AstroAI 100 PSI User manual

V1.0
100PSI Portable Air
Compressor User Manual

Thank you for purchasing the 100PSI Portable Air Compressor from
AstroAI.
This product is a programmable Air Compressor Pump with digital
display that is designed to be used to monitor air pressure while
inflating. Once the pre-set air pressure is reached, the Air
Compressor will automatically shut off.
For optimal performance and safety, please read and follow all of the
instructions below before operating the device. Please keep this
manual for future reference.
We hope you enjoy your new Air Compressor! Thank you again for
choosing AstroAI, if you have any questions or concerns regarding
your product, please contact us at [e-mail].

WARNING
● Please read the instructions carefully before use. Incorrect usage
may damage the product.
● Check the preset pressure value before use. The preset pressure
value should match the object to be inflated.
● PSI, KPA, Bar, KG/CM² are the pressure units, not the pressure
levels.
● Please do not use this product in the rain or where there are any
liquids.
● Keep out of reach of children, if there are children nearby make sure
they are properly supervised.
● Keep the device away from fire, corrosive gases, liquids, and strong
magnetic fields.
● Do not aim the nozzle at people or any part of a human body.
● Contains small accessories which are a choking hazard for young
children.
● Risk of electric shock, do not use air compressor if it is damaged or
if wires are exposed.
● Do not use it on a 24V car power.Connect the pump to a 12V DC,
10A cigarette lighter;Use an AC to DC power converter if you want
to use AC power.
● Avoid extended and continuous use. The optimum time for
continuous use is 15 minutes.
● After extended use, let the pump rest for 10 minutes before using it
again.
● Do not store the air compressor in high-temperatures or in a humid
environment.
● When not in use, disconnect the air compressor from all power
sources.
● The air nozzle is compatible with all Schrader valves. For use with
cars, small trucks and SUVS, motorcycles, and bicycles. The pump
is not intended for use with high pressure or large volume
applications.
● Do not over-inflate tires. High pressure air can cause injury.
● Move the product by using the handle. Do not drag the product by
pulling the power cord or the air hose.

DIAGRAM
3LED Light
Air Pressure Gauge
1
Carrying Handle
2
Inflation Tube
4
LED Light Switch
5
Inflation Switch
6
Power Cord
7
Long Cone Adapter
9
Needle Valve Adapter
10
Short Cone Adapter
11
Replacement Fuse
12
Valve Extender
13
12V Cigarette Lighter Plug
8
9 10 11 12
● During use, do not touch any parts of the air compressor apart from
the switch and handle. The air pump gets hot during use and stays
hot for some time after.
● Do not use chemical reagents to clean the air compressor. Only use
mild soap and a cloth dipped in hot water to clean the plastic parts.
1
2
3
4
5
6
7
8
13
Easy-Connect Schrader ValveAdapter
14
14

● Ensure that your car engine is running before you use it.
OPERATION INSTRUCTIONS
● Use the “M” button to set your desired pressure unit (4 options:
KPA,PSI, BAR, KG/CM²).
● Use the “ + ”and “ - ” buttons to set the
chosen pressure. Use the tire pressure
guide on the inside of the driver’s door for
guidance. Make sure that the preset
pressure is higher than the current
pressure of your tire.
● Remove the valve cap from the valve stem
of your tire, then attach the air nozzle to the
valve stem.
Tips:In order to get a strong seal, place the
nozzle directly onto the tire valve. Putting the
air chuck on the nozzle from an angle could
result in an improper seal or inaccurate
reading. Once the air chuck is placed, thread
the nozzle to create a strong seal.
● Plug the inflator pump into your car’s 12V outlet securely, to ensure
a strong connection.
PSI BAR KPA Kg/cm²
PSI
Kg/cm²
BAR
KPA
M
PSI
Kg/cm²
BAR
KPA
M

SPECIFICATIONS
Working Voltage DC 12V
Maximum Amps 10 Amps
Power 120W
Inflating Speed 1.23 CFM (35L/ Min)
Maximum Working
Pressure 100 PSI
Display Units
Continuous Operating
Time 15 Minutes Maximum
Power Cable Length 10ft (3 m)
Dimensions 8.4*6.8*3.9in
KPA, PSI, BAR, KG/CM
²
● After inflation is complete, turn off the inflation switch
and disconnect the power cord from the 12V outlet,
unscrew the valve connector, place the tire valve cap
back on the valve stem.
● The LED flashlight is controlled by the light switch.
Press the button to switch on or off.
● Turn on pump with the power switch by pressing the
inflation switch.

TROUBLESHOOTING
Air Compressor
will not inflate
Air Compressor
is operating
abnormally
Air leaking
through hose
● Ensure the in-line fuse is securely inserted
correctly;replace fuse if necessary.
● Check vehicle cigarette lighter fuse, it should
berated at 10A or higher.
● Ensure there is a strong connection with the
power cord and 12V socket.
● Preset tire pressure is lower than current tire
pressure, increase the preset tire pressure to
the manufacturer recommended level.
● The inflation nozzle is not connected properly
to the tire’s valve stem.
● The 12V socket is not connected securely.
● Preset tire pressure is lower than current tire
pressure, increase the preset tire pressure to
the manufacturer recommended level.
● Ensure there is a firm connection between the
air nozzle and the tire valve.
Slow inflation
Shuts off after
extended use
● The inflation nozzle is not connected properly
to the tire’s valve stem.
● Excessive use will slow the inflation rate of the
pump. Let cool for 10 minutes.
● If the air compressor continues to run for more
than 15 minutes, it will shut off due to
overheating protection. Please let it cool for 10
minutes.

● 1 x AstroAI 12 Volt Air Compressor
● 1 x User Manual
● 1 x Inflation Needle
● 2 x Cone Inflation Adapters
● 1 x Schrader Valve Adapter
● 1 x Valve Extender
● 1 x Replacement Fuse
Each AstroAl Portable Air Compressor will be free from defects in its
material and works. This warranty does not cover fuses and damage
from neglect, misuse, contamination, alteration, accident, or abnormal
conditions of usage or handling. This warranty covers the original
purchaser only and is not transferable.
Questions or Concerns? We’re happy to help! [email protected]
PRODUCT HIGHLIGHTS
● Automatic Shut off: The air compressor automatically shuts off when
the pre-set pressure value is reached.
● LCD Digital Display: Provides accurate measurements. It is easy to
operate, read and understand.
● Longer Power Cord: The 10ft cable enables it to reach any part of
the car easily.
● Portable Design: Easy to carry and store in a car.
PACKAGE CONTENTS
3 YEAR WARRANTY LIMITED WARRANTY FROM ASTROAI
