aspenhome Queen Estate Panel HB I201-412 User manual

07-10-2018
Page1/3
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
FORINDOORUSEONLY
I201-412
I201-402
I201-403
COMPONENTS LIST:I201-403
No. Description Sketch Quantity
1Footboard 1PC
2Supportleg(forcenterrail) 4PCS
HARDWARELIST:I201-412
No. Description Sketch Quantity
ABolt1/4"*2" 8PCS
BBolt1/4"*1-3/8" 8PCS
CLockWasher1/4" 16PCS
DFlatWasher1/4"*3/4" 16PCS
EAllenWrench4mm 1PC
HARDWARELIST:I201-402
No. Description Sketch Quantity
FHangerBolt5/16"*3-1/2" 8PCS
GFlatwasher5/16x9/16" 8PCS
HLockWasher5/16" 8PCS
IHexNut5/16" 8PCS
JHexWrench12mm 1PC
KWoodScrewM4*1-1/2" 8PCS
LAllenWrench4mm 1PC
COMPONENTS LIST:I201-412
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
COMPONENTS LIST:I201-402
No. Description Sketch Quantity
1Bedrails 2PCS
2Slats 4PCS
ITEMNO:I201-412QueenEstate Panel HB
I201-402QueenRails
I201-403QueenLowProfile FB

07-10-2018
Page2/3
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
ITEMNO:I201-412QueenEstate Panel HB
I201-402QueenRails
I201-403QueenLowProfile FB
STEP1:Puttheheadboardfacedown
onasoftsurface.Attachtheleft leg
and rightlegtoheadboard byusing 8
bolts(A),lockwashers(C) and flat
washers(D).
STEP3:Attachthecentersupport
legtoheadboardandwoodstretcher
byusing4bolts(B),lockwashers(C)
andflatwashers(D).
STEP2:Attachthewoodstretchertothe
legsbyusing4bolts(B),lockwashers(C)
andflatwashers(D).
UPPER
position
Slatbearer
SideRail
STEP4:TherailsshipwiththeslatbearersassembledinUPPERpositionforastorageset up and
mustbemovedtoLOWERpositionfor thenon-storagesetup.Movetheslat bearersdowntothe
LOWERposition.Removethebolts(10pcs)andwoodscrews(10pcs)from theslat bearersand side
railsasshownbelow.Thenre-attachtheslatbearerstothesiderailsindesiredposition withbolts,
lockwashers,flatwashersandwoodscrews. Caution:Donot overtightenboltsasthismay
loosenthethreadedinsertsinthesiderails.
LOWER
position WoodScrew
A
C
D
E
HBBackside
Right Leg
LeftLeg
WoodStretcher B
C
D
E
B
C
D
E

07-10-2018
Page3/3
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
STEP5:Screwthebolts(F)intoHB&FB.Aligntheboltswiththeholesintheend ofsiderailsand
attachthesiderailstoHB&FBusingflatwasher(G),lockwashers(H)andnuts(I).Thenuseahex
wrench(J)totightenall thenuts.
F
GHIJSideRail
Slatbearer
Side Rail
Side Rail Makesuretheslatbeareris
intheLOWERposition.
STEP6:Attachthesupportlegswithlevelertotheslats.
Adjustthelevelersonbottom ofsupportlegswhennecessary. SupportLeg
Leveler
ThisEndUp
Slat
STEP7:Arrangetheslatsontheslat bearers
equallyandattachtotheslat bearerswith
wood screws (K).
ITEMNO:I201-412QueenEstate Panel HB
I201-402QueenRails
I201-403QueenLowProfile FB
FUNCTIONALITY INSTRUCTION
WoodScrews(K)
1PoweredUSBPortfor
Charging on bothsides
I201-412
I201-402
I201-403

07-10-2018
Page1/4
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
FORINDOORUSEONLY
I201-412
I201-402
I201-403D
HARDWARELIST:I201-403D
No. Description Sketch Quantity
MBolt1/4"*1-3/8" 8PCS
NLockWasher1/4" 8PCS
OFlatWasher1/4"*3/4" 8PCS
PAllenWrench4mm 1PC
QWoodScrewM4*1" 8PCS
COMPONENTS LIST:I201-403D
No. Description Sketch Quantity
1Footboard 1PC
2SupportLeg(forcenterrail) 2PCS
3Supportleg(forpedestal) 3PCS
4Decking 4PCS
5Center rail 1PC
ITEMNO:I201-412QueenEstate Panel HB
I201-402QueenRails
I201-403DQueenStorageFB
HARDWARELIST:I201-412
No. Description Sketch Quantity
ABolt1/4"*2" 8PCS
BBolt1/4"*1-3/8" 8PCS
CLockWasher1/4" 16PCS
DFlatWasher1/4"*3/4" 16PCS
EAllenWrench4mm 1PC
HARDWARELIST:I201-402
No. Description Sketch Quantity
FHangerBolt5/16"*3-1/2" 8PCS
GFlatwasher5/16x9/16" 8PCS
HLockWasher5/16" 8PCS
IHexNut5/16" 8PCS
JHexWrench12mm 1PC
KWoodScrewM4*1-1/2" 8PCS
LAllenWrench4mm 1PC
COMPONENTS LIST:I201-412
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
COMPONENTS LIST:I201-402
No. Description Sketch Quantity
1Bedrails 2PCS
2Slats 4PCS

07-10-2018
Page2/4
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
ITEMNO:I201-412QueenEstate Panel HB
I201-402QueenRails
I201-403DQueenStorageFB
STEP1:Puttheheadboardfacedown
onasoftsurface.Attachtheleft leg
and rightlegtoheadboard byusing 8
bolts(A),lockwashers(C) and flat
washers(D).
STEP3:Attachthecentersupport
legtoheadboardandwoodstretcher
byusing4bolts(B),lockwashers(C)
andflatwashers(D).
STEP2:Attachthewoodstretchertothe
legsbyusing4bolts(B),lockwashers(C)
andflatwashers(D).
STEP4:Putfootboard upsidedownonapadded,cleansurface.Attachsupportlegs(forpedestal)to
footboard. Turn footboardrightsideup.
Leveler
SupportLeg
A
C
D
E
HBBackside
Right Leg
LeftLeg
WoodStretcher B
C
D
E
B
C
D
E

07-10-2018
Page3/4
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
STEP5:Screwthebolts(F)intoHB&FB.Aligntheboltswiththeholesintheend ofsiderailsand
attachthesiderailstoHB&FBusingflatwasher(G),lockwashers(H)andnuts(I).Thenuseahex
wrench(J)totightenall thenuts.
F
GHIJ
Makesuretheslatbeareris
intheUPPERposition.
SideRail
Slatbearer
Side Rail
Side Rail
STEP6:Attachcenterrail tothefootboard and centersupportlegof headboard using4bolts(M),
lockwashers(N)andflatwashers(O).
O
PMN
Centerrail
STEP7:Attach2supportlegs(for centerrail)tothe
centerrailusing4bolts(M),lockwashers(N)and flat
washers(O).UsetheAllenWrench(P)totightenall
ofthebolts.
O
PMNCenterRail
SupportLeg
(forcenterrail)
Leveler
ITEMNO:I201-412QueenEstate Panel HB
I201-402QueenRails
I201-403DQueenStorageFB
Center rail

07-10-2018
Page4/4
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
WoodScrews(K)
STEP9:Putthedeckingovertheslats,securedeckingtotheslatswithwood screws (Q)through
thepre-drilledholesinthedecking asshownbelow.
ITEMNO:I201-412QueenEstate Panel HB
I201-402QueenRails
I201-403DQueenStorageFB
STEP8:Arrangeslatsontheslatbearersand then
laydeckingontop oftheslats. Makesuretheslats
arepositionedalongtheseamsofthedecking as
showninthedetailinSTEP9underthe
pre-drilledhole. Removethedecking and attach
slatstotheslatbearerswithwoodscrews(K).
FUNCTIONALITY INSTRUCTION
Slat
Decking
Decking
Theslat shouldsupport
bothpiecesofdecking.
Makesurethatthereisaslat
underthepre-drilledhole.
Q
Decking
Pre-drilledhole
I201-412
I201-402
I201-403D
Cedar-linedStorageDrawers
2PoweredUSBPortfor
Charging on bothsides

07-10-2018
Page1/4
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
UTILITYKNIFE(FORCALKING)
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
FORINDOORUSEONLY
I201-415
I201-406
I201-410 I201-407
COMPONENTS LIST:I201-407
No. Description Sketch Quantity
1Footboard 1PC
2Supportleg(forcenterrail) 5PCS
HARDWARELIST:I201-415
No. Description Sketch Quantity
ABolt1/4"*2" 8PCS
BBolt1/4"*1-3/8" 8PCS
CLockWasher1/4" 16PCS
DFlatWasher1/4"*3/4" 16PCS
EAllenWrench4mm 1PC
HARDWARELIST:I201-406/410
No. Description Sketch Quantity
FHangerBolt5/16"*3-1/2" 8PCS
GFlatwasher5/16x9/16" 8PCS
HLockWasher5/16" 8PCS
IHexNut5/16" 8PCS
JHexWrench12mm 1PC
KWoodScrewM4*1-1/2" 10PCS
LAllenWrench4mm 1PC
MPolyCap(onlyfor410) 8PCS
COMPONENTS LIST:I201-415
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
COMPONENTS LIST:I201-406
No. Description Sketch Quantity
1Bedrails 2PCS
2Slats 5PCS
COMPONENTS LIST:I201-410
No. Description Sketch Quantity
1Bedrails 2PCS
2Slats 5PCS
3Centerrail(Long) 1PC
ITEMNO:I201-415KingEstate Panel HB
I201-406King Rails
I201-410CalKing Rails
I201-407KingLowProfile FB

07-10-2018
Page2/4
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
ITEMNO:I201-415KingEstate Panel HB
I201-406King Rails
I201-410CalKing Rails
I201-407KingLowProfile FB
STEP1:Puttheheadboardfacedown
onasoftsurface.Attachtheleft leg
and rightlegtoheadboard byusing 8
bolts(A),lockwashers(C) and flat
washers(D).
STEP3:Attachthecentersupport
legtoheadboardandwoodstretcher
byusing4bolts(B),lockwashers(C)
andflatwashers(D).
STEP2:Attachthewoodstretchertothe
legsbyusing4bolts(B),lockwashers(C)
andflatwashers(D).
UPPER
position
Slatbearer
SideRail
LOWER
position
WoodScrew
STEP4:TherailsshipwiththeslatbearersassembledinUPPERpositionforastorageset up and
mustbemovedtoLOWERpositionfor thenon-storagesetup.Movetheslat bearersdowntothe
LOWERposition.Removethebolts(10pcs)andwoodscrews(10pcs)from theslat bearersand side
railsasshownbelow.Thenre-attachtheslatbearerstothesiderailsindesiredposition withbolts,
lockwashers,flatwashersandwoodscrews. Caution:Donot overtightenboltsasthismay
loosenthethreadedinsertsinthesiderails.
A
C
D
E
HBBackside
Right Leg
LeftLeg
WoodStretcher
B
C
D
E
B
C
D
E

07-10-2018
Page3/4
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
STEP5:Screwthebolts(F)intoHB&FB.Aligntheboltswiththeholesintheend ofsiderailsand
attachthesiderailstoHB&FBusingflatwasher(G),lockwashers(H)andnuts(I).Thenuseahex
wrench(J)totightenall thenuts.
F
GHIJ
Theoutsideholesmatchto6/6bedrails-406,
theinsideholesmatchto6/0bedrails-410.
SideRail
Slatbearer
Side Rail
Side Rail
ITEMNO:I201-415KingEstate Panel HB
I201-406King Rails
I201-410CalKing Rails
I201-407KingLowProfile FB
Makesuretheslatbeareris
intheLOWERposition.
STEP6:Attachthesupportlegswithlevelertotheslats.
Adjustthelevelersonbottom ofsupportlegswhennecessary. SupportLeg
Leveler
ThisEndUp
Slat
STEP7:Arrangetheslatsontheslat bearers
equallyandattachtotheslat bearerswith
wood screws (K).
WoodScrews(K)
STEP8:For Cal Kingbed,insertpolycapsintotheholeson
headboardandfootboard.For regularKingbed,skipthisstep. PolyCap(M)

07-10-2018
Page4/4
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
ITEMNO:I201-415KingEstate Panel HB
I201-406King Rails
I201-410CalKing Rails
I201-407KingLowProfile FB
FUNCTIONALITY INSTRUCTION
2PoweredUSBPortfor
Charging on bothsides
2PoweredUSBPortfor
Charging on bothsides
I201-410
I201-407
I201-415
I201-406
I201-407
I201-415

07-10-2018
Page1/5
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
UTILITYKNIFE(FORCALKING)
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
FORINDOORUSEONLY
I201-415
I201-406
I201-410 I201-407D
HARDWARELIST:I201-407D
No. Description Sketch Quantity
NBolt1/4"*1-3/8" 8PCS
OLockWasher1/4" 8PCS
PFlatWasher1/4"*3/4" 8PCS
QAllenWrench4mm 1PC
RWoodScrewM4*1" 5PCS
COMPONENTS LIST:I201-407D
No. Description Sketch Quantity
1Footboard 1PC
2SupportLeg(forcenterrail) 2PCS
3Supportleg(forpedestal) 3PCS
4Decking 3PCS
5Centerrail(Short) 1PC
6Filler 2PCS
ITEMNO:I201-415KingEstate Panel HB
I201-406King Rails
I201-410CalKing Rails
I201-407DKingStorageFB
HARDWARELIST:I201-415
No. Description Sketch Quantity
ABolt1/4"*2" 8PCS
BBolt1/4"*1-3/8" 8PCS
CLockWasher1/4" 16PCS
DFlatWasher1/4"*3/4" 16PCS
EAllenWrench4mm 1PC
HARDWARELIST:I201-406/410
No. Description Sketch Quantity
FHangerBolt5/16"*3-1/2" 8PCS
GFlatwasher5/16x9/16" 8PCS
HLockWasher5/16" 8PCS
IHexNut5/16" 8PCS
JHexWrench12mm 1PC
KWoodScrewM4*1-1/2" 10PCS
LAllenWrench4mm 1PC
MPolyCap(onlyfor410) 8PCS
COMPONENTS LIST:I201-415
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
COMPONENTS LIST:I201-406
No. Description Sketch Quantity
1Bedrails 2PCS
2Slats 5PCS
COMPONENTS LIST:I201-410
No. Description Sketch Quantity
1Bedrails 2PCS
2Slats 5PCS
3Centerrail(Long) 1PC

07-10-2018
Page2/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
ITEMNO:I201-415KingEstate Panel HB
I201-406King Rails
I201-410CalKing Rails
I201-407DKingStorageFB
STEP1:Puttheheadboardfacedown
onasoftsurface.Attachtheleft leg
and rightlegtoheadboard byusing 8
bolts(A),lockwashers(C) and flat
washers(D).
STEP3:Attachthecentersupport
legtoheadboardandwoodstretcher
byusing4bolts(B),lockwashers(C)
andflatwashers(D).
STEP2:Attachthewoodstretchertothe
legsbyusing4bolts(B),lockwashers(C)
andflatwashers(D).
STEP4:Putfootboard upsidedownonapadded,cleansurface.Attachsupportlegs(forpedestal)to
footboard. Turn footboardrightsideup.
A
C
D
E
HBBackside
Right Leg
LeftLeg
WoodStretcher B
C
D
E
Leveler
SupportLeg
B
C
D
E

07-10-2018
Page3/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
ITEMNO:I201-415KingEstate Panel HB
I201-406King Rails
I201-410CalKing Rails
I201-407DKingStorageFB
STEP5:Screwthebolts(F)intoHB&FB.Aligntheboltswiththeholesintheend ofsiderailsand
attachthesiderailstoHB&FBusingflatwasher(G),lockwashers(H)andnuts(I).Thenuseahex
wrench(J)totightenall thenuts.
F
GHIJ
Theoutsideholesmatchto6/6bedrails-406,
theinsideholesmatchto6/0bedrails-410.
Makesuretheslatbeareris
intheUPPERposition.
SideRail
Slatbearer
Side Rail
Side Rail
STEP6:Attachcenterrail tothefootboard and centersupportlegof headboard using4bolts(N),
lockwashers(O)andflatwashers(P).
O
QN
Centerrail
Theshortcenterrailthat is
packedinstorageFBworks
with-406Kingrails(6/6);
TheLongcenterrail thatis
packedinCalKing side
railsworkswith-410 Cal
Kingrails(6/0).
STEP7:Attach2supportlegs(for centerrail)tothe
centerrailusing4bolts(N),lockwashers(O)and flat
washers(P).UsetheAllenWrench(Q)totightenall
ofthebolts.
O
QN
CenterRail
SupportLeg
(forcenterrail)
Leveler
Center rail
P
P

07-10-2018
Page4/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
ITEMNO:I201-415KingEstate Panel HB
I201-406King Rails
I201-410CalKing Rails
I201-407DKingStorageFB
WoodScrews(K)
STEP8:Arrangeslatsontheslatbearersand then
laythedecking on topof theslats.Makesurethe
top andbottom slatsaresituatedunderneaththe
pre-drilledholesasshownbelow inSTEP10.
Removethedecking andattachslatstotheslat
bearerswithwoodscrews(K).
Filler Notch
STEP9:For theCal Kingbed,bothfilerboardsarenotched.
Usingautilityknifeonlycutoffthesmall pieceat thenotchon
oneofthefillerboards.Thiscutofffillerboardwill beplacedat
thefoot ofthebedgoingfromleft toright asshownontheright
sidebelowinSTEP10.ForthestandardKingbed,skipthisstep
and arrangethedeckingboardson shownon theleftsidebelow.
STEP10:Putthedeckingovertheslats,securedeckingtotheslatswithwood screws (R)through
thepre-drilledholesinthedecking asshownbelow.
Decking Decking Decking
Filler
Filler
Decking Decking Decking
Filler
Makesurethatthereisaslat
underthepre-drilledhole.
R
Decking
Pre-drilledhole
ShortFiller
StandardKingBed Cal King Bed
STEP11:For Cal Kingbed,insertpolycapsintotheholeson
headboardandfootboard.For regularKingbed,skipthisstep. PolyCap(M)

07-10-2018
Page5/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
ITEMNO:I201-415KingEstate Panel HB
I201-406King Rails
I201-410CalKing Rails
I201-407DKingStorageFB
FUNCTIONALITY INSTRUCTION
2PoweredUSBPortfor
Charging on bothsides
2PoweredUSBPortfor
Charging on bothsides
Cedar-linedStorageDrawers
Cedar-linedStorageDrawers
I201-415
I201-406
I201-410
I201-407D
I201-415
I201-407D
