diagrams ......................................................................8
1.5 ARTonPlus Series UPS Electronic Boards....................................................................12
1.5.1 PCB Locations...................................................................................................13
1.5.2 PFC3P-R1 IGBT Rectifier Controller Board........................................................15
1.5.3 IPMD Intelligent Power Module (IPM) Driver Board............................................18
1.5.4 P3MC-R5 UPS Main Controller Board................................................................20
1.5.5 ADVS01-R1 DC-3 Phase AC Voltage Sample Board .........................................25
1.5.6 SDXC300-R1 Bypass and Inverter SCR Driver Board........................................28
1.5.7 STP01-R2 Switching Power Supply Board.........................................................30
1.5.8 ITF3-R2 3Ph/3Ph UPS Interface Board..............................................................31
1.5.9 STM01 Output Monitoring Board........................................................................33
1.5.10 OPS3 3Ph Voltage and Current Sample Board..................................................34
II. UPS INSTALLATION..........................................................................................................39
2.1. Introduction..................................................................................................................39
2.2. Unpacking....................................................................................................................39
2.3. Equipment Positioning..................................................................................................39
2.4. Connecting the UPS power cables...............................................................................39
2.4.1 Safety Earth.......................................................................................................40
2.4.2 Cable connection procedure...............................................................................40
2.4.3 Description of connection terminals of the UPS...................................................41
2.4.4 Battery installation..............................................................................................42
III. FRONT PANEL...................................................................................................................46
3.1. Introduction..................................................................................................................46
3.2. Front panel menu descriptions......................................................................................46
3.2.1 Measures Menu items...........................................................................................47
3.2.2 Alarms Menu items...............................................................................................47
3.2.3 Information Menu items.........................................................................................47
3.2.4 Adjust Menu items................................................................................................48
3.2.5 Options Menu items..............................................................................................48
3.2.6 Command Menu items..........................................................................................49
3.2.7 Time Menu items..................................................................................................50
3.2.8 Service Menu items..............................................................................................50
3.3. Status Messages..........................................................................................................50
3.4. Shutdown Messages....................................................................................................51
3.5. Fault Messages and Quick Troubleshooting.................................................................51
IV. PARALLEL OPERATION....................................................................................................54
4.1. Introduction..................................................................................................................54
4.2. Parallel operation modes of ARTonPlus Series UPSs...................................................55
4.2.1 Parallel Mode........................................................................................................55
4.2.2 Redundant Mode..................................................................................................55
4.2.3 N+1 Redundant Mode...........................................................................................56

V. OPERATING INSTRUCTIONS.............................................................................................59
5.1. Introduction..................................................................................................................59
5.2 Operating Instruction for a single UPS unit (online operation)........................................59
5.2.1 Procedure for turning on the UPS to supply the load from a complete
Power-off condition.........................................................................................................59
5.2.2 Power off ..............................................................................................................59
5.2.3 Switching into Maintenance Bypass Mode.............................................................60
5.2.4 Switching from Maintenance Bypass into normal Operation...................................60
5.3 Operating Instruction for Parallel connected UPSs........................................................60
5.3.1 Procedure for turning on the UPS (First Installation)..............................................60
5.3.2 Power off..............................................................................................................61
5.3.3 Switching the parallel UPS system into
Maintenance Bypass mode (Uninterrupted transfer)........................................................61
5.3.4 Switching the parallel UPS system into parallel operation from a
Maintenance Bypass power down condition (Uninterrupted transfer)...............................61
VI. MAINTENANCE.................................................................................................................62
6.1. Scheduled Maintenance...............................................................................................62
6.2. Daily checks ................................................................................................................62
6.3. Weekly checks.............................................................................................................62
6.4. Annual Maintenance.....................................................................................................63
6.5. UPS storage and transportation....................................................................................63
VII. FAULTS AND TROUBLESHOOTING ...............................................................................64
7.1. General procedure for fault checking and Troubleshooting ...........................................64
VIII. UPS REMOTE MONITORING AND CONTROL................................................................65
8.1 Using serial port.............................................................................................................65
8.1.1 Communication Routing Switch..............................................................................65
8.2 Serial Communication Cable ..........................................................................................66
8.3 Modem Connection........................................................................................................66
8.3.1 Hardware Configuration.........................................................................................66
8.3.2 Functioning Principle..............................................................................................66
8.3.3 Modem Programming Procedure............................................................................67
8.3.3.1 Smart Modem Programming (PC Modem).................................................67
8.3.4 Modem-UPS Connection Cable..............................................................................67
8.4 Dry contact (interface) Connections................................................................................67
8.5 Remote Monitoring Panel...............................................................................................68

1
SAFETY
IMPORTANT NOTICES
1. Read instructions carefully before installing and starting the UPS
2. All warnings in the manual should be adhered to.
3. All operating instructions should be followed.
4. The unit should be supplied by a grounded outlet. Do not operate the unit without a ground source.
5. Power cord of the UPS should be routed carefully so that they are not to be walked on.
6. Please save this manual.
7. Please save or recycle the packaging materials.
WARNING!
Do not insert any object into ventilation holes or other openings.
To reduce the risk of fire or electric shock, install in temperature and humidity controlled indoor
area free of conductive contaminants.
To reduce the risk of fire, replace fuses with the same type and rating when necessary.
CAUTION!
Only qualified personnel should install or service UPS/batteries.
Risk of electric shock, do not remove cover. No user serviceable parts inside, refer
servicing to qualified service personnel.
The output may be energized when the unit is not connected to a mains supply.
Risk of electric shock! Hazardous live parts inside. This unit is energized from the battery
supply even when the input AC power is disconnected.
To reduce the risk of electric shock, disconnect the UPS from the mains supply before installing a
computer interface signal cable. Reconnect the power cord only after signaling interconnections
have been made.
ABOUT THE BATTERIES
CAUTION: RISK OF ELECTRIC SHOCK!
The battery circuit is not isolated from the mains voltage. Hazardous voltages may
occur between the battery terminals and the ground!
A battery can present a risk of electric shock or burn from high short circuit currents. The following
precautions should be taken when working on batteries :
* Remove watches, rings or other metal objects.
* Use tools with insulated handles.
The batteries in this UPS are recyclable. Batteries must be disposed of according to local
environmental laws. The batteries contain lead and pose a hazard to the environment and human
health if not disposed of properly.
Do not dispose of batteries in a fire. The batteries may explode. Do not open or mutilate the
batteries. They contain an electrolyte which is toxic and harmful to the skin and eyes. If electrolyte
comes into contact with the skin the affected area should be washed immediately.
The internal energy source (the battery) cannot be de-energized by the user.
When changing batteries, install the same number and same type of batteries.

2
I. GENERAL DESCRIPTION
1.1 Introduction
ARTonPlus Series Uninterruptible Power Supplies are double-conversion, on-line UPS’s manufactured with
the latest IGBT and PWM technology, to produce an uninterruptible, microprocessor controlled pure sine
wave output to critical loads.
ARTonPlus Series units are 3-phase in/3-phase out devices, and they are installed between a three phase
critical load, and a 3-phase+N mains supply
The advantages of using ARTonPlus Series UPS:
Power blackout protection:
If the mains power fails, the UPS continues to supply the critical load using the energy stored in its
batteries, keeping the load immune from power disturbances.
Increased power quality:
The UPS has its own internal voltage and frequency regulating circuits, which ensure that, its output to
the critical load is maintained within close tolerances, independent of voltage and frequency variations
on the mains power lines.
Increased noise rejection:
By rectifying the input AC power to DC power and then converting it back to AC (Double-Conversion)
any electrical noise present on the input mains supply line is effectively isolated from the UPS output.
Therefore the critical load is supplied with only clean and uninterrupted AC power.
Basic Features :
Microprocessor Controlled
Double Conversion, on-line UPS
IGBT Rectifier (PWM)
High Input PF
Low THDI
IGBT Inverter (PWM)
Sinusoidal output Waveform.
Low output Voltage THD
High Nonlinear Load capacity (CF 3:1)
High Unbalanced loading capability.
Efficiency Up to 94%
Overload and short circuit Protection
Overtemperature protection
Static Bypass Switch
Maintenance Bypass Switch
Separate bypass input facility (split Bypass)
Parallel Operation (Optional)
LCD Display
Alarm History (Up to 128 Alarms)
Real time clock (date and time)
Emergency Power off (EPO)
Cold-start feature
Dual Polarity Batteries (Internal and/or external)
Automatic and manual Battery Test
Automatic and manual Boost Charge
Battery current limit adjust
Deep discharge protection
AC input filter
AC output filter
Alarm relay contacts (Standard)
RS232 communication port (Standard)
RS485 interface (Optional)
SNMP adapter (Optional)
Remote monitoring Panel (Optional)

3
RS232 port multiplexer (Optional)
MODBUS adapter (Optional)
Diagnostic and adjustment via PC.
Input and/or output isolation transformers (optional)
1.2 Design Concept
Figure 1.1 Block Diagram Of The UPS
S1 (F1-F2-F3) : Rectifier Input Switch / Fuses
S2 (F4-F5-F6) : Bypass Input Switch / Fuse
S3 : Maintenance Bypass Switch
S4 (F7-F8-F9) : Output Switch / Fuse
S5 (F10-F11-F12) : Battery Switch / Fuses
K1 : Rectifier Input Contactor
K2 : Inverter Output Contactor
DESCRIPTION OF BLOCKS
RECTIFIER: In ARTonPlus Series UPSs, a PWM controlled IGBT rectifier is used to increase input power
factor (PFC) and to decrease input current harmonics (THDI).
The IGBT rectifier accepts 3-phase AC input and produces a dual polarity DC voltage for both supplying
the inverter and charging the batteries.
BATTERIES: Batteries are used as reserve DC power supply for the Inverter in case of mains failure. In
ARTonPlus Series, batteries are connected in series with a center-tap output to obtain a dual polarity DC
supply.
Batteries are discharged by the inverter during mains failure. The discharged batteries are re-charged by
the IGBT Rectifier on a constant current / constant voltage basis, if AC mains power is available.
Rectifier /
Charger
3 PHASE
MAINS I/P
Battery
(Dual Polarity)
Maintenance
Bypass Switch
Static
Bypass
S2
(F4-F5-F6)
S1
(F1
-
F2
-
F3)
S5
(F10
-
F11
-
F12)
S3
S4
(F7-F8-F9)
Inverter
K2
3 PHASE
AC Output
K1

- -

SB

4
INVERTER: It is manufactured by using the latest IGBT technology and Pulse width Modulation (PWM)
technique. The Inverter converts the DC BUS voltage supplied by the IGBT Rectifier and / or the batteries
into a well regulated 3-phase AC voltage with fixed voltage and frequency.
The output of the inverter is used to supply the critical loads connected to the UPS output.
STATIC TRANSFER SWITCH (STATIC BYPASS) : This is an electronically controlled transfer switch,
which enables the critical load to be connected either to inverter output or to a by-pass power source.
During normal operation, the load is supplied by the inverter output, but in case of an overload it is
automatically transferred to the bypass source without any interruption.
MAINTENANCE BYPASS SWITCH (MBS) : This is a manually controlled mechanical switch, which is
used to supply the critical load, using the bypass source, when the UPS is shut down for maintenance or
troubleshooting purposes.
The load is unprotected against mains supply disturbances and black-outs when it is connected to either
static or maintenance bypass supply.
1.2.1 OPERATING MODES OF UPS
ARTonPlus Series UPSs are capable of operating in various different modes for maximum application
flexibility. These modes are:
-ONLINE mode: This is the normal operation mode for a single UPS. As long as the mains supply is
available and in required tolerances, the load is supplied by the well regulated inverter output and the
batteries are charged at the same time. In case of mains failure, the inverter keeps supplying the load
using the energy stored in the batteries.
-ECONO mode: This is the off-line operation mode for a single UPS. As long as the mains supply is
available and in required tolerances, the load is supplied by the mains supply (bypass supply) via the
Static Bypass Switch of the UPS and the batteries are charged at the same time. During that time
inverter keeps running under no-load conditions and takes over the load in case of a mains supply
(bypass supply) failure, without any interruption. After restoration of the mains supply the load is
transferred back to bypass supply again.
- PARALLEL, REDUNDANT and N+1 REDUNDANT modes are used for parallel operation of two or
more UPS units and will be explained in parallel operation section later in this manual.
When operating in one of the above operating modes, UPS may be in one of the following operating
conditions:
A. Normal Operation (If Mains supply is available):
All fuses and power switches are closed (except the Maintenance Bypass Switch), and the load is
supplied by the Inverter Output. During normal operation, the Rectifier supplies DC power to the Inverter
and charges the Batteries at the same time.
B. Battery Operation :
The Batteries are connected to the Rectifier output. In case of a mains failure (mains power outage or
AC input voltage out of tolerance), the Rectifier stops operating and the DC voltage necessary for the
inverter operation is supplied by the batteries. Therefore the AC voltage output supplying the critical
load is not interrupted, until the batteries are fully discharged. At the end of the discharging time the
Inverter is turned off and it start again automatically, together with the Rectifier, when the mains power
is restored, and the UPS returns o normal operation.
The Rectifier is also turned off and Inverter operates on batteries during automatic or manual battery
test procedure.
C. By-Pass Operation :
If the Inverter output is overloaded or in case of a problem in the UPS, the static switch transfers the
load to the bypass supply without any interruption, provided that the bypass supply is available and
within the tolerated limits.
At the end of the overloading period, if the fault condition is restored, static switch transfers the critical load
again to the inverter output. Note that, during operation from the bypass supply, the critical load may be
effected by any possible disturbances or power failure in the bypass supply.

5
RS232
Communication Port
(DB9 Female)
Figure 1.2 10-15-20 kVA Switch configuration
Dry Relay Output Contacts
Battery circuit
breaker Input Emergency Stop Line Failure Relay Battery Low Relay
( RS232 / SNMP )
Communication
Select Switch
S
7
ON / OFF
Switch
S5
(Battery Input, F10-F11-F12)
S1
(AC Input, F1-F2-F3)
S3
(Maintenance by-pass)
S2
(By-Pass, F4-F5-F6)
S4
(AC Output, F7-F8-F9)
By-Pass
Relay
Parallel Com. Ports.
S6
Manual Bypass
Switch

6
Masaüstünü Göster.scf
Figure 1.3 30-40 kVA Switch configuration
RS232
Communication Port
(DB9 Female)
Dry Relay Output Contacts
Battery circuit
breaker Input Emergency Stop Line Failure Relay Battery Low Relay
( RS232 / SNMP )
Communication
Select Switch
S
7
ON / OFF
Switch
S5
(Battery Input, F10-F11-F12)
S1
(AC Input, F1-F2-F3)
S3
(Maintenance by-pass)
(Under the cover)
S2
(By-Pass, F4-F5-F6)
S4
(AC Output, F7-F8-F9)
By-Pass
Relay
Parallel Com. Ports.
S
6
Manual Bypass
Switch

7
1.3 Technical Specifications
MODEL 10 15 20 30 40
Output (KVA) 10 15 20 30 40
Output (KW) 8 12 16 24 32
Output Power Factor 0,8
INPUT
Number of Phases 3 Phase + Neutral
Input Voltage 220/380 Vac , 230/400Vac or 240/415Vac 3phase+N
Input Voltage Tolerance +20%,-25% (+15% , -30% for 240/415Vac)
Input Power Factor (PF) 0,98 - 0,99 (at full load)
Input THDI ≤ 5 % (at full load)
Input Frequency 50Hz ± 5 %
By-pass Voltage 220/380 Vac , 230/400Vac or 240/415Vac 3phase+N
By-pass Frequency 50Hz
By-pass Frequency Tolerance (± 2 % )
RFI Level EN50091
Split By-pass Connection Available
OUTPUT
Number of phases 3 Phase + Neutral
Output Voltage 220/380 Vac , 230/400Vac or 240/415Vac 3phase+N
Output Voltage Tolerance ± 1 %
Output Frequency 50 Hz
Output Frequency Tolerance (line synchron) (± 2 % )
Output Frequency Tolerance (free running) ± 0,2 %
Efficiency (at full linear load) up to 94 %
Load Crest Factor 3 : 1
Output Voltage THD ≤ 3 %
Overload 125% Load 10min. , 150% Load 1min.
BATTERIES
Total Number
60 (2x30) pieces 12V
Float Charge Voltage (250C) ± 405 Vdc
End of Discharge Voltage ± 300 Vdc
Battery Test Automatic and Manual
Boost Charge Available
INTERFACE
RS 232 comm. port Standard (Optional port multiplexer available)
RS 485 comm. port Optional
Remote Monitoring Panel Optional
SNMP Adapter Optional
Modbus Adapter Optional
Alarm Relay Contacts 3x Dry Relay Contacts
(Line failure, battery low, bypass)
EPO Input Standard
ENVIRONMENT
Operating Temperature 0 - 400C
Operating Humidity < 90% (Non-Condensing)
Acoustic Noise ≤ 50 dB ≤ 55 dB
Dimensions (HxWxD) (mm) 1035 x 375 x 735 1440 x 495 x 845
Protection Class IP20
Weight (Without Batteries) (approx. kgs) 105 110 115 185 200

8
1.4 ARTonPlus Series UPS Basic Diagrams
Figure.1.4.1CYCLONESERIES 3Ph/3PhUPSBLOCKDIAGRAM
BYPASSSW/FUSE
S2
3-Phase
ACI/P
ACInput
SW/Fuse
RECTIFIERINPUT
CONTACTOR
3-PhIGBT
RECTIFIER
+405V
-
405V
K1
FUSE
3-Ph
INVERTER
OUTPUT
SW/FUSE
K2
+BUS
CAP.
-BUS
CAP.
CT
CT
+Battery
Group
-Battery
Group
FUSE
AC
AC
DC
DC
INVERTER
BYPASS
3-Phase ACO/P
STATIC
SWITCHES

9
Figure 1.4.
2
IGBT Rectifier

10
Figure 1.4.3 Transformerless 3-Phase Inverter

11
Figure 1.4.4 ARTonPlus series UPS Basic Diagram

12
1.5 ARTonPlus SERIES UPS ELECTRONIC CONTROL BOARDS
You will find below a list of PCBs used in ARTonPlus Series 3 Phase in / 3 Phase out UPSs :
1 PFC3P-R1 3 PHASE POWER FACTOR CORRECTION BOARD
(IGBT RECTIFIER CONTROLLER BOARD)
2 IPMD3P (2 pieces) IPM (INTELLIGENT POWER MODULE) DRIVER BOARD
3 P3MC-R5 UPS MAIN CONTROLLER BOARD
4 ADVS01-R1 DC - 3 PHASE AC VOLTAGE SAMPLE BOARD
5 SDXC300-R1 BYPASS & INVERTER SCR DRIVER BOARD
6 STP01-R2 SWITCHING POWER SUPPLY BOARD
7 MODPAN02-R1 LCD PANEL BOARD
8 ITF3-R2 3 Ph / 3 Ph UPS INTERFACE BOARD
9 RS330-R1 SERIAL COMMUNICATION (RS232) BOARD
10 STM01 OUTPUT MONITORING BOARD
11 OPS3 3 PH VOLTAGE AND CURRENT SAMPLE BOARD
12 CPC01-R2 CAPACITOR CHARGER BOARD
13 CUR03 or CT311 CURRENT TRANSFORMER BOARD (3 Ph)
14 PARA04 PARALLEL OPERATION CONTROLLER BOARD
15 PARA3PX 3 Ph PARALLEL CURRENT SAMPLING BOARD
16 PAI33 PARALLEL SOCKET BOARD

13
1.5.1 PCB LOCATIONS
S
DXC300
-
R1
ADVS01-R1
OPS3
RS330-R1
TOP VIEW Figure 1.5.1 10-15-20 kVA
ITF3-R2
FRONT VIEW
LEFT VIEW
IPMD3P
P3MC-R5
RIGHT VIEW
STM01 CPC01-R2
STP01-R1
PFC3P-R1
IPMD3P

14
Figure 1.5.2
30
-
40
kVA
SDXC300-R1
ITF3-R2
FRONT VIEW
LEFT VIEW
P3MC-R5
RIGHT VIEW
STM01
CPC01-R2
STP01-R1
IPMD3P
RS330
-
R1
TOP VIEW
OPS3
ADVS01-R1
PFC3P-R1
IPMD3P

15
1.5.2 PFC3P-R1 IGBT RECTIFIER CONTROLLER BOARD:
This electronic controller board is used to control the 3-Phase IGBT Rectifier at the input stage of the
ARTonPlus Series tansformerless Uninterruptible Power Supplies. By using an IGBT rectifier and this
control board, the nput power factor of the UPS is corrected (to 0.99 at full load) and the input current THD
is improved (less than 5% at full load).
A) Basic functions of PFC3P-R1
1. It takes the 3-Phase AC nput voltage and current samples coming to the IGBT rectifier and
generates necessary PWM- IGBT driving signals to correct the input pF and to decrease the input
current distortion (THDI). The signals for the control of each phase is generated independently.
2. It takes the positive and negative DC output voltage samples of the rectifier and adjust the
driving signal pulse widhts to keep these DC voltages constant under normal loading conditions. In case
of overloading of the IGBT rectifier, the rectifier output voltages are decreased to limit the rectifier output
and thus the UPS input current. Different current limiting values for different UPS power ratings can be
set by changing some fixed resistors on PFC3P-R1 board (R63, R124 and R186).
3. In ARTonPlus Series UPSs, the IGBT rectifier produces a dual polarity DC voltage at its output to
supply the transformerless Inverter stage. The batteries which are the reserve energy supply for the
UPS are directly connected to the rectifier outputs again as two separate battery groups with opposite
polarity. The total number of batteries (12V), in a standard ARTonPlus Series UPS, is 60 (30+30). Thirty
batteries are used for one polarity and the other thirty are used for the opposite polarity. The float
charging voltage value for 2X30 batteries is +/- 405V dc. Therefore the no-load output voltage of the
IGBT rectifier is adjusted to +/- 405V (810V dc total).
During normal operation, IGBT rectifier supplies power to the Inverter and charges the batteries at the
same time. PFC3P-R1 board takes the battery current samples and adjusts the IGBT driving signals to
limit the maximum battery charging current to a pre-adjusted safe value suitable for the VA rating of the
batteries. Therefore the output voltages of the rectifier change in accordance with the battery voltages
during the charging period of the batteries.
4. PFC3P-R1 board accepts some control signals from UPS Main Controller Board (P3MC-R5)
and performs the following functions:
-Boost Charge: During boost charge, the rectifier output voltages are increased to the boost
charging voltage level for the batteries and kept at that level until the end of the boost charging
period. At the end of the boost charging period, the rectifier output voltages are decreased to the
float charge level again. The boost charge voltages for positive and negative battery groups are
adjusted separately on PFC3P-R1 board.
-Rectifier Start: When the P3MC-R5 board sends a ‘’Rectifier Start’’ signal to the PFC3P-
R1 board, the input contactor (K1) is energized and the IGBT rectifer starts operating.
-Battery Test: When the P3MC-R5 board sends a ‘’Battery Test’’ signal to the PFC3P-R1
board, the rectifier output voltages are both decreased to a preadjusted value and kept at that level
until the end of the battery test procedure.
5. On the other hand, PFC3P-R1 board sends the following signals to the UPS Main Controller Board:
1. ‘’Rectifier Fault’’
2. ‘’ Positive battery group current sample (either charging or discharging)
3. ‘’ Negative ‘’ ‘’ ‘’ ‘’ ‘’
4. ‘’ Negative battery voltage sample’’

16
B) Adjustments of PFC3P-R1 IGBT Rectifier Controller Board:
-AR1 : Rectifier output voltage with only R-phase operation, (increases CW)
-AR2 : ‘’ ‘’ ‘’ ‘’ “ S-phase ‘’ ‘’
-AR3 : Positive (+) battery group boost charge voltage, (increases CW)
-AR4 : Negative (-) ‘’ ‘’ ‘’ ‘’ ‘’
-AR5 : (+) and (-) battery groups battery test voltage level, (increases CW)
-AR6 : AC input currents THD adjustment,
-AR7 : (-) battery group charging current limit, (increases CW)
-AR8 : (+) ‘’ ‘’ ‘’ ‘’ ‘’ ‘’
-AR9 : Rectifier output voltage with only T-phase operation, (increases CW)
-AR10 : Rectifier negative (-) output voltage, (a single adjustment for equalizing the neg. Output
voltage to the poz. output voltage, increases CW)
-AR11 : Rectifier fault threshold level adjustment.
C) PFC3P-R1 Test Points
-TP1 : R-phase, full-wave rectified AC input voltage sample, (……. V peak at 220V)
-TP2 : R-phase IGBT driving signals (0-12V)
-TP3 : R-phase, AC input voltage sample, (……..V dc at 220V)
-TP4 : R-phase, AC input current sample,
-TP5 : Electronic GND (= input line Neutral)
-TP6 : S-phase, full-wave rectified AC input voltage sample, (…..V peak at 220V)
-TP7 : S-phase IGBT driving signals (0-12V)
-TP8 : S-phase, AC input voltage sample (….. V dc at 220V)
-TP9 : S-phase, AC input current sample,
-TP10 : +12V dc (+/- 0.5V)
-TP11 : -12V dc (+/- 0.5V)
-TP12 : +17V dc (+/- 1.0V)
-TP13 : T-phase, full-wave rectified AC input voltage sample, (….V peak at 220V)
-TP14 : T-phase IGBT driving signals (0-12V)
-TP15 : T-phase, AC input voltage sample (…V dc at 220V)
-TP16 : T-phase, AC input current sample,
D) PFC3P-R1 board ‘’jumper’’ positions
There are various jumper connections on the board which are inserted or removed during testing or normal
operation of the rectifier. Their list and positions are given below:
During normal operation:
JP5=JP8=JP12=JP17 = ‘’1’’ (inserted or short circuited)
JP1=JP2=JP3=JP4=JP6=JP7=JP9=JP10=JP11=JP13=JP14=JP15=JP16=JP18=JP19 = ‘’0’’ (removed)
Note: JP1, JP9 and JP16 are used to start or stop the IGBT rectifier phase by phase. They are used to
enable or disable the rectifier to operate on the desired input phase (or phases). If JP1, for example, is
inserted then the rectifier stops using the R-phase (stops generating driving signals for R-phase) for
generating its DC output. If it is removed then the rectifier starts using R-phase. JP9 and JP16 do the same
for S and T-phases respectively. During rectifier output voltage adjustments, they are removed one by one
to adjust the output voltage when operating on each phase separately.
