Askari Scout User manual

SCOUT
OPERATORS MANUAL
Askari Scout
Outdoor Dual PIR Motion Detector
Product Features
www.askaribeams.co.za
•Dual, xed beam PIR’s (Passive InfraRed)
•Audible walk-test mode
•Detection range adjustable from
5 meters to 15 meters
•Optional Double Hit mode setting
•Optional Trigger sensitivity setting
•Weather proof (10 year UV warranty)
• Unbeatable false alarm immunity
• Small and unobtrusive
430mm x 50mm x 950mm
ISO 9000-2000 Approved
Product Features
• Dual, xed beam PIR’s
• On installation, in walk-test mode, the unit will conrm RF communication with
the Askari Alarm I/O
• Detection range adjustable from 5 meters to 15 meters
• Optional Double Hit mode setting
• Optional Trigger sensitivity setting
• 4 x ‘C’ cell batteries with battery life expectancy of over 2 years
• Weather proof
Installation:
With the Askari Scout in walk-test mode, and programmed into a Alarm I/O, it will
trigger intruder (3 beeps) which will be followed by a low tone. The low tone is
transmitted by the Alarm I/O and indicates receipt of the intruder signal.
Choose a location for your Scout and ensure you are getting signal conrmation at that
location by triggering both beams and waiting for the low tone.
The Askari Scout has a single ball-joint mounting bracket with 3 possible bracket
mounting locations on the back of the spine.
Survey the area you wish the beams to cover. If the ground is relatively at, install the
bracket in the middle mounting location. If the unit is to be angled upward, choose a
higher mounting location, and if the unit is to angled downward, choose a lower
mounting location.

The Askari Scout is a Wireless, Dual PIR Motion Detector
with Bi-Directional Communications NOTE: A) The on-board walk-test buzzer will continue to be active until the Scout
has had no intruder triggers for 20 minutes
B) When the Scout is programmed into a Alarm I/O, and in walk-test
mode, intruder signal (3 beeps) will be followed by a low tone to conrm
RF communication. This allows the installer to position the Scout
anywhere on the property where RF communication is conrmed.
Programming into a Nano
To enter into programming mode on the Nano, press and hold button 1, now press
button 8 and release both buttons.
The LED’s for buttons 1, 4, 5, 6, 7 and 8 will light up.
Now press the right hand side button to activate programming mode - the Nano will
emit a high tone to conrm you are now in programming mode.
Press button 1 for detector programming – the Nano will beep once to conrm you
are in detector programming mode
• The Nano zone LED’s will switch on for any programmed zone.
• Select the appropriate zone on the Nano, the Zone LED will switch on and all
other zone LED’s will switch o
• Trigger the Scout Tamper code by waving your hand in front of it with
the battery cover o
• You will hear a beep and all lights will ash to signal the programming is
complete and the Nano will return to standby mode
• Repeat as above for all other Scouts, programming them to individual zones
Product Operation
Mounting height
0.8 to 1.2 m
Side view
Parallel
Top view
Transmitter
• Transmits intruder signal to the Askari Alarm I/O and the
Askari Nano
• Transmits Autotest and Tamper signals to the Askari Alarm I/O and Nano
• Has an open-eld transmitter/receiver range of 400 meters
Receiver
• Receives conrmation of transmissions from the Askari Alarm I/O and Nano
• Receives conguration update data from the Askari Nano
Programming
The Askari Scout can be programmed into the Askari Alarm I/O or the Askari Nano
Remove the battery cover from the Askari Scout using the Allen Key supplied
(in the Alarm I/O package)
Remove the battery-saver tag.
The Scout will start up, hit Tamper SW to ‘Walk-Test’ mode. The on-board buzzer will
activate and will beep once for a bottom eye trigger, twice for a top eye trigger and 3
times for both
The Scout will settle after 1 minute
Programming into an Alarm I/O
• To enter programming mode on the Alarm I/O, press and release the Program
switch on the Alarm I/O
• The Program/Delete LED will switch on and the LED’s of all programmed zones
will switch on
•Wait a few seconds, the Program/Delete LED will switch o and then on again,
and all the programmed zone LED’s will switch o
• You are now in Programming mode
• Press and release the appropriate zone switch on the Alarm I/O, the zone
LED will switch on
• Trigger the Scout Tamper code by pushing the Tamper switch
• The Alarm I/O will accept the programming, return to standby mode, and
all programmed zone LED’s will be on
• Replace the battery cover
• Repeat as above for all other Scouts, programming them to individual zones
15 m
