Endress+Hauser SpectraSensors OXY5500 User guide

P/N 4900002247 rev B
OXY5500 Analyzer
Safety Manual

Products of
4333 W Sam Houston Pkwy N, Suite 100
Houston, TX 77043-1223
Tel: [phone]
Fax: [phone]
www.spectrasensors.com
Copyright © 2017 SpectraSensors, Inc. No part of this manual may be reproduced in
whole or in part without the express written permission of SpectraSensors, Inc.
SpectraSensors reserves the right to change product design and specifications at any
time without prior notice.
OXY5500 Analyzer
Safety Manual

Revision History
Revision Engineering Order Date
A EO16609 Dec. 21, 2016
B ECR17051 April 7, 2017

Installation Safety Manual i
TABLE OF CONTENTS
List of Tables/Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
1: Introduction
How to Use This Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Conventions Used in this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Documents Provided with the OXY5500 Analyzer . . . . . . . . . . . . . . . . . . . . . . . 1-1
SpectraSensors Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
2: General Safety Information
Intended Equipment Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Warning Labels and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Equipment Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Instructional Symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Analyzer Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Equipment Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Personnel Responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Potential Risks Affecting Personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Mitigating risks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Electrocution hazard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Explosion hazard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Electrostatic discharge. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
3: Equipment Installation
Mounting the Analyzer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Lifting/carrying the analyzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Environmental Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Opening/Closing the Analyzer Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Protective chassis and ground connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Protective ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Chassis ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Electrical Wiring Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
External Circuit Breaker Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
4: Equipment Operation
Operating Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Intermittent Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
To prepare, clean and decontaminate the analyzer for shipment or storage . . 4-1
Cleaning the Instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
5: Maintenance and Service
Fuse Ratings and Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Service Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Customer Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Before contacting Technical Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Appendix A: Specifications
Technical Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Index-1

OXY5500 Analyzer
ii 4900002247 rev. A 4-7-17
THIS PAGE INTENTIONALLY LEFT BLANK

Installation Safety Manual iii
LIST OF TABLES/FIGURES
Figures
Figure 5–1. Inside cabinet view - fuse location . . . . . . . . . . . . . . . . . . . . . . . 5-1
Tables
Table 5–1. Fuse specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Table A–1. OXY5500 analyzer specifications. . . . . . . . . . . . . . . . . . . . . . . . . A-1

OXY5500 Analyzer
iv 4900002247 rev. A 4-7-17
THIS PAGE INTENTIONALLY LEFT BLANK

Installation Safety Manual 1–1
1 - INTRODUCTION
SpectraSensors’ OXY5500 analyzer is a stand-alone oxygen meter designed to
detect oxygen in gases such as Natural Gas and air. Its design is based on
fluorescence quenching technology that creates very stable, internally
referenced measured values.
In order to operate the analyzer safely, it is important to closely review all
information contained in the manuals provided with the analyzer. Refer to
Documents Provided with the OXY5500 Analyzer. This manual is divided
into the following sections:
•General Safety Instructions (Chapter 2)
•Equipment Installation (Chapter 3)
•Equipment Operation (Chapter 4)
•Equipment Maintenance and Service (Chapter 5)
How to Use This Manual
Take a moment to familiarize yourself with this manual by reading the Table
of Contents. This manual has been written to address the most common
safety issues related to the installation and operation of the OXY5500 analyzer.
Additional information has been provided with the purchased analyzer to
instruct qualified users in the general installation, operation and maintenance
of the equipment.
Images, tables and charts have been included with instruction to provide a
visual understanding of the analyzers and its functions. Special symbols are
also used to provide the user with key information regarding the system
configuration and/or operation. Users should pay close attention to this
information.
Conventions Used in this Manual
In addition to the symbols and instructional information, this manual is created
with “hot links” to enable the user to quickly navigate between different
sections within the manual. These links include table, figure and section
references and are identified by a pointing finger cursor when rolling over
the text. Simply click on the link to navigate to the associated reference.
Documents Provided with the OXY5500 Analyzer
Each OXY5500 analyzer shipped from the factory is packaged with documents
specific to the model that was purchased. Generally, the documents included
with each shipment are:
•Safety Manual
•Operator’s Manual

OXY5500 Analyzer
1–2 4900002247 rev. B 4-7-17
•Sample Conditioning System (SCS) Manual, if applicable
•Calibration Certificate
•OXY5500 Service Software Manual
SpectraSensors Overview
SpectraSensors, Inc. is a leading manufacturer of technologically advanced
electro-optic gas analyzers for the industrial process, gas distribution and
environmental monitoring markets. Headquartered in Houston, Texas, Spec-
traSensors was incorporated in 1999 as a spin-off of the NASA/Caltech Jet
Propulsion Laboratory (JPL) for the purpose of commercializing space-proven
measurement technologies initially developed at JPL. SpectraSensors was
acquired by the Endress + Hauser Group in 2012, which has expanded our
reach in the global marketplace.

Installation Safety Manual 2–1
2 - GENERAL SAFETY INFORMATION
Each analyzer shipped from the factory includes documentation for the purpose
of relaying installing, operating and safety instructions to the responsible party
and/or operator of the equipment. This chapter reviews the general safety
instruction for every OXY5500 analyzer.
Intended Equipment Use
The OXY5500 analyzer is intended for use as instructed in the documentation
package provided with the equipment. This information provided should be
read and referenced by anyone installing, operating or having direct contact
with the OXY5500 analyzer. Any use of the equipment in a manner not specified
by SpectraSensors could impair the protection provided by the equipment.
Warning Labels and Cautions
Instructional icons are provided in all equipment manuals and on the OXY5500
analyzer to alert the user of potential hazards, important information and
valuable tips. Following are the symbols and associated warning and caution
types to observe when servicing the analyzer. Some of these symbols are
provided for instructional purposes only and are not labeled on the system.
Equipment Labels
Warning statement for hazardous voltage. Contact may cause
electric shock or burn. Turn off and lock out system before
servicing.
Failure to follow all directions may result in damage or
malfunction of the analyzer.
PROTECTIVE EARTH GROUND - Symbol indicates the
connection point of the ground wire from the main power source.
Power specifications for AC connection.

OXY5500 Analyzer
2–2 4900002247 rev. B 4-7-17
Power specifications for DC connection.
Access for signal wiring.
Follow instructions to avoid
electrostatic discharge.
Use appropriate tools to
avoid electrostatic
discharge.
Substitution of components
may void certification.
Switch off power before
replacing components to
avoid explosion risk.
Switch off power before
disconnecting system to
avoid explosion risk.
Ensure grounding wire is
connected at all times
during operation.
WARNING - POTENTIAL ELECTROSTATIC CHARGING HAZARD –
SEE INSTRUCTIONS
______________________________________________________
AVERTISSEMENT - DANGER DE CHARGE ELECTROSTATIQUE
POTENTIELS - VOIR LES INSTRUCTIONS
WARNING - USE DAMP CLOTH TO CLEAN DISPLAY AND KEYPAD
TO AVOID STATIC ELECTRICITY DISCHARGE.
______________________________________________________
AVERTISSEMENT - AUX CHARGES ELECTROSTATIQUES.
UTILISER UN CHIFFON HUMIDE POUR NETTOYER L’AFFICHEUR
ET LE CLAVIER.
WARNING - EXPLOSION HAZARD – SUBSTITUTION OF COMPO-
NENTS MAY IMPAIR SUITABILITY FOR CLASS I, DIVISION 2 OR
ZONE 2 (II 3G)
______________________________________________________
AVERTISSEMENT - RISQUE D'EXPLOSION – LA SUBSTITUTIOND
E COMPOSANTSP EUTR ENDRE CE MATERIEL INACCEPTABLE
POUR LES EMPLACEMENTS DE CLASSE I, DIVISION 2 OU ZONE 2
(II 3G)
WARNING - EXPLOSION HAZARD - DO NOT REPLACE ________
UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS
KNOWN TO BE NON-HAZARDOUS
______________________________________________________
AVERTISSEMENT - RISQUE D'EXPLOSION - COUPER LE
COURANT OU S'ASSURER QUE L'EMPLACEMENT EST DESIGNE
NON DANGEREUX AVANT DE REMPLACER LE ______
WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT EQUIP-
MENT UNLESS POWER HAS BEEN SWITCHED OFF OR THE
AREA IS KNOWN TO BE NON-HAZARDOUS
______________________________________________________
AVERTISSEMENT - RISQUE D'EXPLOSION - AVANT DE
DECONNECTER L'EQUIPEMENT, COUPER LE COURANT OU
S'ASSURER QUE L'EMPLACEMENT EST DESIGNE NON
DANGEREUX
CAUTION: DO NOT OPERATE MACHINE WITH GROUNDING WIRE
DISCONNECTED
_______________________________________________________
ATTENTION: NE PAS METTRE L'APPAREIL EN MARCHE QUAND
LE CON DUCTEUR DE MISE A LA TERRE EST DEBRANCHE.

General Safety Information
Installation Safety Manual 2–3
Instructional Symbols
Analyzer Technical Specifications
For each model of the OXY5500 analyzer, a set of technical specifications are
provided that outline recommended equipment settings and ratings. Refer to
Appendix A for technical specifications for the OXY5500.
Equipment Rating
The OXY5500 is a stand-alone precision system enclosed in a NEMA 4X and
IP66 rated stainless steel case. The rugged design and low power consumption
makes the OXY5500 ready for an indoor or outdoor application in Class 1,
Division 2, Groups A, B, C and D environments according to CSA standards
CAN/CSA C22.2 No. 0-M91, CAN/CSA C22.2 No. 94.2-07 / UL50E, CAN/CSA
C22.2 No. 213-M1987, CAN/CSA 61010-1-12, ANSI/UL 61010-1, CAN/CSA
C22.2 No. 60529:05, ANSI/ISA 12.12.01 - 2007 and ANSI/IEC 60529 - 2004.
In addition, the Oxygen analyzer is also marked as II 3 G, Ex nA IIC T3 Gc
IP66 and certified according to ATEX/IECEx standards IEC/EN 60079-0 and
IEC/EN 60079-15.
All electrical and communications specifications are provided in the OXY5500
Operator’s Manual (P/N 4900002239).
General notes and important information concerning the
installation and operation of the analyzer.
Failure to follow all directions may result in damage or
malfunction of the analyzer.
Warning statement for hazardous voltage. Contact may cause
electric shock or burn. Turn off and lock out system before
servicing.
Maximum voltage and current specifications for fuses.

OXY5500 Analyzer
2–4 4900002247 rev. B 4-7-17
Personnel Responsibility
Potential Risks Affecting Personnel
This section addresses the appropriate actions to undertake when faced with
hazardous situations during or before service of the analyzer. It is not possible
to list all potential hazards within this document. The user is responsible for
identifying and mitigating any potential hazards present when servicing the
analyzer.
Mitigating risks
Refer to the instructions for each situation listed below to mitigate associated
risks.
Electrocution hazard
1. Shut off power at the main disconnect external to the analyzer.
2. Open enclosure door.
If service must be performed with power engaged:
1. Note any live electrical components and avoid any contact with
them.
2. Only use tools with a safety rating for protection against accidental
contact with voltage up to 1000V (IEC 900, ASTF-F1505-04, VDE
0682/201).
Explosion hazard
Any work in a hazardous area must be carefully controlled to avoid creating any
possible ignition sources (e.g., heat, arching, sparking, etc.). All tools must be
The safety of the analyzer is the responsibility of the installer and
the organization he/she represents.
Technicians are expected to follow all safety protocols established
by the customer that are necessary for servicing the analyzer.
This may include, but is not limited to, lockout/tagout procedures,
toxic gas monitoring protocols, PPE requirements, hot work
permits and other precautions that address safety concerns
related to performing service on process equipment located in
hazardous areas.
Complete this action before performing any service that requires
working near the main input power or disconnecting any wiring or
other electrical components.

General Safety Information
Installation Safety Manual 2–5
appropriate for the area and hazards present. Electrical connections must not
be made or broken with power on (to avoid arching).
Electrostatic discharge
Use a damp cloth to clean the display and keypad to avoid static electricity
discharge.
Adhere to all warning labels to prevent damage to the unit. Refer to “Warning
Labels and Cautions” on page 2-1.

OXY5500 Analyzer
2–6 4900002247 rev. B 4-7-17
THIS PAGE INTENTIONALLY LEFT BLANK

Installation Safety Manual 3–1
3 - EQUIPMENT INSTALLATION
The information in this chapter is related to safety during the equipment
installation.
Mounting the Analyzer
The OXY5500 is manufactured for wall installations. Depending on your
application and configuration, the analyzer will come mounted on a plate or
Unistrut®(or equivalent) metal frame. Refer to the OXY5500 Operator’s Manual
(P/N 4900002239) or the layout diagrams provided with the purchased
OXY5500 analyzer for detailed mounting dimensions.
Lifting/carrying the analyzer
At approximately 5.44 Kg (12 lbs) without sample conditioning system (SCS),
the OXY5500 can easily be lifted from the packaging and moved to the
installation location. Take care to lift or carry the analyzer by the enclosure and
not by any ancillary probes or cables, or damage may occur.
If the analyzer is configured with an optional integrated sample conditioning
system (SCS), two individuals may be required to lift and move the analyzer
system. Refer to the OXY5500 SCS Overview Manual (P/N 4900002244) for
more information.
Environmental Considerations
The analyzer should be mounted in an enclosure or, if outside, under a sun
shade to prevent direct sunlight exposure.
The analyzer shall not be mounted more than 2,000 meters above sea level.
Mounting brackets for equipment intended to be mounted on a
wall and/or part/s that support heavy loads shall withstand four
times the maximum static load.
When mounting the analyzer, be sure to position the instrument
so that it is not difficult to operate adjacent devices. Allow 1 meter
(three feet) of room in front of the analyzer and any switches.
It is critical to mount the analyzer so that the supply and return
lines reach the supply and return connections on the chassis,
while still maintaining flexibility, so that the sample lines are not
under excessive stress.

OXY5500 Analyzer
3–2 4900002247 rev. B 4-7-17
Opening/Closing the Analyzer Enclosure
Protective chassis and ground connections
Before applying any electrical signal or power, the protective and chassis
grounds must be connected.
Protective ground
•The protective ground (AWG and mm2), routed with the phase and
neutral wire, shall be equal or greater than the phase or neutral
wires.
•The protective ground shall be connected in such a way that it is
unlikely to be removed during servicing that does not require
disconnection of the protective conductor.
•The protective ground is the first wire to be connected to the analyzer
and the last one to be removed; its color can be either solid green or
green/yellow.
Chassis ground
•The chassis wire must be at least 6mm2.
•The chassis ground wire shall be connected to the rod or frame of the
shelter as soon as the protective ground wire is connected to the
instrument.
Hazardous voltage and risk of electric shock.Failure to
properly ground the analyzer may create a high-voltage shock
hazard.
Conduit seals or Ex e cable gland should be used where
appropriate in compliance with local regulations.
Apply 20 in-lbs of torque on each bolt to ensure the door is closed
properly to maintain required ingress protection.

Equipment Installation
Installation Safety Manual 3–3
Electrical Wiring Requirements
External Circuit Breaker Requirements
After installing all necessary conduit runs, make sure any remaining conduit
hubs, if installed with the Analyzer (Module 1) enclosure, are CSA and/or UL
Certified and rated Type 4X and/or IP66.
Interconnection of the analyzer enclosure shall be accomplished
using wiring methods approved for Class 1, Division 2 hazardous
locations as per the Canadian Electrical Code (CEC) Appendix J
and the National Electric Code (NEC) Article 501. The installer is
responsible for complying with all local installation codes.
Because the breaker in the customer-provided power distribution
panel or switch will be the primary means of disconnecting the
power from the analyzer, the power distribution panel should be
located in close proximity to the equipment and within easy reach
of the operator, or within 10 feet of the analyzer.
The customer-provided circuit breaker must be marked as the
disconnecting device for the analyzer. This switch or breaker shall
not interrupt the protective earth conductor.
The electrical installation to which the analyzer is connected must
be protected against transients. The protective device must be set
at a level not exceeding 140% of the peak rated voltage values at
the power supply terminals.
Thread lubricant must be applied on all conduit hub threaded
connections. SpectraSensors recommends using STL8 lubricant
on all conduit screw thread and it’s taped openings.

OXY5500 Analyzer
3–4 4900002247 rev. B 4-7-17
THIS PAGE INTENTIONALLY LEFT BLANK
