Asus 1005HA - Eee PC Seashell Operating manual

E4716
15G06Q154000
Quick Use Guide
Windows® XP Edition

Quick Use Guide - 2
Powering on your Eee PC
These are only quick instructions for using your Eee PC.
2. Connect the AC power
adapter
Remember to fully charge the battery before first use and whenever
it is depleted to prolong battery life.
• When you open the display panel, do not force it down to the table
or else the hinges may break! Never lift the Eee PC by the display
panel!
• Only use power adapters supplied with this Eee PC or specifically
approved by the manufacturer or retailer for use with this model
or else damage may occur to the Eee PC.The output voltage of this
adapter is +19Vdc, 2.1A.
3. Turn ON the Eee PC
1
2
3
110V-220V
1. Install the battery pack
3
12
Damage may occur if you use
a different adapter to power
the Eee PC.You may damage
both your battery pack and
the Eee PC with a faulty AC-DC
adapter.

Quick Use Guide - 3
Shutdown
Do the following instructions to turn down your Eee PC.
1. Click the start button to display the start menu.
2. Click Turn Off Computer.
1
2
3. Select Turn Off to power off your Eee PC.
3

Quick Use Guide - 4
Launching for the First Time
For the first time you start your Eee PC, the Windows wizard will launch
automatically and lead you through setting up your preferences and some
basic information. Follow the wizard instructions to finish the initialization.
Conguring a network connection
Wireless Network Connection
1. Double-click the crossed wireless network icon in the
Notification area.
2. Select the wireless access point
you want to connect to from the
list and click Connect to build
the connection.
If you cannot find the desired access point, click Refresh network
list in the left pane and search in the list again.
If the wireless connection icon does not show in the Notification
area, activate the wireless LAN function by pressing
+
(<Fn> + <F2>) before configuring a wireless network connection.

Quick Use Guide - 5
3. When connecting, you may have
to enter a password.
4. After a connection has been
established, the connection is
shown on the list.
5. You can see the wireless
network icon in the Notification
area.
The wireless connection icon disappears when you press
+ (<Fn> + <F2>) to disable the WLAN function.

Quick Use Guide - 6
Local Area Network
To establish a wired network, follow the instructions below:
Using a dynamic IP:
1. Right-click the network icon with
a yellow warning triangle on
the Windows® taskbar and select
Open Network Connections.
3. Click Internet Protocol
(TCP/IP) and click Properties.
2. Right-click Local Area
Connection and select
Properties.
4. Click Obtain an IP address
automatically and click OK.

Quick Use Guide - 7
5. Click Create a new
connection to start the New
Connection Wizard.
6. Click Next.
7. Select Connect to the
Internet and click Next.
8. Select Set up my
connection manually.
9. Select your connection type
and click Next.
10. Enter your ISP Name and
click Next.

Quick Use Guide - 8
11. Enter your User name and
Password. Click Next.
12. Click Finish to finish the
configuration.
13. Enter your user name and password.
Click Connect to connect to the
Internet.
Using a static IP:
1. Repeat the step 1–3 of Using a dynamic IP to start the static IP
network configuration.
2 Click Use the following IP address.
3. Enter the IP address, Subnet mask and Gateway from your service
provider.
4. If needed, enter the preferred DNS Server address and alternative
address.
5. After entering all the related values, click OK to build the network
connection.
Contact your Internet Service Provider (ISP) if you have problems
connecting to the network.
