Chapter 1 Introduction
ank you for purchasing ASRock Rack EP2C621D16HM-AB / EP2C622D16HM-C
motherboard, a reliable motherboard produced under ASRock Rack’s consistently
stringent quality control. It delivers excellent performance with robust design
conforming to ASRock Rack’s commitment to quality and endurance.
In this manual, chapter 1 and 2 contains introduction of the motherboard and step-
by-step guide to the hardware installation. Chapter 3 and 4 contains the conguration
guide to BIOS setup and information of the Support CD.
1.1 Package Contents
• ASRock Rack EP2C621D16HM-AB / EP2C622D16HM-C Motherboard
(Half Form Factor: 20-in x 6.5-in, 50 cm x 16.5 cm)
• Quick Installation Guide
• Support CD
• 1 x SATA3 Cable (60 cm)
• 1 x MINISAS Cable(12G) 60cm
• 1 x Screw for M.2 Socket
If any items are missing or appear damaged, contact your authorized dealer.
Because the motherboard specications and the BIOS soware might be updated, the con-
tent of this manual will be subject to change without notice. In case any modications of
this manual occur, the updated version will be available on ASRock Rack website without
further notice. You may nd the latest memory and CPU support lists on ASRock Rack
website as well. ASRock Rack’s Website: www.ASRockRack.com
If you require technical support related to this motherboard, please visit our website for
specic information about the model you are using.
http://www.asrockrack.com/support/

2 3
English
1.2 Specications
EP2C621D16HM-AB / EP2C622D16HM-C
MB Physical Status
Form Factor Half Width
Dimension 20’’ x 6.5’’ (50cm x 16.5 cm)
Processor System
CPU Intel® Xeon® Scalable Processor
Socket Dual Socket P, LGA3647
Chipset EP2C621D16HM-AB:
Intel®C621
EP2C622D16HM-C:
Intel®C622
System Memory
Capacity 16 DIMM slots
Type - Six Channels memory technology
- Support DDR4 2666/2400 RDIMM and LRDIMM
Voltage 1.2V
DIMM Sizes RDIMM: 32GB, 16GB, 8GB, 4GB
LRDIMM: 64GB, 32GB
Expansion Slot
PCIe 3.0 x 16 2 slots
Mezzanine slot EP2C621D16HM-AB:
1 x Mezzanine Type A
1 x Mezzanine Type B
EP2C622D16HM-C:
1 x Mezzanine Type C
Storage
SATA Controller 10 x SATA3 (including 1x SATA DOM ports and 1x M.2 ports)
Management
BMC Controller ASPEED AST2500
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management GLAN
Features - Watch Dog
- NMI
Graphics
Controller ASPEED AST2500
VRAM DDR4 16MB
Rear Panel I/O
VGA Port 1 x D-Sub
USB 3.0 Port 2
LAN Port 1 (IPMI) Lan port (RJ45)
LAN Ports with LED (ACT/LINK LED and SPEED LED)

EP2C621D16HM-AB / EP2C622D16HM-C
2 3
English
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, front
LAN LED)
TPM Header 1
IPMB Header 1
Fan Header 4x system Fan (6-pin)
USB 2.0 Header 1 ( supports 2 USB 2.0)
M.2 1 (up to 2280)
SATA DOM 1
Mezzanine EP2C621D16HM-AB:
1 x Mezzanine Type A
1 x Mezzanine Type B
EP2C622D16HM-C:
1 x Mezzanine Type C
System BIOS
BIOS Ty pe 256Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU Temperature Sensing
- System Temperature Sensing
Fan - CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
1.05V_PCH, +BAT, 3VSB, 5VSB
Support OS
OS Microso® Windows® (Server OS)
- Server 2012 R2 (64 bit)
- Server 2016 (64 bit)
Linux®
- RedHat Enterprise Linux Server 6.8 (64 bit) / 7.2 (64 bit)
- CentOS 6.8 (64 bit) / 7. 2 (64 bit)
- SUSE Enterprise Linux Server 11 SP4 (64 bit) /12 SP3 (64 bit)
- FreeBSD 11 (64 bit)
- Ubuntu 16.04/15.10 (64 bit)
Virtual:
- VMWare ESXi 6.5

4 5
English
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-
dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it
will pass the WHQL tests.
* Please refer to our website for the latest OS support list.
* Before installing the Linux OS, please rst enter the BIOS settings, go to
“Advanced” > “Chipset Conguration” and set “IGPU Multi-Monitor” option
to “Disabled”.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C

EP2C621D16HM-AB / EP2C622D16HM-C
4 5
English
1.3 Unique Features
ASRock Rack Instant Flash is a BIOS ash utility embedded in Flash ROM. is con-
venient BIOS update tool allows you to update system BIOS without entering operat-
ing systems rst like MS-DOS or Windows®. With this utility, you can press the <F6>
key during the POST or the <F2> key to enter into the BIOS setup menu to access
ASRock Rack Instant Flash. Just launch this tool and save the new BIOS le to your
USB ash drive, oppy disk or hard drive, then you can update your BIOS only in a
few clicks without preparing an additional oppy diskette or other complicated ash
utility. Please be noted that the USB ash drive or hard drive must use FAT32/16/12
le system.

6 7
English
1.4 Motherboard Layout
16.5cm (6.5 in)
50cm (20 in)
VGA1
1
IPMI_
LAN1
TPM1
1
PSU_SMB1
1
IPMB1
HDLED RESET
PLED PWRBTN
PANEL1
1
UID
1
AUX_PANEL1
11
1
1
SATA_0
11
PCIE1
BIOS
ROM
NMI_BTN1
FRON_LED_LAN34
USB 3.0
T: USB2
B: USB1
11
11
T 1
RSATAPWR1
BMC_SMB2
1
HSBP_1
MEZZ_MB_A1
11
11
DDR4_L1(64 bit, 2 88-pin module, Blue) DDR4_K1 (64 bit, 288-pin module, Blue) DDR4_J1 (64 bit, 288-pin module, Blue) DDR4_J2 (64 bit, 288-pin module, White)
DDR4_G2(64 bit, 2 88-pin module, White) DDR4_G1(64 bit, 2 88-pin module, Blue) DDR4_H1 (64 bit, 288-pin module, Blue) DDR4_I1(64 bit, 2 88-pin module, Blue)
DDR4_F1(64 bit, 2 88-pin module, Blue) DDR4_E1Blue(64 bit, 288-pin module,) DDR4_D1 (64 bit, 288-pin module, Blue) DDR4_D2 (64 bit, 288-pin module, White)
DDR4_A2 (64 bit, 288-pin module, White) DDR4_A1 (64 bit, 288-pin module, Blue) DDR4_B1 Blue(64 bit, 288-pin module,) DDR4_C1 (64 bit, 288-pin module, Blue)
25
29
30
14
15
16
17
18
19
27
CPU1
31
USB_5_6
1
PCIE2
1
CHASSIS_ID1
1
CHASSIS_ID0
NUT80
M2_1
NUT80
M2_1
BMC
ROM
MEZZ_MB_B1
MEZZ_1_C1
Intel
C621/
C622
11
OCU3
OCU1
OCU2
SYSTEM_FAN1
SYSTEM_FAN2
SYSTEM_FAN4
SYSTEM_FAN3
1
J4
CON28
CON27
BAT1
SATA_0_7
PECI1
(EP2C622D16HM)
(EP2C621D16HM-AB)
(EP2C621D16HM-AB)
CPU2
BMC
AST2500
Super
I/O
RAID_1
1
BMC_DEBUG1ME_RECOVERY1 PWM_CFG
26
24
23
32
33
34
35
36
37
38
39
40
7
13
1
2
3
4
5
6
12
9
10
11
20
21
22
28
41
42
43
44
45
46
47
8

EP2C621D16HM-AB / EP2C622D16HM-C
6 7
English
No. Description
1 USB 2.0 Header (USB_5_6)
2 System Panel Header (PANEL1)
3PSU SMBus (PSU_SMB1)
4 Intelligent Platform Management Bus header (IPMB1)
5 Virtual RAID On CPUHeader (RAID_1)
6 Mezzanine Card Slot (MEZZ_MB_B1) (for EP2C621D16HM-AB only)
7 M.2 Socket (M2_1) (Type 2280)
8 PCI Express 3.0 x16 Slot (PCIE2)
9 Chassis ID1 Jumper (CHASSIS_ID1)
10 Chassis ID0 Jumper (CHASSIS_ID0)
11 BMC Debug Header (BMC_DEBUG1)
12 ME Recovery Jumper (ME_RECOVERY1)
13 PWM Conguration Header (PWM_CFG)
14 CPU Socket 1 LGA-3647 (Socket P) (CPU1)
15 3 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, DDR4_C1, Blue)*
16 1 x 288-pin DDR4 DIMM Slot (DDR4_A2, White)*
17 CPU Socket 2 LGA-3647 (Socket P) (CPU2)
18 3 x 288-pin DDR4 DIMM Slots (DDR4_G1, DDR4_H1, DDR4_I1, Blue)*
19 1 x 288-pin DDR4 DIMM Slot (DDR4_G2, White)*
20 System Fan Connector (SYSTEM_FAN1)
21 System Fan Connector (SYSTEM_FAN2)
22 ATX 12V Power Connector (CON27)
23 ATX 12V Power Connector (CON28)
24 System Fan Connector (SYSTEM_FAN4)
25 PSU Header (J4)
26 System Fan Connector (SYSTEM_FAN3)
27 3 x 288-pin DDR4 DIMM Slots (DDR4_J1, DDR4_K1, DDR4_L1, Blue)*
28 OCuLink x4 Connector (OCU2)
29 1 x 288-pin DDR4 DIMM Slot (DDR4_J2, White)*
30 OCuLink x4 Connector (OCU3)
31 OCuLink x4 Connector (OCU1)
32 3 x 288-pin DDR4 DIMM Slots (DDR4_D1, DDR4_E1, DDR4_F1, Blue)*
33 1 x 288-pin DDR4 DIMM Slot (DDR4_D2, White)*
34 Mini SAS HD Connector (SATA_0_7)

8 9
English
No. Description
35 CPU PECI Mode Jumper (PECI1)
36 Non Maskable Interrupt Button (NMI_BTN1)
37 TPM Header (TPM1)
38 Mezzanine Card Slot (MEZZ_MB_A1) (for EP2C621D16HM-AB only)
39 Auxiliary Panel Header (AUX_PANEL1)
40 PCI Express 3.0 x8 Slot (PCIE1)
41 BMC SMBus Header (BMC_SMB_1)
42 Backplane PCI Express Hot-Plug Connector (HSBP_1)
43 Front LAN LED Connector (FRONT_LED_LAN34)
44 SATA DOM Connector (SATA_0)
45 SATA DOM Power Jumper (SATAPWR1)
46 ermal Sensor Header (TR1)
47 Mezzanine Card Slot (MEZZ_MB_C1) (for EP2C622D16HM-C only)
*For DIMM installation and conguration instructions, please see p.19 (Installation of Memory Modules
(DIMM)) for more details.

EP2C621D16HM-AB / EP2C622D16HM-C
8 9
English
4
3
21
1.5 I/O Panel
No. Description No. Description
1VGA Port (VGA1) 3 LAN RJ-45 Port (IPMI_LAN1)*
2 USB 3.0 Ports (USB3_1_2) 4 UID Switch (UID)
LAN Port LED Indications
*ere are two LED next to the LAN port. Please refer to the table below for the LAN port
LED indications.
Dedicated IPMI LAN Port LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10M bps connection or no
link
Blinking Yellow Data Activity Yellow 100M bps connection
On Link Green 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port

10 11
English
1.6 Block Diagram
EP2C621D16HM-AB
LPC
UPI0
UPI1
Channel A
Channel B
Channel C
Channel D
Channel E
Channel F
Channel G
Channel H
Channel I
Channel J
Channel K
Channel L
DMI 3.0 x4
x16 PCIe Gen3
3
PCH
LBG-1G
(TDP 15W)
C621
x16 PCIe Riser
x4 PCIe Gen 3
10x SATA3
M.2
SATA DOM
2x USB 3.0 Rear I/O
x1 PCIe Gen2
BMC IPMI/Dedicate Port
TPM HEADER
DDR4
2x USB 2.0 Internal
SMBus
IPMB HEADER
4x system Fan
UID
x4 PCIe Gen3
x4 PCIe Gen 3
PWR 12V IN
2U4N-F
OCP 2.0 Conn. A
OCP 2.0 Conn. B
x16 PCIe Gen3
X16 PCIe BOM optional
for OCP 2.0 CONN.A and B
x16 PCIe Gen3
x16 PCIe Riser
2U4N-F Seriers
AEP for channel A/D AEP for channel G/J
Intel® Xeon®
Scalable Processor Intel® Xeon®
Scalable Processor

EP2C621D16HM-AB / EP2C622D16HM-C
10 11
English
LPC
UPI0
UPI1
Channel A
Channel B
Channel C
Channel D
Channel E
Channel F
Channel G
Channel H
Channel I
Channel J
Channel K
Channel L
DMI 3.0 x4
x16 PCIe Gen3
3
Lewisbrug-NS
LBG-2
(TDP 17W)
C622
x16 PCIe Riser
10x SATA3
M.2
SATA DOM
2x USB 3.0 Rear I/O
x1 PCIe Gen2
TPM HEADER
DDR4
2x USB 2.0 Internal
SMBus
IPMB HEADER
4x system Fan
UID
x4 PCIe Gen3
x4 PCIe Gen 3
PWR 12V IN
2U4N-F
OCP 2.0 Conn. C
x4 KR BOM optional
for OCP 2.0 CONN.C
x16 PCIe Gen3
x16 PCIe Gen3
x16 PCIe Riser
2U4N-F Seriers
AEP for channel A/D AEP for channel G/J
Intel® Xeon®
Scalable Processor Intel® Xeon®
Scalable Processor
x4 PCIe Gen 3
BMC IPMI/Dedicate Port
EP2C622D16HM-C

12 13
English
Chapter 2 Installation
is is a half form factor (20’’ x 6.5’’, 50 cm x 16.5 cm) motherboard. Before you install the
motherboard, study the conguration of your chassis to ensure that the motherboard ts
into it.
EP2C621/EP2C622 Series are dual socket motherboards that support Intel® Xeon® Scalable
Processor. Please install a primary processor (BootStrap Processor) into “CPU1” socket
and then install a non-Primary Processor (Application Processors) into “CPU2” socket.
*For a single CPU, please install it into “CPU1” socket (framed by a square).
Make sure to unplug the power cord before installing or removing the motherboard. Failure
to do so may cause physical injuries to you and damages to motherboard components.
2.1 Screw Holes
Place screws into the holes indicated by circles to secure the motherboard to the chassis.
Do not over-tighten the screws! Doing so may damage the motherboard.
2.2 Pre-installation Precautions
Take note of the following precautions before you install motherboard components or
change any motherboard settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the motherboard’s components due to static electricity, NEVER
place your motherboard directly on the carpet or the like. Also remember to use a
grounded wrist strap or touch a safety grounded object before you handle the compo-
nents.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded anti-static pad or in
the bag that comes with the component.
5. When placing screws into the screw holes to secure the motherboard to the chassis,
please do not over-tighten the screws! Doing so may damage the motherboard.
Before you install or remove any component, ensure that the power is switched o or the
power cord is detached from the power supply. Failure to do so may cause severe damage to
the motherboard, peripherals, and/or components.

EP2C621D16HM-AB / EP2C622D16HM-C
12 13
English
2.3 Installing the CPU and Heatsink
1. Before you insert the CPU into the socket, please check if the PnP cap is on the socket,
if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to
insert the CPU into the socket if above situation is found. Otherwise, the CPU will be
seriously damaged.
2. Unplug all power cables before installing the CPU.
1
2

14 15
English
1. Before you installed the heatsink, you need to spray thermal interface material between the CPU
and the heatsink to improve heat dissipation.
2. Illustration in this documentation are examples only. Heatsink or fan cooler type may dier.
3
4
180o
