ARX SPL 12 User manual

Speaker System
Installation/Flying Details
FRONT SIDE REAR
TOP BOTTOM
SPL 8H Cabinet Dimensions and Layout
Flying Point
locations
Connector
Part # R1434
Cabinet fitting
Part # R1436
The recessed flying points on the SPL
12 are designed to receive a single stud
spring-loaded track connector. See be-
low.
The SPL 8H has 6m T-nuts pre-installed
on the Top and on the Right Hand Side
when looking from the front. These are
laid out ready to accept 6mm bolts to
mount an Omnimount Series 100 brack-
et/clamp assembly to the cabinet.
Mounting brackets are available from
Omnimount, or can be ordered through
ARX to be delivered with your speaker
system
Check www.omnimount.com for dis-
tributor details for your country
FRONT SIDE REAR
TOP BOTTOM
Omnimount
100 series
mounting
Dimensions
Connectors are available from Penn Fab-
rications worldwide, or can be ordered
through ARX to be delivered with your
speaker system
Check www.penn-fabrication.com for
distributor details for your country All dimensions
in millimetres
SPL 12 Cabinet Dimensions and Layout

FRONT SIDE BACK
Rigging options include recessed flying
points designed to receive a single stud
spring loaded connector for systems that
willbetransported,or10mmcaptivenuts
toinstalleyeboltsforsystemsusedinfixed
installations.
BOTTOMTOP
All dimensions
in millimetres
FR
PMX 12 Cabinet Dimensions and Layout
FRONT SIDE REAR
TOP
450 450450
620
SPL SUB15
Enclosure layout
FRONT SIDE REAR
TOP
515 585 515
730
SPL SUB18SPL SUB18
SPL SUB18SPL SUB18
SPL SUB18
enclosure layout
FR
SPL SUB 15 Cabinet Dimensions and Layout
SPL SUB 18 Cabinet Dimensions and Layout
SPL SUB 15 and 18 have a screw mount plate
fitted to their top surface to enable a K & M
screw-in pole mount to be fitted.
Part # KM 24116.000.55
Pole mounts are available from K & M world-
wide, or can be ordered through ARX to be
delivered with your speaker system
Check www.k-m.de for distributor details
for your country
Connector
Part # R1434
Cabinet fitting
Part # R1436
Connectors are available from Penn Fabrica-
tions worldwide, or can be ordered through
ARX to be delivered with your speaker sys-
tem
Check www.penn-fabrication.com for dis-
tributor details for your country
Eye bolt
Part #
R1737M

FRONT
M SUB ENCLOSURE LAYOUTM SUB ENCLOSURE LAYOUT
M SUB ENCLOSURE LAYOUTM SUB ENCLOSURE LAYOUT
M SUB ENCLOSURE LAYOUT
PRO SUB ENCLOSURE LAYOUTPRO SUB ENCLOSURE LAYOUT
PRO SUB ENCLOSURE LAYOUTPRO SUB ENCLOSURE LAYOUT
PRO SUB ENCLOSURE LAYOUT
SIDE REAR
TOP
FRONT SIDE REAR
TOP
580510
730
450450
620
510
450
STEP 2: Tighten up grub screw (1) on the
mounting bracket. Leave adjustment arm (2)
loose.
STEP 3: Attach the mounting plate to the
speaker box using the 2 machine screws (3)
and shakeproof washers
STEP 4: Attach the mounting bracket to the
wall using 4 suitable fasteners (4)
STEP 5: Adjust the angle as required and then
tighten adjustment arm (2)
STEP 6: Connect appropriate Input signal to
the cabinet
(see below)
!
"
#
$
AMBIENCE1HORIZONTALMOUNTING
AMBIENCE1VERTICAL
MOUNTING
STEP1: Attach the mounting
plate to the arm of the
mounting bracket
ARX Ambience 1 speakers are suitable for both
Vertical and Horizontal installation, depending
on the coverage pattern required.
Care must be taken to ensure that the surface to
which they are to be mounted is capable of
supporting the weight of the Ambience 1.
In a brick/concrete wall, make sure that suitable
anchor bolts are used.
In a plasterboard/drywall installation, it is impor-
tantto ensurethemountingfastenersarescrewed
through the plasterboard surface to the support-
ing stud or beam underneath.
instaLLation procedure
The Pro-SUB and the M-SUB
have a screw mount plate fitted
to their top surface to enable a
K & M screw-in pole mount to
be fitted.
Part # KM 24116.000.55
Pole mounts are available from
K & M worldwide, or can be or-
dered through ARX to be deliv-
ered with your speaker system
Check www.k-m.de for distrib-
utor details for your country
