Asko HG8953BGBx User manual

INSTRUCTIONS FOR USE
Gas hob
EN
HG1935AB / HG9ABE1A
HG8953BGBx / HG9ABE1A

3Pictograms used ........................................
4Safety ..........................................................
9Description .................................................
9Control knob ................................................
10Use ..............................................................
10Pans .............................................................
11Wok ring and small pan grid ........................
11Pan support .................................................
11Burner ..........................................................
12Wok burner position .....................................
13Operation ....................................................
13Ignition and adjustment ...............................
14Maintenance ...............................................
14Daily cleaning ..............................................
15Faults ..........................................................
15General ........................................................
17Technical data ............................................
17
Information according to regulation (EU)
66/2014 ........................................................
18Installation ..................................................
18Safety ..........................................................
20Preparations for installation .........................
21Built-in ..........................................................
22Gas connection ............................................
23Connecting & testing ...................................
24Environmental aspects ..............................
24Disposal of the appliance and packaging ....
Contents

The following symbols are used throughout the manual, and they have the following meanings:
INFORMATION!
Information, advice, tip, or recommendation
WARNING!
Warning –general danger
GAS CONNECTION!
Warning –gas connection
ELECTRIC SHOCK!
Warning –danger of electric shock
HOT SURFACE!
Warning –danger of hot surface
DANGER OF FIRE!
Warning –danger of fire
It is important that you carefully read the instructions.
3
Pictograms used

WARNING!
READ CAREFULLY AND KEEP IT FOR FUTURE REFERENCE!
General
The manufacturer cannot be held liable for any damage resulting
from failure to follow the safety instructions and warnings.
Damage caused by incorrect connection, incorrect fitting, or incorrect
use is not covered by the warranty.
WARNING!
This appliance and the accessible parts will become hot during
use. Do not touch hot parts. Keep children younger than 8 away
from the appliance unless they are under continuous supervision.
DANGER OF FIRE!
WARNING: Danger of fire: do not store items on the cooking
surfaces.
NOTE!
CAUTION! The cooking process has to be supervised. A short
term cooking process has to be supervised continuously.
DANGER OF FIRE!
WARNING: Cooking with fat or oil on a hob without supervision
can be dangerous and can lead to a fire.
•NEVER try to extinguish a fire with water. Instead, switch the
appliance off and then cover the flames with, for example, a lid
or a fire blanket.
•Never flambé under a cooker hood. The high flames can cause
a fire, even if the cooker hood is switched off.
4
Safety

WARNING!
Use only hob guards designed by the manufacturer of the cooking
appliance or indicated by the appliance manufacturer in the
instructions for use as suitable or hob guards incorporated in the
appliance. The use of inappropriate guards can cause accidents.
•If a drawer underneath the appliance is permitted (see the
installation instructions), without an intermediate bottom, this
should not be used to store highly flammable objects/materials.
Ensure that there is adequate clearance of a few centimetres
between the bottom of the hob and the contents of any drawers.
•The hob is only to be used for the preparation of food.
•The appliance is not designed for heating rooms.
•Do not warm closed tins on the hob. There will be a build-up of
pressure that will cause tins to explode. You might get injured or
scalded.
•Never cover the appliance with a cloth or something similar. If the
appliance is still hot or is switched on, there is a risk of fire.
•Do not use the appliance as a worktop. The appliance may
accidentally be switched on or still be hot, which means objects
could melt, become hot or catch fire.
•Do not use the appliance in temperatures below 5 °C.
•The appliance should not be placed or used outdoors.
•When you use the hob for the first time, you will notice a “new
smell”. Don’t worry, this is normal. If the kitchen is well ventilated,
the smell will soon disappear.
•The appliance is not intended to be operated by means of an
external timer or separate remote control system.
•Never open the casing of the appliance.
•Never use a steam cleaner for cleaning the appliance.
Only clean the appliance when switched off. The steam of a steam
cleaner could reach the conducting parts and cause an electrical
short.
5
Safety

•The ceramic top is extremely strong but not unbreakable.
For example, a spice jar or sharp utensil falling on it could cause
it to break.
WARNING!
WARNING: If the surface is cracked, switch off the appliance to
avoid the possibility of electric shock.
Ceramic glass plate broke
•Shut immediately off all burners and any electrical heating element
and isolate the appliance from the power supply.
•Do not touch the appliance surface.
•Do not use the appliance.
WARNING!
Households with children and people with special needs
This appliance can be used by children aged 8 years and over,
as well as by people with reduced physical, sensory or mental
capabilities or lack of experience and knowledge, provided they
are supervised and instructed in the safe use of the appliance and
understand the hazards involved.
•Do not allow children to play with the appliance.
•Do not allow children to clean or maintain the appliance unless
supervised.
•Do not keep objects that children might find interesting in
cupboards above or behind the appliance.
•The cooking zones/burners heat up during use and stay hot for
a while afterwards. Keep young children away from the hob during
and immediately after cooking.
6
Safety

WARNING!
Prolonged intensive use of the appliance may call for additional
ventilation, for example opening of a window, or more effective
ventilation, for example increasing the level of mechanical
ventilation where present.
CAUTION: The use of a gas cooking appliance results in the
production of heat, moisture and products of combustion in the room
in which it is installed. Ensure that the kitchen is well ventilated
especially when the appliance is in use: keep natural ventilation
holes open or install a mechanical ventilation device (mechanical
extractor hood).
•The burner components are hot during and immediately after use.
Do not touch them, and avoid contact with non-heat resistant
materials.
•Never immerse hot burner caps and pan supports in cold water.
Rapid cooling can damage the enamel.
•The distance between the pan and a knob or non-heat resistant
wall should always be greater than one centimetre. In the case
of smaller distances, the high temperature may cause the knobs
or wall to discolour and/or deform.
•Always use the pan supports and suitable cookware.
•Always place the pan on the pan support. Placing the pan directly
on the burner cap can result in dangerous situations.
•Aluminium trays or foil are not suitable as cooking utensils.
They can burn into the burner caps and pan supports.
•The hob can only function effectively if the burner components
have been assembled using the guide ridges. Ensure that the
pan supports lie properly against each other and flat on the drip
tray. Only then can the pans be positioned stably.
•Keep oven gloves or oven cloths away from the flame.
•Do not use griddle plates or baking plates.
7
Safety

•Clean the burner parts regularly for the safe and correct operation
of the burners.
•Missing rubber feet from the pan supports can cause scratches
on the drip tray or poor combustion of the burner. If the rubber
feet are missing, please contact our service department.
8
Safety

Control knob
1. Rapid burner
2. Semi-rapid burner
3. Simmer burner
4. Wok burner
5. Pan support
6. Glass top
7. Wok selector ring
8. Control knob
9. Zone indication
10. 0 position
11. High setting
12. Low setting
13. Wok setting (wok burner)
14. Roasting setting (wok burner)
9
Description

Pans
Always ensure that the flames remain under the pan. A lot of energy is lost when flames burn around
the outside of the pan. The handles could also become too hot.
wrong
right
Suitable cookware
Only use cookware with a suitable diameter. The cookware must not protrude over the edge of the
hob. Never use small cookware on large burners. The flames must not touch the sides of the cookware.
Refer to the table.
Maximum pan bottom
diameter
Minimum pan bottom diameterBurner
30 cm18 cmWok burner
26 cm16 cmRapid burner
22 cm14 cmSemi-rapid burner
22 cm12 cmSimmer burner
Min. 1 cm
WARNING!
The distance between the pan and a knob or non-heat resistant wall
should always be greater than one centimetre. In the case of smaller
distances, the high temperature may cause the knobs or wall to
discolour and/or deform.
10
Use

Wok ring and small pan grid
Small pan gridWok ring
The wok ring for use with the wok burner supplied or obtainable as an accessory provides extra
stability for woks with a round base.
The small pan grid-supplied or obtainable as an accessory makes it possible to use very small pans.
CAUTION!
Do not use the small pan grid on the wok burner.
Only use the wok ring on the wok stand in combination with a (round-based) wok. The wok ring
may discolour if used on the searing setting.
Pan support
Place the pan support vertically, without sliding it over the glass top. Use the positioning notches to
position the pan support on the glass top.
Burner
Use the leads (1) to put together the burner parts.
11
Use

Wok burner position
Place the wok burner in the correct way.
Placing the wok burner parts incorrectly can
result in a poorly functioning burner.
position
distributor position rings
side view
1. Place the burner distributor (2) in the
burner housing (1).
2. Use the positioning notches to place the
inner ring (3) on the burner distributor (2).
3. Use the positioning notches to place the
outer ring (4) on the burner distributor (2).
12
Use

Ignition and adjustment
The burner is fully adjustable between high and low settings.
1. Press the control knob and turn it anticlockwise. The burner will ignite.
2. Keep the control knob fully depressed for at least 3 seconds between high and low settings.
The thermocouple safety pilot has been activated.
3. If desired, turn the wok selector ring to the roasting setting (5). The inner ring (wok setting) will
switch off and the outer ring (roasting setting) will switch on.
4. The wok burner will switch automatically to the wok setting if the control knob of the wok burner
is set to 0.
NOTE!
It is possible to switch between wok setting and roasting setting and back during cooking.
If the control knob is in the off setting (0-setting) the selector ring cannot be changed to the
roasting setting. Always turn this knob back completely to 0.
13
Operation

Daily cleaning
Regular maintenance after use prevents spilt food from setting too long and creating stubborn stains.
Use a mild detergent for this.
First clean the control knobs, burners and pan support and only then the drip tray or glass cover.
This prevents the drip tray or glass cover to becoming dirty again after cleaning.
NOTE!
•Burner parts should not be cleaned in the dishwasher.
•Dishwasher detergents can corrode burner parts!
Stubborn stains
Persistent stains can best be removed with a fluid detergent or a plastic scouring sponge. Never
use scouring powder, scouring pads, sharp objects or aggressive cleaning products.
Persistent stains on the glass cover
Clean the glass cover with a special cleaning product for ceramic hobs. Water stains or limescale
are best cleaned using cleaning vinegar.
NOTE!
•Never use abrasives. These leave scratches in which dirt and limescale can accumulate.
•Never use anything sharp such as steel wool or scourers.
Persistent stains on the stainless steel (drip trays)
Persistent stains on stainless steel are best removed with a special stainless steel cleaning product.
Always wipe with the structure of the steel to prevent scraping away the protective layer (damage
caused in this way does not fall under the guarantee!) The surface of stainless steel drip trays can
discolour slightly over time.
Brass wok burner parts
Some wok burner parts are made of brass. It is not unusual to see a change in the colour of the
brass as a result of the high temperatures involved in wok use.
TIP!
Consult the website for additional maintenance and cleaning instructions!
14
Maintenance

General
NOTE!
If you notice a crack in the glass top (however small), switch off the hob immediately, unplug the
hob, and close off the gas supply.
Then contact the Service Department.
Troubleshooting table
If your hob does not work properly, it does not always mean that it is defective. Make sure to check
the points mentioned below in the table, or visit our website for more information.
SolutionPossible causeSymptom
Turn off the main gas supply valve.
Contact your installer.
The appliance connection is
leaking.
There is a smell of gas near
the appliance.
Contact your installer.The electrical connection is
not correct.
The burner does not ignite.
Replace the fuse or switch on the fuse
again in the fuse box.
Fuse defective/fuse switched
off in fuse cupboard.
Clean/dry the spark plug.Spark plug (1) dirty/damp.
Use the centring notches to put the
burner parts together.
Burner parts not placed
correctly.
Clean/dry the burner parts. Make sure
that the outflow holes are open.
Burner parts dirty/damp.
Open the main gas valve.Main gas supply valve
closed.
Consult you gas supplier.Fault in gas mains.
Connect a new gas bottle or have the
tank refilled.
Gas bottle or tank is empty.
Check whether the gas used is suitable
for the appliance. Contact your installer
if it is not correct.
The wrong type of gas used.
Use the centring notches to put the
burner parts together.
Burner parts not placed
correctly.
The burner does not burn
evenly.
Clean/dry the burner parts. Make sure
that the outflow holes are open.
Burner parts dirty/damp.
Check whether the gas used is suitable
for the appliance. Contact your installer
if it is not correct.
The wrong type of gas used.
15
Faults

SolutionPossible causeSymptom
Keep the control knob fully depressed
for at least 3 seconds between high
and low settings. This can take longer
the first time because of the gas
supply.
The control knob has not
been depressed long or
deep enough (at least 3
seconds).
Burner extinguishes after
igniting.
Clean/dry the thermocouple.Thermocouple (2) is dirty.
Close the gas main switch and pull the
plug out of the socket. Contact your
installer.
Ceramic glass plate broke
Please note! Do not throw a broken
ceramic glass plate in the glass
recycling bin but take this to the
Municipality's waste recycling centre.
Table continued from last page
16
Faults

Information according to regulation (EU) 66/2014
Measurements according EN60350-2 / EN 30-2-1
HG1935AB
HG8953BGBx
Model identification
Gas hob
Type of hob
5
Number of gas burners
61.5
Rapid burnerEnergy efficiency per gas burner (EEgas
burner) in %
62.1
Semi-rapid burner
59.1
Wok burner
61.2
Energy efficiency for the gas hob (EEgas hob) in %
G30 / G31 28-30 /
37 mbar
G30 / G31 50
mbar
G20 20 mbarG25.3 25 mbar
G25 25 mbar
Burner
kW / g/hkW / g/hkWkW
0.80 / 581.00 / 721.001.00Simmer burner
1.50 / 1082.00 / 1442.002.00Semi-rapid burner
2.00 / 1442.70 / 1943.003.00Rapid burner
2.40 / 1373.15 / 2273.003.00Wok setting (wok
burner)
4.50 / 3245.90 / 4256.006.00Roasting setting
(wok burner)
17
Technical data

Safety
•This appliance should only be connected by a registered installer.
•Prior to installation, ensure that the local distribution conditions
(voltage, frequency, nature of the gas and gas pressure) and the
adjustment of the appliance are compatible.
•The voltage, frequency, power, type of gas and the country for
which the appliance has been designed are shown on the
appliance rating plate.
•The walls and the worktop surrounding the appliance must be
heat resistant up to at least 105 °C.
•The worktop into which the hob is fitted should be flat.
Electrical connection
•This appliance must be earthed.
•The electrical connection must comply with national and local
regulations.
•The wall plug socket and plug should always be accessible.
•If a stationary appliance is not fitted with a supply cord and a
plug, or with other means for disconnection from the supply mains
having a contact separation in all poles that provide full
disconnection under overvoltage category III conditions, the
means for disconnection must be incorporated in the fixed wiring
in accordance with the wiring rules. Using an omnipolar switch
with a contact separation of at least 3 mm fitted in the supply
cable will fulfil this requirement.
•The supply cord must hang freely and should not be fed through
a drawer.
18
Installation

Gas connection
•Gas connection 1/2”ISO 228 / ISO 7-1 / EN 10226-1 (1/2”ISO
228 / 1/2”ISO 228 FR only).
•The gas connection must comply with national and local
regulations. See appliance label for technical gas data.
•This appliance is not connected to a combustion products
evacuation device. It shall be installed and connected in
accordance with current installation regulations. Particular attention
shall be given to the relevant requirements regarding ventilation.
•We recommend that the gas hob be connected by means of a
fixed pipe. Connection using a specially designed safety hose is
also permitted.
•The pipe behind the oven must be made entirely out of metal.
•A safety hose may not be bent and must not come into contact
with moving parts of kitchen units.
•The gas supply valve must always be placed in an easily
accessible position.
Service
•Faulty parts may only be replaced by original parts.
The manufacturer can only guarantee that original parts meet
safety requirements.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
19
Installation

Preparations for installation
Free space around the appliance
D (mm)C (mm)B (mm)A (mm)
min. 120min. 450min. 900min. 650
Accessibility
Accessibility
Oven
20
Installation
