TLB-C Brushless Electric Screwdrivers
Operation Manual
Table of Contents
Overview ...................................................................................................................1
General Safety Rules...................................................................................................1
Safety Instructions......................................................................................................2
Description of Operation.............................................................................................2
Grounding Instructions...............................................................................................2
Installation Instructions ..............................................................................................2
Torque Adjustment Operation .....................................................................................3
Servicing ....................................................................................................................3
Warranty....................................................................................................................3
Overview
Thank you very much for selecting the TLB-C Brushless Electric Screwdriver.
Read this manual before placing tool in service or operation. Save
these instructions for future reference. It is the responsibility of the
employer to place the information in this manual into the hands of
the operator. Failure to observe the following warnings could result
in injury. When using electric tools, basic safety precautions should
always be followed to reduce the risk of re, electric shock, and
personal injury. After having read these instructions, keep them in a
convenient place so you or the operator can refer to them whenever
necessary.
Note: ASG is not responsible for customer modication of tools for
applications on which ASG was not consulted
PLEASE NOTE: When repairing or replacing tools or
components on any TLB Series purchased in 2016 or prior,
please contact ASG representative
General Safety Rules
Electrical Safety
• Keep work area clean and well lit.
• Electric screwdriver plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) electric screwdrivers.
These precautions will reduce the risk of electric shock.
• Do not expose an electric screwdriver to rain or wet conditions as this will increase
the risk of electric shock.
• Never use the cord to carry, pull, or unplug the electric screwdriver. Keep cord
away from heat, oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
Personal Safety
• Stay alert and pay attention to your surroundings when operating an electric screwdriver.
Do not use an electric screwdriver while you are tired or under the inuence of drugs,
alcohol, or medication, as this could result in serious personal injury.
• Ensure the switch is in the off position before plugging in to avoid accidental
starting.
• Keep proper footing and balance at all times.
Electrical Screwdriver Use and Care
• Use the correct electric screwdriver and power supply for your application.
• Do not use an electric screwdriver if the switch is broken. Any electric screwdriver
that cannot be controlled with the switch is dangerous and must be repaired.
• Disconnect the plug from the power source before making any adjustments,
changing accessories, or storing the electric screwdriver. Such preventive safety
measures reduce the risk of starting the electric screwdriver accidentally.
• Keep out of reach of children and untrained personnel. Electric screwdrivers are
dangerous in the hands of untrained users.
Service
• Have your electric screwdriver serviced by ASG. This will ensure that the safety and
quality of the electric screwdriver is maintained.

ASG, Division of Jergens, Inc.
15700 S. Waterloo Road | Cleveland, OH 44110-3898 | Phone: [phone] | Fax: [phone] | Email: [e-mail] | Web: www.asg-jergens.com | Revision: 8/24/2020 | Page 2 of 3
TLB-C Brushless Electric Screwdrivers
Operation Manual
Grounding Instructions
The tool should be grounded while in use to protect the operator from electric shock.
The tool is equipped with a three-conductor cord and three-prong grounding-type plug
to t the proper grounding-type receptacle. The green (or green and yellow) conductor
in the cord is the grounding wire. Never connect the green (or green and yellow) wire
to a live terminal.
Green and Yellow Earth
Blue Neutral
Brown Live
Safety Instructions
• Make sure the switch is in the OFF position and tool is unplugged when changing a bit
• Do not allow chemicals such as acetone, benzene, thinner, trichloroethylene ketone, or
other similar chemicals to come in contact with the screwdriver housing as damage
will result.
• Do not drop or misuse the screwdriver.
• Do not adjust the torque setting higher than 8 on the torque scale.
• There should be a tool rest interval for cycles of three seconds or longer. This tool is
intended for a duty cycle of 0.8 seconds on, 3.2 seconds off.
• Do not tighten more than 800 tapping screws (size: 3mm. Length: 5mm) per hour.
• Do not use this screwdriver for tightening wood screws.
• Do not operate the Forward/Reverse Switch while the motor is running.
• Turn the switch to the OFF position and unplug the screwdriver and power supply
when the tool is not in use
• Always grasp the plug of the power cord when plugging in/unplugging.
• Always secure the power supply to avoid movement.
• If the power supply overheats or is overloaded with maximum current rating, the
high-speed fuse will cut off the power. If this situation continues, stop operation
immediately and contact ASG for repair.
• Do not disassemble the electric screwdriver or try to repair it yourself.
Description of Operation
Inserting/Removing Bit and Bit Type
• Push up the holder clamp to unlock it.Thus, the bit can be freely attached and detached.
• Insert the power plug into a receptacle and set the switch to “F” (forward position)
• Apply the bit to the screw head and either press the lever or push to start the tool.The
switch will be turned ON to start the motor running.
• When the screw is tightened and reaches the torque that you had set, the tool will
stop automatically.
• To reverse the screw, set the changeover switch to “R” (reverse position).
Do not operate this tool without protective earth connected
Installation Instructions
• Use the power supply voltage recommended in the specication of this manual.
• When using a commercial power supply be sure to set up circuit and safety
breakers. You must also properly ground the mechanisms.
• The temperature and humidity should be kept at appropriate levels.
• Do not set up the power supply in a room that has poor ventilation and where it
may be exposed to dust and metallic particles.
• Do not put anything on top of power supply
• Attach the power supply securely to a at, stable surface.
• Do not permit unauthorized personnel to operate this power supply or electric screwdriver.
• Do not set up the power supply near any high voltage machinery
• Avoid setting up or storing the power supply in wet or oily environments or where
it might be exposed to corrosive or ammable gases.

ASG, Division of Jergens, Inc.
15700 S. Waterloo Road | Cleveland, OH 44110-3898 | Phone: [phone] | Fax: [phone] | Email: [e-mail] | Web: www.asg-jergens.com | Revision: 8/24/2020 | Page 3 of 3
TLB-C Brushless Electric Screwdrivers
Operation Manual
Torque Adjustment Operation
• Determine the torque output of the tool by checking a tightened fastener with a torque
tester such as the ASG DTT or DTT-L.
• Increase or decrease the torque by rotating the Spring Adjusting Ring. Rotating the ring
clockwise to a higher number on the torque scale increases torque output while rotating
the ring counterclockwise to a lower number decreases the torque output.
• Continue to check the adjustment with a torque tester until you are satised with
the torque output. If you are making nal torque adjustments on line, always start
below the desired torque and work upward.
• The torque scale on the tool goes from 0 to 8. Only the even numbers appear: 2,4,6,
and 8. This is not the actual torque the tool is going to produce. The numbers on the
scale are only a point of reference.
Servicing
Maintenance and Inspection
• Do not use the tool more than 8 hours a day.
• Do not let the motor and power supply get over heated. Do not run more than
10-15 screws/minute.
• If you use the tool more than 8 hours a day, have the tool evaluated for
preventative maintenance.
• Inspect tool cords periodically. If damaged, contact ASG.
• Do not remove any labels.
Using non-ASG replacement parts may result in decreased
tool performance and increased maintenance and may void all
warranties.
All repairs and maintenance of this tool must be performed by ASG
ASG is not responsible for customer modication of tools for
applications on which ASG was not consulted.
It is the responsibility of the employer to place the information in
this manual into the hands of the operator.
Servicing (Continued)
DO NOT ATTEMPT TO REPAIR THIS ELECTRIC SCREWDRIVER
SAVE THESE INSTRUCTIONS - DO NOT DISCARD
Warranty
The warranty is 1 year after delivery. If any troubles should occur, please contact ASG.
In the following cases, the purchaser shall pay for parts and labor regardless of the
terms of warranty:
• Failure due to improper handling.
• Failure due to product modication or improper processing.
• Failure due to causes beyond control (for example earthquake or re).
• Consumables, replaceable parts, and replacement work expenses.
PLEASE NOTE: When repairing or replacing tools or components on any TLB
Series purchased in 2016 or prior, please contact ASG representative
