Ascape ascend 1 User manual

Page 1
First Time Setup & Pairing
Page 6
Power Dock & Device Charging
Page 3
Maximizing Connection Strength
Page 2
Headphone Wearing
Page 4
Headphone Controls
Page 5
Headphone Features
Page 7 - 8
Troubleshooting Connection

FIRST TIME SETUP & PAIRING
#1
Charge power dock and earbuds
for 1 hour before first use
#2
Install the largest ear tips
that fit your ears comfortably
#4
Wait for both LEDs
to flash Blue & Red
#6
Open your device’s Bluetooth settings
and select ASCAPE - Ascend 1
#3
Hold both earbuds for
10 seconds to begin pairing
#5
Insert Earbuds and wait
30 seconds to hear "Pairing”
PG. 1

HEADPHONE WEARING
#1
Find R/L label between
charging contacts
#2
Match each earbud to the
correct ear and insert tip first
#5
End with button horizontal,
and earbud tucked into ear
#4
Rotate earbud button
downward toward back
#3
Start with button oriented
vertically towards face
PG. 2

Earbuds are paired together, then left earbud
connects to device/smartphone
For optimal connectivity wear or position
device on the left side of your body
During phone calls, Bluetooth technology
only allows the use of the left earbud
MAXIMIZE CONNECTION PERFORMANCE
PG. 3

HEADPHONE CONTROLS
Hold button 3 sec. to power ON/OFF
Hold button 10 sec. for pairing mode
Press button 1x to answer/end call
Press button 2x to skip forward
Press button 3x to skip backward
Press button 1x to pause/play
Hold button 1 sec. for personal assistant
Press button 2x to reject a call
PG. 4

HEADPHONE FEATURES
Clear Voice Calling
Dual Digital Mics
Easy to Connect
LED Indicators
Ultra-Fast Charging
Magnetic Contacts
Find Your Perfect Fit
3 Rubber Tips Included
CONNECT ONLY ONE HEADPHONE
Press
ASCAPE - Ascend 1
in Bluetooth Settings
Hold Button
for 10 Seconds
Wait for LED to
Flash Red & Blue
PG. 5

POWER DOCK & DEVICE CHARGING
Open Power Dock Here
Power Dock LED
Charging Indicators
Headphone LED
Charging Indicators
HEADPHONES
While Charging (Flashing)
Fully Charged (Off)
•Working Distance: <10M
•Battery Capacity: 60mAH Each
•Talking-Time: 4 Hours
•Music-Play Time: 3.5 Hours
•Charging Time: 1 Hour
Low Power (Flashing)
While Charging (Red)
Fully Charged (Blue)
•Battery Capacity: 400mAH
•Earbud Charging: 4x Lifecycles
(without connecting to external power)
POWER DOCK
PG. 6

TROUBLESHOOTING CONNECTION (1 of 2)
#5
Remove earbuds from charging dock
and hold both buttons for 10 seconds
to turn ON and begin pairing.
#1
Turn both earbuds OFF by holding
both buttons for more than 3 seconds.
Place earbuds into charging dock.
#2
Disconnect each "E10" or "Ascape"
device in your phone's Bluetooth settings.
(Click in iPhone Settings)
#4
Turn OFF your phone's
Bluetooth functionality.
(click the Green Slider on iPhone)
OFF
#3
Remove every Bluetooth device
from your phone’s auto pair memory.
(click "Forget This Device" on iPhone)
Forget This Device
#6
Check LEDs on both earbuds.
They should begin to quickly flash
Red & Blue back and forth.
PG. 7

TROUBLESHOOTING CONNECTION (2 of 2)
#9
Wait 10-15 seconds for your earbud
device to appear on your phone.
Click ASCAPE - Ascend 1 to connect.
#7
Insert earbuds into your ears.
Wait for up to 30 seconds to hear
"Left Channel, Right Channel, Pairing"
#8
Once you hear "Pairing" turn your
phone’s Bluetooth function back ON.
(Green slider on iPhone)
ON
#10
Hear "Connected" and look for headphone
symbol on your phone. Play music to
confirm audio comes from both earbuds.
PG. 8
