aspenhome Oxford I07-412-WBR User manual

I07-403
I07-402
I07-400
I07-403
I07-402
05-16-2017
Page1/6
ITEMNO:I07-412-WBR/PEP/BLKQueenPanel HB
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
FORINDOORUSEONLY
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
I07-402-WBR/PEP/BLKQueenRails
I07-403-WBR/PEP/BLKQueenLowProfile FB
I07-400-WBR/PEP/BLKQueenSleigh HB
OPTION1:Queen LPPanelBed
OPTION2:Queen LP Sleigh Bed
I07-412

05-16-2017
Page2/6
COMPONENTS LIST:I07-412
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
HARDWARELIST:I07-412
No. Description Sketch Quantity
ABolt 5/16"*2" 6PCS
BBolt5/16"*1-9/16" 3PCS
CBolt5/16"*1-3/8" 4PCS
DLockWasher 5/16"13PCS
EFlatWasher 5/16"*3/4" 13PCS
FAllenWrench5mm 1PC
HARDWARELIST:I07-402
No. Description Sketch Quantity
MWoodScrewM4*1-3/16" 8PCS
NHangerBolt5/16"*3-1/16" 8PCS
OLockWasher5/16" 8PCS
PFlatwasher5/16"x5/8" 8PCS
QHexNut5/16" 8PCS
RHexWrench90*25*2mm 1PC
COMPONENTS LIST:I07-402
No. Description Sketch Quantity
1Bedrails 2PC
2Slats 4PC
COMPONENTS LIST:I07-403
No. Description Sketch Quantity
1Footboard 1PC
2Supportleg(forslats) 4PCS
3Bunfoot 2PCS
COMPONENTS LIST:I07-400
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
HARDWARELIST:I07-400
No. Description Sketch Quantity
GWoodDowel 3/8"*1-9/16" 8PCS
HBolt5/16"*1-9/16" 9PCS
IBolt5/16"*1-3/8" 4PCS
JLockWasher 5/16"13PCS
KFlatWasher 5/16"*3/4" 13PCS
LAllenWrench5mm 1PC
ITEMNO:I07-412-WBR/PEP/BLKQueenPanel HB
I07-402-WBR/PEP/BLKQueenRails
I07-403-WBR/PEP/BLKQueenLowProfile FB
I07-400-WBR/PEP/BLKQueenSleigh HB

05-16-2017
Page3/6
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
D
E
STEP1:Puttheheadboardfacedownon a
softsurface.Attachtheleftlegand right
legtoheadboardbyusing6bolts(A), lock
washers(D)and flat washers(E).
HBBackside
C
D
E
F
STEP2:Attachthewoodstretchertothe
legsbyusing4bolts(C),lockwashers(D)
andflatwashers(E).
LeftLeg
Right Leg
HBBackside
WoodStretcher
B
D
E
F
STEP3:Attachthecentersupport
legtoheadboardand wood
stretcherbyusing3bolts(B), lock
washers(D)and flat washers(E).
CenterSupport Leg
HBBackside
OPTION1: Queen LPPanelBed
Slatbearerin
upperposition
Slatbearerin
lowerposition
STEP5:Thesiderailsmaybeusedon eitherside.
Arrangethesiderailssotheslatbearersarein
LOWERPOSITIONprior toattachmentinSTEP6.
ITEMNO:I07-412-WBR/PEP/BLKQueenPanel HB
I07-402-WBR/PEP/BLKQueenRails
I07-403-WBR/PEP/BLKQueenLowProfile FB
I07-400-WBR/PEP/BLKQueenSleigh HB A
F
Leveler
Bun Foot STEP4:Putfootboard upside
downonapadded, cleansurface.
Attachbunfeet tofootboard. Turn
footboardrightsideup.

05-16-2017
Page4/6
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
O
PQ
R
STEP6:Screwthebolts(N)intoHB&FB.Aligntheboltswiththeholesintheend ofsiderails
andattachthesiderailstoHB&FBusingflatwasher(P),lockwashers(O)and nuts(Q).Thenuse
ahexwrench(R)totightenall thenuts.
Makesuretheslatbeareris
intheLOWERposition.
N
Headboard
Slatbearer
SideRail
SideRail
SideRail
STEP7:Attachthesupportlegswithlevelertothe
slats.Adjustthelevelersonbottomofsupport legs
whennecessary.
SupportLeg
Leveler
ThisEndUp
Slat
STEP8:Arrangetheslatsontheslat bearer
equallyandattachtotheslat bearerwith
wood screws (M).
WoodScrews(M)
ITEMNO:I07-412-WBR/PEP/BLKQueenPanel HB
I07-402-WBR/PEP/BLKQueenRails
I07-403-WBR/PEP/BLKQueenLowProfile FB
I07-400-WBR/PEP/BLKQueenSleigh HB

05-16-2017
Page5/6
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP1:Puttheheadboardfacedownon a
softsurface.Insert8wooddowels(G)into
headboard,Thenattachtheleft legand
right legtoheadboardbyusing6bolts(H),
lockwashers(J)andflatwashers(K).
HJK
L
G
I
J
K
L
STEP2:Attachthewoodstretchertothe
legsbyusing4bolts(I),lockwashers(J)
andflatwashers(K).
HBBackside
LeftLeg
Right Leg
WoodStretcher
CenterSupport Leg
HBBackside
STEP3:Attachthecentersupport legto
headboardandwood stretcherby using 3
bolts(H),lockwashers(J)andflat
washers(K).
HBBackside
L
H
K
J
STEP4toSTEP11aresameasOPTION 1
OPTION2: Queen LP Sleigh Bed
ITEMNO:I07-412-WBR/PEP/BLKQueenPanel HB
I07-402-WBR/PEP/BLKQueenRails
I07-403-WBR/PEP/BLKQueenLowProfile FB
I07-400-WBR/PEP/BLKQueenSleigh HB

FUNCTIONALITY INSTRUCTION
2PoweredUSBPortfor
Charging on bothsides
I07-403
I07-402
I07-412
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
2PoweredUSBPortfor
Charging on bothsides
I07-403
I07-402
I07-400
05-16-2017
Page6/6
ITEMNO:I07-412-WBR/PEP/BLKQueenPanel HB
I07-402-WBR/PEP/BLKQueenRails
I07-403-WBR/PEP/BLKQueenLowProfile FB
I07-400-WBR/PEP/BLKQueenSleigh HB

05-16-2017
Page1/6
ITEMNO:I07-412-WBR/PEP/BLKQueenPanel HB
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
FORINDOORUSEONLY
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
I07-402-WBR/PEP/BLKQueenRails
I07-403D-WBR/PEP/BLKQueenStorageFB
I07-400-WBR/PEP/BLKQueenSleigh HB
OPTION1:QueenStorage PanelBed
OPTION2:QueenStorage Sleigh Bed
I07-403D
I07-402
I07-412
I07-400
I07-403D
I07-402

05-16-2017
Page2/6
COMPONENTS LIST:I07-412
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
HARDWARELIST:I07-412
No. Description Sketch Quantity
ABolt 5/16"*2" 6PCS
BBolt5/16"*1-9/16" 3PCS
CBolt5/16"*1-3/8" 4PCS
DLockWasher 5/16"13PCS
EFlatWasher 5/16"*3/4" 13PCS
FAllenWrench5mm 1PC
HARDWARELIST:I07-402
No. Description Sketch Quantity
MWoodScrewM4*1-3/16" 8PCS
NHangerBolt5/16"*3-1/16" 8PCS
OLockWasher5/16" 8PCS
PFlatwasher5/16x5/8" 8PCS
QHexNut5/16" 8PCS
RHexWrench90*25*2mm 1PC
HARDWARELIST:I07-403D
No. Description Sketch Quantity
SWoodScrewM4*1 8PCS
TBolt5/16"*1-3/16" 8PCS
ULockWasher5/16" 8PCS
VFlatwasher5/16x3/4" 8PCS
WAllenWrench5mm 1PC
COMPONENTS LIST:I07-402
No. Description Sketch Quantity
1Bedrails 2PC
2Slats 4PC
COMPONENTS LIST:I07-403D
No. Description Sketch Quantity
1Footboard 1PC
2SupportLeg(forcenterrail) 2PCS
3Supportleg(forpedestal) 3PCS
4Decking 4PCS
5Center rail 1PCS
6Bunfoot 2PCS
COMPONENTS LIST:I07-400
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
HARDWARELIST:I07-400
No. Description Sketch Quantity
GWoodDowel 10*1-9/16" 8PCS
HBolt5/16"*1-9/16" 9PCS
IBolt5/16"*1-3/8" 4PCS
JLockWasher 5/16" 13PCS
KFlatWasher 5/16"*3/4" 13PCS
LAllenWrench5mm 1PC
ITEMNO:I07-412-WBR/PEP/BLKQueenPanel HB
I07-402-WBR/PEP/BLKQueenRails
I07-403D-WBR/PEP/BLKQueenStorageFB
I07-400-WBR/PEP/BLKQueenSleigh HB

05-16-2017
Page3/6
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
D
E
STEP1:Puttheheadboardfacedownon a
softsurface.Attachtheleftlegand right
legtoheadboardbyusing6bolts(A), lock
washers(D)and flat washers(E). HBBackside
C
D
E
F
STEP2:Attachthewoodstretchertothe
legsbyusing4bolts(C),lockwashers(D)
andflatwashers(E).
LeftLeg
Right Leg
HBBackside
WoodStretcher
B
D
E
F
STEP3:Attachthecentersupport
legtoheadboardand wood
stretcherbyusing3bolts(B), lock
washers(D)and flat washers(E).
CenterSupport
Leg
HBBackside
STEP4:Putfootboard upsidedownonapadded,cleansurface.Attachsupport legs(forpedestal)and
bun feet tofootboard.Turnfootboardrightsideup.
Leveler
SupportLeg
OPTION1: QueenStorage Panel Bed
ITEMNO:I07-412-WBR/PEP/BLKQueenPanel HB
I07-402-WBR/PEP/BLKQueenRails
I07-403D-WBR/PEP/BLKQueenStorageFB
I07-400-WBR/PEP/BLKQueenSleigh HB
A
F
Leveler
Bun Foot

05-16-2017
Page4/6
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
Slatbearerin
upperposition
Slatbearerin
lowerposition
STEP5:Thesiderailsmaybeusedon eitherside.
Arrangethesiderailssotheslatbearersarein
UPPERPOSITIONpriortoattachmentinSTEP6.
O
PQR
STEP6:Screwthebolts(N)intoHB&FB.Aligntheboltswiththeholesintheend ofsiderails
andattachthesiderailstoHB&FBusingflatwasher(P),lockwashers(O)and nuts(Q).Thenuse
ahexwrench(R)totightenall thenuts.
WTUV
Centerrail
STEP7:Attachcenterrailtothefootboardandcentersupportlegofheadboardusing 4bolts(T),
lockwashers(U)andflatwashers(V).
Makesuretheslatbeareris
intheUPPERposition.
N
Headboard
Slatbearer
SideRail
SideRail
SideRail
Centerrail
ITEMNO:I07-412-WBR/PEP/BLKQueenPanel HB
I07-402-WBR/PEP/BLKQueenRails
I07-403D-WBR/PEP/BLKQueenStorageFB
I07-400-WBR/PEP/BLKQueenSleigh HB

05-16-2017
Page5/6
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP8:Attach2supportlegs(for centerrail)tothe
centerrailusing4bolts(T),lockwashers(U)and flat
washers(V).UsetheAllenWrench(W)totightenall
ofthebolts.
CenterRail
SupportLeg
(forcenterrail)
Leveler
WoodScrews(M)
STEP10:Putthedeckingovertheslats,
securedeckingtotheslatswithwood
screws(S)throughthepre-drilledholes
inthedeckingasshownbelow.
Makesurethatthereisaslat
underthepre-drilledhole.
S
Decking
Pre-drilledhole
Decking
Decking
Decking
Decking
WTUV
Slat
Decking
Decking
ITEMNO:I07-412-WBR/PEP/BLKQueenPanel HB
I07-402-WBR/PEP/BLKQueenRails
I07-403D-WBR/PEP/BLKQueenStorageFB
I07-400-WBR/PEP/BLKQueenSleigh HB
STEP1:Puttheheadboardfacedownon a
softsurface.Insert8wooddowels(G)into
headboard,Thenattachtheleft legand
right legtoheadboardbyusing6bolts(H),
lockwashers(J)andflatwashers(K).
HJK
L
G
HBBackside
LeftLeg
Right Leg
OPTION2: QueenStorage Sleigh Bed
Theslat shouldsupport
bothpiecesofdecking.
STEP9:Arrangeslatsontheslatbearersand then
laydeckingontop oftheslats. Makesuretheslats
arepositionedalongtheseamsofthedecking as
showninthedetailinSTEP9underthe
pre-drilledhole. Removethedecking and attach
slatstotheslatbearerswithwoodscrews(M).

FUNCTIONALITY INSTRUCTION
2PoweredUSBPortfor
Charging on bothsides
I07-403D
I07-402
I07-412
05-16-2017
Page6/6
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
I
J
K
L
STEP2:Attachthewoodstretchertothe
legsbyusing4bolts(I),lockwashers(J)
andflatwashers(K).
WoodStretcher
CenterSupport Leg
HBBackside
STEP3:Attachthecentersupport legto
headboardandwood stretcherby using 3
bolts(H),lockwashers(J)andflatwashers(K).
HBBackside
L
H
K
J
STEP4toSTEP11aresameasOPTION 1
ITEMNO:I07-412-WBR/PEP/BLKQueenPanel HB
I07-402-WBR/PEP/BLKQueenRails
I07-403D-WBR/PEP/BLKQueenStorageFB
I07-400-WBR/PEP/BLKQueenSleigh HB
I07-402
I07-400
I07-403D
2PoweredUSBPortfor
Charging on bothsides
Cedar-linedStorage
Drawers
Cedar-linedStorageDrawers

05-16-2017
Page1/6
ITEMNO:I07-415-WBR/PEP/BLKKing Panel HB
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
FORINDOORUSEONLY
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
I07-406-WBR/PEP/BLKKing Rails
I07-410-WBR/PEP/BLKCal King Rails
I07-407-WBR/PEP/BLKKingLowProfile FB
I07-407
I07-410
I07-406
I07-415
I07-404-WBR/PEP/BLKKing Sleigh HB
I07-404
I07-407
OPTION 1: King/CalKingLPPanelBed
OPTION 2: King/Cal KingLPSleighBed
I07-410
I07-406

05-16-2017
Page2/6
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
COMPONENTS LIST:I07-415
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
UTILITYKNIFE(FORCALKING)
HARDWARELIST:I07-415
No. Description Sketch Quantity
ABolt 5/16"*2" 6PCS
BBolt5/16"*1-9/16" 3PCS
CBolt5/16"*1-3/8" 4PCS
DLockWasher 5/16"13PCS
EFlatWasher 5/16"*3/4" 13PCS
FAllenWrench5mm 1PC
HARDWARELIST:I07-406/410
No. Description Sketch Quantity
MWoodScrewM4*1-3/16" 10PCS
NHangerBolt5/16"*3-1/16" 8PCS
OLockWasher5/16" 8PCS
PFlatwasher5/16x5/8" 8PCS
QHexNut5/16" 8PCS
RHexWrench90*25*2mm 1PC
SWoodCap(Onlyfor410) 8PCS
COMPONENTS LIST:I07-406
No. Description Sketch Quantity
1Bedrails 2PC
2Slats 5PC
COMPONENTS LIST:I07-410
No. Description Sketch Quantity
1Bedrails 2PCS
2Slats 5PCS
3Center rail 1PC
COMPONENTS LIST:I07-407
No. Description Sketch Quantity
1Footboard 1PC
2Supportleg(forslats) 5PCS
3Bunfoot 2PCS
COMPONENTS LIST:I07-404
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
HARDWARELIST:I07-404
No. Description Sketch Quantity
GWoodDowel 3/8"*1-9/16" 8PCS
HBolt5/16"*1-9/16" 9PCS
IBolt5/16"*1-3/8" 4PCS
JLockWasher 5/16"13PCS
KFlatWasher 5/16"*3/4" 13PCS
LAllenWrench5mm 1PC
ITEMNO:I07-415-WBR/PEP/BLKKing Panel HB
I07-406-WBR/PEP/BLKKing Rails
I07-410-WBR/PEP/BLKCal King Rails
I07-407-WBR/PEP/BLKKingLowProfile FB
I07-404-WBR/PEP/BLKKing Sleigh HB

05-16-2017
Page3/6
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ITEMNO:I07-415-WBR/PEP/BLKKing Panel HB
I07-406-WBR/PEP/BLKKing Rails
I07-410-WBR/PEP/BLKCal King Rails
I07-407-WBR/PEP/BLKKingLowProfile FB
I07-404-WBR/PEP/BLKKing Sleigh HB
A
D
E
F
STEP1:Puttheheadboardfacedownon a
softsurface.Attachtheleftlegand right
legtoheadboardbyusing6bolts(A), lock
washers(D)and flat washers(E). HBBackside
C
D
E
F
STEP2:Attachthewoodstretchertothe
legsbyusing4bolts(C),lockwashers(D)
andflatwashers(E).
LeftLeg
Right Leg
HBBackside
WoodStretcher
B
D
E
F
STEP3:Attachthecentersupport
legtoheadboardand wood
stretcherbyusing3bolts(B), lock
washers(D)and flat washers(E).
CenterSupport Leg
HBBackside
OPTION1: King/CalKingLPPanel Bed
Slatbearerin
upperposition
Slatbearerin
lowerposition
STEP5:Thesiderailsmaybeusedon eitherside.
Arrangethesiderailssotheslatbearersarein
LOWERPOSITIONprior toattachmentinSTEP6.
Leveler
Bun Foot STEP4:Putfootboard upside
downonapadded, cleansurface.
Attachbunfeet tofootboard. Turn
footboardrightsideup.

05-16-2017
Page4/6
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ITEMNO:I07-415-WBR/PEP/BLKKing Panel HB
I07-406-WBR/PEP/BLKKing Rails
I07-410-WBR/PEP/BLKCal King Rails
I07-407-WBR/PEP/BLKKingLowProfile FB
I07-404-WBR/PEP/BLKKing Sleigh HB
O
PQ
R
STEP6:Screwthebolts(N)intoHB&FB.Aligntheboltswiththeholesintheend ofsiderails
andattachthesiderailstoHB&FBusingflatwasher(P),lockwashers(O)and nuts(Q).Thenuse
ahexwrench(R)totightenall thenuts.
Makesuretheslatbeareris
intheLOWERposition.
N
Headboard
Slatbearer
Theoutsideholesmatchto6/6bedrails,
theinsideholesmatchto6/0bedrails.
SideRail
SideRail
SideRail
STEP7:Attachthesupportlegswithlevelertothe
slats.Adjustthelevelersonbottomofsupport legs
whennecessary. SupportLeg
Leveler
ThisEndUp
Slat
STEP8:Arrangetheslatsontheslat bearer
equallyandattachtotheslat bearerwith
wood screws (M).
WoodScrews(M)
STEP9:ForCalKingbed,insertwoodcaps(S)intotheholeson
headboardandfootboard.For regularKingbed,skipthisstep. Wood Cap

05-16-2017
Page5/6
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ITEMNO:I07-415-WBR/PEP/BLKKing Panel HB
I07-406-WBR/PEP/BLKKing Rails
I07-410-WBR/PEP/BLKCal King Rails
I07-407-WBR/PEP/BLKKingLowProfile FB
I07-404-WBR/PEP/BLKKing Sleigh HB
FUNCTIONALITY INSTRUCTION
STEP1:Puttheheadboardfacedownon a
softsurface.Insert8wooddowels(G)into
headboard,Thenattachtheleft legand
right legtoheadboardbyusing6bolts(H),
lockwashers(J)andflatwashers(K).
HJK
L
G
I
J
K
L
STEP2:Attachthewoodstretchertothe
legsbyusing4bolts(I),lockwashers(J)
andflatwashers(K).
HBBackside
LeftLeg
Right Leg
WoodStretcher
CenterSupport Leg
HBBackside
STEP3:Attachthecentersupport legto
headboardandwood stretcherby using 3
bolts(H),lockwashers(J)andflat
washers(K).
HBBackside
L
H
K
J
STEP4toSTEP11aresameasOPTION 1
OPTION2: King/Cal KingLPSleighBed
2PoweredUSBPortfor
Charging on bothsides
I07-407
I07-406
I07-415

05-16-2017
Page6/6
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ITEMNO:I07-415-WBR/PEP/BLKKing Panel HB
I07-406-WBR/PEP/BLKKing Rails
I07-410-WBR/PEP/BLKCal King Rails
I07-407-WBR/PEP/BLKKingLowProfile FB
I07-404-WBR/PEP/BLKKing Sleigh HB
2PoweredUSBPortfor
Charging on bothsides
I07-407
I07-410
I07-415
2PoweredUSBPortfor
Charging on bothsides
2PoweredUSBPortfor
Charging on bothsides
I07-407
I07-406
I07-404
I07-407
I07-410
I07-404

05-16-2017
Page1/7
ITEMNO:I07-415-WBR/PEP/BLKKing Panel HB
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
FORINDOORUSEONLY
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
I07-406-WBR/PEP/BLKKing Rails
I07-410-WBR/PEP/BLKCal King Rails
I07-407D-WBR/PEP/BLKKingStorageFB
I07-407D
I07-410
I07-406
I07-415
I07-404-WBR/PEP/BLKKing Sleigh HB
I07-404
I07-406
I07-407D
I07-410
OPTION 1: King/CalKingStoragePanelBed
OPTION 2: King/Cal kingStorageSleighBed

05-16-2017
Page2/7
COMPONENTS LIST:I07-415
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
UTILITYKNIFE(FORCALKING)
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
HARDWARELIST:I07-415
No. Description Sketch Quantity
ABolt 5/16"*2" 6PCS
BBolt5/16"*1-9/16" 3PCS
CBolt5/16"*1-3/8" 4PCS
DLockWasher 5/16" 13PCS
EFlatWasher 5/16"*3/4" 13PCS
FAllenWrench5mm 1PC
HARDWARELIST:I07-406/410
No. Description Sketch Quantity
MWoodScrewM4*1-3/16" 10PCS
NHangerBolt5/16"*3-1/16" 8PCS
OLockWasher5/16" 8PCS
PFlatwasher5/16x5/8" 8PCS
QHexNut5/16" 8PCS
RHexWrench90*25*2mm 1PC
SWoodCap(Onlyfor410) 8PCS
HARDWARELIST:I07-407D
No. Description Sketch Quantity
TWoodScrewM4*1 6PCS
UBolt5/16"*1-3/16" 8PCS
VLockWasher5/16" 8PCS
WFlatwasher5/16x3/4" 8PCS
XAllenWrench5mm 1PC
COMPONENTS LIST:I07-406
No. Description Sketch Quantity
1Bedrails 2PC
2Slats 5PC
COMPONENTS LIST:I07-410
No. Description Sketch Quantity
1Bedrails 2PCS
2Slats 5PCS
3Centerrail(Long) 1PC
COMPONENTS LIST:I07-407D
No. Description Sketch Quantity
1Footboard 1PC
2SupportLeg(forcenterrail) 2PCS
3Supportleg(forpedestal) 3PCS
4Decking 4PCS
5Centerrail(Short) 1PCS
6Filler 1PCS
7Bunfoot 2PCS
COMPONENTS LIST:I07-404
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
HARDWARELIST:I07-404
No. Description Sketch Quantity
GWoodDowel 3/8"*1-9/16" 8PCS
HBolt5/16"*1-9/16" 9PCS
IBolt5/16"*1-3/8" 4PCS
JLockWasher 5/16"13PCS
KFlatWasher 5/16"*3/4" 13PCS
LAllenWrench5mm 1PC
ITEMNO:I07-415-WBR/PEP/BLKKing Panel HB
I07-406-WBR/PEP/BLKKing Rails
I07-410-WBR/PEP/BLKCal King Rails
I07-407D-WBR/PEP/BLKKingStorageFB
I07-404-WBR/PEP/BLKKing Sleigh HB
