NetComm NF20MESH User manual

CloudMesh Gateway
NF20MESH THE ULTIMATE WI-FI FIXER
All manuals and user guides at all-guides.com

22
GETTING
STARTED
PRE-CONFIGURED?
If you received your gateway from your service provider
and they have provided you with their own instructions,
refer to those to complete the setup. In some cases, the
gateway has been pre-congured for you and is ready to use.
Otherwise, you will need to complete the setup yourself.
All manuals and user guides at all-guides.com

3
BEFORE YOU BEGIN
Ensure that you have the following information
from your service provider:
- How your Internet service will physically connect to your gateway
- The Settings specic to your type of service.
There are two ways to connect your gateway to the Internet service:
Ethernet WAN
This is the most common access type in Australia and New Zealand
and covers xed line technologies such as nbn™ FTTP, HFC, FTTC
as well as UFB Fixed Wireless and Sky Muster™ satellite services.
This type of Internet service uses the red WAN port on the
back of the gateway to connect to the dedicated connection
box installed by your access network provider.
ADSL or VDSL
These access types are provided by nbn™ FTTB, FTTN
or ADSL/VDSL over a traditional telephone line.
This connection uses the grey DSL port on the back of the gateway.
SOURCE CODE - GNU General Public License
This product includes software code that is subject to the GNU General Public License
(“GPL”) or GNU Lesser General Public License (“LGPL”). This code is subject to the
copyrights of one or more authors and is distributed without any warranty.
A copy of this software can be obtained by contacting NetComm.
All manuals and user guides at all-guides.com

44
ETHERNET WAN
CONNECTIONS
All manuals and user guides at all-guides.com

5
Here’s how things connect for Ethernet WAN connections
5
nbn™ Connection box
/ UFB Optical Network
Terminal (ONT)
All manuals and user guides at all-guides.com

66
ADSL / VDSL
CONNECTIONS
All manuals and user guides at all-guides.com

77
Here’s how things connect for ADSL / VDSL connections
WALL SOCKET
All manuals and user guides at all-guides.com

88
CONNECTING
WITH WI-FI
1. Turn on the CloudMesh Gateway.
Wait a few minutes for it to start up.
2. Type the network name and password on the
Wi-Fi Security Card into your wireless device when
connecting or scan the QR code.
POWER BUTTON
All manuals and user guides at all-guides.com

99
SCAN
OR
TYPE
The username
and password are
case sensitive.
All manuals and user guides at all-guides.com

1010
CONFIGURING
YOUR GATEWAY
All manuals and user guides at all-guides.com

CONFIGURING YOUR GATEWAY
To complete the setup, you will need the following
information from your service provider:
- Internet service type (ADSL/VDSL/Ethernet WAN)
- Connection type (PPPoE/PPPoA/Dynamic IP/Static IP)
- Other specics depending on your connection
type including 802.1P priority, VLAN Tag, WAN
IP Address, Subnet Mask and DNS Servers
- VoIP settings from your service provider if
you intend to use a phone with your service.
When you have the necessary information, follow these steps:
1. Push the power button on the side of the
Wi-Fi 6 Gateway to turn it on.
Wait a few minutes for it to complete starting up.
2. Open a web browser and type 192.168.20.1
into the address bar, then press Enter.
3. At the login screen, type admin into the Username eld. In the
Password eld, type the unique password printed on the label on
the bottom of the gateway, then click on the Login > button
4. Follow the Basic Setup to complete the conguration.
11
All manuals and user guides at all-guides.com

1212
WI-FI / LIGHTS
TURNING ON & OFF
All manuals and user guides at all-guides.com

13
OR
13
TO TURN
LIGHTS ON / OFF
Press and hold for
more than 6 seconds
TO TURN
WI-FI ON / OFF
Press and hold for
more than 6 seconds
All manuals and user guides at all-guides.com

141414
TELEPHONE
CONNECTION
All manuals and user guides at all-guides.com

151515
All manuals and user guides at all-guides.com

16
APP
CLOUDMESH
All manuals and user guides at all-guides.com

17
DOWNLOAD THE CLOUDMESH APP
Finding the best place for your CloudMesh
Satellite is easy using the CloudMesh App.
- Satellite placement assistance
- WiFi Analytics
- WiFi Troubleshooting
- Setup does not require the App
Get it on the App Store or Google Play.
All manuals and user guides at all-guides.com

NOTES:
18
All manuals and user guides at all-guides.com

NOTES:
19
All manuals and user guides at all-guides.com

CloudMesh Gateway
NF20MESH THE ULTIMATE WI-FI FIXER
AU Casa Systems Inc.
18-20 Orion Road, Lane Cove
NSW 2066, Sydney
Australia |[phone]
ANZ HEAD OFFICE
SYDNEY
www.netcomm.com
US Casa Systems Inc.
100 Old River Road,
Andover, MA 01810
USA |[phone]
CORPORATE HEADQUARTERS
ANDOVER
www.casa-systems.com MPRT-00051-000 - NF20MESH - Rev 5
NetComm Wireless Limited is part of Casa Systems, Inc.
Casa Systems, the future of NetComm
