Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfill your needs for many years to
come. Scandinavian design combines clean lines, everyday functionality, and
high quality. These are key characteristics of all our products and the reason
they are greatly appreciated throughout the world.
To get the most out of your new dishwasher, we recommend that you read the
operating instructions before using it. The operating instructions also include
information on how you can help protect the environment.
Do you need this Use&Care Guide in spanish? Log onto
www.askona.com/customer-care to download.
¿Necesita esta Instrucciones de uso y cuidado en español? Entre en
www.askona.com/customer-care y descárguesela.
Operating Instructions
Dishwasher
ASKO D5434XXL W/B/S
Contents
2Front panel
3Important safety instructions
4Before washing for the first time
5Loading the dishwasher
7Using the dishwasher
10Settings
12Care and maintenance instructions
14Troubleshooting
17Technical information
18Service
19Program chart
Front panel
The panel is fitted with touch buttons with audible feedback (see the chapter Settings).
PROG
START
STOP
2
1
89
3
45
6
10
11
12
13
14
7
1 Program selector
2 Heavy wash
3 Sanitation wash
4 Normal wash
5 Eco wash
6 Quick wash
7 Rinse & Hold
8 High temperature
9 Long dry
10 Start/Stop
11 Display
12 Delayed start
13 Child lock (button lock)
14 Rinse aid indicator
NOTE!
• Two minutes after the last button press, the display enters left-on mode to save energy. The display brightness is reduced. Press
the Program selector once, or one of the option buttons, to reactivate the display.
Customer Care Center 1-800-898-1879
www.askona.com
2
Important safety
instructions
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARNING!
This manual does not cover all possible conditions and
situations that may occur. Common sense and caution should
always be used when installing, operating, and maintaining
any appliance.
• Read all instructions before using the dishwasher.
• Dishwashers must be electrically grounded. Read the
Installation Instructions for details.
• Use the dishwasher only for its intended purpose.
• Do not run the dishwasher while you are out of the home.
• Use only automatic dishwasher detergents and rinse agents.
• To reduce the risk of injury, keep detergents and rinse aids
out of the reach of children.
• Do not load sharp items near the door; you could damage
the door seal.
• Place sharp knives in the cutlery basket with the sharp ends
down to avoid the risk of cut-type injuries.
• Do not wash plastic items unless they are marked
“dishwasher safe” or the equivalent. For items not marked,
check the manufacturer’s recommendations. Items not
dishwasher safe could become deformed or melt and create
a potential fire hazard.
• Do not operate the dishwasher unless all enclosure panels
are properly in place (i.e., guard plate, access panel, toe
kick, etc.).
• Do not tamper with controls by removing or changing.
• Do not abuse, sit on, or stand on the dishwasher door or
baskets.
• To reduce the risk of injury, do not allow children to play in
or on a dishwasher.
• Under certain conditions, hydrogen gas may be produced
in a hot water system that has not been used for two weeks
or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water
system has not been used for two weeks, before using the
dishwasher turn on all hot water faucets and let the water
flow from each for several minutes. This will release any
accumulated hydrogen gas. As the gas is flammable, do
not smoke or use an open flame during this time.
• When removing an old dishwasher from service or
discarding it, remove the door to the washing compartment.
• Do not store or use combustible materials, gasoline, or other
flammable vapors and liquids in the vicinity of this or any
other appliance.
• Disconnect electrical power to dishwasher before servicing.
• Repairs should be done by a qualified technician.
• Read the grounding instructions in the installation
instructions.
Child safety
TIP!
Dishwasher detergents and rinse aids are corrosive, so always
keep them out of reach of children.
• Should a child swallow dishwasher detergent or rinse aid,
give plenty to drink immediately, i.e., one or two glasses of
milk or water. Do not try to induce vomiting. Seek medical
advice immediately: Call the National Capital Poison Center
at 1-800-222-1222.
• Always close the door and start the dishwasher as soon as
you put in the detergent.
• Always keep small children away from the machine when it is
open. There may be some detergent residue left inside the
machine.
• If dishwasher detergent gets in someone’s eyes, rinse them
with plenty of water for at least 15 minutes.
• Do not allow children to use or play in or on the dishwasher.
• Load sharp objects with the pointed end facing the back of
the dishwasher. Sharp items loaded in the cutlery basket
should be loaded with pointed ends down.
Activate child lock (Kid Safe™)
You can activate the child lock (button lock) to prevent children
from starting the dishwasher (see the section Settings).
Winter storage/Transport
• Store the dishwasher where the temperature remains above
freezing.
• Avoid long transport distances in very cold weather.
• Transport the dishwasher upright or laying on its back.
Overflow guard function
The overflow protection starts pumping out the machine and turns
off the water supply if the water level in the dishwasher exceeds
the normal level. If the overflow protection is triggered, turn off
the water supply and call the Customer Care Center.
Care and maintenance instructions
When cleaning the edge around the door, use only a slightly
damp cloth. Do not spray water around the edge! Moisture can
make its way into the lock, which contains electrical components.
Packing material
Please sort waste materials in accordance with local guidelines.
Disposal
• When the machine has reached the end of its service life and
is to be disposed of, it should immediately be made unusable.
Pull out the power cable and cut it as short as possible.
• The dishwasher is manufactured and labeled for recycling.
• Contact your municipality for information about where and
how your dishwasher can be recycled correctly.
Customer Care Center 1-800-898-1879
www.askona.com 3
Before washing for the
first time
Water supply
The machine can be connected to either a hot (max. 160 °F, 70
°C) or cold water supply. We recommend a cold water supply.
The water pressure should be 4.2-140 psi. See also the section
Economic dishwashing in the chapter Loading the dishwasher.
Program key
Some dishwashers include program keys in different languages.
Attach the program key in the appropriate language to the top
of the door.
Checking water hardness
Contact the local water utility to check the water hardness in your
area. This is important to determine how much detergent and
rinse aid to use.
Top up with rinse aid
Drying is faster if you use rinse aid.
1 Open the rinse aid compartment lid.
2 Carefully top up with rinse aid. Only add rinse aid to the level
marked max.
3 Wipe up any spilled rinse aid around the compartment.
4 Close the lid firmly.
Selecting the rinse aid dosage
Rinse aid dispensing can be set from (Off) to (High
dose). (Factory settings: )
Increase the rinse aid dosage:
• If the dishes have water marks.
Reduce the rinse aid dosage:
• If the dishes have a sticky white/blue film.
• If the dishes are streaked.
• Heavy foaming. If you have very soft water, the rinse aid can
be diluted 50:50 with water.
Setting the rinse aid dosage
The section Settings describes how to set the rinse aid dosage.
Refill rinse aid indicator
When the rinse aid needs topping up, the above symbol lights
on the display.
NOTE!
After topping up, it may take a while before the symbol goes
out.
Customer Care Center 1-800-898-1879
www.askona.com
4
Loading the dishwasher
Economic dishwashing
Run programs only with a full load
Wait until the dishwasher is fully loaded before running a program,
this way you save energy. Use the Rinse & Hold program to rinse
the dishes if there are any unpleasant odors while you wait for
the dishwasher to become fully loaded.
Run programs at a lower temperature
If the dishes are only lightly soiled, you can select a lower
temperature with certain programs. See also the section Selecting
Options in the chapter Using the dishwasher.
Select a program with Short dry
To save energy, use Short dry. The drying result will be better if,
once the program is finished, you leave the door slightly open.
Do not rinse under running water
Simply scrape off large food particles before loading the
dishwasher.
Choose a green detergent
Read the environmental declaration on the packaging!
Connect to cold water...
If you use oil or electricity to heat your home.
Connect to hot water (max. 160 °F (70 °C))...
If you use district heating, solar power, or geothermal power to
heat your home. Choosing a hot water connection cuts program
times and reduces the dishwasher's electricity consumption.
Fragile dishes
Some cookware is not dishwasher safe. This can be for several
reasons. Some materials cannot withstand high temperatures,
others can be damaged by dishwasher detergent.
Fragile decoration
Porcelain with decoration on top of the glazing (the items feel
rough) should not be washed in a dishwasher.
Crystal/Glass
Position items so that they do not touch each other during the
wash. Use the lowest possible wash temperature and the shortest
possible program. Select Short dry. Antique and very fragile items
should not be washed in a dishwasher.
Glass washed in a dishwasher at high temperatures can gradually
develop a gray film that cannot be removed. Wash fragile glasses
at a low temperature and with a small amount of detergent.
Silver
Silver and stainless steel items should not come into contact, as
the silver can become discolored.
Cutlery with glued handles
Some types of glue are not dishwasher safe. In such cases, the
handles may loosen.
Wood
Wooden items should only be washed in a dishwasher if marked
dishwasher safe.
Aluminum
Aluminum can lose its shine if washed in a dishwasher. However,
good quality aluminum pans can be washed in a dishwasher,
even if some of the shine will be lost.
Plastic items
Avoid washing plastic items that cannot withstand high
temperatures.
Typical load for 10 place settings
Upper basket with 10 place settings AHAM DW-1
Lower basket with 10 place settings AHAM DW-1
Upper basket
Place glasses, cups, bowls, side plates, and saucers in the upper
basket. Wine glasses are placed on the wine glass shelf and
knives are placed in the knife stand on the right (if equipped).
NOTE!
All dirty surfaces should face in and down!
Customer Care Center 1-800-898-1879
www.askona.com 5
Lower basket
Place plates, side plates, serving dishes, pots, and cutlery (in
the cutlery basket) in the lower basket.
Place pots and pans in the rear left of the lower basket to best
utilize dishwashing performance from the rear spray nozzle
(Power Zone™ Pot & Pans), which is intended for these types of
dishes.
Fold-down plate supports
Lower the fold-down plate supports when washing pots.
1
2
Forward mount for plate support
Used for plates with a diameter greater than 9 3/4" (25 cm).
1
2
3
4
Cutlery basket
Place cutlery with the handles facing down, except for knives,
and spread them out as much as possible. Ensure that spoons
do not stack inside each other.
The cutlery basket is best placed in the middle at the front of the
lower basket to best utilize dishwashing performance from the
unique spray nozzle (Power Zone™ Cutlery), which is intended
for the cutlery basket.
NOTE!
Do not place cutlery made of different materials, such as silver
and stainless steel, in the same place (risk of discoloration).
WARNING!
Knives and other pointed items must be placed with the points
down in the cutlery basket or horizontally in other baskets.
Fold-down section for small items
The cutlery basket has a fold-down section in the middle for small
items, or small shafts, such as electric whisk attachments.
ac
b
Customer Care Center 1-800-898-1879
www.askona.com
6
Using the dishwasher
Add detergent
1 Prewash detergent compartment
2 Main wash detergent compartment
We recommend that you use only unscented, granular automatic
dishwashing detergent. Using the wrong detergent could cause
flooding and/or damage your dishwasher. Do not use detergent
that has been wet and is clumped. Also, check the expiration
date on the container.
The amount of detergent needed can vary due to differences in
water hardness. To determine the water hardness in your area,
contact your local water utility or area water softening company.
The harder the water, the more detergent you may need. Refer
to the chart below for the recommended detergent amounts
based on water hardness. Remember, you should adjust the
amount of detergent you use by small amounts until you find the
correct amount. Twelve grains and higher is extremely hard water
and detergent alone may not be enough. You may need to use
a water softener to maximize the performance of your dishwasher.
Also, in areas with hard water (9+) you may need to wash at lower
temperatures to prevent hard water deposits from forming in tank
and wash system. In hard water areas, both the dishes and the
machine can develop a white or gray film after a while. If this
happens, run the Normal wash program with high temperature
and two tablespoons of citric acid or commercially available
dishwasher cleaner in the detergent compartment (with no dishes
in the machine).
NOTE!
We recommend that you do not add prewash detergent for the
program Quick wash.
NOTE!
If you use a dishwashing detergent with a rinse aid additive,
you should not fill the rinse aid dispenser. This could cause a
film on your dishes.
Recommended detergent amounts based on water hardness
Detergent amountsWater hardness
Prewash 1 teaspoon
Main wash 1 to 1-1/2 tablespoons
Soft
(0-3 grains per gallon)
Prewash 1 teaspoon
Main wash 1 to 2 tablespoons
Medium
(4-8 grains per gallon)
Prewash 1 teaspoon
Main wash 2 to 3 tablespoons
Hard
(9+ grains*)
*12 grains and higher is extremely hard water.
WARNING!
Children must be supervised – dishwasher detergent is
corrosive!
NOTE!
Use only dishwasher detergent! Liquid hand-washing detergent
must not be used as the foam that forms prevents the
dishwasher from operating effectively.
Dishwasher tablets
Halve the tablet if it is difficult to close the dispenser lid. There is
a risk that the detergent will not be released properly if the lid is
tight and cannot open correctly.
NOTE!
Dishwasher tablets are not recommended for short programs
(less than 75 minutes). Use powder or liquid dishwasher
detergent instead.
3-in-1/All-in-one detergent
Read through the directions for these products carefully. If
anything is unclear, contact the detergent manufacturer.
Program selection
Press the Program selector one or more times until the desired
program symbol lights.
Heavy wash
Program for very dirty dishes, such as pans, casserole dishes,
and oven dishes. If these dishes do not completely fill the
dishwasher, you can add plates and other dishes that can
withstand a Heavy wash to fill out the load.
Sanitation wash
A program with the ability to help with most household germs
and extra dirty dishware. This program will have a high final rinse
temperature for a good drying result and germ treatment.
NOTE! Do not put in dishware that cannot stand high wash or
rinse temperatures.
Customer Care Center 1-800-898-1879
www.askona.com 7
Normal wash
Use to wash normally soiled dishes, such as plates, serving
dishes, cups, glasses, and so on.
Eco wash
Use when you want to save energy. For normally soiled dishes.
Quick wash
This program is used for glasses and porcelain that is lightly
soiled, such as coffee cups.
Rinse & Hold
Use to rinse dishes while you wait for the dishwasher to become
fully loaded.
Selecting Options
To select an option, press one of the option buttons. The field
next to the button lights when the option is activated. The available
options depend on the selected program. Once you have started
the program, the options you selected are saved for the next time
you use the same program. An exception is the Delayed start
option.
High temperature
Activate this option for improved dishwashing results. The
machine then uses a higher temperature for the main wash.
If you want to use the lower temperature, press until the field next
to the button turns off.
You can vary the temperature as shown below:
150 °F (65 °C) / 160 °F (70 °C)Sanitation wash:
130 °F (55 °C) / 150 °F (65 °C)Normal wash:
140 °F (60 °C) / 150 °F (65 °C)Heavy wash:
85 °F (30 °C) / 140 °F (60 °C)Quick wash:
120 °F (50 °C) / 140 °F (60 °C)Eco wash:
Long dry
A higher temperature in the final rinse and a longer drying phase
improves the drying result if you activate the Long dry option.
This causes a slight increase in energy consumption.
If you want a program with Short dry, press so that the field next
to the button turns off.
Delayed start
When you select Delayed start, the dishwasher will start 1-24
hours after you press the Start/Stop button.
1 Press the button once to activate Delayed start. Press the
button several times – or hold it in – to set the desired number
of hours.
2 Press Start/Stop and the dishwasher counts down 1 hour at
a time and starts after the selected delay.
Press and hold Start/Stop for five seconds if you want to cancel
the Delayed start option.
NOTE!
Remember to press the Start/Stop button to start the program.
Start the dishwasher
Press and hold Start/Stop until the display flashes three times
with the remaining time. This indicates that the program has
started. Close the door properly, otherwise the dishwasher will
not start. The display indicates if the door is open.
NOTE!
If the machine does not start within 2 minutes of the last button
press, the display returns to showing the last program run.
Time remaining
Once you have selected a program and options, the display
indicates how long the program took the last time it was used.
Once you have started the dishwasher, the display indicates how
much program time remains. The remaining time is updated after
the water for the final rinse has been heated.
This may differ somewhat from time to time depending on the
temperature of the water supply, the amount of dishes, the
ambient temperature, and other factors.
The time counts down while the program is running and the
remainder of the program is displayed. The remaining time is
displayed, e.g., 1:15, meaning that 1 minute 15 seconds of the
program remains.
NOTE!
During the first run of each program, the remaining time
displayed can be slightly misleading, as the dishwasher is
estimating the time. When you run the program a second time,
the dishwasher will calculate the remaining time based on the
previous duration of the program.
Stopping or changing a program
If you want to change programs after starting the dishwasher,
open the door then press and hold Start/Stop for five seconds.
Add more detergent if the lid of the detergent dispenser has
opened. Then choose a new program, press Start/Stop, and close
the door.
Do you want to add more dishes?
Open the door. The dishwasher stops automatically. Add the
dishes, close the door, and the dishwasher resumes the program.
Customer Care Center 1-800-898-1879
www.askona.com
8
If the dishwasher is turned off using
the main power switch or due to a
power failure
If the program was not finished, the interrupted program resumes
when power is restored.
NOTE!
During drying, the program is interrupted if the power is cut or
the door is open for more than 2 minutes.
Once the program has finished
Once the program has finished, "End" appears on the display.
A buzzer also sounds at the end of the program. See the section
Settings, which describes how to change this function.
Once the dishwasher has finished, it uses only standby power.
Turn off the dishwasher using the main power switch if you want
to completely cut the power. Turn off the water supply valve after
each use.
Customer Care Center 1-800-898-1879
www.askona.com 9
Settings
Do as follows to open the settings menu:
Turn off the dishwasher using the main power switch. Wait about five seconds.1.
Then press the main power switch again. Wait until the numbers appear in the right-hand display before continuing to
the next step.
2.
Within five seconds, press and hold the Program selector (wait for the audible signal confirming the button press) and
then immediately press the Long dry button without releasing the Program selector.
3.
+
Keep the buttons pressed until the symbols for the Heavy wash and Rinse & Hold programs start to flash.4.
TIP!
Be sure to press right on the symbols, so as not to inadvertently activate any other button. Try again if you fail to open
the settings menu the first time.
PROG
START
STOP
3UHVV WR VDYH WKH VHWWLQJ YDOXH DQG FRQWLQXH
WR WKH QH[W VHWWLQJ
&XUUHQW VHWWLQJ
&XUUHQW VHWWLQJ YDOXH
3UHVV WR EURZVH EHWZHHQ VHWWLQJ YDOXHV
'LVSOD\
You can now adjust the following settings:
DescriptionSettingsOptionsButton press
You can activate the child lock (button lock) option
to prevent children from starting the dishwasher.
Child lock
(Kid Safe™)
(Off)
(On) Press the High temperature and Long dry buttons
simultaneously to temporarily deactivate the button
lock when you want to start the dishwasher. The
button lock is automatically reactivated after 2 min-
utes.
Press Start/Stop to save the setting value and continue to the next setting.
If you do not want to change any other settings, keep pressing Start/Stop to step through the entire settings menu.
The dishwasher uses a buzzer to indicate when a
program is finished or when a fault has occurred.
Buzzer volume
(Off)
(Low)
(High)
Press Start/Stop to save the setting value and continue to the next setting.
Customer Care Center 1-800-898-1879
www.askona.com
10
