ASTER TECHNOLOGIES FT-650 User manual

FLOW METER
FT-650
1
FM 564741
ASTER TECHNOLOGIES
ISO-9001:2008 Certified Company
(Full bore type)

sr loA te Techno gies
TECHNICAL SPECIFICATIONS
2. Enclosure
1. Physical dimensions
ABS Weather proof IP 65
Relay output for batch quantity
105 X 105 X 130 mm
90 mm X 90 mm (panel cut out)
3. Mounting Field/Panel
3 seconds
+ 2% of FSD
1 no. 5 A @ 230 VAC
16 X 2 Alphanumeric LCD
Using front panel keypad.
From sensor
230V A.C./115V A.C./24V D.C.
4-20mA Current
RS-485 Optional
0.01/0.1 depending on range
6. Flow rate sampling
7. Resolution
8. Accuracy
9. Alarms/Control relays
10. Display
11. Calibration/Set point
4. Supply power
13. Output
5. Display range
12. Input
INDICATOR
3
Sensor
1.Type Full bore turbine
2.Fluid Water
3.S.G of medium 1
4.Max operating pressure 5.0 Kg/
cm²
6.Bearing Ceramic with SS ball
5.Max operating Temp 60°C
7.Size 1”
2”
8.End connection BSPM
BSPM
9.Face to face distance(mm) 205
260
10.Range ( LPH) 250-8000
1000-30000
11.Impeller Polypropylene
0-999999.9 m³/0-9999999 liters

Aster Tcnologies
eh
4
12.Body Material Glass filled nylon
3 mtr 3 core Teflon
only for water of normal pH.For any other applications
contact nearest dealer
** Each sensor is calibrated with specific meter. Hence use the
sensor & meter as a single set.
GETTING AQUAINTED WITH THE METER:
This meter is user friendly & easy to understand. Its operation
will be clear when we go through all the parts of the meter.
It is the main part of flow meter. It consists of a
turbine having magnets on its periphery. As the turbine rotates
pulses are generated and sensed. These pulses are proportional to
the flow through pipe.
This is the unit that processes the information received
from sensor and displays actual flow in the line. this unit
also controls the flow by transmitting signals to dosing pumps,
hooters, valves etc through inbuilt relays.
WIRING CONNECTIONS:
Output
B RG
21
Sensor 1Sensor 2
5
34
Sr.No.
MAINS RELAY
NO X X NCC XN P
Not Appl
Factor:
Part no.# FT-650 FB 2 1 1 N
2
X
-
-
1
X
+
+
With relay output only
4-20 mA current O/P with relays
RS-485 O/P with relays
Description
Current O/P
RS 485 O/P(Tx)
Terminal details
Part no.
FT-650 FB 2 1 1 NNot appl.
FT-650 FB 2 1 1 C
FT-650 FB 2 1 1 R
13.Cable
* Suitable
1. SENSOR:
2. METER :
4
X
G
3
X
B
With one sensor only
With two sensors
Description
SENSOR 2
Terminal details
FT-650 FB 2 11 1 N Not appl.
FT-650 FB 2 21 1 N
5
X
R
Part no.

Aster Tcnologies
eh
INSTALLATION GUIDELINES:
1)METER: Meter has been designed to suit panel as well as field
mounting as shown below.
5
PANEL MOUNT APPLICATION FIELD MOUNT APPLICATION
MOUNTING POSSIBILITIES
Sensor Cable
10 X D 10 X D
Inlet Outlet
1) While installing the sensor in line follow the arrow direction on the
sensor body.
2) Sensor will be ideally located in horizontal line with minimum
straight run as mentioned above.
3) Ensure upstream & downstream of 10 inches & 20 inches on
either side for 1” & 2” line size respectively.
4) It is recommended not to loosen or tighten NUTS of the
sensor while fitting on line (use extra union connectors on both
ends).
2)SENSOR:
Press this downwards
& Push forward to lock
Press this downwards
& Pull out to unlock.

Aster Tcnologies
eh
ON SITE CALIBRATION OF METER:
Each flow meter normally comes duly calibrated along
with the corresponding sensor (for a given line size). In case re -
calibration is required at site,the previously programmed channel
constant can be increase/decreased in proportion to the difference
n the reading between the actual flow and the displayed reading.
Follow the instructions given below.
KEY TO BE PRESSED
DISPLAY
Scroll & select ch simultaneously
PASSWORD :000
Enter the password 123 using scroll & select ch keys
CH1 CONSTANT
ml/PULSE:_ _ _
previously set value
Required value can be set by scroll & select ch key
EXIT
In case of a dual sensor meter, CH2 CONSTANT can be
KEY TO BE PRESSED
DISPLAY
Scroll & select ch simultaneously
PASSWORD :000
Enter the password 123 using scroll & select ch keys
CH1 CONSTANT
ml/PULSE:_ _ _
previously set value
Required value can be set by scroll & select ch key
CH2 CONSTANT
ml/PULSE:_ _ _
previously set value
Required value can be set by scroll & select ch key
EXIT
PROGRAMMING FLOW MONITOR:
Aster Flow Monitor is user friendly and can be operated in
following different modes as:
Batcher Mode/Totaliser Mode
Flow Comparator Mode
Rate switch mode
Pulsar mode
[To change the settings i.e . (operating the meter in a mode
other than Totaliser) contact nearest dealer.]
6
Flow rate indicator

BATCHER MODE:
In this mode the relay is programmed to operate after a
fixed quantity of water passes through the sensor. When the power
to the unit is switched ON, it displays
ASTER
And then FR1: 00000.0 Lit /hr
Press scroll key to toggle between Total O/P T1 : 00000.0 Lit &
Batch Qty B1 : 00000.0 Lit
The unit will count down the batch volume till value
becomes zero after which relay will get energized.Relay could
Operate in the following modes in case of a batcher.
(1) Auto reset: In this mode relay will give a 2 sec pulse and
will get reset aNd meter will start counting down the next
batch.
(2) Manual Reset:
Aster Tcnologies
eh
Once programmed quantity of water has
passed through the sensor,relay will get energized with
“BATCH OVER “indication on the display.Relay can be
reset by pressing ACK. key
(3) Two Relay Operation: When 80% of the water batch
quantity passes through sensor ,the first relay gets
energized .This relay can be reset by pressing the ACK. key
and second relay will get energized with “BATCH OVER“
indication on display after programmed quantity of water
passes. Relay can be reset by pressing ACK. key
HOW TO SET THE RELAY OPERATION MODE:
7
KEY TO BE PRESSED DISPLAY
Scroll & select simultaneously PASSWORD :000
Enter the password 234 using scroll & select keys
Menu ENGG UNITS
MENU CH1 ENGG UNITS
Menu m³
m³can be changed to Liters by select ch key.
Menu QUIT
Menu RELAY OPERATION
Menu CH1 RELAY OPRN
Menu MANUAL RESET
MANUAL RESET can be changed to AUTO RESET by select
ch key.

Aster Tcnologies
eh
HOW TO DO BATCHER SETTINGS:
KEY TO BE PRESSED DISPLAY
Menu View settings
The display scrolls through all the settings of meter and
finally comes to --
CHANGE SETTINGS
Menu CH1 SETTINGS
Menu
CH1 BATCH QTY (and th en
previously set value)
Set required batch quantity by using scroll & select ch key
Menu QUIT
8
Menu QUIT
Menu EXIT
HOW TO RESET THE TOTALISER READING:
By using this function we can reset various values such as Totaliser
reading, batch quantity, batch count er etc.
KEY TO BE PRESSED DISPLAY
Scroll & select ch simultaneously PASSWORD :000
Enter the password 456 using Scroll & Select ch keys.
Menu CLR CH1 TOT? NO
To reset the total press Select ch key CLR CH1 TOT? YES
Menu CLR CH1 BATCH? NO
CLR CH1 BATCH? YES
Menu CLR CH1 CNTR? NO
CLR CH1 CNTR? YES
Menu Exit
To reset the total press Select ch key
To reset the total press Select ch key
FLOW COMPARATOR MODE:
This mode is ideal for Reverse Osmosis systems. Here the
meter is supplied with 2 sensors (one for permeate line and the
other for reject or feed line). The meter displays both the flow
rates and also calculates the % RECOVERY. One could set the relay
at a particular recovery % and relay would get energized
whenever the system recovery crosses the set point.

Aster Tcnologies
eh
NOTE:Second sensor is normally supplied for reject flow sensing.
This can however be assigned as the inlet sensor. To change the
factory settings, contact nearest dealer or supplier.
9
Recovery can be calculated by the formula:
Permeate flow Rate (PR)
% Recovery =
Permeate flow rate(PR) + Reject flow rate (RR)
The relay will get energized, if actual recovery exceeds the set
value.
HOW TO SET THE FLOW COMPARATOR:
KEY TO BE PRESSED DISPLAY
Menu View settings
The display scrolls through all the
settings of meter and comes to
Change Settings?
Menu CH1 SETTINGS
Menu
RECOVERY: _ _ _ _ previously set
value
Set required recovery quantity by using scroll & select ch key
Menu
HYSTERESIS:_ _ _ _ previously set
value
Set required Hysteresis using scroll & select ch key
Menu QUIT
Menu Display scrolling
Menu Auto
Auto can be changed to manual by select ch key & vice versa
Menu EXIT
Menu
IN CASE OF 4-20mA OUTPUT:
In case of transmitter,meter takes the sensor input
& gives 4-20mA output current.Factory settings for ZERO
(value of flow at which transmitter would give 4 mA current) & SPAN
(value of flow at which transmitter would give 20 mA current) are:
Reading
4mA
20mA
Current Output(mA)
00.00
X 100

10
Instrument also works as 4_20 mA current simulator.It gives 4 mA & 20 mA
current for calibration of other instruments.Follow the below guideline:
Aster Tcnologies
eh
IN CASE OF RS-485 OUTPUT:
In case of Flow meter with RS-485 output,if number of instruments are
connected through same wire then each instrument should have it’s specific
address(called as meter address).To set the meter address follow the
below guideline.
Actual value
MENU
Use VIEW & ACK.key to change the address.
ENTER THE PASSWORD 0345 USING VIEW & ACK. KEY
KEY TO BE PRESSED DISPLAY
PASS
VIEW & ACK
MENU Addr
Previously set meter address
ENTER THE PASSWORD 0420 USING VIEW & ACK. KEY
20 mA
KEY TO BE PRESSED DISPLAY
PASS
VIEW & ACK
MENU
MENU
4 mA
Instrument will give 4 mA current
Instrument will give 20 mA current
End
MENU
Actual reading
MENU
To change the SPAN settings follow below guideline:
Menu
000.00 m3/hr.
previously set value
Required value can be set by scroll & select ch key.
Scroll & select ch simultaneously
PASSWORD :000
Enter the password 678 using scroll & select ch keys
Menu
SPN

Aster Tcnologies
eh
*MOV – 14mm Dia. and 320V AC ** FUSE - 630mA 11
TROUBLE PROBABLE CAUSE ACTION
Flow less than the
minimum sensing
value required
Ch f
sensing
velocity.
Turbine not moving
freely.
Display
remains zero
even if flow is
there.
Wrong wiring
Adequate straight run
is not provided at
upstream, downstream
of sensor.
Connect the wires as per
Provide straight run as per
guidelines.
Provide abend between the
valve and the sensor.
Meter shows
error in
reading
Scale factor disturbed
No display
High voltage
Frequent
Fuse failure MOV short Replace MOV* as well as
FUSE**
ecK i any downstream
valve is closed. Open the
valve, remove the sensor
from the fitting and check
the change in reading by
physically rotating the
turbine. If meter shows
reading check whether
there is actual flow.
Change the fitting if
normal flow is less than the
minimum
Check the direction Arrow.If
it is wrong correct the
orientation.
Remove the sensor.Clean
Turbine & ensure free
movement of turbine wheel
Refer opening instructions
(Page 12)
Check factor.Correct factor
as mentioned on sensor.
Check input supply & make
proper connections
Check MOV/FUSE; if it is
burnt then replace it with
new one
wiring diagram.
Recalibrate the meter
In case of multiple
instruments ensure that
the serial number of sensor
& meter is same.
TROUBLESHOOTING:

Parts List
Turbine
Sensor Cable
Ball
O-ring
Sensor body
Bush
Pipe
Nut
Red +5V D.C.
-
Black- Ground
Green - Output
Opening Instructions:
Aster Tcnologies
eh
1) While opening the sensor for cleaning always ensure that
the arrow is pointing downwards before removing the turbine
to avoid falling of the ball.
*In case sensor is being connected directly to a PLC/Pulse
counter it is recommended to put a pull up resistance of1kohm
across O/P(Green) and Supply(Red) wires.
Contact us:
ASTER TECHNOLOGIES,
Email: [email protected]
12
Quick Reference :
Sr.No.
Password
Feature
Page no.
1
123
Calibration
6
2
234
Relay Operation
7
3
456
Reset readings
8
4----
Batcher settings
8
5420
Current output
10
6678
Span settings
10
7345
10
Meter address
(In case of RS 485 O/P only)
Tele No.:91-020-32517858
Revision no.05.21.12.13
Issue date: 01/01/2014
Survey No. 32/1B/2,
Behind Hotel Shivai,
Kondwa-Pisoli Road,Pisoli
Tal:Haveli Dist.: Pune
Pune-411060
