GREAT BRITAIN
For consumer contact, please visit www.clasohlson.co.uk and click on customer service.
ENGLISH
1 2
3
Ver. 201207
Rechargeable
LEDcamping lantern
Art.no 31-1978 Model FD390ER30
Please read theentire instruction manual before use and save it for
future reference. Wereserve theright for any errors in text or images
and for making any necessary technical changes to this document.
Ifyou should have any questions concerning technical problems
please contact our Customer Services.
Safety
• This product must not be used by anyone (including children)
suffering from physical or mental impairment. Thisproduct
should not be used by anyone that has not read theinstruction
manual unless they have been instructed in its use by someone
who will take responsibility for their safety.
• Never let children play with theproduct.
• Always turn thelamp off when it is not in use.
• Prolonged use of thelamp when thebattery begins to weaken
will diminish thebattery capacity.
Product description
Powerful LED lamp. Classicshape. 30 LEDs. 12 V charger included.
Care and maintenance
Clean theproduct by wiping it with asoft, damp cloth.
Neveruse abrasive cleaning agents or solvents.
Disposal
When it is time to dispose of this product, do so in accordance with
local regulations. Ifyou are unsure how to proceed, contact your
local authority.
Specifications
Height 34 cm
Battery Lead-acid battery 6 V, 4 Ah
Charging current 180 mA
Charger 12 V DC (+ in the centre)
Current draw Approx. 0.45 A
Mounting theshade
1. Put thehandle into theupright position (fig. 1).
2. Pass theshade down over thehandle and align thenotches with
thehandle fixing nuts (fig. 2 & 3).
12 V charging
1. Turn the on/off switch to the OFF
position and connect the charger
cable to the back of the lantern.
2. Connect the charger cable to your
car's cigarette socket or other
available 12 V power source.
Thered LED below the socket will
indicate that charging is in progress.
Operation
If the battery is completely discharged, it will require about 20 hours
of charging to reach full charge again.
Example:
Charging time Operating time
5 hours Approx 2 hours
10 hours Approx 4 hours
20 hours Approx 8–10 hours
Note:
• Plug the charger into your vehicle’s 12 V socket*. Never charge
the battery for more than 30 hours; this could seriously drain
and/or damage your vehicle battery.
• Give the lantern a full charge if it is to be stored and not to be
used for a long time.
• If the storage temperature is:
- 10 ºC or lower, charge the battery every 6 months.
- 10–27 ºC, charge the battery every 3 months.
- 27–40 °C, charge the battery every 2 months.
• The battery needs to be fully charged from time to time; the
capacity of the battery will deteriorate if it is merely charged for
short periods at a time.
* Some vehicles have the 12 V socket connected to the ignition
which means the socket has no power when the ignition is off.
Thelantern’s charging current is only 180 mA but don’t forget that
there may be other electrical components in your vehicle which
consume power when the ignition is on. Read your vehicle's
handbook if you areunsure.
Turn theon/off knob clockwise to
turn thelantern on.
Turn theon/off knob
anticlockwise to turn
thelantern off.
