Asus VE278H User manual

VE278 Series
LCD Monitor
User Guide
April 2012

ii
Copyright © 2012 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
Table of contents
Notices......................................................................................................... iii
Safety information ...................................................................................... iv
Care & Cleaning........................................................................................... v
1.1 Welcome! ...................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Assembling the monitor base..................................................... 1-2
1.4 Connect cables............................................................................. 1-2
1.5 Monitor introduction .................................................................... 1-3
1.5.1 Front of the LCD monitor ................................................ 1-3
1.5.2 Rear of the LCD monitor ................................................. 1-5
1.5.3 QuickFit Function ............................................................ 1-6
2.1 Detaching the arm/stand
(for VESA wall mount) ..............................................................2-1
2.2 Adjusting the monitor.................................................................. 2-2
3.1 OSD (On-Screen Display) menu ................................................. 3-1
3.1.1 How to reconfigure.......................................................... 3-1
3.1.2 OSD Function Introduction.............................................. 3-1
3.2 Specications............................................................................... 3-6
3.3 Troubleshooting (FAQ)................................................................ 3-7
3.4 Supported Timing List ................................................................. 3-8

iii
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
• Thisdevicemaynotcauseharmfulinterference,and
• Thisdevicemustacceptanyinterferencereceivedincluding
interferencethatmaycauseundesiredoperation.
Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfora
ClassBdigitaldevice,pursuanttoPart15oftheFCCRules.Theselimits
are designed to provide reasonable protection against harmful interference
inaresidentialinstallation.Thisequipmentgenerates,usesandcan
radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordance
withmanufacturer’sinstructions,maycauseharmfulinterferencetoradio
communications.However,thereisnoguaranteethatinterferencewill
not occur in a particular installation. If this equipment does cause harmful
interferencetoradioortelevisionreception,whichcanbedeterminedby
turningtheequipmentoffandon,theuserisencouragedtotrytocorrect
theinterferencebyoneormoreofthefollowingmeasures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmenttoanoutletonacircuitdifferentfromthatto
which the receiver is connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
AsanEnergyStar® Partner,ourcompanyhasdeterminedthatthis
productmeetstheEnergyStar® guidelinesforenergyefficiency.
Canadian Department of Communications Statement
ThisdigitalapparatusdoesnotexceedtheClassBlimitsforradio
noise emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.

iv
Safety information
• Beforesettingupthemonitor,carefullyreadallthedocumentationthat
came with the package.
• Topreventfireorshockhazard,neverexposethemonitortorainor
moisture.
• Nevertrytoopenthemonitorcabinet.Thedangeroushighvoltages
insidethemonitormayresultinseriousphysicalinjury.
• Ifthepowersupplyisbroken,donottrytofixitbyyourself.Contacta
qualifiedservicetechnicianoryourretailer.
• Beforeusingtheproduct,makesureallcablesarecorrectlyconnected
andthepowercablesarenotdamaged.Ifyoudetectanydamage,
contactyourdealerimmediately.
• Slotsandopeningsonthebackortopofthecabinetareprovidedfor
ventilation.Donotblocktheseslots.Neverplacethisproductnearor
over a radiator or heat source unless proper ventilation is provided.
• Themonitorshouldbeoperatedonlyfromthetypeofpowersource
indicatedonthelabel.Ifyouarenotsureofthetypeofpowersupplyto
yourhome,consultyourdealerorlocalpowercompany.
• Usetheappropriatepowerplugwhichcomplieswithyourlocalpower
standard.
• Donotoverloadpowerstripsandextentioncords.Overloadingcan
result in fire or electric shock.
• Avoiddust,humidity,andtemperatureextremes.Donotplacethe
monitorinanyareawhereitmaybecomewet.Placethemonitorona
stable surface.
• Unplugtheunitduringalightningstormorifitwillnotbeusedfora
long period of time. This will protect the monitor from damage due to
power surges.
• Neverpushobjectsorspillliquidofanykindintotheslotsonthe
monitor cabinet.
• Toensuresatisfactoryoperation,usethemonitoronlywithULlisted
computers which have appropriate configured receptacles marked
between100-240VAC.
• Ifyouencountertechnicalproblemswiththemonitor,contacta
qualifiedservicetechnicianoryourretailer.

v
Care & Cleaning
• Beforeyouliftorrepositionyourmonitor,itisbettertodisconnectthecables
and power cord. Follow the correct lifting techniques when positioning the
monitor.Whenliftingorcarryingthemonitor,grasptheedgesofthemonitor.
Donotliftthedisplaybythestandorthecord.
• Cleaning.Turnyourmonitoroffandunplugthepowercord.Cleanthemonitor
surfacewithalint-free,non-abrasivecloth.Stubbornstainsmayberemoved
with a cloth dampened with mild cleaner.
• Avoidusingacleanercontainingalcoholoracetone.Useacleanerintended
forusewiththeLCD.Neverspraycleanerdirectlyonthescreen,asitmaydrip
inside the monitor and cause an electric shock.
The following symptoms are normal with the monitor:
• Thescreenmayflickerduringtheinitialuseduetothenatureofthefluorescent
light. Turn off the Power Switch and turn it on again to make sure that the
flicker disappears.
• Youmayfindslightlyunevenbrightnessonthescreendependingonthe
desktoppatternyouuse.
• Whenthesameimageisdisplayedforhours,anafterimageoftheprevious
screenmayremainafterswitchingtheimage.Thescreenwillrecoverslowlyor
youcanturnoffthePowerSwitchforhours.
• Whenthescreenbecomesblackorflashes,orcannotworkanymore,contact
yourdealerorservicecentertofixit.Donotrepairthescreenbyyourself!
Conventions used in this guide
WARNING:Informationtopreventinjurytoyourselfwhentryingto
complete a task.
CAUTION:Informationtopreventdamagetothecomponentswhen
tryingtocompleteatask.
IMPORTANT:InformationthatyouMUSTfollowtocompleteatask.
NOTE:Tipsandadditionalinformationtoaidincompletingatask.

vi
Wheretondmoreinformation
Refer to the following sources for additional information and for product and
software updates.
1. ASUS websites
TheASUSwebsitesworldwideprovideupdatedinformationonASUS
hardware and software products. Refer to http://www.asus.com
2. Optional documentation
Yourproductpackagemayincludeoptionaldocumentationthatmayhave
beenaddedbyyourdealer.Thesedocumentsarenotpartofthestandard
package.

1-1ASUSLCDMonitorVE278Series
1.1 Welcome!
ThankyouforpurchasingtheASUS®VE278SeriesLCDmonitor!
ThelatestwidescreenLCDmonitorfromASUSprovidesacrisper,broader,and
brighterdisplay,plusahostoffeaturesthatenhanceyourviewingexperience.
Withthesefeatures,youcanenjoytheconvenienceanddelightfulvisual
experiencethattheVE278Seriesbringsyou!
1.2 Package contents
CheckyourVE278SeriesLCDpackageforthefollowingitems:
LCD monitor
Monitor base
Quick start guide
warrantycard
1xPowercord
1xVGAcable
1xDVIcable(onlyforVE278N)
1xHDMI-DVIcable(onlyforVE278H)
1xAudiocable(onlyforVE278H)
Ifanyoftheaboveitemsisdamagedormissing,contactyourretailer
immediately.

1-2 Chapter 1: Product Introduction
1.3 Assembling the monitor base
To assemble the monitor base:
1. Attachthebasetothearmandfixwiththescrewtojointhemtightly.Youcan
easilytightenthescrewbyfingers.
2. Adjustthemonitortotheanglethatismostcomfortableforyou.
Werecommendthatyoucoverthetablesurfacewithsoftclothtoprevent
damage to the monitor.
1
2
Make sure to screw the base to the arm tightly.
1.4 Connect cables
To connect cables:
Connectthecablesyouneedbasedonchapter1.5.2,page1-5.

1-3ASUSLCDMonitorVE278Series
1.5 Monitor introduction
1.5.1 Front of the LCD monitor
VE278H
VE278N
6 7
3 5 8
12
6 7
4 5 8
12
1. Button:
• Automaticallyadjusttheimagetoitsoptimizedposition,clock,and
phasebylongpressingthisbuttonfor2-4seconds(forVGAmodeonly).
• Usethishotkeytoswitchfromsixvideopresetmodes(SceneryMode,
StandardMode,TheaterMode,GameMode,NightViewMode,and
sRGBMode)withSPLENDID™VideoIntelligenceTechnology.
• ExittheOSDmenuorgobacktothepreviousmenuastheOSDmenu
is active.
2. QuickFit Button:
• ThisisahotkeytoactivatetheQuickFitfunctiondesignedforalignment.
• TheQuickFitfunctioncontains7pagesofcommongridpatterns,paper
sizes,andphotosizes.
3. Button:
• Press this button to decrease the value of the function selected or move
tothenextfunction.ThisisalsoahotkeyforContrastadjustment.

1-4 Chapter 1: Product Introduction
4. Button:
• Press this button to decrease the value of the function selected or move
tothenextfunction.ThisisalsoahotkeyforVolumeadjustment.
5. MENUButton:
• Press this button to enter the OSD menu.
• Pressthisbuttontoenter/selecttheicon(function)highlightedwhilethe
OSD is activated.
6. Button:
• Press this button to increase the value of the function selected or move
to the previous functions.
• ThisisalsoahotkeyforBrightnessadjustment.
7. Input Select Button:
• UsethishotkeytoswitchfromVGA,DVI(VE278N),HDMI(VE278H)input
signal.
8. PowerButton/PowerIndicator:
• Pressthisbuttontoturnthemonitoron/off.
• The color definition of the power indicator is as the below table.
Status Description
Blue ON
Amber Standbymode
OFF OFF

1-5ASUSLCDMonitorVE278Series
1.5.2 Rear of the LCD monitor
134
VE278N
VE278H
2
145 6
7
1 AC-IN port
2 HDMI port
3 DVI port
4 VGA port
5 Audio - in Port
6 Earphone - out Port
7 Screw Holes for VESA Wall Mount

1-6 Chapter 1: Product Introduction
1.5.3 QuickFit Function
TheQuickFitfunctioncontainsthreepatterns:(1)Grid(2)Papersize(3)Photo
size.
1. Gridpatterns
Thegridpatternsfacilitatedesignersanduserstoorganizecontentandlayoutona
page and achieve a consistent look and feel.
AlignmentGrid
2. Papersize
QuickFitprovidesnumerouscommonlyusedstandardpapersizesforusersto
viewtheirdocumentsinrealsizeonthescreen.
Letter

1-7ASUSLCDMonitorVE278Series
3. Photosize
ThevariousrealphotosizesdisplayedintheQuickFitfunctionprovides
photographersandotheruserstoaccuratelyviewandedittheirphotosinrealsize
on the screen.
Photo4x6,3x5,2x2
Photo8x10,5x7

2-1 Chapter 2: Setup
2.1 Detaching the arm/stand
(for VESA wall mount)
ThedetachablestandoftheVE278SeriesLCDmonitorisspeciallydesignedfor
VESAwallmount.
To detach the arm/stand:
1. Disconnectpowerandsignalcables.Carefullyput the front of the monitor
face down on a clean table.
2. Useascrewdrivertoremovethe two screws that secure the stand to the
monitor.
3. Detach the stand from the monitor.
• Werecommendthatyoucoverthetablesurfacewithsoftclothtoprevent
damage to the monitor.
• Holdthestandofthemonitorwhileremovingthescrews.
• TheVESAwallmountkit(100x100mm)ispurchasedseparately.
• UseonlytheULListedWallMountBracketwithminimumweight/load
24.4kg(Screwsize:4x10mm).

2-2ASUSLCDMonitorVE278Series
2.2 Adjusting the monitor
• Foroptimalviewing,werecommendthatyoulookatthefullfaceofthe
monitor,thenadjustthemonitortotheanglethatismostcomfortableforyou.
• Hold the stand to prevent the monitor from falling while changing its angle.
• Youcanadjustthemonitor’sanglefrom-5˚to20˚.
-5 ~ 20

3-1 Chapter3:GeneralInstruction
3.1 OSD (On-Screen Display) menu
3.1.1 Howtorecongure
VE278
Splendid
Color
Input Select
Move Menu Exit
System Setup
Scenery Mode
Standard Mode
Theater Mode
Game Mode
Night View Mode
sRGB
1. PresstheMENUbuttontoactivatetheOSDmenu.
2. Press and  to navigate through the functions. Highlight and activate
thedesiredfunctionbypressingtheMENUbutton.Ifthefunctionselected
hasasub-menu,press and  again to navigate through the sub-menu
functions.Highlightandactivatethedesiredsub-menufunctionbypressing
theMENUbutton.
3. Press and  to change the settings of the selected function.
4. ToexittheOSDmenu,pressthe button. Repeat step 2 and step 3
toadjustanyotherfunction.
3.1.2 OSD Function Introduction
1. Splendid
Thisfunctioncontainssixsub-functionsthatyoucanselectforyour
preference.EachmodehastheResetselection,allowingyoutomaintain
yoursettingorreturntothepresetmode.

3-2ASUSLCDMonitorVE278Series
VE278
Splendid
Color
Input Select
Move Menu Exit
System Setup
Scenery Mode
Standard Mode
Theater Mode
Game Mode
Night View Mode
sRGB
• Scenery Mode:Thisisthebestchoiceforsceneryphotodisplayingwith
SPLENDID™VideoIntelligenceTechnology.
• Standard Mode: This is the best choice for document editing with
SPLENDID™VideoIntelligenceTechnology.
• Theater Mode: This is the best choice for movie watching with
SPLENDID™VideoIntelligenceTechnology.
• Game Mode:ThisisthebestchoiceforgameplayingwithSPLENDID™
VideoIntelligenceTechnology.
• Night View Mode:Thisisthebestchoiceforplayingdark-scenegame
orwatchingdark-scenemoviewithSPLENDID™VideoIntelligence
Technology.
• sRGB: This is the best choice for viewing photos and graphics from PCs.
IntheStandardMode,theSaturation,SkinTone,Sharpness,andASCR
functions are not user-configurable.
InthesRGB,theSaturation,ColorTemp.,SkinTone,Sharpness,Brightness,
Contrast and ASCR functions are not user-configurable.
2. Color
Selecttheimagecoloryoulikefromthisfunction.
VE278
Splendid
Color
Input Select
Move Menu Exit
System Setup
Brightness
Contrast
Saturation
Color Temp.
90
80
50
User Mode
Natural
OFF
Skin Tone
Smart View
• Brightness: The adjusting range is from 0 to 100. The button is
alsoahotkeytoactivatethisfunction.

3-3 Chapter3:GeneralInstruction
• Contrast: The adjusting range is from 0 to 100. The button(Only
forVE278N)isalsoahotkeytoactivatethisfunction.
• Saturation: The adjusting range is from 0 to 100.
• Color Temp.:Containsthreepresetcolormodes(Cool,Normal,Warm)
andoneUserMode.
• Skin Tone:ContainsthreecolormodesincludingReddish,Natural,and
Yellowish.
• Smart view:TheversatileviewingpositionswithSmartViewTechnology
IntheUserMode,colorsofR(Red),G(Green),andB(Blue)are
userconfigurable; the adjusting range is from 0 ~ 100.
3. Image
YoucanadjusttheimageSharpness,TraceFree(OnlyforVE278H),Aspect
Control,ASCR,Position(VGAonly),andFocus(VGAonly)fromthismain
function.
VE278
Splendid
Color
Input Select
Move Menu Exit
System Setup
Focus
Sharpness
Trace Free
ASCR
40
60
Position
OFF
Aspect Control Full
• Sharpness: Adjusts the picture sharpness. The adjusting range is from 0
to 100.
• Trace Free: SpeedsuptheresponsetimebyOverDrivetechnology.The
adjustingrangeisfromlower0tofaster100.(OnlyforVE278H)
• Aspect Control:Adjuststheaspectratioto“Full”,“4:3”,“Overscan”.
(OverscanisavailableonlyforVE278HHDMIsource)
• ASCR:SelectONorOFFtoenableordisabledynamiccontrastratio
function.
• Position:Adjuststhehorizontalposition(H-Position)andthevertical
position(V-Position)oftheimage.Theadjustingrangeisfrom0to100
(OnlyavailableforVGAinput).

3-4ASUSLCDMonitorVE278Series
• Focus:ReducesHorizonal-linenoiseandVertical-linenoiseoftheimage
byadjusting(Phase)and(Clock)separately.Theadjustingrangeisfrom
0to100(OnlyavailableforVGAinput).
Phaseadjuststhephaseofthepixelclocksignal.Withawrongphase
adjustment,thescreenshowshorizontaldisturbances.
Clock(pixelfrequency)controlsthenumberofpixelsscannedbyonehorizontal
sweep.Ifthefrequencyisnotcorrect,thescreenshowsverticalstripesandthe
image is not proportional.
4. Input Select
Select the input source from VGA,DVI.(VE278N)
VE278
Splendid
Color
Input Select
Move Menu Exit
System Setup
VGA
DVI
Select the input source from VGA,HDMI1,HDMI2.(VE278H)
VE278
Splendid
Color
Input Select
Move Menu Exit
System Setup
VGA
HDMI1
HDMI2

3-5 Chapter3:GeneralInstruction
5. System Setup
Adjuststhesystemconfiguration.
VE278
Splendid
Color
Input Select
Move Menu Exit
System Setup
Splendid Demo Mode OFF
Language
Information
50
OFF
English
1/2
Volume
ECO Mode
OSD Setup
VE278
Splendid
Color
Input Select
Move Menu Exit
System Setup
2/2
VS239
All Reset
• Splendid Demo Mode: Activate the demo mode for the Splendid
function.
• Volume: Adjust the earphone or speaker output volume level. The
adjustingrangeisfrom0to100.(OnlyforVE278H.)
• ECO Mode:Activatetheecologymodeforpowersaving.
• OSD Setup:Adjuststhehorizontalpostition(H-Position),verticalposition
(V-Position),OSDTimeout,DDD/CI,andTransparencyoftheOSD
screen.
• Language:SelectOSDlanguage.TheselectionsforNon-EUandNon-
USversionOSDare:English,TraditionalChinese,SimplifiedChinese,
Japanese,Persian,ThaiandIndonesian;TheselectionsforEUand
USversionOSDare:English,German,Italian,French,Dutch,Spanish,
Russian,Poland,Turkey,Portugal,Czech,Croatia,Hungary,Romania
• Information:Displaysthemonitorinformation.
• All Reset:Selects“Yes”torevertallsettingstothefactorydefaultmode.
