ASROCK Rack C236 WSI4-85 User manual

C236 WSI4-85 / C236 WSI4-85L / C236 WSI4-65L
Quick Installation Guide
www.asrockrack.com
No. Description No. Description
1 USB 3.0 Port (USB3_2) 6 LAN RJ-45 Port (LAN2)
2 USB 3.0 Port (USB3_1) 7 LAN RJ-45 Port (LAN3)
3VGA Port (VGA1) 8 LAN RJ-45 Port (LAN4)
4HDMI Port 9 Front Speaker (Lime)
5 LAN RJ-45 Port (LAN1)
4
2
P/N: 15G065087100AK V1.0
Install the Server Board
Motherboard Layout
Jumper Cap On/O
The server board User's Manual is available for download from the ASRock Rack's ofcial website
at http://www.asrockrack.com.
Take note of the following precautions before you install server board components or change any
server board settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the server board’s components due to static electricity, NEVER place your
server board directly on the carpet or the like. Also remember to use a grounded wrist strap or
touch a safety grounded object before you handle the components.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded anti-static pad or in the bag
that comes with the component.
5. When placing screws into the screw holes to secure the server board to the chassis, please do
not over-tighten the screws! Doing so may damage the server board.
1
1Insert the server board into the chassis.
2Affi x the screws clockw ise into the
mounting holes in all of the corners of
the server board.
Do not over-tighten the screws
When the ju mper cap is placed on t he pins, the
jumper is “Short”. If no jumper cap is placed on the
pins, the jumper is “Open”.
The illustration shows a 3-pin jumper whose pin1
and pin2 are “Short” when a jumper cap is placed on
these 2 pins.
I/O Panel
DDR4_B2 (64 bit, 260-pin module)
17.0cm (6.7 in)
17.0cm (6.7 in)
ATXPWR1
CMOS
Battery
1
5
11
9
7
8
13
12
14
15
16
17
18
FRNT_FAN1
TPM1
1
6
19
20
21
CPU_FAN1
HDLED RESET
PLED PWRBTN
PANEL1
1
SATA_1
34
33
32
DDR4_B1 (64 bit, 260-pin module)
DDR4_A2 (64 bit, 260-pin module)
DDR4_A1 (64 bit, 260-pin module)
1
USB_1_2
USB3_3_4
COM1
1
1
SATA_SGPIO2
1
SATA_SGPIO1
SATA_2
SATA_3
SATA_4
SATA_5
SATA_0
PCIE7
11
SPEAKER1
AUX_PANEL1
1
1
1
1
11
11
SATA_PWR2
1
SATA_PWR1
1
CHASSIS_ID0
CHASSIS_ID1
CHASSIS_ID2
HDMI_SPDIF1
1
SATAPWR1
1
1
1
1
HD_AUDIO1
BIOS
NUT30
NUT42NUT60
NUT80
M2_1
USB 3.0
T: USB3_1
B: USB3_2
HDMI1
LAN4
VGA1
LAN3
LAN2
LAN1
CON1
SEC_OR1
NMI_BTN1
USB3_5
PCH
(RED)
T 1
R
234
22
2324
25
26
27
28
29
30
31
35
36
37
LED_LAN_3_4
C236 WSI4
CLRMOS1
10
1
No. Description
1 COM Port Header (COM1)
2TPM Header (TPM1)
3 CPU Fan Connector (CPU_FAN1)
4 ATX Power Connector (ATXPWR1)
5 12V DC Input Power Connector (CON1)
62 x 260-pin DDR4 SO-DIMM Slots
(DDR4_A2, DDR4_B2)
72 x 260-pin DDR4 SO-DIMM Slots
(DDR4_A1, DDR4_B1)
8 USB 2.0 Header (USB_1_2)
9 USB 3.0 Header (USB3_4_5)
10 Clear CMOS Pad (CLRMOS1)
11 SATA DOM Power Jumper (SATAPWR1)
12 Vertical Type A USB 3.0 (USB3_5)
13 SATA SGPIO Connector (SATA_SGPIO1)
14 SATA3 Connector (SATA_1)
15 SATA3 Connector (SATA_2)
16 SATA3 DOM Connector, (SATA_0), Red
17 SATA3 Connector (SATA_3)
18 SATA3 Connector (SATA_4)
19 SATA3 Connector (SATA_5)
20 Front Fan Connector (FRNT_FAN1)
21 System Panel Header (PANEL1)
22 Speaker Header (SPEAKER1)
23 SATA SGPIO Connector (SATA_SGPIO2)
24 SATA DOM Power Header (SATA_PWR2)
25 SATA DOM Power Header (SATA_PWR1)
26 Auxiliary Panel Header (AUX_PANEL1)
27 PCI Express 3.0 Card Slot 7 (PCIE7)
28 M.2 Socket (M2_1)
29 ermal Sensor Header (TR1)
30 LAN LED Connector (LED_LAN_3_4)
31 HDMI SPDIF Header (HDMI_SPDIF1)
32 Chassis ID2 Jumper (CHASSIS_ID2)
33 Chassis ID1 Jumper (CHASSIS_ID1)
34 Chassis ID0 Jumper (CHASSIS_ID0)
35 Front Panel Audio Header (HD_AUDIO1)
36 ME Recovery Jumper Jumper (SEC_OR1)
37 Non Maskable Interrupt Button (NMI_BTN1)
6
5
3
2
1
4 87 9
