Asiatelco U270V User manual

User Manual
Gateway U270V

Important Notice
Due to the nature of wireless communications, transmission and reception of data can never be
guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although
significant delays or losses of data are rare when wireless devices such as the router are used in a
normal manner with a well-constructed network, the router should not be used in situations
where failure to transmit or receive data could result indamage of any kind to the user or any
other party, including but not limited to personal injury, death or loss of property. Atel accepts
no responsibility for damages of any kind resulting from delays or errors in data transmitted or
received using the Atel router or for failure of the Atel router to transmit or receive such data.
Safety Precautions
Do not operate the router:
• In areas where blasting is in progress
• Where explosive atmospheres may be present
• Near medical equipment
• Near life support equipment or any equipment that may be susceptible to any form of radio
interference. In such areas, the router MUST BE POWERED OFF. The Atel router can transmit
signals that could interfere with this equipment.
Do not operate the router in any aircraft, whether the aircraft is on the ground or in flight. In
aircraft, the router MUST BE POWERED OFF. When operating, the router can transmit signals
that could interfere with various onboard systems.
Note:
Some airlines may permit the use of cellular phones while the aircraft is on the ground and
the door is open. The router may be used at this time.
The driver or operator of any vehicle should not operate the router while in control of a
vehicle. Doing so will detract from the driver or operator’s control and operation of that
vehicle. In some states and provinces, operating such communications devices while in
control of a vehicle is an offense.
Limitation of Liability
The information in this manual is subject to change without notice and does not represent a
commitment on the part of Atel.
ATEL SPECIFICALLY DISCLAIMS LIABILITY FOR ANY AND ALL DIRECT, INDIRECT, SPECIAL, GENERAL,
INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR EXEMPLARY DAMAGES INCLUDING, BUT NOT
LIMITED TO, LOSS OF PROFITS OR REVENUE OR ANTICIPATED PROFITS OR REVENUE ARISING OUT
OF THE USE OR INABILITY TO USE ANYATEL PRODUCT, EVEN IF ATEL HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES OR THEY ARE FORESEEABLE OR FOR CLAIMS BY ANY THIRD
PARTY.

TABLE OF CONTENTS
1. Introduction ......................................................................................5
2. Product Overview ............................................................................5
3. Using your Router............................................................................6
3.1 Package Contents........................................................................................ 6
3.2 Router Interfaces.......................................................................................... 6
3.3 LED.............................................................................................................. 6
3.4 RJ-45 Switch ................................................................................................ 7
3.5 Other Features ............................................................................................. 7
3.6 Setting up your hardware.............................................................................. 8
4. Configuring your Router................................................................9
4.1 Login ............................................................................................................ 9
4.2 Dashboard.................................................................................................... 9
4.3 Status......................................................................................................... 10
4.3.1 WAN Status............................................................................................................ 10
4.3.2 WiFi LAN Status .................................................................................................... 11
4.3.34G Status................................................................................................................. 11
4.3.4Software Status ...................................................................................................... 12
4.3.5 Device List ............................................................................................................. 12
4.3.6UPnP Status............................................................................................................ 12
4.3.7VoIP......................................................................................................................... 12
4.4 Settings ...................................................................................................... 13
4.4.1 Basic Settings ........................................................................................................ 13
4.4.2Advanced Settings ................................................................................................. 21
4.4.3System Settings...................................................................................................... 32
4.5 4G ............................................................................................................... 37
4.5.1APN Settings........................................................................................................... 37
4.5.2 PIN Management................................................................................................... 38
5. VoIP Call Function......................................................................... 39
5.1 Activating Voice over IP.............................................................................. 40
5.2 Placing Voice Calls..................................................................................... 40
5.3 Receiving Voice Calls................................................................................. 40

6. Technical Specification ............................................................... 40
7. Certification.................................................................................... 41

1. Introduction
Thank you for purchasing the U270V router with Voice over IP (VoIP). This user manual will
help you setup, configure and outline best practices for maximizing your home network
performance with the router.
2. Product Overview
In minutes, you will be able to connect your computers to the Internet and you will be able to
make a phone call using VoIP. The following is a list of features that make your new U270V
router an ideal solution for your home or small office network. Implementation of these features
depends on the particular service provider and account features you have chosen.
Some features described in this manual may not be supported by your service provider or may
not be available with your network account. For details of the services and accounts available,
contact your service provider.
VoIP Calling
Your router (U270V) features a Voice over Internet Protocol (VoIP) function that allows you to
make voice calls over a VoIP network by simply connecting a wired, landline phone to your
network-connected router.
Plug-and-Play
Your router was factory-set for compatibility with a particular service provider. Thus, your
router operates on radio channels and enables services specific to your network service
provider. Once your router has been activated on your service provider’s network, you can
connect to the Internet. After your router is activated, connect it to your computer using the
Ethernet (RJ-45) cable or via Wi-Fi. You are now ready to use the Internet.
Web-Based Advanced User Interface
You can easily setup the router’s advanced functions through your web browser and without
having to install additional software onto your computer. There are no drivers to install and,
you can easily make changes and perform setup functions from any computer that is
connected to your U270V
•NAT IP Address Sharing
•Support for VPN Pass Through
•Built in Dynamic Host Configuration Protocol (DHCP)
•Integrated 802.11b/g/n Wireless Access Point
•MAC Address Filtering
Integrated 10/100 Mbit/s 3-Port Switch
The U270V has a built-in 3-port network switch to allow your wired computers to share printers,
data and MP3files, digital photos, and much more. The switch features automatic detection so
it will adjust to the speed of connected devices. The switch will transfer data between
computers and the Internet simultaneously without interrupting or consuming resources.
Integrated 802.11 b/g/n Wireless Access Point

The U270V supports Wi-Fi modes b/g and n. Your router as default is set to Wi-Fi b/g/n mixed
mode. To use another mode you can change this by logging into the web interface
(instructions can be found in section 4.4.1.2).
3. Using your Router
3.1 Package Contents
•U270V router
•2xAntennas
•RJ-45 Ethernet Networking Cable
•Power Supply and Car Charger (12V)
•Quick guide
3.2 Router Interfaces
The U270V is designed to be placed on a desktop or wall mounted. All the ports at the back of
the router are for better organization and utility. The LED indicators are easily visible on the top
of the router to provide you with information about network activity and status.
3.3 LED
Items
Description

Power
On(Yellow)
Only charger plug or Full charged
Blinking(Yellow)
Charger plug in and charge for battery
Blinking (Red)
Battery in and no charger plug in the
battery is in low status,
WIFI
On(Yellow)
WIFI has turned on
Blinking(Yellow)
Active data passed through Wi-Fi
OFF
WIFI has turned off
WPS
Blinking(Yellow)
WPS is activated.
WPS led is off after one minutes
Off
WPS is Off
Connect
On(Yellow)
LTE data connection is established
Blinking(Yellow)
LTE data is connecting
Off
No data connection
Signal
On(Yellow)
Band 31
On(Green)
Band 3
On(pink)
Band 7
On(Blue)
Band 20
3.4 RJ-45 Switch
The RJ-45 Switch has three Ethernet ports supporting up to 100 Mbit/s. Use any
of the 3 ports and an Ethernet cable to connect the router to your computer.
3.5 Other Features
（1）WPS Key
（2）Reset Key
（3）Phone line（RJ-11）
（4）Network connection to Computers (RJ-45/Ethernet)
（5）Power On/Off Switch
（6）Power Jack

3.6 Setting up your hardware
1. Make sure your router is not connected to any power source and that all the LEDs are OFF.
2. How to setup the antennas for maximized performance:
①Antennas are located on both sides of the router.
②Attach the antennas to the back of the router
③Hand tighten the antennas so that they are securely attached to the router
3. Locate the power supply that is included with your router. Plug the power supply’s small
connector into the power port on the router (6). Plug the power supply into an empty power
outlet.
4. Switch on the router (5). Look at the Power LED on top of the router and make sure the LED
is lit.
5. Wait for a few seconds while the router searches for network service. When the router finds

a suitable network the Connect LED is lit yellow. Refer to the Signal LED’s for acquired signal
strength and band.
6. Locate the Ethernet cable that is included with your router. Plug one end of the cable into
any Ethernet port on your router. Plug the other end of the cable into the networking port
on your computer.
Alternatively connect to the router through Wi-Fi
4. Configuring the router
The following section will guide you through the steps to properly configure
and personalize all settings in your router.
4.1 Login
Open a web browser and enter 192.168.0.1 in the address bar. A login window
will be displayed and you will be prompted to enter a username and a password
to login.
Use the following information to login:
Username: admin
Password: admin
When successfully logged in you will be able to navigate through the web
interface of the router. The web interface persists of four main section called
Dashboard, Status, Settings and 4G. Every section has their own submenus with
pages to display more specific information or options for that particular subject
or feature.
4.2 Dashboard
On the dashboard you will have a view over the most important information
the web interface can provide including radio parameters, WAN and LAN IP
addresses, Wi-Fi SSID and password, software versions and SIM identification
numbers and at the top you can find SIM status, connection status as well as a
hyperlink to Net1 support webpage and the logout button.

Figure 4-2-1Dashboard Page
4.3 Status
In this section you will find the status pages for Wi-Fi & LAN, 4G, Software
versions, Device List, UPnP and VoIP.
Figure 4-3-1 Status
4.3.1 WAN Status
On the WAN Status page you can see WAN IP Address, WAN Primary DNS and
WAN Secondary DNS information.

Figure4-3-1-1 WAN Status
4.3.2 WiFi & LAN Status
On this page you can see Wi-Fi & LAN information such as SSID, Channel,
Security mode, LAN IP and DHCP Server information.
Figure 4-3-2-1 WiFi LAN Status
4.3.3 4G Status
In the 4G Status menu you can see LTE information like Connection Status, SIM
Status, SIM numbers, Radio levels, MIMO status and frequency of the LTE
network you are connected to.
Figure 4-3-3-1 LTE Status

4.3.4 Software Status
On this page you can see installed IDU- and LTE software versions.
Figure 4-3-4-1 Software
4.3.5 Device List
In the device list you can see information regarding currently connected
devices like hostname, MAC address, IP address, expiring time and connection
type.
Figure 4-3-5-1 Device List
4.3.6 UPnP Status
On the UPnP Status page you can see rules for active UPnP connections.
Figure 4-3-6-1 UPnP
4.3.7 VoIP
The VoIP page displays Registration status and VoIP APN.
Figure 4-3-7-1 VoIP

4.4 Settings
The Settings section consists of three main menus named Basic Settings,
Advanced Settings and System Settings.
Figure4-4-1 Settings
4.4.1 Basic Settings
Figure4-4-1-1 Basic Settings
4.4.1.1 LAN Settings
On the LAN Settings page all settings for the internal LAN can be viewed and
changed.

Figure 4-4-1-1-1 LAN Settings
IP Address
Enter the IP address of your router (factory default: 192.168.0.1).
Subnet Mask
Subnet mask is an address code that determines the size of a network. The
subnet mask is by default set to 255.255.255.0 (/24) and cannot be changed.
DHCP
Enables or Disables the DHCP server. If you disable the DHCP server, you
must have another DHCP server within your network or you will have to
configure static IP addresses on all other devices.
Start IP Address
Specifies an IP address for the DHCP server to start with when assigning IP
addresses to hosts. The default starting address is 192.168.0.2. This address
cannot end with .0, .1 or .255 as these addresses are reserved for network,
gateway and broadcast addresses.
End IP Address
Specifies an ending IP address with when assigning IP addresses to hosts.
When all IP addresses are used no more devices can be connected. The
default end address is 192.168.0.254. This address cannot end with .0, .1
or .255 as these addresses are reserved for network, gateway and broadcast
addresses.
Lease Time

Specifies the amount of time in seconds a host will keep the assigned IP
address. When the lease time is up the host will be assigned a new IP address.
Static IP
IP/MAC binding function, the router will assign a static IP address to a host
with a MAC address matching with what is specified.
Note:
1. If you change IP address for the router you must use the new address to
access the web interface.
2. If you configure the router IP address to be in another subnet the DHCP will
automatically adapt but advanced settings like port forwarding needs to be
re-configured.
4.4.1.2 Wi-Fi Settings
On the Wi-Fi Settings page you can configure your Wi-Fi and WLAN to match
your personal preference like changing network name and password for security
reasons and change channel and bandwidth for performance optimization.
Figure 4-4-1-2-1 WiFi Settings
Wi-Fi Status
The Wi-Fi status is enabled in default, you can only connect to the device by
CAT-5 Ethernet cable if it is disabled.
Wi-Fi Standard
The router can operate in five different wireless modes: ”11b/g mixed mode”,
“11b only”, “11g only”, “11b only”, ”11b/g/n mixed mode”.

Figure 4-4-1-2-2 WiFi standard
Network Name (SSID)
To identify your wireless network, a network name called SSID (Service Set
Identifier) is used. You can set it to anything you like and you should make sure
that your SSID is unique if there are other wireless networks operating in your
area.
Channel
This option determines what frequency your WLAN will be operating in. It is
not necessary to change channel unless you are experiencing interference from
other nearby WLANs.
Figure 4-4-1-2-3 Frequency (Channel)
Broadcast SSID
By broadcasting the SSID local wireless devices will display the network name
in its list of available WLANs. If broadcasting is disabled the SSID is “invisible”
and must be entered manually by the user in the device.
AP Isolation
This function can isolate wireless stations on your network from each other.
Wireless devices will be able to communicate with the router but not with each
other.
Channel Bandwidth
20 MHz channel bandwidth support up to150 Mbit/s connections.
40 MHz channel bandwidth support up to 300 Mbit/s connections.
Security Mode: Disabled, OPENWEP, SHAREDWEP, WPA-PSK, WPA2-PSK,

WPA-PSK/WPA2-PSK
a) WEP Security Mode
Security Mode: OPEN, SHARED
Key Format: Hexadecimal and ASCII formats are provided. Hexadecimal
format stands for any combination of hexadecimal digits (0-9, a-f, A-F) in the
specified length. ASCII format stands for any combination of keyboard
characters in the specified length.
Default Key: Anyone of Key 1, Key 2, Key 3 and Key4 with 2 kinds of key
format.
Figure 4-4-1-2-4 OPENWEP
Figure 4-4-1-2-5 SHAREDWEP
b) WPA Security Mode
Security Mode: WPA-PSK, WPA2-PSK, WPA-PSK/WPA2-PSK
WPA Algorithms: TKIP, AES, TKIPAES
Keywords: 1~32 characters
Key Renewal Interval: 0~4194303s

Figure 4-4-1-2-6 Default WiFi Security
Figure 4-4-1-2-7 WPA-PSK
Figure 4-4-1-2-8 WPA-PSK/WPA2-PSK
4.4.1.3 Multiple SSID
On this page you can add multiple SSID’s to be used when connecting to your
WLAN. New SSID’s will be displayed in the rule table and can be edited or deleted.
Maximum rule count is 5.
Figure 4-4-1-3-1 Multiple SSID page

Figure 3-4-1-3-2 Add New Rule
Figure 4-4-1-3-3 Rule Table
4.4.1.4 WPS Settings
On this page, you can modify WPS settings. This feature can make your
wireless client within a few minutes automatically synchronized with the WLAN
and establish the connection via Wi-Fi.
WPS method
Push the button (default), Enter the PIN of client device, Use the PIN of the
device.
WPS Status
This displays the real-time information of WPS processing while wireless
client tries to communicate with each other over Wi-Fi.
PBC Mode
(1)Press the WPS button on your router.
(2)If your device is set to search for other WPS devices the router will
automatically send it’s WLAN information to your device over Wi-Fi and a
handshake will be performed between them and your device will connect to

your WLAN.
Enter the PIN of client device
(1) Wireless clients choose enrollee mode, the wireless client software will
randomly generate a PIN code. Then click on the tool interface "PIN" button.
(2) Input the PIN code which got from the wireless client and click the “Apply”
button on this “WPS” configuration page.
Use the PIN of the device
(1)Create the random PIN by clicking the “Generate” button, and share this
PIN to wireless client.
(2) In the wireless client choice registrar model, and the input device of the
PIN code.
Figure 4-4-1-4-1 WPS page
4.4.1.5 UPnP
On this page you can enable or disable UPnP.
Figure 4-4-1-5-1 UPnP
