Ascendo CCM5-P User manual

CCM5-P
CCM6-P
PASSIVE MONITORS
Coaxial Cinema Series
On Wall & On Ceiling Speakers
TECHNICAL DATA
CCM5-P
Point Source two-way Coaxial speaker
HF Driver:
Neodymium tweeter with soft dome
diaphragm
LF Driver:
130mm Woofer featuring Lightweight paper
cone and High-power, long-throw magnet
systems
Power Handling:
100W max (undistorted music program)
Frequency Range:
+/- 3dB from 80Hz to 20kHz (on wall)
Sensitivity:
1 W/1m 88dB
Nominal Impedance:
8 Ohm (6 Ohm minimum)
Speaker design:
Vented high absorbency, low resonance
enclosure
Terminals:
Gold-plated 4-way binding posts
Dimensions:
240 x 400 x 75mm (W x H x D)
CCM6-P
Point Source two-way Coaxial speaker
HF Driver:
Neodymium tweeter with soft dome
diaphragm
LF Driver:
165mm Woofer featuring Lightweight paper
cone and High-power, long-throw magnet
systems
Power Handling:
300W max (undistorted music program)
Frequency Range:
+/- 3 dB from 80Hz to 20kHz (on wall)
Sensitivity:
1 W/1m 93dB
Nominal Impedance:
8 Ohm (6 Ohm minimum)
Speaker design:
Vented high absorbency, low resonance
enclosure
Terminals:
Gold-plated 4-way binding posts
Dimensions:
260 x 440 x 88mm (W x H x D)
The information contained in this manual is subject to change without prior notice. The most current
version of this manual is available on our ofcial website at: www.aia-cinema.com
Copyright © 2020. Ascendo Immersive Audio GmbH. All rights reserved.
OWNER’S MANUAL
ASCENDO Immersive Audio GmbH
Galgenmühle 5 | 91522 Ansbach
Germany
aia-cinema.com
[email protected]om
Marking by the “CE” symbol indicates
compliance of this device with the EMC
(Electromagnetic Compatibility) and LVD
(Low Voltage Directive) standards of the
European Community.
This product must be returned to the
separate collection system for electronic
products. Do not dispose this product
together with general household waste.

CONGRATULATIONS on choosing the Ascendo’s CCM5-P or CCM6-P
On Wall & On Ceiling Loudspeakers.
These powerful point source coaxial two-way loudspeakers feature soft dome tweeter diaphragm
technology with strong Neodymium magnet material and are capable of outstanding performance.
Please take a few moments to read this manual. The advice it contains will enable you to get the very
best performance out of your Acoustic Energy loudspeakers.
UNPACKING AND
MAINTENANCE
Your speaker should be treated with the same
care you would treat a piece of furniture. Use
only a piece of soft cloth and a small quantity
of warm soapy water to clean the loudspeakers.
Avoid touching the cone of the bass unit or treble
dome since this may leave a nger mark or even
damage the dome and spoil its performance.
After unpacking, we suggest you retain all
packing material for future transports.
RUNNING-IN PERIOD
The performance of the speaker will change
subtly during the listening period.
Please allow your new speakers to play about 50
hours of music at normal listening level before
doing any critical listening.
ROOM POSITIONING
The performance of a loudspeaker system in a
room varies greatly with its placement. Those
speakers are designed for On Wall or On Ceiling
mount to take advantage of the so-called
boundary gain obtained in the bass notes. The
speakers must be installed hanging on the wall
or ceiling. You will experience the most accurate
sound picture if you listen from a position halfway
between the loudspeakers. This holds also
true using the speakers as object-based Dolby
Atmos® Ceiling or Surround speakers. Objects in
the direct sound path can disturb the coherence
of the sound picture. Try out different positions
before deciding on a nal arrangement.
MOUNTING
The CCM5-P and CCM6-P speakers possess three
mounting options. They have “keyholes” on the
back side to allow hanging them on the wall, they
have two “through” mounting holes, to allow
for at On-Wall or On Ceiling mount and they
possess a “VESA” 100 Mounting option to use a
standard VESA mount. Because the speaker is a
vented design, it must be mounted in a way that
allows a free air ow from the port.
FRONT CLOTH PANEL
The CCM5-P and CCM6-P speaker comes with a
magnetic attached front mounted frame, covered
with acoustic transparent cloth. The covers can
be easily removed by pulling them away.
NOTE!
The CCM5-P and CCM6-P should be installed on a
wall or on a ceiling for best performance. The full
sound performance of these speakers is obtained,
when they are wall/ceiling mounted by taking
advantage of the boundary gain giving them
extended low frequency performance.
Please note: As of September 2020, a new in
Wall Mounting kit becomes available as optional
accessory. Please consult with your ASCENDO
dealer.
CONNECTIONS
Make sure to turn off all ampliers before
connecting your new speaker to your system.
Connect the cable to the terminals. Use the
marking of the cable to ensure that the red or ”+”
mark of the amplier is connected to the ”+” side
of the terminal, also marked with red.
We recommend high quality loudspeaker cables.
Ask your dealer or Installer for the best cables
suiting your needs.
POWER HANDLING
ASCENDO recommends using ampliers with a
high dynamic power range. The most important
thing is, that the amplier has sufcient power
reserves for handling peaks and transients
present in the music signal. The power rating
gure of a loudspeaker depends mostly on the
clean power provided by the amplier. A power
rating of e.g. 100W RMS says only that you can
play a continuous tone of 1kHz at this output.
It does not mean that you can turn the volume
all the way up on a 100W amplier and expect
clear sound and healthy speakers.
The greatest danger to a loudspeaker is
distorted or clipped amplier signals. Distorting
ampliers produce overtones in the entire
spectrum, with a high energy that can easily
damage the speaker units. Because a more
powerful amplier can play without producing
distortion on the output, we have the paradox
here, it is a greater risk to damage speakers by
playing loud with a smaller amplier.
CAUTION!
If you hear distortion when you increase the
volume this is normally a sign of overloading
the amplier or the speaker and you should
immediately reduce the output level to not
damage the speakers permanently. Use
of loudness, bass or treble boost controls
increases the risk of overloading the amplier.
We recommend that you use these controls
with great care.
SERVICE
Shall your ASCENDO loudspeaker system require
service, or if you have difculty in achieving the
rightfully expected ne performance of which
your ASCENDO loudspeaker systems are capable
of, consult your dealer that has the knowledge
required, to provide expert advice and assistance.
In case the ASCENDO dealer is unable to assist
you, you are welcome to contact the ASCENDO
Technical Department at: [email protected]om
WARRANTY CONDITIONS
This product is covered by warranty, depending
on the conditions in the country where it is sold. If
the speaker is returned for service, please include
the original dated receipt with the product. This
warranty is valid only in the country of purchase,
to the original purchaser and is non-transferable.
ASCENDO loudspeakers are movie and music
listening devices and should be used for listening
purposes only. They must not be connected to any
other equipment than audio ampliers within the
specied power range.
ASCENDO cannot be held responsible for damage
or injuries caused by improper mounting, use
and the speaker being used in violation with the
recommendations and warnings in this manual
packaged with the speakers.
