aspenhome IKJ-412-KD User manual

09-23-2016
Page1/5
ITEMNO:IKJ-400-KDQueenSleigh BedHB
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
FORINDOORUSEONLY
IKJ-403D
IKJ-402L
IKJ-400-KD
IKJ-403D
IKJ-402L
IKJ-412-KD
OPTION2:Queen StoragePanelBed
OPTION1:Queen StorageSleighBed
IKJ-412-KDQueenPanel HB
IKJ-402LQueenSideRails
IKJ-403DQueen StorageFB

COMPONENTS LIST:IKJ-412-KD
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
HARDWARELIST:IKJ-412-KD
No. Description Sketch Quantity
HBolt1/4"*1-3/4" 10PCS
ILockWasher 1/4"10PCS
JFlatWasher 1/4"10PCS
KAllenWrench4mm 1PC
COMPONENTS LIST:IKJ-402L
No. Description Sketch Quantity
1Bedrails 2PCS
2Slats 4PCS
3Supportlegswithleveler 4PCS
COMPONENTS LIST:IKJ-403D
No. Description Sketch Quantity
1Footboard 1PC
2SupportLeg(forpedestal) 3PCS
3SupportLeg(forslats) 3PCS
4Decking 4PCS
COMPONENTS LIST:IKJ-400-KD
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
HARDWARELIST:IKJ-400-KD
No. Description Sketch Quantity
ABolt 1/4"*1-3/4" 10PCS
BLockWasher 1/4" 10PCS
CFlatWasher 1/4" 10PCS
DAllenWrench4mm 1PC
HARDWARELIST:IKJ-402L
No. Description Sketch Quantity
EWoodScrew 8PCS
FAllenWrench4mm 1PC
09-23-2016
Page2/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
HARDWARELIST:IKJ-403D
No. Description Sketch Quantity
GWoodScrew 8PCS
ITEMNO:IKJ-400-KDQueenSleigh BedHB
IKJ-412-KDQueenPanel HB
IKJ-402LQueenSideRails
IKJ-403DQueen StorageFB

09-23-2016
Page3/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
OPTION1: Queen StorageSleighBed
A
B
C
D
HBBackside
LeftLeg
Right Leg
STEP1:Laytheheadboardfacedownon
asoftsurface.Attachtheleftlegand right
legtoheadboardbyusing6bolts(A), lock
washers(B)andflatwashers(C).
STEP2:Attachthewoodstretchertothe
legsbyusing4bolts(A),lockwashers(B)
andflatwashers(C).
WoodStretcher
A
B
C
D
HBBackside
STEP3:Layfootboard upsidedownon
apadded,cleansurface.Attachsupport
legs(for pedestal)tofootboard.Turn
footboardrightsideup.
Leveler
SupportLeg
STEP4:Hookthesiderailstotheheadboardandfootboard.
Slatbearer
SideRail
Headboard
ITEMNO:IKJ-400-KDQueenSleigh BedHB
IKJ-412-KDQueenPanel HB
IKJ-402LQueenSideRails
IKJ-403DQueen StorageFB

09-23-2016
Page4/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
STEP5:Attachthesupportlegswithlevelertotheslats.
Adjustthelevelersonbottom ofsupportlegswhen
necessary. SupportLeg
Leveler
ThisEndUp
Slat
WoodScrews(E) STEP6:Arrangeslatsontheslatbearers
and thenlaydeckingontop oftheslats.
Makesuretheslatsarepositionedalongthe
seamsofthedeckingasshowninthedetail
inSTEP7underthepre-drilledhole.
Removethedeckingandattachslatstothe
slatbearerswithwoodscrews(E).
STEP7:Putthedeckingovertheslats,securedeckingtotheslatswithwood screws (G)through
thepre-drilledholesinthedecking asshownbelow.
Decking
Slat
Decking
Decking
Theslat shouldsupport
bothpiecesofdecking.
Decking
Decking
Decking
Makesurethatthereisaslat
underthepre-drilledhole.
GDecking
Pre-drilledhole
ITEMNO:IKJ-400-KDQueenSleigh BedHB
IKJ-412-KDQueenPanel HB
IKJ-402LQueenSideRails
IKJ-403DQueen StorageFB

09-23-2016
Page5/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
OPTION2: Queen StoragePanelBed H
I
J
K
HBBackside
LeftLeg
Right Leg
STEP1:Laytheheadboardfacedownon
asoftsurface.Attachtheleftlegand right
legtoheadboardbyusing6bolts(H), lock
washers(I) and flat washers(J).
STEP2:Attachthewoodstretchertothe
legsbyusing4bolts(H),lockwashers(I)
andflatwashers(J).
WoodStretcher
HBBackside
FUNCTIONALITY INSTRUCTION
STEP3toSTEP7aresameasOPTION 1
IKJ-403D
IKJ-402L
IKJ-412-KD
H
I
J
K
IKJ-403D
IKJ-402L
IKJ-400-KD
ITEMNO:IKJ-400-KDQueenSleigh BedHB
IKJ-412-KDQueenPanel HB
IKJ-402LQueenSideRails
IKJ-403DQueen StorageFB
